1996 HONDA ODYSSEY check engine

If Your Engine Won't Start, Jump Starting

The Starter Operates Normally In this case, the starter motorsounds normal when you turn the
ignition switch to START (III), but
the engine does not run. Are you using the proper starting
procedure? Refer to Starting the
Engine on page 119 . Do you have fuel? Turn the
ignition switch to ON (II) for a
minute and watch the fuel gauge.
The low fuel level warning light may not be working, so you were
not reminded to fill the tank. There may be an electrical
problem, such as no power to the
fuel pump. Check all the fuses (see page 208).
If you find nothing wrong, you will
need a qualified technician to find
the problem. See Towing on page
213.
Jump Starting
If your car's battery has run down,
you may be able to start the engine by using a booster battery. Although
this seems like a simple procedure,
there are several precautions you should take. Follow the directions
closely.
You cannot start a Honda by pushing or pulling it. To jump start your car:
1. Open the hood and check the physical condition of the battery(see page 162 ). In very cold
weather, check the condition of the electrolyte. If it seems slushyor like ice, do not try jump starting
until it thaws.

If a battery sits in extreme cold, the
electrolyte inside can freeze.

Attempting to jump start with a frozen battery can cause it to rupture or
explode.

2. Turn off all the electrical acces- sories: heater, A/C, stereo system
lights, etc. Put the transmission in Neutral or
Park and set the parking brake.
Taking Care of the Unexpected
NOTICE

A battery can explode if you do
not follow the correct procedure,
seriously injuring anyone nearby.
Keep all sparks, open flames,
and smoking materials away
from the battery.ProCarManuals.coms t Main Menu Table of Contents

Jump Starting

3. Connect one jumper cable to the positive ( + ) terminal on the
booster battery. Connect the other
end to the positive ( + ) terminal
on your Honda's battery. 4. Connect the second jumper cable
to the negative ( — ) terminal on
the booster battery. Connect theother end to the grounding strap
as shown. Do not connect this
jumper cable to any other part of the engine.
5. If the booster battery is in another car, have an assistant start that car
and run it at a fast idle.
BOOSTER
BATTERY

6. Start your car. If the starter motor still operates slowly, check the
jumper cable connections to make sure they have good metal-to-
metal contact.
7. Once your car is running, discon- nect the negative cable from your
car, then from the booster battery.
Disconnect the positive cable from
your car, then the booster battery.

Taking Care of the UnexpectedProCarManuals.comMain Menu s t Table of Contents

If Your Engine Overheats

4. If the temperature gauge stays at the red mark, turn off the engine.
5. Wait until you see no more signs of steam or spray, then open the

hood.

6. Look for any obvious coolant leaks, such as a split radiator hose.
Everything is still extremely hot, so use caution. If you find a leak, it
must be repaired before you continue driving (see Towing on
page 213 ).
7. If you don't find an obvious leak, check the coolant level in the
radiator reserve tank (see page150 ). If the level is below the
MIN mark, add coolant to half-way
between the MIN and MAX marks.
8. If there was no coolant in the reserve tank, you may also have toadd coolant to the radiator. Let the
engine cool down until the pointer reaches the middle of the tempera-
ture gauge, or lower, before check-
ing the radiator.
9. Using gloves or a large heavy cloth, turn the radiator capcounterclockwise, without pushing
down, to the first stop. This
releases any remaining pressure in
the cooling system. After the pressure releases, push down on
the cap and turn it until it comesoff. 10.Start the engine and set the
temperature control lever tomaximum. Add coolant to the
radiator up to the base of the filler
neck. If you do not have the
proper coolant mixture available,
you can add plain water. Remember to have the coolingsystem drained and refilled with
the proper mixture as soon as you
can.

11. Put the radiator cap back on tightly. Run the engine and watch
the temperature gauge. If it goesback to the red mark, the engine
needs repair. (See Towing on
page 213.)
12.If the temperature stays normal, check the coolant level in the
radiator reserve tank. If it has gone down, add coolant to theMAX mark. Put the cap back on

tightly.

Taking Care of the Unexpected

Removing the radiator cap
while the engine is hot can
cause the coolant to spray out, seriously scalding you.
Always let the engine and radiator cool down before
removing the radiator cap.ProCarManuals.comMain Menu s t Table of Contents

Low Oil Pressure

This indicator should light when the ignition is ON (II), and go out after
the engine starts. It should nevercome on when the engine is running.
If it starts flashing, it indicates that
the oil pressure dropped very low for a moment, then recovered. If the
indicator stays on with the engine
running, it shows that the engine has
lost oil pressure and serious engine damage is possible. In either case,
you should take immediate action.
Running the engine with low oil
pressure can cause serious mechanical damage almost immediately. Turn offthe engine as soon as you can safely get
the car stopped.

1. Safely pull off the road and shut off the engine.
2. Let the car sit for a minute. Open the hood and check the oil level(see page 146). Although oil level
and oil pressure are not directly
connected, an engine that is very
low on oil can lose pressure during cornering and other driving

maneuvers.

3. If necessary, add oil to bring the level back to the full mark on thedipstick (see page 146). 4. Start the engine and watch the oil
pressure light. If the light does nogo out within ten seconds, turn of
the engine. There is a mechanical problem that needs to be repaired
before you can continue driving.
(See Towing on page 213 .)

Taking Care of the Unexpected
NOTICE

LOW OIL PRESSURE INDICATORProCarManuals.comMain Menu s t Table of Contents

Malfunction Indicator Lamp

MALFUNCTION INDICATOR LAMP

This indicator comes on for a few seconds when you turn the ignition
switch ON (II). If it comes on at any
other time, it indicates that one of
the engine's emissions control systems may have a problem. Even
though you may feel no difference in
your car's performance, it can reduce your fuel economy and cause
your car to put out excessive emissions. Continued operation may
cause serious engine damage. If this indicator light comes on, have
your car checked by the dealer as
soon as possible. Drive moderately
until the dealer has inspected the
problem. Avoid full-throttle accelera- tion and driving at high speed.
If you keep driving with the malfunc-
tion indicator lamp/check engine light
on, you can damage your car's
emission controls and engine. Those
repairs may not be covered by your
car's warranties.

Taking Care of the Unexpected NOTICEProCarManuals.comMain Menu s t Table of Contents

Fuses

ABS FUSE BOX
Cars equipped with ABS have a third
fuse box for the ABS. It is in the engine compartment on the right
side.
Checking and Replacing Fuses

If something electrical in your car
stops working, the first thing youshould check for is a blown fuse.
Determine from the chart on pages 211 and 212 , or the diagram on the
fuse box lid, which fuse or fuses control that component. Check those
fuses first, but check all the fuses
before deciding that is not the cause. Replace any blown fuses and check
the component's operation.
1. Turn the ignition switch to LOCK (0). Make sure the headlights and
all other accessories are off.
2. Remove the cover from the fuse box. 3. Check each of the large fuses in
the under-hood fuse box by
looking through the top at the wire
inside. Removing these fusesrequires a Phillips-head screw-driver.

CONTINUED

Taking Care of the Unexpected BLOWNProCarManuals.comMain Menu s t Table of Contents

Index

Accessories
Installation.................................. 115

ACCESSORY (Ignition Key
Position)........................................ 50

Adding Automatic Transmission
Fluid........................................ 155
Brake Fluid................................. 156

Engine Coolant........................... 151

Engine Oil................................... 146

Power Steering Fluid................. 157
Windshield Washer Fluid......... 154

Additional Safety Information........ 18

Door Locks................................... 19Driving with Pets......................... 19
Head Restraint Position.............. 18
Seat-back Position........................ 18

Storing Cargo Safely................... 19

Additives, Engine Oil..................... 148
Adjustments
Mirrors.......................................... 64

Head Restraints........................... 56
Seats.............................................. 54

Steering Wheel............................ 44
Airbag (SRS).................................... 12

Air Cleaner..................................... 158

Air Conditioning............................... 74
Maintenance............................... 168

Usage............................................. 74

Air Outlets (Vents).......................... 76

Air Pressure, Tires........................ 170
Alcohol and Drugs........................... 28

Alcohol in Gasoline........................ 108
Antifreeze....................................... 150

Anti-lock Brakes (ABS)
Description................................. 220

Indicator Light..................... 35, 125

Operation.................................... 125

Anti-theft Steering Column Lock.. 49

Appearance Care........................... 183

Ashtray.............................................. 69

Audio System................................... 83

Automatic Speed Control................ 48
Automatic Transmission............... 120
Capacity, Fluid........................... 218

Checking Fluid Level................ 155
Shifting........................................ 120
Shift Lever Positions................. 120
Shift Lock Release..................... 123 Battery
Charging System Light............... 34
Jump Starting............................. 200 Maintenance............................... 162

Specifications............................. 219

Before Driving............................... 107
Belts, Seat........................................... 5
Beverage Holder.............................. 66
Body Repair.................................... 189
Brakes Anti-lock System (ABS)............ 125Break-in, New Linings .............. 108

Fluid............................................ 156

Light, Burned-out...................... 179

Parking.......................................... 65

System Indicator.......................... 34
Wear Indicators......................... 124
Brakes, ABS Description................................. 220Operation.................................... 125
System Indicator.................. 35, 125
Braking System.............................. 124
CONTINUEDProCarManuals.comMain Menu s t

Index
Break-in, New Car......................... 108
Brightness Control, Instruments... 41
Brights, Headlights......................... 40
Bulb Replacement Back-up Lights........................... 179
Brake Lights............................... 179
Ceiling Light............................... 181
Front Parking Lights................. 178
Front Side Marker Lights......... 178
Headlights.................................. 177
License Plate Lights.................. 180 Specifications............................. 219
Turn Signal Lights..................... 178
Bulbs, Halogen............................... 177
Cables, Jump Starting With.......... 200
Capacities Chart............................. 218
Carbon Monoxide Hazard............ 29

Cargo, Loading............................... 116

Cassette Player Care............................................. 101
Operation.............................. 87, 99
CAUTION, Explanation of............. ii
CD Player................................. 90, 102 Center Pocket.................................. 68
Certification Label......................... 216
Chains............................................. 174
Change Oil How to......................................... 148

When to....................................... 140

Changing a Flat Tire..................... 193
Changing Engine Coolant............. 152 Charging System Indicator.... 34, 205
Checking Automatic Transmission
Fluid........................................ 155
Battery Condition...................... 162
Brake Fluid................................. 156
Drive Belts.................................. 169
Engine Coolant........................... 150
Engine Oil................................... 146
Fuses........................................... 209
Power Steering Fluid................. 157
Checklist, Before Driving............. 118
Child Safety...................................... 20 Childproof Door Locks................... 52
Cigarette Lighter............................. 69

Cleaner, Air.................................... 158

Cleaning
Aluminum Wheels..................... 185
Carpeting................................... 186

Exterior...................................... 184

Fabric......................................... 186

Interior....................................... 186

Seat Belts................................... 187

Vinyl........................................... 186
Window...................................... 187

CLEAN Light................................ 101

Clock, Setting the .........................
66

CO in the Exhaust........................
224

Cold Weather, Starting in............ 119

Compact Spare............................... 192

Consumer Information*................ 227

Controls, Instruments and.............. 33

Coolant
Adding........................................

151

Checking................................ 150

Proper Solution......................
150

Temperature Gauge.................. 38

Corrosion Protection.................... 188

Crankcase Emission Control
System........................................ 224

Cruise Control Operation............. 46
Customer Relations Office.......... 229ProCarManuals.comMain Menu s t
