BODY FRONT WIPER AND WASHER
BO−29
1996 LAND CRUISER (RM451U)
INSPECTION
1. INSPECT FRONT WASHER NOZZLE
(a) While operating the washer, check that both the point
where the washer fluid from the upper nozzles hits the
windshield, and the upsurge area, are within the range in-
dicated by the arrow.
AApprox. 460 mm (18.1 in.)
BApprox. 300 mm (11.8 in.)
CApprox. 250 mm (9.84 in.)
DApprox. 400 mm (15.7 in.)
EApprox. 410 mm (16.1 in.)
FApprox. 220 mm (8.66 in.)
GApprox. 60 mm (2.36 in.)
(b) Check if the lower point where the washer fluid hits the
windshield is within the range of the wiping pattern (the
area of the glass which is wiped by the wiper blades).
2. ADJUST FRONT WASHER NOZZLE
Using a tool like that shown in the illustration, change the direc-
tion of the nozzle hole to adjust the point where washer fluid
strikes the windshield.
