1997 FORD F250 instrument cluster

11
Instrumentation
%*
[IS00600(FM)01/96]
The instrument panel (dashboard) on your
vehicle is divided into several different sections.
The illustrations on the following pages show
the major parts of the instrument panel that are
described in this chapter. Some items shown
may not be on all vehicles.
*
[IS00700(F )03/96]
Your vehicle has one of the following clusters:
*
[IS00900(F )03/96]
q
A mechanical cluster
*
[IS01000(F )03/96]
q
A mechanical cluster with tachometer
*
[IS01100(F )03/96]
If you are not sure which cluster your vehicle
has, check the diagrams on the following pages
of this section.
File:03ltisf.ex
Update:Tue May 28 08:40:24 1996
ProCarManuals.com

12 [IS01150(F )05/96]
full page art:0020027-HInstrument Panel, Controls and Mechanical Cluster with
Tachometer
File:03ltisf.ex
Update:Tue May 28 08:40:24 1996
ProCarManuals.com

71
%*
[CF26900(FM)02/96]
The Turn Signal Lever
*
[CF27000(FM)02/96]
You can use the turn signal lever on the left side
of the steering column to:
*
[CF27100(FM)02/96]
q
operate the turn signals and cornering lamps
*
[CF27200(F )03/96]
q
turn the high beams on/off
*
[CF27300(F )03/96]
q
flash the lamps
*
[CF27400(F )03/96]
q
turn the windshield wipers and washer
on/off
%*
[CF27500(FM)01/96]
Turn Signals
*
[CF27600(FM)01/96]
Move the lever up to signal a right turn. Move
it down to signal a left turn. The corresponding
indicator light in the instrument cluster will
flash.
*
[CF27700(FM)01/96]
If the turn signal stays on after you turn, move
the lever back to the center (off) position.
[CF27800(FM)04/96]
one third page art:0020081-C
Turn signal lever and functions
*
[CF27900(FM)08/95]
If the turn indicator light in the instrument
panel does not illuminate or remains on (doesn't
flash) when you signal a turn, the turn signaling
system is malfunctioning. Have this condition
corrected as soon as possible, but make sure that
you use the accepted hand signals in the
meantime.
File:05ltcff.ex
Update:Tue May 28 08:42:43 1996
ProCarManuals.com

146 [GF01200(F )04/96]Rear Disc Brakes (F-Super Duty and
F-Series Stripped Chassis Only)
[GF01300(FM)04/96]
The rear disc brakes are self-adjusting. They do
not require service other than periodic
lubrication of the caliper slide rails and
inspection for pad wear.
*
[GF01350(FM)01/96]
Hydraulic Power Brakes
*
[GF01400(F )03/96]
The hydraulic brake system is made up of two
independent hydraulic circuits. One hydraulic
circuit supplies fluid to the front disc brakes and
the other hydraulic circuit supplies fluid to the
rear drum brakes. These two circuits are
supplied by a common hydraulic brake fluid
reservoir, with a fluid level sensor.
*
[GF01500(FM)01/96]
The brake light in the instrument cluster will
light for low brake fluid in the common brake
fluid reservoir.
*
[GF01550(FM)01/96]
RWARNING
An increase in pedal travel will result in
reduced braking capability. The brake
system should be checked immediately.
%*
[GF01700(F )01/96]
Rear Anti-lock Brakes
[GF01800(F )04/96]
Except for F-Super Duty and F-Series
Commercial and Motorhome Stripped Chassis,
F-Series Light Trucks are equipped with a Rear
Antilock Brake System. This system prevents at
least one and often both rear wheels from
locking up when the brakes are applied in a
panic stop, for example.
*
[GF01900(F )01/96]
Even with the Anti-lock Brake System, you
should be careful when braking. Front brake
lock up on any surface, even on smooth
pavement causes loss of steering control. Heavy
braking on roads with loose surfaces such as
File:09ltgff.ex
Update:Thu May 30 15:25:49 1996
ProCarManuals.com

166 [GF16050(F )04/96]NOTE: All transfer cases on F-350 4x4 trucks
are equipped with an opening for a
power take-off (PTO). If this opening
is used for a transfer case mounted
PTO, additional transfer case lubricant
is required. Refer to the Refill
Capacities section for lubricant fill
requirements. Vehicles equipped with
an E4OD automatic transmission and a
7.3L diesel engine will require exhaust
modification for PTO clearance. For
vehicles equipped with an E4OD
automatic transmission: If a transfer
case mounted PTO is operated with the
transfer case shift lever in neutral, a
Vehicle Speed Sensor Self-test error
may be set in the Powertrain Control
Module (PCM) causing the
transmission to function abnormally,
and the Transmission Control Indicator
Light (TCIL) may flash on and off
repeatedly. Normal transmission
function should return when the
transfer case has been engaged and the
vehicle is driven. If the TCIL continues
to flash or the transmission continues
to operate abnormally contact your
Ford dealer as soon as possible.
% [GF16100(F )04/96]
4x4 system indicator lights
[GF16150(F )04/96]
A 4x4 light and a LOW RANGE light are
located at the lower right of the instrument
cluster.
[GF16200(F )04/96]
q
2H position Ð Neither the 4X4 or the LOW
RANGE lights are lit.
[GF16250(F )04/96]
q
4H position Ð Only the 4x4 light is lit.
File:09ltgff.ex
Update:Thu May 30 15:25:49 1996
ProCarManuals.com

280
%*
[MC18300(FM)01/96]
Power Steering Fluid
*
[MC18350(FM)01/96]
Check the level of the power steering fluid at
least twice a year (i.e., every Spring and Fall).
*
[MC18400(FM)01/96]
To check the level of your power steering fluid:
*
[MC18450(FM)04/96]
1. Start the engine and let it run until the
power steering fluid reaches normal
operating temperature. The power steering
fluid will be at the right temperature when
the engine coolant temperature gauge in the
instrument cluster is near the center of the
NORMAL operating temperature range.
*
[MC18500(FM)01/96]
2. While the engine idles, turn the steering
wheel back and forth several times. Make
sure that the cap assembly is installed at this
time.
*
[MC18550(F )01/96]
3. Turn the engine off.
%*
[MC18650(FM)01/96]
4. Check the fluid level on the dipstick (which
is highlighted in yellow in your vehicle). The
fluid level should be between the arrows in
the FULL HOT range, which is marked on
the side of the dipstick, opposite the side
marked FULL COLD. Do not add fluid if the
level is within the FULL HOT range.
*
[MC18700(FM)01/96]
one third page art:0021016-B
Power steering dipstick
File:11ltmcf.ex
Update:Tue May 28 08:52:04 1996
ProCarManuals.com

366 [QI05900(F )04/96]
full page art:0021056-BInstrument cluster
File:16ltqif.ex
Update:Tue May 28 08:54:23 1996
ProCarManuals.com

378 Index
High-mount brakelamp......... 310
description.............. 310
replacing the bulb........... 310
Hitch.................. 210
Hood.................. 260
latch location............. 260
lubrication specifications........ 324
release lever............. 260
working under the hood........ 258
Horn................... 75
I
Identification Number, Vehicle (VIN).... 7
Idle, relearning.........137, 253, 258
Ignition
chime................. 69
positions of the ignition......... 67
removing the key............ 69
Indicator lights and chimes (see Lights) . . . 12
Infant seats (see Safety seats).....120, 122
Instrument cluster, mechanical....... 15
Instrument panel
cleaning............... 314
lighting up panel and interior...... 64
registers................ 58
Interval wipers............72±73
J
Jack.................. 237
operation.............240, 243
positioning............240, 243
storage................ 237
Jump-starting your vehicle
attaching cables............ 252
disconnecting cables.......... 253
