1997 FORD ASPIRE adding oil

12 [IS03900(ALL)04/96]If the light stays on or illuminates while the
engine is running:
*
[IS04000(ALL)03/96]
1. Pull off the road as soon as safely possible.
[IS04100(ALL)01/96]
2.Shut off the engine immediately.Continued
operation could cause severe engine damage.
[IS04200(ALL)01/96]
3. Check the engine oil level. Make sure the car
is on level ground.
[IS04300(ALL)01/96]
4. Add oil to the full mark on the dipstick
before you drive your car again. Do not
overfill. Do not operate the engine when the
oil light is on. For more information about
adding oil, seeEngine oil recommendationsin
the Index.
[IS04350(ALL)01/96]
WARNING
Do not rely on the oil light to tell you
when the oil is low. Have the oil checked
often. It is possible for damage to occur if
an engine is operated with a low oil level.
%*
[IS04500(ALL)03/96]
High Beam Light
*
[IS04600(ALL)03/96]
This light illuminates when the headlamps are
turned to high beam or when you flash the
lights. If your vehicle is equipped with daytime
running lights and you have your headlamps on
your high beam telltale will not illuminate when
you flash the lights.
*
[IS04700(ALL)01/96]
one inch art:0030174-A
High beam light
File:03icisf.ex
Update:Tue Mar 4 08:51:24 1997

150
*
[MC05650(ALL)05/96]
NOTE: Ford production and aftermarket
(Motorcraft) oil filters are designed for
added engine protection and long life.
If a replacement oil filter is used that
does not meet Ford material and design
specifications, startup engine noises or
knock may be experienced. It is
recommended you use the appropriate
ªMotorcraftº oil filter (or another brand
meeting Ford specifications) for your
engine application.
%*
[MC05700(ALL)01/96]
Checking and Adding Engine Oil
*
[MC05800(ALL)01/96]
Since the proper amount of engine oil is
important for safe engine operation, check the oil
using the dipstick each time you put fuel in
your vehicle. Remember the engine must be off,
the oil must be warm and the vehicle must be
parked on level ground.
%*
[MC05900(ALL)01/96]
Checking the engine oil level:
*
[MC06000(ALL)01/96]
1. Turn the engine off after it has warmed up
and allow a few minutes for the engine oil
to drain back into the oil pan.
[MC06100(ALL)01/96]
2. Set the parking brake fully and make sure
the gearshift is securely latched in P (Park)
or 1 (First).
*
[MC06200(ALL)01/96]
3. Open the hood. Protect yourself from engine
heat.
[MC06300(ALL)01/96]
4. Locate the dipstick (highlighted in yellow)
and carefully pull it out of the engine.
*
[MC06400(ALL)01/96]
5. Wipe the dipstick clean and put it back into
position, making sure it is fully seated.
File:11icmcf.ex
Update:Tue Mar 4 08:57:16 1997

151 [MC06500(ALL)01/96]
quarter page art:0032227-B
Engine oil dipstick
[MC06600(ALL)01/96]
6. Carefully pull the dipstick out again. If the
oil level is at or below the ªLº line, add
engine oil as necessary. If the oil level is
beyond the letter ªFº, engine damage or
high oil consumption may occur and some
oil must be removed from the engine.
[MC06700(ALL)04/96]
NOTE: The distance between the L (low) and
F (full) marks on the dipstick
represents 1.06 qts (1.0 liter).
*
[MC06800(ALL)01/96]
7. Put the dipstick back in and make sure it is
fully seated.
*
[MC06900(ALL)01/96]
It may be necessary to add some oil between oil
changes. Make sure you use a CERTIFIED
engine oil of the preferred viscosity. Your
vehicle's warranty coverage may not apply if
engine damage is caused by the use of improper
engine oil.
*
[MC07000(ALL)09/96]
Add engine oil through the oil filler cap
highlighted in yellow. To add oil, remove the
filler cap and use a funnel to pour oil into the
opening. Be careful not to overfill the engine.
Recheck the oil level after you finish adding oil.
File:11icmcf.ex
Update:Tue Mar 4 08:57:16 1997

Index 243
Index
A
ABS warning light (see Anti-lock
brake system)............. 15
Accessory position on the ignition..... 44
Additives, engine oil.......... 149
Air bag supplemental restraint system . 69, 78
and child safety seats........77±78
description............. 69,71
driver air bag........... 69,71
indicator light............. 14
operation............... 71
passenger air bag............ 71
service and information labels.... 71,75
tone generator............. 74
Air cleaner filter, specifications...... 199
Antenna, radio (see Electronic
sound system)......... 19,27,42
Antifreeze (see Engine coolant)...... 155
Anti-lock brake system (ABS)
description.............. 105
see also Brake............ 105
warning light.............. 15
warninig light............. 9
Appeals (see Dispute settlement board) . . 214
Assistance (see Customer assistance) . . . 211
Audio system (see Electronic
sound system)............. 19
Autolamp system (see Headlamps)..... 46
Automatic transaxle
fluid, adding............. 161
fluid, checking............ 161
Automatic transmission
driving an automatic overdrive.... 112
fluid, adding............. 161
File:icixf.ex
Update:Tue Mar 4 08:59:36 1997

248 Index
Engine (continued)
fuel injected engine, starting.....93±94
fuel pump shut-off switch....... 100
preparing to start............ 93
starting................. 94
starting after a collision........ 100
storing your vehicle........195, 197
Engine block heater............ 97
Engine coolant............. 155
checking and adding......... 155
checking hoses............ 159
disposal...........146, 152, 162
drain and flush............ 159
preparing for storage......... 197
proper solution........146, 152, 162
recovery reservoir........... 155
temperature gauge........... 17
Engine coolant temperature gauge..... 17
description............... 17
mechanical............... 17
Engine coolant temperature
guage:electronic............. 17
Engine fan............... 146
Engine:idle speed control.......... 96
Engine knocking............. 177
Engine oil............... 149
changing oil and oil filter.....150, 152
checking and adding......... 150
check oil warning light......... 11
dipstick............... 150
disposal...........146, 152, 162
engine oil pressure warning light..... 11
filter, specifications.......... 199
low oil warning light.......... 11
specifications............. 149
synthetic oil............. 149
ªbreak-inº oils............. 5
viscosity............... 149
Exhaust fumes............. 102
Extended Service Plan, Ford........ 4
File:icixf.ex
Update:Tue Mar 4 08:59:36 1997

254 Index
N
National Highway Traffic Safety
Administration............ 209
New vehicle break-in........... 5
O
Octane rating............176±177
Odometer................. 18
description............... 18
trip odometer.............. 18
Oil filter..............152, 199
Oil (see Engine oil)........... 149
Oil viscosity.............. 149
On-board diagnostic (OBD II) system . . . 183
Overseas offices............. 220
P
Parking brake.............. 108
operation............... 108
warning light.............. 9
Parts (see Motorcraft Parts)........ 199
PCV valve, specifications......... 199
Power features, mirrors.......... 51
Power steering
dipstick............... 159
fluid, checking and adding....... 159
servicing............... 110
Prop rod, hood............. 148
R
Radio (see Electronic sound systems).... 19
Regulations, National Highway Traffic Safety
Administration............ 209
Reporting safety defects......... 209
Restraints, safety (see Safety restraints)
adult................ 57,63
infant................. 77
Roadside assistance........... 211
File:icixf.ex
Update:Tue Mar 4 08:59:36 1997
