1996 Mercury Sable Owner's Manuals

142 [FV11150(ALL)04/95]
one third page art:0000417-DThe master controls on the driver's door
%*
[FV11201(ALL)08/95]
Your vehicle is equipped with a ªone touch
downº feature. This feature allows the driver to
fully open the driver's window by firmly
pressing the switch and then releasing. The ªone
touch downº feature can be stopped by pressing
the up or down switch again.
[FV11250(ALL)02/95]
one third page art:0000418-D
The window controls on the passenger's door
[FV11270(ALL)03/95]
Accessory Delay
[FV11290(ALL)04/95]
The power windows and moon roof (if
equipped) can be operated for 45 seconds after
the ignition has been turned to the OFF position
if the front doors have not been opened.
File:fcfvs.ex
Update:Wed Dec 20 09:39:11 1995

143
%*
[FV11301(ALL)02/95]
Moon Roof (If equipped)
[FV11351(ALL)03/95]
You can use the moon roof in your vehicle in
two ways. Move it back to open the glass panel,
or you can move it up to ventilate the vehicle.
[FV11400(ALL)02/95]
The moon roof will only operate when the
ignition is in the ON or ACC position or when
the key has been removed from the ignition and
no doors have been opened.
[FV11451(ALL)02/95]
one third page art:0000419-D
The map lamps and the switches for the moon roof
[FV11500(ALL)02/95]
The roof console SLIDE switch is used to open
and close the moon roof.
[FV11550(ALL)04/95]
Press the AUTO portion of the switch and the
roof will fully open automatically. Press the
switch again during the opening cycle and the
roof will stop at that location.
[FV11600(ALL)04/95]
To close the moon roof, press and hold the front
portion of the switch. At the fully closed
position, the motor automatically turns off.
[FV11850(ALL)02/95]
The roof console TILT switch is used to tilt the
moon roof.
[FV11900(ALL)04/95]
To tilt the moon roof into vent position from the
closed position, press the UP portion of the
switch.
File:fcfvs.ex
Update:Wed Dec 20 09:39:11 1995

144
*
[FV12000(ALL)04/95]
To close from vent position, press and hold the
DN portion of the switch.
*
[FV12100(ALL)01/95]
RWARNING
Do not let children play with the
moon roof. They may seriously hurt
themselves.
*
[FV12200(ALL)01/95]
Occasionally wiping the outside guide rail covers
of the moon roof with a clean cloth will help
keep the moon roof working properly.
[FV12300(ALL)11/94]
quarter page art:0000420-B
The moon roof
*
[FV12400(ALL)01/95]
Sliding Shade
*
[FV12500(ALL)01/95]
The moon roof has a sliding shade that you can
manually open or close to block the sun when
the glass panel is shut.
*
[FV12600(ALL)01/95]
To close the sliding shade, pull the shade toward
the front of the vehicle. The shade automatically
opens and locks when the moon roof is opened.
File:fcfvs.ex
Update:Wed Dec 20 09:39:11 1995

145
%*
[FV12700(ALL)01/95]
Seats
%*
[FV12702(ALL)04/95]
Head Restraints
*
[FV12704(ALL)02/95]
If you use them properly, head restraints are
intended to help protect your head and neck in
a collision.
*
[FV12705(ALL)04/95]
RWARNING
A head restraint helps protect you
best if you position it behind your
head and not behind your neck.
*
[FV12706(ALL)02/95]
Standard head restraints
*
[FV12708(ALL)01/95]
You can adjust the head restraints for your
comfort and protection.
[FV12714(ALL)02/95]
one third page art:0000031-E
Adjusting the standard head restraint
File:fcfvs.ex
Update:Wed Dec 20 09:39:11 1995

146
*
[FV12720(ALL)01/95]
Four-way head restraints
[FV12722(ALL)05/94]
Your vehicle may have a four-way head
restraint. It can be adjusted in four directions.
You can raise it about two inches (five cm) from
its normal position, and you can move it
forward up to 60 degrees until you reach the
desired position.
[FV12724(ALL)03/92]
one third page art:0010049-B
Adjusting the four-way head restraint
%*
[FV12900(ALL)03/95]
Manual Seats
[FV13000(ALL)04/95]
You can move the front seats forward or
backward and tilt the seatback forward or
backward.
[FV13200(ALL)04/95]
quarter page art:0000421-C
The front seat adjustment bar
File:fcfvs.ex
Update:Wed Dec 20 09:39:11 1995

147 [FV13300(ALL)04/95]
one third page art:0000422-C
The handle to recline the back of the driver's seat
*
[FV13900(ALL)01/95]
RWARNING
Never adjust the driver's seat or
seatback when the vehicle is moving.
You could lose control of the vehicle
and injure someone.
*
[FV13950(ALL)02/95]
RWARNING
Always drive and ride with your
seatback upright and the lap belt
snug across the hips to reduce the
risk of serious injury to the abdomen
or neck that could be caused by
sliding under the safety belts in a
collision.
*
[FV15650(ALL)04/95]
RWARNING
Luggage or other cargo should not be
piled higher than the seatbacks. This
will help keep items from being
thrown about and injuring people in
a collision or sudden stop.
File:fcfvs.ex
Update:Wed Dec 20 09:39:11 1995

148 %
*
[FV21900(ALL)02/95]
Power Seats (If equipped)
[FV22000(ALL)02/95]
If your vehicle has power seats, you can adjust
the driver's seat in several directions. You can
raise or lower the whole front seat, move the
seat forward or backward and tilt the front and
back of the seat up or down. If your vehicle is
equipped with power lumbar support, the
lumbar switch also lets you inflate a pad on the
seatback.
[FV22200(ALL)02/95]
half page art:0000423-D
The seat controls on the driver's seat
File:fcfvs.ex
Update:Wed Dec 20 09:39:11 1995

149 [FV22800(ALL)05/94]
Inflating the lumbar support (If equipped)
[FV22950(ALL)04/89]
To inflate the pads, press and hold the front of
the switch. To deflate the pads, press and hold
the back of the switch.
[FV23000(ALL)11/94]
one third page art:0000424-B
The seat controls for the lumbar support on the driver's
seat
%*
[FV23100(ALL)11/94]
Using the Split-Folding Rear Seat
*
[FV23125(ALL)11/94]
Your vehicle is equipped with split-folding rear
seats. One or both rear seatbacks can be folded
down to provide additional cargo space.
[FV23150(ALL)04/95]
Detach the shoulder belt from the lap belt in the
center rear seating position before folding down
the passenger side of the rear seat.
[FV23175(ALL)11/94]
To lower the rear seatback from inside the
vehicle:
[FV23225(ALL)02/95]
1. Lift the seatback release handle on the upper
outboard corner of the seatback.
[FV23250(ALL)02/95]
2. Grasp the pull tab and fold the seatback
forward until it rests on the cushion.
File:fcfvs.ex
Update:Wed Dec 20 09:39:11 1995
