1997 FORD CONTOUR warning

142
*
[GF14200(ALL)01/96]
n
Service your vehicle more frequently if you tow a trailer.
(SeeServicing your vehicle if you towin this chapter.)
*
[GF14300(ALL)12/95]
Ten to 15% of the loaded trailer's weight should be on the
tongue. However, the tongue load should never exceed 10% of
the maximum weight that your vehicle can safely tow.
*
[GF14400(ALL)12/95]
New vehicles should be driven 2,000 miles (3,200 km) before
towing a trailer.
*
[GF14500(ALL)01/96]
RWARNING
Towing trailers beyond the maximum recommended
gross trailer weight exceeds the limit of the vehicle and
could result in engine damage, transaxle damage,
structural damage, loss of control, and personal injury.
*
[GF14600(ALL)01/96]
RWARNING
Do not tow a trailer when using a temporary spare tire.
*
[GF14700(ALL)12/95]
You should also limit your trailer's load when you tow in high
altitudes.
*
[GF14800(ALL)03/96]
Preparing to Tow
*
[GF14900(ALL)01/96]
For your safety and for the good of your vehicle, use the right
equipment for the type of trailer you tow. Also, make sure that
all towing equipment is properly attached to your vehicle. If
you are not certain that you are using the right equipment in
the proper manner, see your Ford or Lincoln-Mercury dealer.
*
[GF15000(ALL)12/95]
Do not use hitches that clamp onto your vehicle's bumper. The
bumper is not designed to bear the load.
File:09cdgfo.ex
Update:Thu Sep 12 11:04:39 1996

144
*
[GF16200(ALL)01/96]
RWARNING
Do not connect a trailer's hydraulic brake system directly
to your vehicle's brake system. Your vehicle may not
have enough braking power and your chances of having
a collision greatly increase.
%*
[GF16300(ALL)12/95]
Connecting the trailer's lights
*
[GF16400(ALL)12/95]
Do not connect a trailer's lighting system wiring directly to
your vehicle's lighting system wiring.To get the proper
equipment for hooking up your trailer's lights, see your local
trailer dealer and your Ford dealer. Be sure to follow their
instructions carefully.
*
[GF16500(ALL)12/95]
If you do not install trailer lights correctly, you may cause
damage to the vehicle's lighting system.
%*
[GF16600(ALL)01/96]
Driving While You Tow
*
[GF16700(ALL)01/96]
Be especially careful when driving while you tow a trailer.
Never drive faster than 45 mph (70 km/h) when you tow in
hilly country on hot days. Also, anticipate stops so that you can
brake gradually.
[GF16800(ALL)12/95]
If your vehicle has a manual transaxle and you are towing a
trailer, you should select gear positions which will avoid jerking
or excessive engine speed. If you need to drive excessively in 1
(First) or 2 (Second), it may indicate that the trailer is too big or
heavily loaded for your vehicle's drivetrain. Continuous driving
in these two gears while towing a trailer is not recommended.
[GF16900(ALL)12/95]
When you tow up or down steep hills, move the manual
transaxle gearshift to a lower gear. This will increase engine
power on upgrades and engine braking on downgrades.
File:09cdgfo.ex
Update:Thu Sep 12 11:04:39 1996

146
*
[GF18100(ALL)01/96]
n
Do not quickly move the steering wheel unless necessary.
*
[GF18200(ALL)01/96]
n
Drive slower than you normally would.
*
[GF18300(ALL)01/96]
n
Give your vehicle more distance to stop.
*
[GF18400(ALL)12/95]
n
Pump the brake pedal steadily and evenly to avoid locking
your wheels.
*
[GF18500(ALL)01/96]
n
Consider using one of the lower gears.
*
[GF18600(ALL)01/96]
RWARNING
To avoid losing control on slippery roads, do not
downshift into 1 (First) with the automatic transaxle
when moving faster than 20 mph (32 km/h). Do not
downshift into 1 (First) with the manual transaxle when
moving faster than 10 mph (16 km/h).
*
[GF18700(ALL)03/96]
RWARNING
Do not use the speed control in heavy traffic or on roads
that are winding, slippery, or unpaved.
*
[GF18800(ALL)01/96]
If you have an automatic transaxle and your vehicle gets stuck
(for example, in mud or snow), you may try to ªrockº it out of
the spot. Shift, in a steady rhythm, between forward and reverse
gears. While in each gear, press lightly on the accelerator and
release.
*
[GF18900(ALL)01/96]
RWARNING
Do not spin the wheels at over 35 mph (55 km/h). The
tires may fail and injure a passenger or bystander.
File:09cdgfo.ex
Update:Thu Sep 12 11:04:39 1996

150
[ER00700(ALL)04/96]
13-1/2 pica
art:0000530-D
The left-hand trim panel in the driver's footwell
*
[ER00800(ALL)03/96]
RWARNING
If you see or smell fuel, do not reset the switch or try to
start your vehicle. Have all the passengers get out of the
vehicle and call the local fire department or a towing
service.
*
[ER00900(ALL)03/96]
If your engine cranks but does not start after a collision or
substantial jolt:
*
[ER01000(ALL)01/96]1.
Turn the ignition key to the OFF position.
*
[ER01100(ALL)03/96]2.
Check under the vehicle for leaking fuel.
*
[ER01200(ALL)01/96]3.
If you do not see or smell fuel, push the red reset button
down. If the button is already set, you may have a different
mechanical problem.
File:10cdero.ex
Update:Thu Sep 12 11:06:09 1996

Roadside Emergencies
151
*
[ER01300(ALL)01/96]4.
Turn the ignition key to the ON position for a few seconds,
then turn it to the OFF position.
*
[ER01400(ALL)03/96]5.
Check under the vehicle again for leaking fuel.If you see or
smell fuel, do not start your vehicle again.If you do not
see or smell fuel, you can try to start your vehicle again.
% [ER01900(ALL)12/95]
Fuses, Circuit Breakers and Relays
[ER02000(ALL)12/95]
Fuses, circuit breakers, and relays protect your vehicle's
electrical system from overloading. If electrical parts in your
vehicle are not working, the system may have been overloaded
and blown a fuse or relay, or tripped a circuit breaker. Before
you replace or repair any electrical parts, check the appropriate
circuit protector.
[ER02100(ALL)12/95]
The following charts tell you which circuit protector protects
each electrical part of your vehicle. If a fuse blows or a circuit
breaker opens a circuit, all the parts of your vehicle that use the
circuit will not work.
*
[ER02200(ALL)01/96]
Once you have determined which fuses or circuit breakers to
check, follow the procedures underChecking and replacing fuses
orChecking and replacing circuit breakerslater in this chapter.
*
[ER02300(ALL)12/95]
RWARNING
Always remove the key from the ignition before working
on or replacing fuses.
File:10cdero.ex
Update:Thu Sep 12 11:06:09 1996

160
[ER04300(ALL)12/95]
7-1/2 pica art:0001319-A
The side view of a typical fuse
[ER04400(ALL)12/95]
eight pica
chart:0001255-B*
[ER04500(ALL)01/96]
RWARNING
Always replace a fuse with one that has the specified
amperage rating. Using a fuse with a higher amperage
rating can cause severe wire damage and could start a
fire.
%*
[ER04600(ALL)01/96]
Circuit Breakers
[ER04700(ALL)12/95]
If you need to check a circuit breaker that is on the instrument
panel fuse panel, seeChecking and replacing fusesto find out how
to locate the fuse panel and pull it down.
*
[ER04800(ALL)01/96]
Diagnostic equipment is needed to check circuit breakers. Refer
to the manufacturer's instructions.
File:10cdero.ex
Update:Thu Sep 12 11:06:09 1996

Roadside Emergencies
161
[ER04900(ALL)12/95]
Circuit breakers will reset themselves and allow the electrical
parts to work again once the overload on the circuit is gone. If
the circuit breakers continue to cut off electricity, have your
vehicle's electrical system checked.
*
[ER05000(ALL)01/96]
If you replace a circuit breaker, use one with the same
amperage rating. To remove a circuit breaker mounted in the
fuse panel, grip it with your finger and thumb and pull it
straight out of its socket.
%*
[ER05100(ALL)02/96]
Changing a Tire
*
[ER05200(ALL)02/96]
If you get a flat tire while you are driving, do not apply the
brake heavily. Instead, gradually decrease the speed. Hold the
steering wheel firmly and slowly move to a safe place on the
side of the road. Park on a level spot, turn off the ignition, set
the parking brake, and turn on the hazard flashers.
%*
[ER05300(ALL)02/96]
The Temporary Spare Tire
%*
[ER05400(ALL)02/96]
You may have a high pressure temporary spare tire. This spare
tire is smaller than a regular tire and is designed for emergency
use only. Use it only when you get a flat tire and replace it as
soon as you can. This spare tire is marked with the words
ªTEMPORARY USE ONLYº so that you can easily identify it.
*
[ER05500(ALL)02/96]
RWARNING
If you use the temporary spare tire continuously or do
not follow these precautions, the tire could fail, causing
you to lose control of the vehicle, possibly injuring
yourself or others.
File:10cdero.ex
Update:Thu Sep 12 11:06:09 1996

164
*
[ER07100(ALL)03/96]
RWARNING
If the vehicle slips off the jack, you or someone else
could be seriously injured.
*
[ER07200(ALL)01/96]2.
Get out the spare tire and jack.
*
[ER07300(ALL)03/96]
RWARNING
To avoid injury, never run the engine with one wheel off
the ground, such as when changing a tire.
[ER07400(ALL)12/95]3.
Remove the wheel cover from the wheel with the tapered
end of the wheel lug wrench. Insert and twist the handle,
then pry against the inner wheel cover flange. For
information about removing optional wheel center ornaments
seeStyled Polycast Wheel Ornamentslater in this section.
[ER07500(ALL)12/95]4.
Loosen the wheel lug nuts by pulling up on the handle of
the wrench one-half turn counterclockwise. Do not remove
the wheel lug nuts until you raise the tire off the ground.
For information about removing anti-theft lug nuts, see
Anti-Theft Wheel Lug Nutslater in this section.
%*
[ER07600(ALL)01/96]
Removing and Replacing the Tire
[ER07700(ALL)12/95]1.
Place the scissors-type jack under the side of the vehicle and
adjust the jack height with the jack handle. The jack should
fit in the notch in the vertical rocker panel flange which is
nearest to the wheel to be changed. The front and rear
jacking notches on each side of the vehicle are marked by
arrows in the rocker panel.
[ER07800(O )02/96]
On sport models with ªskirts,º you must remove a portion
of the skirt before placing the jack under the vehicle.
Squeeze the removeable portion of the skirt and pull down.
A tether connects it to the rocker panel.
File:10cdero.ex
