Downloaded from www.Manualslib.com manuals search engine R05599
0.13 sec.
0.13 sec. 3 sec. ON
OFF
R12881
1,100 ± 30 mm
(43.31 ± 1.18 in.)
R12882
830 ± 30 mm
(32.68 ± 1.18 in.)
BR1865
0.13 sec.
0.13 sec. ON
OFF
R05596
0.13 sec. Braking0.13 sec. DI−324
− DIAGNOSTICSANTI−LOCK BRAKE SYSTEM
1996 TOYOTA T100 (RM449U)
(4) Check that the ABS warning light blinks.
HINT:
If the ABS warning light does not blink, inspect the ABS warning
light circuit (See page DI−354).
(5) Jack up the rear side of the vehicle slowly.
HINT:
When measuring the height, measure at the center of the lower
body of the vehicle.
(6) Check that the warning light blinks.
If the warning light turns on, inspect the deceleration sensor
installation. If the sensor installation is OK, replace the decel-
eration sensor.
(7) Jack down the vehicle slowly.
(8) Jack up the front side of the vehicle slowly, as
shown.
HINT:
When measuring the height, measure at the center of the lower
body of the vehicle.
(9) Check that the warning light blinks.
If the warning light turns on, inspect the deceleration sensor
installation. If the sensor installation is OK, replace the decel-
eration sensor.
(10) Jack down the vehicle slowly.
(c) Check the deceleration sensor operation.
(1) Drive the vehicle straight ahead at about 20 km/h
(12.4 mph) or more, lightly depress the brake pedal.
(2) Check that there is no change in the warning light
pattern.
(3) Drive the vehicle straight ahead at about 20 km/h
(12.4 mph) or more, and depress the brake pedal
moderately.
(4) Check that the warning light turns on while braking.

Downloaded from www.Manualslib.com manuals search engine R05597
0.13 sec. 0.13 sec.
Braking
− DIAGNOSTICSANTI−LOCK BRAKE SYSTEM
DI−325
1996 TOYOTA T100 (RM449U)
(5) Drive the vehicle straight ahead at about 20 km/h
(12.4 mph) or more, and depress the brake pedal
strongly.
(6) Check that the warning light pattern changes while
braking, as shown.
If the operation is not as specified, inspect the deceleration sen-
sor installation. If the sensor installation is OK, replace the de-
celeration sensor.
(7) Stop the vehicle and turn the ignition switch OFF.
(8) Remove the SST from the terminals of the DLC1.
SST 09843−18020
(d) Check the DTC of the speed sensor function.
Code No.DiagnosisTrouble Area
71Low output voltage of right front speed sensorRight front speed sensor
Sensor installation
72Low output voltage of left front speed sensorLeft front speed sensor
Sensor installation
73Low output voltage of right rear speed sensorRight rear speed sensor
Sensor installation
74Low output voltage of left rear speed sensorLeft rear speed sensor
Sensor installation
75Abnormal change in output voltage of right front speed
sensorRight front speed sensor rotor
76Abnormal change in output voltage of left front speed
sensorLeft front speed sensor rotor
77Abnormal change in output voltage of right rear speed
sensorRight rear speed sensor rotor
78Abnormal change in output voltage of left rear speed
sensorLeft rear speed sensor rotor
79*Deceleration sensor is faultyDeceleration sensor
Sensor installation
*: 4WD models

Downloaded from www.Manualslib.com manuals search engine DI0ZZ−03
− DIAGNOSTICSANTI−LOCK BRAKE SYSTEM
DI−331
1996 TOYOTA T100 (RM449U)
PROBLEM SYMPTOMS TABLE
If a normal code is displayed during the DTC check but the problem still occurs, check the circuits for each
problem symptom in the order given in the table below and proceed to the relevant troubleshooting page.
SymptomsInspection CircuitSee page
ABS does not operate.
Only when 1. − 4. are all normal and the problem is still occurring, replace the
ABS ECU.
1. Check the DTC reconfirming that the normal code is output.
2. IG power source circuit.
3. Speed sensor circuit.
4. Check the ABS actuator with a checker.
If abnormal, check the hydraulic circuit for leakage (See page DI−xx).
DI−321
DI−347
DI−341
BR−58
ABS does not operate
efficiently.
Only when 1. − 4. are all normal and the problem is still occurring, replace the
ABS ECU.
1. Check the DTC reconfirming that the normal code is output.
2. Speed sensor circuit.
3. Stop light switch circuit.
4. Check the ABS actuator with a checker.
If abnormal, check the hydraulic circuit for leakage (See page DI−362).
DI−321
DI−341
BR−58
ABS warning light
abnormal.1. ABS warning light circuit.
2. ABS ECU.DI−354
DTC check cannot be done.
Only when 1. and 2. are all normal and the problem is still occurring, replace the
ABS ECU.
1. ABS warning light circuit.
2. Tc terminal circuit.
DI−354
DI−358
Speed sensor signal check
cannot be done.1. Ts terminal circuit.
2. ABS ECU.DI−360

Downloaded from www.Manualslib.com manuals search engine − DIAGNOSTICSANTI−LOCK BRAKE SYSTEM
DI−355
1996 TOYOTA T100 (RM449U)
INSPECTION PROCEDURE
Troubleshooting in accordance with the chart below for each trouble symptom.
ABS warning light does not light upGo to step 1
ABS warning light remains onGo to step 3
1 Check ABS warning light.
See Combination Meter Troubleshooting on page BE−2.
NG Repair bulb or combination meter assembly.
OK

Downloaded from www.Manualslib.com manuals search engine − DIAGNOSTICSANTI−LOCK BRAKE SYSTEM
DI−357
1996 TOYOTA T100 (RM449U)
3 Is DTC output?
Check DTC on page DI−321.
YES Repair circuit indicated by code output.
NO
4 Does ABS warning light go off if short pin is removed?
NO Check for short in harness and connector be-
tween warning light, DLC1 and ECU (See page
IN−26).
YES
5 Check ABS control relay (See step 2).
NG Replace ABS control relay.
OK
Check for short in harness and connector between DLC1 and ABS control relay (See page
IN−26).

Downloaded from www.Manualslib.com manuals search engine F00363
BRABS ECU
DLC1
Y−BY−B
EBIE1 A15
E1
3116
20
TcTc
AB0119S08097F00445
ON
E
1
Tc(−)
(+)
DI−358
− DIAGNOSTICSANTI−LOCK BRAKE SYSTEM
1996 TOYOTA T100 (RM449U)
Tc Terminal Circuit
CIRCUIT DESCRIPTION
Connecting terminals Tc and E1 of the DLC1 causes the ECU to display the DTC by flashing the ABS warning
light.
WIRING DIAGRAM
INSPECTION PROCEDURE
1 Check voltage between terminals Tc and E1 of DLC1.
CHECK:
(a) Turn the ignition switch ON.
(b) Measure voltage between terminals Tc and E
1 of DLC1.
OK:
Voltage: 10 − 14 V
OK If ABS warning light does not blink even after Tc
and E
1 are connected, ECU may be defective.
NG
DI10U−03

Downloaded from www.Manualslib.com manuals search engine F00363
BRABS ECU
DLC1
R−YR−Y
EBIE1 A15
E1
3161
6
TsTs
AB0119S08096F00446
ON
E
1
Ts(−)
(+)
DI−360
− DIAGNOSTICSANTI−LOCK BRAKE SYSTEM
1996 TOYOTA T100 (RM449U)
Ts Terminal Circuit
CIRCUIT DESCRIPTION
The sensor check circuit detects abnormalities in the speed sensor signal which cannot be detected with
the DTC check.
Connecting terminals Ts and E
1 of the DLC1 in the engine compartment starts the check.
WIRING DIAGRAM
INSPECTION PROCEDURE
1 Check voltage between terminals Ts and E1 of DLC1.
CHECK:
(a) Turn the ignition switch ON.
(b) Measure voltage between terminals Ts and E
1 of DLC1.
OK:
Voltage: 10 − 14 V
OK If ABS warning light does not blink even after Ts
and E
1 are connected, ECU may be defective.
NG
DI10W−03

Downloaded from www.Manualslib.com manuals search engine DI0XG−01
Vehicle Brought to Workshop
Identification of Problem
Confirmation Test
END
Repair
Customer Ploblem Analysis
DI−364
DI−365
DI−369
DI−373 Warning Light Check
DTC Check and Recording
Malfunction Code Clearance
DTC Check and Recording
DTC Chart
Circuit Inspection
Malfunction Code Clearance
DTC Check
Step
,:
Diagnostic steps permitting
the use of the TOYOTA
hand−held tester.34
1
2
3
4
5
7
8
9
10
11
12
5,10,1112,,
Symptom Simulation
IN−16
Does Not Light Up
Normal Code
Normal CodeNormal
Code
Malfunction Code
Malfunction Code
6
Normal Code
DI−365
DI−365
DI−365
DI−365
DI−365
− DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI−363
620 Author: Date:
1996 TOYOTA T100 (RM449U)
SUPPLEMENTAL RESTRAINT SYSTEM
HOW TO PROCEED WITH TROUBLESHOOTING
Troubleshooting in accordance with the procedure on the following pages.
