1996 TOYOTA T100 check engine

Downloaded from www.Manualslib.com manuals search engine AB0118AB0119S08098FI1394H00342
ACC ON
or
DLC1
E1
Tc
Code 31
− DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI−395
1996 TOYOTA T100 (RM449U)
3 Is DTC 31 output again?
PREPARATION:
Clear malfunction code.
CHECK:
(a) Turn ignition switch to LOCK, and wait at least 20 se-
conds.
(b) Turn ignition switch to ACC or ON, and wait at least 20 se-
conds.
(c) Repeat operation in steps (a) and (b) at least 5 times.
(d) Using SST, connect terminals Tc and E1 of DLC1.
SST 09843−18020
(e) Check the DTC.
NO Using simulation method, reproduce malfunc-
tion symptoms (See page IN−16).
YES
Replace center airbag sensor assembly.

Downloaded from www.Manualslib.com manuals search engine H18114
ONAirbag Sensor Assembly
IG
2Acc
(+) (−)
AB0119AB0234H00351
ON
− DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI−397
1996 TOYOTA T100 (RM449U)
INSPECTION PROCEDURE
1 Preparation.
PREPARATION:
(a) Turn ignition switch to LOCK.
(b) Disconnect center airbag sensor assembly connector.
(c) Turn ignition switch ON. But do not start engine.
(d) Measure voltage between terminal IG
2 or ACC on con-
nector wire harness side of center airbag sensor assem-
bly and body ground, and operate electric system (defog-
ger, wiper, headlight, heater blower, etc.).
Voltage: 6 V − 11.5 V at IG
2 and ACC
(e) Turn electric system switch OFF.
(f) Turn ignition switch to LOCK.
(g) Remove voltmeter and connect center airbag sensor as-
sembly connector.
2 Does SRS warning light turn off?
PREPARATION:
(a) Turn ignition switch to LOCK.
(b) Connect steering wheel pad connector.
(c) Connect center airbag sensor assembly connector.
(d) Turn ignition switch ON.
CHECK:
Operate electric system (defogger, wiper, headlight, heater
blower, etc.), and check that SRS warning light goes off.
NO Check for DTCs. If a DTC is output, perform trou-
bleshooting for DTC. If a normal code is output,
replace center airbag sensor assembly.
YES
From results of above inspection, malfunctioning part can now be considered normal. To make
sure of this, use simulation method to check.

Downloaded from www.Manualslib.com manuals search engine H18115
LOCK
Center Airbag
Sensor Assembly
− DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI−399
1996 TOYOTA T100 (RM449U)
INSPECTION PROCEDURE
1 Does SRS warning light turn off?
PREPARATION:
(a) Turn ignition switch to LOCK.
(b) Disconnect negative (−) terminal cable from the battery,
and wait at least 90 seconds.
(c) Disconnect center airbag sensor assembly connector.
(d) Connect negative (−) terminal cable to battery.
CHECK:
Check operation of SRS warning light.
NO Check SRS warning light circuit or terminal AB
circuit of DLC1.
YES
Replace center airbag sensor assembly.

Downloaded from www.Manualslib.com manuals search engine N14677
Fuse
DI−400
− DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
1996 TOYOTA T100 (RM449U)
SRS Warning Light Circuit Malfunction (Does not light up, when
ignition switch is turned to ACC or ON.)
CIRCUIT DESCRIPTION
The SRS warning light is located on the combination meter.
When the SRS is normal, the SRS warning light lights up for approx. 6 seconds after the ignition switch is
turned from LOCK position to ACC or ON position, and then turns off automatically.
If there is a malfunction in the SRS, the SRS warning light lights up to inform the driver of the abnormality
When terminal Tc and E1 of the DLC1 are connected, the DTC is displayed by the blinking of the SRS warn-
ing light.
WIRING DIAGRAM
See page DI−398.
INSPECTION PROCEDURE
1 Check ECU−B Fuse.
PREPARATION:
Remove ECU−B fuse.
CHECK:
Check continuity of ECU−B fuse.
OK:
Continuity
HINT:
Fuse may be burnt out even if it appears to be OK during
visual inspection.
If fuse is OK, install it.
NG Go to step 6.
OK
2 Check connection of center airbag sensor assembly connector.
NG Repair.
OK
DI98B−01

Downloaded from www.Manualslib.com manuals search engine H18116
Airbag Sensor Assembly
LA
(−)
(+)ON
− DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI−401
1996 TOYOTA T100 (RM449U)
3 Preparation. (See step 1 on page DI−396)
4 Check SRS warning light circuit.
PREPARATION:
(a) Connect negative (−) terminal cable to battery.
(b) Turn ignition switch to ACC or ON.
CHECK:
Measure voltage LA terminal of harness side connector of cen-
ter airbag sensor assembly and body ground.
OK:
Voltage: 10 − 16 V
NG Check SRS warning light bulb/repair SRS
warning light circuit.
OK

Downloaded from www.Manualslib.com manuals search engine AB0118AB0119W05587W05586
H00350
H00346
Center Airbag
Sensor Assembly
Spiral
CableD Squib
ACC ON
w/o Tachometer w/ Tachometeror
DI−402
− DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
1996 TOYOTA T100 (RM449U)
5 Does SRS warning light come on?
PREPARATION:
(a) Disconnect negative (−) terminal cable from the battery.
(b) Connect center airbag sensor assembly connector.
(c) Connect negative (−) terminal cable to battery, and wait
at least 2 seconds.
(d) Turn ignition switch to ACC or ON.
CHECK:
Check operation of SRS warning light.
OK:
SRS warning light comes on.
NO Check terminal LA of center airbag sensor
assembly. If normal, replace center airbag
sensor assembly.
YES
From results of above inspection, malfunctioning part can now be considered normal. To make
sure of this, use simulation method to check.
6 Is new ECU−B fuse burnt out again?
NO Using simulation method, reproduce
malfunction symptoms. (See page IN−16)
YES
Check harness between ECU−B fuse and
SRS warning light.

Downloaded from www.Manualslib.com manuals search engine AB0118AB0119W05587W05586AB0117H00347
ACC ON
or LOCK
w/o Tachometer
w/ Tachometer
AB0118
R14305AB0119
H00030
ACCON
or
E1
Tc
(+) (−)
DI−404
− DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
1996 TOYOTA T100 (RM449U)
INSPECTION PROCEDURE
If DTC is not displayed, do following troubleshooting:
1 Does SRS warning light up for approx. 6 seconds?
PREPARATION:
Check operation of SRS warning light after ignition switch is
turned from LOCK position to ACC or ON position.
NO Check SRS warning light system (See page
DI−365).
YES
2 Check voltage between terminals Tc and E1 of DLC1.
PREPARATION:
Turn ignition switch to ACC or ON.
CHECK:
Measure voltage between terminals Tc and E1 of DLC1.
OK:
Voltage: 10 − 16 V
OK Go to step 4.
NG

Downloaded from www.Manualslib.com manuals search engine AB0118
R14304AB0119
H00031
ACCON
orTc
(+)
(−)
− DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI−405
1996 TOYOTA T100 (RM449U)
3 Check voltage between terminals Tc of DLC1 and body ground.
CHECK:
Measure voltage between terminal Tc of DLC1 and body
ground.
OK:
Voltage: 10 − 16 V
OK Check harness between terminal E1 of DLC1
and body ground.
NG
