1996 NISSAN FRONTIER Owners Manual

The instrument brightness control operates
when the light switch is in theorposition.
Turn the control to adjust the brightness of
the instrument panel lights.Push the switch on to warn other drivers
when you must stop or park under emer-
gency conditions. All turn signal lights flash.
WARNING
cWhen stalled or stopped on the road-
way under emergency conditions,
move the vehicle well off the road.cDo not use the hazard warning flash-
ers while moving on the highway
unless unusual circumstances force
you to drive so slowly that your ve-
hicle might become a hazard to other
traffic.
cSome state laws may prohibit the
use of the hazard warning flasher
switch while driving.
cTurn signals do not work when the
hazard warning flasher lights are on.
The flasher can be actuated with the ignition
switch in any position.
SIC0052SIC0050
INSTRUMENT BRIGHTNESS
CONTROLHAZARD WARNING FLASHER
SWITCH
1-12
ZX

The cigarette lighter element is an acces-
sory. A genuine NISSAN cigarette lighter or
equivalent can be purchased from your lo-
cal NISSAN dealer.
The cigarette lighter operates when the
ignition switch is in the ACC or ON position.
Push the lighter in all the way. When the
lighter is heated, it springs out.
Return the lighter to its original position after
use.
WARNING
The cigarette lighter should not be
used while driving in order that full
attention may be given to the driving
operation.
CAUTION
The cigarette lighter socket is a power
source for the cigarette lighter element
only. The use of the cigarette lighter
socket as a power source for any other
accessory is not recommended.
WARNING
cAvoid abrupt starting and braking
when the cup holder is being used to
prevent spilling the drink. If the liq-
uid is hot, it can scald you or your
passenger.
cThe cup holder should not be used
while driving in order that full atten-
tion may be given to the driving
operation.
AIC0700AIC0743
CIGARETTE LIGHTER
(ACCESSORY) AND ASH
TRAYCUP HOLDER
(If so equipped)
1-13
ZX

The interior light has a three-position switch
and operates regardless of ignition key
position.
cWhen the switch is in the OFF position,
the interior light does not illuminate, re-
gardless of door position.cWhen the switch is in the centerjor
DOOR position, the interior light illumi-
nates by opening the doors.
cWhen the switch is in the ON position,
the interior light illuminates whether any
door is opened or closed.
Cargo light operation
On King Cab models, the light can be used
as a cargo light by simply pulling the light
down. This light is convenient at night when
loading cargo.
For further information regarding personal
light bulb replacement, refer to ªBulb re-
placementº in the ``Do-it-yourself opera-
tions'' section.
NOTE:
Leaving the interior light switch in the
ON position for extended periods of time
will result in a discharged battery.
IC0278M
AIC0704
INTERIOR LIGHT AND
CARGO LIGHTMAP LIGHT
(If so equipped)
1-14
ZX

The side windows can be opened or closed
by turning the hand crank on each door. To
open the window, turn the crank counter-
clockwise. To close the window, turn the
crank clockwise.The power window operates when the igni-
tion key is ON.
To open or close the window, press the
switch and hold it down. The main switch
(driver's switches) also opens or closes the
passenger side window.
Locking passenger's window
When the lock button is pushed in, only the
driver side window can be opened or
closed. Push it in again to cancel.The passenger switch opens or closes the
passenger's window. To open or close the
window, hold the switch down.
AIC630AIC0741AIC0718
MANUAL WINDOW POWER WINDOW
(If so equipped)
1-15
ZX

POWER WINDOW AUTOMATIC
SWITCH
To fully open the driver side window, com-
pletely press down the switch and release it;
it need not be held. The window automati-
cally opens all the way. To stop the window,
just press the opposite side of the switch.
A light press on the switch causes the
window to open while the switch is pressed.
WARNING
cMake sure that all passengers have
their hands, etc. inside the vehicle
before closing the windows.
cDo not leave children unattended in-
side the vehicle. They may inadvert-
ently activate switches.
Pull the lever up to unlock, then slide the
window open.
AIC0719AIC0745
REAR SLIDING WINDOW
(If so equipped)
1-16
ZX

Tilting up
Pull the handle down, then push the handle
up to the fully tilted position.
WARNING
cWhile closing the sunroof, be ex-
tremely careful not to have any part
of your body in the sunroof opening.
cDo not stand up or extend any por-
tion of your body out of the opening
while driving.cRemove water drops, snow, ice or
sand from the sunroof before
opening.
cDo not place any heavy object on the
sunroof or surrounding area.
IC1300-AIC0197
OPERA WINDOW
(If so equipped)SUNROOF
(If so equipped)
1-17
ZX

Closing
Pull the handle forward to unlock, then push
the handle up completely.
Removing the sunshade
1. Turn each knob counterclockwise while
lifting the sunshade upward.
2. Slide the shade backward to remove it.
Installing the sunshade
1. Insert two hooks on front edge of sun-
shade into holders on the roof.
2. Align two bolts on rear edge of sunshade
with lock nuts, then securely tighten the
bolts.
Do not remove or install the sunshade
while driving.
IC0198AIC0706
1-18
ZX

Removing the sunroof
1. Remove the sunshade before removing
the sunroof.
2. Tilt the roof.
3. Push the knob located on each end of the
handle and push the roof upwards to
disengage the handle linkage.
4. Pull the sunroof up from outside of the
vehicle until it is perpendicular to the roof
panel.5. Slide the sunroof to the left and remove
the roof.
Do not remove the roof while driving.
Installing the roof
1. While placing the sunroof perpendicular
to the roof panel, position the sunroof
and engage the retainer with the hinge.
2. Slide the roof to the right until the red
mark on the hinge disappears.
3. Carefully lower the panel, making sure it
is in line with the roof opening.
4. Engage the handle linkage.
Be sure the sunroof is securely in-
stalled.
SIC0072SIC0073
1-19
ZX
