1996 TOYOTA RAV4 air condition

ABS Antilock Brake System
A/C Air Conditioner
assy assembly
ECT Electronic Controlled Transmission
ECU Electronic Control Unit
e.g. Exempli Gratia (for Example)
Ex. Except
FWD Front Wheel Drive Vehicles
4WD Four Wheel Drive Vehicles
in. inch
LH Left-hand
LHD Left-hand Drive
MIG Metal Inert Gas
M/Y Model Year
PPS Progressive Power Steering
RH Right-hand
RHD Right-hand Drive
SRS Supplemental Restraint System
w/ with
w/o without
ABBREVIATIONS USED IN THIS MANUAL
For convenience, the following abbreviations are used in this
manual.
INTRODUCTIONINœ15

Rear Combination Light (PMMA/PP)
Roof Side Inner Garnish (TSOP)
Air Conditioner Unit (PP)
Heater Blower (PP)
Rear Bumper Side Seal (PE)
Cowl Side Trim Board (PP)
Deck Trim Side Panel (TSOP) Front Door Outside Scuff Plate (PP/PE)
Back Door Outside Handle (PC) Rear Door Outside Scuff Plate (PP/PE)
Rear Bumper Piece (TSOP)
Licence Plate Light (PC)
Reflex Reflector (PMMA/ABS)
HINT:
wResin material differs with model.
/ Made up of 2 or more kinds of materials.
PLASTIC BODY PARTSPPœ6

N09214
DLC 3 DI−4
− DIAGNOSTICSENGINE
1996 RAV4 (RM447U)
By switching the ECM to check mode when trouble-
shooting, the technician can cause the MIL to light
up for a malfunction that is only detected once or
momentarily (TOYOTA hand−held tester only) (See
page DI−3).
*2 trip detection logic:
When a logic malfunction is first detected, the mal-
function is temporarily stored in the ECM memory.
If the same malfunction is detected again during the
second drive test, this second detection causes the
MIL to light up.
The 2 trip repeats the same mode a 2nd time. (How-
ever, the IG switch must be turned OFF between the
1st trip and 2nd trip).
Freeze frame data:
Freeze frame data records the engine condition
when a misfire (DTC P0300 − P0304) or fuel trim
malfunction (DTC P0171, P0172), or other malfunc-
tion (first malfunction only), is detected.
Because freeze frame data records the engine
conditions (fuel system, calculator load, engine
coolant temperature, fuel trim, engine speed, ve-
hicle speed, etc.) when the malfunction is detected,
when troubleshooting it is useful for determining
whether the vehicle was running or stopped, the en-
gine warmed up or not, the air−fuel ratio lean or rich,
etc. at the time of the malfunction.
Priorities for Troubleshooting:
If troubleshooting priorities for multiple diagnostic
codes are given in the applicable diagnostic chart,
these should be followed.
If no instructions are given, troubleshoot DTC according to the
following priorities.
(1) DTC other than fuel trim malfunction (DTC P0171,
P0172), EGR (DTC P0401, P0402), and misfire
(DTC P0300 − P0304).
(2) Fuel trim malfunction (DTC P0171, P0172) and
EGR (DTC P0401, P0402).
(3) Misfire (DTC P0300 − P0304).
(b) Check the DLC3.
The vehicle’s ECM uses V.P.W. (Variable Pulse Width) for
communication to comply with SAE J1850. The terminal
arrangement of DLC3 complies with SAE J1962 and
matches the V.P.W. format.

FI3605
ONFlashing
0.13 Seconds OFF
DI−6
− DIAGNOSTICSENGINE
1996 RAV4 (RM447U)
NOTICE:
When simulating symptoms with an OBDII scan tool (Ex-
cluding TOYOTA hand−held tester) to check the DTC, use
normal mode. For codes on the DTC chart subject to ”2 trip
detection logic”, turn the ignition switch OFF after the
symptom is simulated the first time. Then repeat the simu-
lation process again. When the problem has been simu-
lated twice, the MIL lights up and the DTC are recorded in
the ECM.
3. INSPECT DIAGNOSIS (Check Mode)
HINT:
TOYOTA Hand−Held Tester only:
Compared to the normal mode, the check mode has an in-
creased sensitivity to detect malfunctions.
Furthermore, the same diagnostic items which are detected in
the normal mode can also be detected in the check mode.
(a) Check the DTC.
(1) Initial conditions.
Battery positive voltage 11 V or more.
Throttle valve fully closed.
Transmission in park or neutral position.
Air conditioning switched OFF.
(2) Turn ignition switch OFF.
(3) Prepare the TOYOTA hand−held tester.
(4) Connect the TOYOTA hand−held tester to DLC3 at
the lower of the instrument panel.
(5) Turn the ignition switch ON and push the TOYOTA
hand−held tester main switch ON.
(6) Switch the TOYOTA hand−held tester normal mode
to check mode. (Check that the MIL flashes.)
(7) Start the engine. (The MIL goes out after the engine
starts.)
(8) Simulate the conditions of the malfunction de-
scribed by the customer.
NOTICE:
Leave the ignition switch ON until you have checked the
DTC, etc.
(9) After simulating the malfunction conditions, use the
TOYOTA hand−held tester diagnosis selector to
check the DTC and freezed frame data, etc.
HINT:
Take care not to turn the ignition switch OFF. Turning the ignition
switch OFF switches the diagnosis system from check mode to
normal mode, so all diagnostic codes, etc. are erased.

− DIAGNOSTICSENGINE
DI−7
1996 RAV4 (RM447U)
(10) After checking the DTC, inspect the applicable cir-
cuit.
(b) Clear the DTC.
The following actions will erase the DTC and freezed
frame data.
(1) Operating the OBDII scan tool (complying with SAE
J1978) or TOYOTA hand−held tester to erase the
codes.
(See the OBDII scan tool’s instruction book for oper-
ating instructions.)
(2) Disconnecting the battery terminals or EFI fuse.
NOTICE:
If the TOYOTA hand−held tester switches the ECM from
normal mode to check mode or vice−versa, or it the ignition
switch is turned from ON to ACC or OFF during check
mode, the DTC and freezed frame data will be erased.
4. FAIL−SAFE CHART
If any of the following codes is recorded, the ECM enters fail−sate mode.
DTC No.Fail−Safe OperationFail−Safe Deactivation Conditions
P0105Ignition timing fixed at 5° BTDCReturned to normal condition
P0110Intake air temp. is fixed at 68°F (20°C)Returned to normal condition
P0115Engine coolant temp. is fixed at 176°F (80°C)Returned to normal condition
P0120VTA is fixed at 0°
The following condition must be repeated at least
2 times consecutively
When closed throttle position switch is ON:
0.1 V  VTA  0.95 V
P0325Max. timing retardationIgnition switch OFF
P1300Fuel cutIGF signal is detected for 1 ignition
5. CHECK FOR INTERMITTENT PROBLEMS
TOYOTA hand−held tester only:
By putting the vehicle’s ECM in check mode, 1 trip detection logic possible instead of 2 trip detection logic
and sensitivity to detect open circuit is increased. This makes it easier to detect intermittent problems.
(1) Clear the diagnostic trouble codes (See page DI−3)
(2) Set the check mode (See page DI−3)
(3) Perform a simulation test (See page IN−20)
(4) Check the connector and terminal inspection (See page IN−30)
(5) Visual check and contact pressure (See page IN−30)
(6) Handle the connector (See page IN−30)

P00495
Outside
Inside
− DIAGNOSTICSENGINE
DI−9
1996 RAV4 (RM447U)
4 Check air filter.
PREPARATION:
Remove air filter.
CHECK:
Visually check that the air cleaner element is not excessively
dirty or oily.
HINT:
If necessary, clean element with compressed air.
First blow from inside thoroughly,then blow from outside of ele-
ment.
NG Repair or replace.
OK
5 Check idle speed.
PREPARATION:
(a) Warm up engine to normal operating temperature.
(b) Switch off all accessories.
(c) Switch off air conditioning.
(d) Shift transmission into ”N” position.
(e) Connect the OBDII scan tool or TOYOTA hand−held tes-
ter to DLC3 on the vehicle.
CHECK:
Use CURRENT DATA to check the engine idle speed.
OK:
Idling speed: 650 − 750 rpm
NG Proceed to matrix chart of problem symptoms
on page DI−20.
OK

DI−12
− DIAGNOSTICSENGINE
1996 RAV4 (RM447U)
7. ENGINE OPERATING CONDITION
NOTICE:
The value given below for ”Normal Condition” are representative values, so a vehicle may still be
normal even it its value varies from those listed here. So do not decide whether a part is faulty or not
solely according to the ”Normal Condition” here.
(a) CARB Mandated Signals
TOYOTA hand−held tester displayMeasurement ItemNormal Condition *
FUEL SYS #1
Fuel System Bank 1
OPEN: Air−fuel ratio feedback stopped
CLOSED: Air−fuel ratio feedback operating
Idling after warning up: CLOSED
CALC LOAD
Calculator Load:
Current intake air volume as a proportion of max.
intake air volumeIdling: 20.7 − 48.4 %
Racing without load (2,500 rpm) : 17.7 − 45.3 %
COOLANT TEMPEngine Coolant Temperature Sensor ValueAfter warning up: 80 − 95°C (176 − 203°F)
SHORT FT #1Short−term Fuel Trim Bank 10 ± 20 %
LONG FT #1Long−term Fuel Trim Bank 10 ± 20 %
ENGINE SPDEngine SpeedIdling: 700 ± 50 rpm
VEHICLE SPDVehicle SpeedVehicle Stopped: 0 km/h (0 mph)
IGN ADVANCEIgnition Advance
Ignition Timing of Cylinder No.1Idling: BTDC 0 − 10°
INTAKE AIRIntake Air Temperature Sensor ValueEquivalent to Ambient Temp.
MAPAbsolute Pressure Inside Intake ManifoldIdling: 21 − 49 kPa
Racing without load (2,500 rpm): 17 − 46 kPa
THROTTLE POS
Voltage Output of Throttle Position Sensor
Calculated as a Percentage
0V → 0 %, 5V → 100 %Throttle Fully Closed: 6 − 16 %
Throttle Fully Open: 64 − 98 %
O2S B1, S1Voltage Output of Oxygen Sensor
Bnak 1,Sensor 1Idling : 0.1 − 0.9 V
O2FT B1, S1Oxygen Sensor Fuel Trim Bank 1, Sensor 1
(Same as SHORT FT #1)0 ± 20 %
O2S B1, S2Voltage Output of Oxygen Sensor
Bank 1, Sensor 2Driving 50 km/h (31 mph): 0.1 − 0.9 V
*: If no conditions are specifically stated for ”Idling”, it means the shift lever is at N or P position, the A/C switch
is OFF and all accessory switches are OFF.

− DIAGNOSTICSENGINE
DI−13
1996 RAV4 (RM447U)
(b) TOYOTA Enhanced Signals
TOYOTA hand−held tester displayMeasurement ItemNormal Condition *
MISFIRE RPMEngine RPM for first misfire rangeMisfire 0: 0 RPM
MISFIRE LOADEngine load for first misfire rangeMisfire 0: 9 g/r
INJECTORFuel injection time for cylinder No.1Idling: 1.9 − 3.3 ms
IAC DUTY RATIOIntake Air Control Valve Duty Ratio Opening
ratio rotary solenoid type IAC valveIdling: 25 − 60 %
STARTER SIGStarter SignalCranking: ON
A/C SIGA/C Switch SignalA/C ON: ON
PNP SWPark / Neutral Position Switch SignalP or N position: ON
ELCTRCL LOAD SIGElectrical Load SignalDefogger S/W ON: ON
STOP LIGHT SWStop Light Switch SignalStop light switch ON: ON
FC IDLFuel Cut Idle: Fuel cut when throttle valve fully
closed, during decelerationFuel cut operating: ON
FC TAUFuel Cut TAU: Fuel cut during very light loadFuel cut operating: ON
CYL#1
CYL#2
CYL#3
CYL#4
Abnormal revolution variation for each cylinder0 %
IGNITIONTotal number of ignitions for every 1,000
revolutions0 − 2,000
EGR SYSTEMEGR system operating conditionIdling: OFF
FUEL PUMPFuel Pump SignalIdling: ON
EVAP (PURGE) VSVEVAP VSV SignalVSV operating: ON
VAPOR PRESS VSVVapor Pressure VSV SignalVSV operating: ON
A/C CUT SIGA/C Cut SignalA/C S/W OFF: ON
TOTAL FT B1Total Fuel Trim Bank 1: Average value for fuel
trim system of bank 1Idling: 0.8 − 1.2
O2 LR B1, S1
Oxygen Sensor Lean Rich Bank 1, Sensor 1
Response time for oxygen sensor output to
switch from lean to rich.
Idling after warned up: 0 − 1,000 msec.
O2 RL B1, S1
Oxygen Sensor Rich Lean Bank 1, Sensor 1
Response time for oxygen sensor output to
switch from rich to lean.
Idling after warned up: 0 − 1,000 msec.
*: If conditions are specifically stated for ”Idling” , it means the shift lever is at N or P Position, the A/C switch
is OFF and all accessory switches are OFF.
