1996 TOYOTA T100 engine

Downloaded from www.Manualslib.com manuals search engine P15816
Z02917
Ohmmeter
Acceptable
TEMPERATURE °C (°F)
RESISTANCE kΩ
SF0BG−02
− MFI (3RZ−FE)ENGINE COOLANT TEMPERATURE (ECT) SENSOR
MF−45
997 Author: Date:
1996 TOYOTA T100 (RM449U)
ENGINE COOLANT
TEMPERATURE (ECT) SENSOR
INSPECTION
1. DRAIN ENGINE COOLANT
2. REMOVE ENGINE COOLANT TEMPERATURE
SENSOR
(a) Disconnect the ECT sensor connector.
(b) Using a 19 mm deep socket wrench, remove the ECT
sensor and gasket.
3. INSPECT ENGINE COOLANT TEMPERATURE
SENSOR
Using an ohmmeter, measure the resistance between the ter-
minals.
Resistance: Refer to the chart graph
If the resistance is not as specified, replace the ECT sensor.
4. REINSTALL ENGINE COOLANT TEMPERATURE
SENSOR
(a) Using a 19 mm deep socket wrench, install the ECT sen-
sor and gasket.
Torque: 20 N·m (200 kgf·cm, 14 ft·lbf)
(b) Connect the ECT sensor connector.
5. REFILL ENGINE COOLANT

Downloaded from www.Manualslib.com manuals search engine SF1QL−01
Z02772
Ohmmeter
Acceptable
TEMPERATURE °C (°F)
RESISTANCE kΩ
30
20
10
5
3
2
1
0.5
0.3
0.2
0.1
−20 0 20 40 60 80 100
(−4) (32) (68)(104)(140)(176)(212) MF−46
− MFI (3RZ−FE)INTAKE AIR TEMPERATURE (IAT) SENSOR
998 Author: Date:
1996 TOYOTA T100 (RM449U)
INTAKE AIR TEMPERATURE (IAT)
SENSOR
INSPECTION
1. REMOVE IAT SENSOR
2. INSPECT IAT SENSOR
Using an ohmmeter, measure the resistance between the ter-
minals.
Resistance: Refer to the chart graph
If the resistance is not as specified, replace the IAT sensor.
3. REINSTALL IAT SENSOR

Downloaded from www.Manualslib.com manuals search engine P24770
SF0BI−03
P01630
− MFI (3RZ−FE)KNOCK SENSOR
MF−47
999 Author: Date:
1996 TOYOTA T100 (RM449U)
KNOCK SENSOR
INSPECTION
1. REMOVE KNOCK SENSOR
(a) Disconnect the knock sensor connector.
(b) Using SST, remove the knock sensor.
SST 09816−30010
2. INSPECT KNOCK SENSOR
Using an ohmmeter, check that there is no continuity between
the terminal and body.
If there is continuity, replace the sensor.
3. REINSTALL KNOCK SENSOR
(a) Using SST, install the knock sensor.
SST 09816−30010
Torque: 44 N·m (450 kgf·cm, 33 ft·lbf)
(b) Connect the knock sensor connector.

Downloaded from www.Manualslib.com manuals search engine P21698
SF0BK−02
FI6320
Ohmmeter MF−48
− MFI (3RZ−FE)EXHAUST GAS RECIRCULATION (EGR) GAS
TEMPERATURE SENSOR
1000 Author: Date:
1996 TOYOTA T100 (RM449U)
EXHAUST GAS RECIRCULATION
(EGR) GAS TEMPERATURE
SENSOR
INSPECTION
1. REMOVE EGR GAS TEMPERATURE SENSOR
2. INSPECT EGR GAS TEMPERATURE SENSOR
Using an ohmmeter, measure the resistance between the ter-
minals.
Resistance:
64 − 97 kΩ at 50°C (122°F)
11 − 16 kΩ at 100°C (212°F)
2 − 4 kΩ at 150°C (302°F)
If the resistance is not as specified, replace the sensor.
3. REINSTALL EGR GAS TEMPERATURE SENSOR

Downloaded from www.Manualslib.com manuals search engine P15820
SF0BL−02
− MFI (3RZ−FE)HEATED OXYGEN SENSOR
MF−49
1001 Author: Date:
1996 TOYOTA T100 (RM449U)
HEATED OXYGEN SENSOR
INSPECTION
INSPECT HEATER RESISTANCE OF HEATED
OXYGEN SENSORS
(a) Disconnect the heated oxygen sensor connectors.
(b) Using an ohmmeter, measure the resistance between ter-
minals +B and HT.
Resistance:
Bank 1 Sensor 1: 5 − 7 Ω at 20°C (68°F)
Bank 1 Sensor 2: 11 − 16 Ω at 20°C (68°F)
If resistance is not as specified, replace the heated oxygen
sensors.
(c) Reconnect the heated oxygen sensor connectors.

Downloaded from www.Manualslib.com manuals search engine SF0BM−02
P21637
MF−50
− MFI (3RZ−FE)ENGINE CONTROL MODULE (ECM)
1002 Author: Date:
1996 TOYOTA T100 (RM449U)
ENGINE CONTROL MODULE (ECM)
COMPONENTS

Downloaded from www.Manualslib.com manuals search engine SF0BN−01
P15739
− MFI (3RZ−FE)ENGINE CONTROL MODULE (ECM)
MF−51
1996 TOYOTA T100 (RM449U)
REMOVAL
1. REMOVE FRONT DOOR SCUFF PLATE
Remove the 4 screws and front scuff plate.
2. REMOVE COWL SIDE TRIM
Remove the clip and cowl side trim.
3. REMOVE ECM
(a) Disconnect the 4 ECM connectors.
(b) Remove the 3 bolts and ECM.

Downloaded from www.Manualslib.com manuals search engine SF0BO−01
MF−52
− MFI (3RZ−FE)ENGINE CONTROL MODULE (ECM)
1996 TOYOTA T100 (RM449U)
INSPECTION
(See page DI−17)
