1996 Mercury Sable Owner's Manuals

166 [FV40800(ALL)11/94]The Third Seat
[FV40900(ALL)04/95]
The third seat faces the back of the wagon. For
height and weight limits, see the label on the
seat cushion. When the seat is down, the back
part of your wagon has a flat surface for
carrying cargo.
[FV41000(ALL)03/92]
To open up the seat:
[FV41100(ALL)04/95]
1. Unlock the floor panel with the key.
[FV41200(ALL)11/94]
2. Use the handle to fold the floor panel
toward the front of the car.
[FV41250(ALL)04/95]
half page art:0001409-C
Opening the third seat in the rear of the wagon
File:fcfvs.ex
Update:Wed Dec 20 09:39:11 1995

167 [FV41270(ALL)04/95]
half page art:0000442-B
The third seat in a wagon
[FV41350(ALL)04/95]
3.Remove the cargo cover.The cargo cover
must be removed or the seatback cannot be
locked in the upright position.
[FV41450(ALL)11/94]
4. Lift the remote latch release on the left side
of the well and fold the remaining floor
panel toward the front of the car until it
latches. Make sure the seatback is locked in
the upright position by pushing forward and
backward on it.
File:fcfvs.ex
Update:Wed Dec 20 09:39:11 1995

168 [FV41500(ALL)03/92]To close the seat:
[FV41600(ALL)02/95]
1. Ensure that the third row safety belts are
fully stowed, and belts located in notches.
[FV41700(ALL)11/94]
2. Lift the remote latch release and push the
seat down until it latches.
[FV41800(ALL)04/95]
3. Pull up on the handle and push the floor
panel into place.
[FV41850(ALL)11/94]
RWARNING
Be sure to keep the floor panel
closed and locked at all times. If you
do not, unattended children could
possibly become trapped inside. In
addition, loose items could be
thrown around in a collision and
possibly injure someone.
File:fcfvs.ex
Update:Wed Dec 20 09:39:11 1995

169
Electronic Sound Systems
[AS10350(ALL)08/95]
full page art:0001446-B
Stereo Radio
File:fcass.ex
Update:Wed Dec 20 09:30:38 1995

170 [AS10401(ALL)08/95]
full page art:0001447-BStereo Radio with Cassette
File:fcass.ex
Update:Wed Dec 20 09:30:38 1995

171 [AS10550(ALL)08/95]
full page art:0001448-B
Stereo Cassette with CD-DJ
File:fcass.ex
Update:Wed Dec 20 09:30:38 1995

172
[AS10600(ALL)04/95]
Stereo and Stereo Cassette Radios
*
[AS10650(ALL)02/95]
Using the Controls on Your New Radio
*
[AS10700(ALL)02/95]
How to turn the radio on and off
[AS10750(ALL)04/95]
Press the ªVOL PUSH ONº button to turn the
radio on. Press again to turn off.
*
[AS10800(ALL)01/95]
How to adjust the volume
[AS10825(ALL)02/95]
Turn the ªVOL PUSH ONº knob to the right to
increase the volume and to the left to decrease
the volume. Dots illuminate in the display to
show relative volume level.
[AS10840(ALL)04/95]
NOTE: If the volume is set above a certain
level when the ignition is turned off,
the volume will come back to a
ªnominalº listening level when the
ignition is turned back on. However, if
the radio power is turned off with the
ªVOL PUSH ONº button, the volume
will not change and will remain at the
level set when the radio is turned back
on.
*
[AS11000(ALL)02/95]
Selecting the AM or FM frequency band
[AS11125(ALL)04/95]
Press the ªAMº or ªFMº button to select the
desired frequency band or to stop/store cassette
tape (when a cassette is playing). Pressing the
ªFMº button more than once will alternate
between FM1 and FM2. These functions are used
with the station memory buttons described
underHow to tune radio stations.
%*
[AS11200(ALL)01/95]
How to tune radio stations
[AS11300(ALL)04/95]
There are four ways for you to tune in a
particular station. You can manually locate the
station using the ªTUNEº button, ªSEEKº to the
station, ªSCANº to the station or select the
station by using the memory buttons. These four
methods are described below.
File:fcass.ex
Update:Wed Dec 20 09:30:38 1995

173 [AS11400(ALL)02/95]
q
Using the ªTUNEº function
[AS11525(ALL)02/95]
You can change the frequency up or down
one increment at a time by pressing and
releasing either the right (
a) or left (
b) side
of the ªTUNEº or ªTUNE/DISCº button. To
change frequencies quickly, press and hold
down either the right or left side of the
button.
*
[AS11700(ALL)02/95]
q
Using the ªSEEKº function
[AS11825(ALL)02/95]
Press the right (
a) side of the ªSEEKº
button to select the next listenable station up
the frequency band. Press the left (
b) side of
the button to select the next listenable station
down the frequency band. By pressing and
holding the button, listenable stations can be
passed over to reach the desired station.
*
[AS12200(ALL)01/95]
q
Using the ªSCANº function
*
[AS12325(ALL)04/95]
Pressing the ªSCANº button will begin the
scan mode up the frequency band, stopping
on each listenable station for approximately
five seconds. The band indicator (AM, FM1,
FM2) flashes during scan operation.
*
[AS12340(ALL)02/95]
To stop the scan mode on the presently
sampled station, press the ªSCANº button
again.
*
[AS12700(ALL)02/95]
q
Setting the Station Memory Preset buttons
*
[AS12850(ALL)02/95]
Your radio is equipped with 6 station
memory buttons. These buttons can be used
to select up to 6 preset AM stations and 12
FM stations (6 in FM1 and 6 in FM2).
File:fcass.ex
Update:Wed Dec 20 09:30:38 1995
