1997 FORD CONTOUR warning

2225 mph [20 and 40 km/h] for vehicles equipped with the
traction control system). The system turns on the ABS pump
motor for approximately 1/2 second. At this time, a mechanical
noise may be heard and felt. This is a normal part of the
self-check feature. If a malfunction is found during this check
the anti-lock light will come on.
[IS10100(ALL)12/95]
6 pica art:0001210-A% [IS10200(ALL)12/95]
Low Coolant Light (If equipped)
*
[IS10300(ALL)03/96]
This light indicates that the level of the engine coolant is low
inside the coolant recovery bottle and that you should add more
coolant. SeeEngine Coolantin the Index.
[IS10400(ALL)12/95]
6 pica art:0001214-B[IS10500(ALL)12/95]
This light comes on for a few seconds when the ignition is
turned to the START position, but should turn off when the
engine starts. If this light stays on, check the level of coolant
inside the recovery bottle. The level may be slightly above the
MIN line because the light is an ªearly warning.º
File:03cdiso.ex
Update:Thu Sep 12 10:58:17 1996

54
*
[CF07200(ALL)03/96]
RWARNING
The Daytime Running Light (DRL) system will not
illuminate the tail lamps and parking lamps. Turn on
your headlamps at dusk. Failure to do so may result in a
collision.
%*
[CF07300(ALL)01/96]
Lighting Up the Interior and Instrument Panel
[CF07400(ALL)12/95]
When either front door is opened, the footwell lights and the
door courtesy lights come on.
[CF07500(ALL)12/95]
The instrument panel lights, window control lights and door
handle lights come on whenever the headlamp switch is turned
from the OFF position. To dim the instrument panel lights, use
the thumbwheel on the instrument panel to the right of the
steering wheel.
[CF07600(ALL)12/95]
6 pica art:0001177-B
Dimming the instrument panel lights
% [CF07700(ALL)12/95]
Traction Control System (If equipped)
[CF07800(ALL)02/96]
This button turns the traction control system off and on. See the
Driving Chapterfor more information.
[CF07900(ALL)12/95]
6 pica art:0001179-C
The button for the traction control system
File:05cdcfo.ex
Update:Fri Sep 13 08:48:17 1996

56
*
[CF09100(ALL)01/96]
Ignition
%*
[CF09200(ALL)01/96]
Understanding the Positions of the Ignition
[CF09300(ALL)12/95]
10-1/2 pica
art:0001185-D
The positions of the key in the ignition
[CF09400(ALL)12/95]
LOCK and ACCESSORY lock the gearshift for all vehicles with
an automatic transaxle.
*
[CF09500(ALL)01/96]
RWARNING
LOCK position does not lock the gearshift on
floor-mounted manual transaxle gearshifts. If the parking
brake is not set and the gearshift is moved out of gear,
your vehicle may move unexpectedly and injure someone.
*
[CF09600(ALL)12/95]
The automatic transaxle gearshift must be in P (Park) to move
the key to the LOCK position.
*
[CF09700(ALL)01/96]
LOCK is the only position that allows you to remove the key.
The LOCK feature helps to protect your vehicle from theft.
*
[CF09800(ALL)01/96]
If your key is stuck in the LOCK position and will not turn,
move your steering wheel left or right until the key turns freely.
File:05cdcfo.ex
Update:Fri Sep 13 08:48:17 1996

Controls and Features
57
[CF09900(ALL)12/95]
ACCESSORY allows some of your vehicle's electrical accessories
to operate while the engine is not running. For example, you
can use ACCESSORY to turn on the radio without starting the
engine.
*
[CF10000(ALL)01/96]
ON allows you to test your vehicle's warning lights (except the
brake system warning light) to make sure they work before you
start the engine. The key returns to the ON position once the
engine is started and remains in this position while the engine
runs.
*
[CF10100(ALL)01/96]
START cranks the engine. Release the key once the engine starts
so that you do not damage the starter. The key should return to
ON when you release it. The START position also allows you to
test the brake warning light.
%*
[CF10200(ALL)03/96]
Removing the Key From the Ignition
[CF10300(ALL)04/96]
Procedures for removing your key from the ignition vary,
depending on whether your vehicle has an automatic or manual
transaxle.
[CF10400(ALL)04/96]
If your vehicle has an automatic transaxle:
*
[CF10500(ALL)01/96]1.
Put the gearshift lever in P (Park).
*
[CF10600(ALL)01/96]2.
Set the parking brake fully.
[CF10700(ALL)12/95]3.
Rotate the ignition key to the LOCK position.
[CF10800(ALL)12/95]4.
Remove the key from the ignition.
File:05cdcfo.ex
Update:Fri Sep 13 08:48:17 1996

58
[CF10900(ALL)04/96]
If your vehicle has a manual transaxle:
[CF11000(ALL)04/96]1.
Put the gearshift lever in 1 (First).
*
[CF11100(ALL)01/96]2.
Set the parking brake fully.
[CF11200(ALL)12/95]3.
Rotate the ignition key to the LOCK position.
[CF11300(ALL)12/95]4.
Remove the key from the ignition.
[CF11400(ALL)12/95]
The steering wheel locks when the key is removed.
%*
[CF11500(ALL)12/95]
If the driver's door is open while the key is still in the ignition,
a warning chime sounds.
*
[CF11600(ALL)01/96]
RWARNING
Always set the parking brake fully and make sure that
the gearshift is securely latched in P (Park) (automatic
transaxle) or in 1 (First) (manual transaxle).
*
[CF11700(ALL)03/96]
RWARNING
Do not leave children, unreliable adults, or pets
unattended in your vehicle.
File:05cdcfo.ex
Update:Fri Sep 13 08:48:17 1996

Controls and Features
61
*
[CF13600(ALL)01/96]
Windshield Washer
[CF13700(ALL)12/95]
When the lever is pulled to activate the windshield washer, the
wipers operate for about three cycles after the spray stops.
[CF13800(ALL)12/95]
7-1/2 pica art:0001194-D
Washing the windshield
*
[CF13900(ALL)08/95]
Do not try to clean the windshield when the washer fluid
container is empty or activate the washers at any time for more
than 15 seconds continuously. This could damage the washer
pump system.
*
[CF14000(ALL)01/96]
RWARNING
Always warm up the windshield with the defroster
before you use the washer fluid. In freezing weather, the
washer solution may freeze on the windshield and
obscure your vision.
*
[CF14100(ALL)03/96]
For information about refilling the washer fluid or replacing
your windshield wiper blades, seeWindshield washer fluid and
Wipersin the Index.
File:05cdcfo.ex
Update:Fri Sep 13 08:48:17 1996

62
%*
[CF14200(ALL)03/96]
Hazard Flasher
*
[CF14300(ALL)12/95]
The hazard flasher serves as a warning to other drivers to be
careful when approaching or passing your vehicle.
[CF14400(ALL)12/95]
10-1/2 pica
art:0001193-A
Using the hazard flasher switch
%*
[CF14500(ALL)05/96]
Horn
[CF14600(ALL)04/96]
To sound the horn, push the pad in the center of the steering
wheel. Check the horn regularly to be sure it operates properly.
File:05cdcfo.ex
Update:Fri Sep 13 08:48:17 1996

Controls and Features
63
%*
[CF14700(ALL)05/96]
Tilt Steering (If equipped)
[CF14800(ALL)05/96]
RWARNING
Never adjust the steering column/wheel when the vehicle
is moving. You could lose control of the vehicle and
injure someone.
[CF14900(ALL)05/96]
17-1/2 pica
art:0000269-D
The lever to tilt the steering wheel
[CF15000(ALL)05/96]
To change the position of the steering wheel, pull down the
knob on the bottom left-hand side of the column to extend the
lever. Pull the lever toward you, unlocking the column.
[CF15100(ALL)05/96]
Move the steering wheel up or down until you find the position
you prefer. Push the lever away from you, locking the column
in position. When you release the knob, the lever will retract.
