1997 FORD F250 alarm

89
*
[CF65000(F )05/96]
Remote Entry System
(If equipped)
[CF65100(F )04/96]
If your vehicle has the remote entry system, you
can lock or unlock the vehicle doors without
using a key. The remote also has a personal
alarm feature. The buttons for the system are
located on the two hand held transmitters that
came with your vehicle.
*
[CF65200(F )01/96]
The system will work with up to four
transmitters. Your vehicle came with two
transmitters. Additional transmitters can be
ordered from your dealer.
*
[CF65300(F )01/96]
The remote entry features only operate with the
ignition in the OFF position.
[CF65400(F )05/96]
quarter page art:0020788-B
The remote entry transmitter
%*
[CF65500(F )01/96]
Unlocking the doors with the remote entry
system
*
[CF65600(F )04/96]
To unlock the driver's door, press the UNLOCK
control.
*
[CF65700(F )01/96]
To unlock the other doors, press the UNLOCK
button a second time within five (5) seconds of
unlocking the driver's door.
File:05ltcff.ex
Update:Tue May 28 08:42:43 1996
ProCarManuals.com

90
*
[CF65800(F )01/96]
Locking the doors with the remote entry
system
*
[CF66000(F )04/96]
To lock all the doors, press the LOCK control.
[CF66100(F )04/96]
If you would like a signal that the doors are
being locked, press the LOCK button again
within five seconds. The door will lock again,
the horn will beep, and the external lamps will
flash.
%*
[CF66200(F )01/96]
Remote entry personal alarm
*
[CF66300(F )01/96]
If you wish to activate the remote entry system
personal alarm, press the PANIC button. This
will honk the horn and flash the lights for
approximately 2 minutes 45 seconds. You can
turn it OFF by pressing the PANIC button again
from the same transmitter or by turning the
ignition to the ON or ACCESSORY position.
*
[CF66400(F )01/96]
When you use the remote entry UNLOCK or
PANIC buttons, the illuminated entry system
turns on the vehicle's interior lights for 25
seconds. You can turn these lights off with the
remote entry LOCK button or by turning the
ignition to the ON or ACCESSORY position.
*
[CF66500(F )01/96]
quarter page art:0060566-B
File:05ltcff.ex
Update:Tue May 28 08:42:43 1996
ProCarManuals.com

92
*
[CF67400(F )01/96]
quarter page art:0020790-A
Replacing the batteries
%*
[CF67500(F )01/96]
Replacing lost transmitters
*
[CF67600(F )01/96]
In the event a transmitter is lost, you should
take all your vehicle's transmitters to your
dealer to have the remote entry system
deprogrammed for the lost transmitter. This is
necessary to prevent further unauthorized use of
the lost transmitter.
*
[CF67700(F )01/96]
You can also purchase additional transmitters
(up to 4 transmitters can be used) from your
dealer. You will need to take all your
transmitters to the dealer so they can program
them to the remote entry system all at the same
time.
%*
[CF68000(F )01/96]
Illuminated Entry System (If equipped)
[CF68100(F )01/96]
This system will provide illumination of the
vehicle's interior courtesy lamps when either
outside front door handle is pulled or when the
Remote Entry System is used to unlock the door
or sound the Personal Alarm. The system will
automatically turn off after approximately 25
seconds or when the ignition is turned to the
START or ACCESSORY position.
[CF68200(F )04/96]
NOTE: The inside lights will not turn off if
you have turned them on with the
dimmer knob or if any door is open.
File:05ltcff.ex
Update:Tue May 28 08:42:43 1996
ProCarManuals.com

349 [AC01600(F )04/96]
sixteen pica chart:0020765-H
*
[AC01900(FM)05/96]
NOTE: When adding accessories, equipment,
passengers, and luggage to your
vehicle, do not exceed the total weight
capacity of the vehicle or of the front
or rear axle (GVWR, GAWR as shown
on the Safety Compliance Certification
Label). Consult your dealer for specific
weight information.
*
[AC02000(FM)05/96]
NOTE: The Federal Communications
Commission (FCC) or the Canadian
Radio Telecommunications Commission
(CRTC) regulates the use of mobile
communications systems Ð such as
two-way radios, telephones, and theft
alarms Ð that are equipped with radio
transmitters. Any such equipment
installed in your vehicle should comply
with FCC or CRTC regulations and
should be installed only by a qualified
technician.
File:15ltacf.ex
Update:Tue May 28 08:53:43 1996
ProCarManuals.com

Index 367
Index
A
ABS warning light
(see Anti-lock brake system)....... 16
Accessory position on the ignition . . . 67±68
Accessory power source, power
point outlet.............. 66
Additives, engine oil.......... 264
Air bag supplemental restraint system,
and child safety seats......... 122
Air cleaner filter
location............... 261
specifications............. 317
Alarm, activating remote personal..... 90
Alcohol, in fuel............. 297
Antenna, radio (see Electronic
sound system)............. 27
Antifreeze (see Engine coolant)...... 274
Anti-lock brake system (ABS)
description.............. 145
see also Brake............ 145
warning light.............. 16
warninig light............. 15
Appeals (see Dispute settlement board) . . 338
Assistance (see Customer assistance) . . . 335
Audio system (see Electronic
sound system)............. 27
Autolamp system (see Headlamps)..... 63
Automatic transmission
driving an automatic overdrive . . 151, 155
fluid, adding............. 284
fluid, checking............ 283
fluid, refill capacities......... 318
fluid, specification.......... 324
File:ltixf.ex
Update:Tue May 28 08:56:20 1996
ProCarManuals.com

Index 381
Master cylinder, brakes......... 268
Methanol in fuel............ 297
Mileage, calculating fuel economy.... 300
Mirrors.................. 79
dual electric remote control....... 81
rearview................ 79
side view mirrors............ 79
side view mirrors (manual)....... 79
side view mirrors (power)........ 81
Motorcraft parts............. 317
N
National Highway Traffic Safety
Administration............ 333
New vehicle break-in........... 9
O
Octane rating............295±296
Odometer................ 24
description............... 24
trip odometer............. 24
Off road driving, 4-wheel drive..... 172
Oil filter..............267, 317
Oil (see Engine oil)........... 264
Oil viscosity.............. 264
On-board diagnostic (OBD II) system . . . 306
Order forms, service information...... 31
Overdrive............... 155
Overseas offices............. 342
P
Panic alarm feature, remote entry system . . 90
Parking brake
operation.............. 149
warning light.............. 15
Parts (see Motorcraft Parts)....... 317
PCV valve, specifications........ 317
Power door locks............. 84
File:ltixf.ex
Update:Tue May 28 08:56:20 1996
ProCarManuals.com

382 Index
Power features
door locks............... 84
lumbar support............ 106
mirrors............... 79,81
seats................. 105
windows..............84±85
Power point electrical outlet........ 66
Power steering
dipstick............... 280
driving with power steering...... 151
fluid, checking and adding....... 280
fluid, refill capacity.......... 318
fluid, specifications.......... 324
servicing............... 151
Prop rod, hood............. 260
R
Radio (see Electronic sound systems).... 27
Rear anti-lock brakes........... 146
description.............. 146
Rear axle
lubricant specification......... 324
refill capacity............. 318
traction lok.............. 220
Rear window............... 84
washer reservoir........... 271
Refill capacities for fluids........ 318
Regulations, National Highway Traffic Safety
Administration............ 333
Remote entry system............ 89
illuminated entry............ 92
locking/unlocking doors......... 89
panic alarm............... 90
replacement/additional transmitters.... 92
replacing the batteries.......... 91
File:ltixf.ex
Update:Tue May 28 08:56:20 1996
ProCarManuals.com
