1996 TOYOTA PASEO Owners Manual

38
A child restraint system for a small
child or baby must itself be restrained
on the seat with either the lap belt or
the lap portion of the lap/shoulderbelt.
The child restraint system should conform
to the size of the child and properly fit the
vehicle seat. For greater safety, the child
restraint
system should be installed in the
rear seat. According to accident statistics,
children are safer when properly re-strained in the rear seat than in the front seat. When installing a child restraint system,
follow the instructions provided by the
manufacturer of the system. General di- rections are also provided under the fol-
lowing illustrations.
CAUTION!
After installing the child restraint system, make sure it is secured in
place. If it is not restrained securely,
it may cause injury to the child in theevent of a sudden stop or accident.
When not using the child restraint system, keep it secured with the seat belt or place
it somewhere other than in passenger
compartment. This will prevent it injuring passengers in the event of a sudden stop or accident. Your vehicle has anchors for securing the
top strap of a child restraint system. The
anchor
nuts are welded beneath the sheet
metal to permit installation of an anchor
bracket for a child restraint system.
To install an anchor bracket, use an 8 mm
X 30 mm X 1.25 mm coarse thread metric
bolt and a 10 mm (0.4 in.) spacer. Note that the bolts accompanying many child
restraint systems are not metric. You can
damage the anchor nuts on your vehicle
if you force bolts with different thread intothe anchor nuts.
For instructions about how to install the
anchor bracket, see (C) TOP STRAP
ANCHORS AND LOCATIONSº.
If your child restraint system does not pro-
vide any of the necessary parts, you can
purchase the following items from your
Toyota dealer. CRS installation kit (Part No. 04731-22012) Ðcontains 1 bolt, 3 types of spacers and 1 locking clip.
Bolt (Part No. 91511-60830)
(A) INSTALLATION ON REAR SEAT
When installing a rear-facing child re-
straint system, follow the same procedure
as when installing a forward-facing child
restraint system.
ÐChild restraint system

39
CAUTION!
Do not use a rear-facing child re-
straint system in the rear seat if it in-
terferes with the lock mechanism of
the front seats. This may cause se-
vere injury to the child and front pas-
senger in case of sudden braking ora collision.
1. Fasten the lap and shoulder belt over
the child restraint system following the in-
struction provided by its manufacturer.
Keep the lap portion of the belt tight.
CAUTION!
After inserting the tab, make sure
the tab and buckle are locked.
Do not insert coins, clips, etc. in
the buckle as this may prevent you
from properly latching the tab and buckle.
If the seat belt does not function
normally, i mmediately contact your
Toyota dealer.

40
2. Fully extend the shoulder belt to put in the lock mode.3. Place the shoulder belt between the vehicle seatback and the child restraint
system and allow it to retract. To hold the
child restraint system securely, let the
shoulder belt retract as far as it will go
while firmly pushing down the child re-
straint system.4. If your child restraint system requires
the use of a top strap, latch the hook onto
the anchor bracket and tighten the top strap.

41
CAUTION!
After inserting the tab, make sure
the tab and buckle are locked.
Do not insert coins, clips, etc. in
the buckle as this may prevent you
from properly latching the tab and buckle.
If the seat belt does not function
normally, immediately contact your
Toyota dealer.
Make sure the seat belt is securely
locked. Also make sure the child
restraint system is secure by push-
ing and pulling it in different direc-tions.
5. To remove the child restraint system, press the buckle-release button and al-
low the belt to retract. Unhook the top strap.

42
(A) TOP STRAP ANCHORS AND
LOCATIONSÐ
ÐOn the filler panel behind the rear seat
a. Using the illustration as a guide, run your fingers across the trim of the filler panel itself to locate the position of the
holes underneath.
b. Make a hole in the covering directly
above the hole in the filler panel.
c. Insert a 10 mm (0.4 in.) spacer and tighten down the anchor bracket for your
child restraint system with a bolt. Torque the bolt to 16.5Ð24.7 Nm (1.68Ð2.52
kgf m, 12.2Ð18.2 ft lbf). To comply with Canada Motor Vehicle
Safety Standards, vehicles sold in Cana-
da are provided with a bracket set in the
glovebox,
designed for use with any of the
2 anchor locations shown in the illustra-tion.(B) INSTALLATION ON FRONT SEAT Do not use a child restraint system which
requires use of a top strap in the front
seat. A child restraint system which re-
quires use of a top strap should only be
installed in the rear seat.

43
CAUTION!
With front passenger airbag: Do not
use a rear-facing child restraint
system in the front seat because the
force of the rapid inflation of the
passenger airbag may cause severe
injury to the child. When using a
forward-facing child restraint sys-
tem, move the seat as far back as possible.
1. Fasten the lap and shoulder belt over
the child restraint system following the in-
structions provided by its manufacturer.
Keep the lap portion of the belt tight.
CAUTION!
After inserting the tab, make sure
the tab and buckle are locked.
Do not insert coins, clips, etc. in
the buckle as this may prevent you
from properly latching the tab and buckle.

44
If the seat belt does not function
normally, immediately contact your
Toyota dealer.
2. Fully extend the shoulder belt to put in the lock mode.3. Place the shoulder belt between the vehicle seatback and the child restraint
system and allow it to retract. To hold the
child restraint system securely, let the
shoulder belt retract as far as it will go
while firmly pushing down the child re-
straint system.

45
CAUTION!
After inserting the tab, make sure
the tab and buckle are locked.
Do not insert coins, clips, etc. in
the buckle as this may prevent you
from properly latching the tab and buckle.
If the seat belt does not function
normally, immediately contact your
Toyota dealer.
Make sure the seat belt is securely
locked. Also make sure the child re-
straint system is secure by pushing
and pulling it in different directions.
4. To remove the child restraint system, press the buckle-release button and allow
the belt to retract.
