1996 HONDA ODYSSEY roof

Child Safety

If a toddler seat is used in the front
passenger's seat, the vehicle seat should be moved as far back as
possible. If the passenger's bag
inflates, it could seriously hurt a
toddler who is not in the proper position or properly restrained.
We also recommend that any child who is too large to use an infant ortoddler seat ride in the second or
third seat and wear a lap/shoulder
belt properly for protection. If thechild is not large enough to wear the
lap/shoulder belt properly, you should use a booster seat.
Important Safety Reminders

Never hold a baby or child on your
lap when riding in a car. If you are
wearing your seat belt, the violent
forces created during a crash will tear the child from your arms. The child could be seriously hurt or killed.
If you are holding a child and not
wearing a seat belt in a crash, you could crush the child against the car's
interior.
Never put your seat belt over
yourself and a child. During a crash, the belt could press deep into thechild, causing serious internal

injuries.
Two children should never use the
same seat belt. If they do, they could
be very seriously injured in a crash.
If you are driving with small children
in the car, you should use thechildproof door locks to prevent
them from opening the rear doors (see page 54).
For their safety, do not leave
children alone in your car without
adult supervision.
Driver and Passenger SafetyProCarManuals.comMain Menu s t Table of Contents

Instruments and Controls

This section gives information about the controls and displays thatcontribute to the daily operation of
your Honda. All the essential controls are within easy reach.
Control Locations............................ 32
Indicator Lights................................ 33
Gauges.............................................. 37
Speedometer................................ 37

Trip Meter.................................... 37
Odometer......................................
37

Temperature Gauge................... .
38

Fuel Gauge.................................. 38

Maintenanc
e Required

Indicator...................................

38

Controls Nea r
the Steering

Wheel........................................ 39

Headlights.................................... 40
Daytime Running Lights............. 40
Instrument Panel Brightness..... 41
Turn Signals................................. 41
Windshield Wipers...................... 42
Windshield Washers................... 42 Rear Window Wiper and Washer...................................... 43

Hazard Warning........................... 43

Rear Window Defogger.............. 43
Steering Wheel Adjustment....... 44
Steering Wheel Controls................ 46 Cruise Control.............................. 46
Keys and Locks................................ 49
Keys............................................... 49
Ignition Switch............................. 49
Power Door Locks....................... 50
Remote Transmitter.................... 51Childproof Door Locks............... 52
Tailgate......................................... 52
Glove Box..................................... 53

Seats.................................................. 54
Passenger Seating....................... 54

Seat Adjustments......................... 54
Driver's Seat Power Height Adjustment............................... 55
Head Restraints........................... 56 Third Seat Access........................ 56
Removing the Second Seats in the Six-Passenger Model.... 57
Folding the Second Seats in the Seven-Passenger
Model....................................

58

Reclining th e
Second Seat.......... 59

Folding the Third Seat
in All Models............................ 60

Power Windows............................... 62

Sunroof.............................................. 63

Mirrors.............................................. 64
Adjusting the Power Mirrors..... 64

Parking Brake..................................

65

Digital Clock.................................... .
66
Beverage Holder.............................. 66
Dashboard Compartment............... 68 Center Pocket.................................. 68
Vanity Mirror................................... 68 Cigarette Lighter............................. 69
Ashtrays............................................ 69 Interior Lights.................................. 70

Ceiling Lights............................... 70

Spotlights...................................... 70
Tailgate Light............................... 71 Courtesy Lights........................... 71

Instruments and ControlsProCarManuals.comMain Menu s t

Controls Near the Steering Wheel

The two levers on the steering column contain controls for driving
features you use most often. The left lever controls the turn signals,
headlights, and high beams. The right lever controls the windshield
wipers.
The rear window defogger switch and hazard warning switch are on
the dashboard under the center air
vent.
The controls near the left air vent are for the sunroof, cruise control
and instrument panel brightness.
The lever on the underside of the steering column allows you to tilt the
steering wheel.

Instruments and Controls

HAZARD WARNING LIGHT

SHIFT LEVER
REAR WINDOW

DEFOGGER
HORN
BUTTONS

SUNROOF

SWITCH

CRUISE
CONTROL

INSTRUMENT
BRIGHTNESS
HEADLIGHTS/

TURN SIGNALS
TILT

ADJUSTMENT
WINDSHIELD

WIPERS/WASHERSProCarManuals.comMain Menu s t Table of Contents

Keys and Locks

If you use the unlock feature on the
remote transmitter, and a door or the
tailgate is not opened within 20 seconds, all doors and the tailgate
will automatically lock. The remote transmitter will not work if the key isin the ignition.

This device complies with Part 15 of the

FCC rules. Operation is subject to the

following two conditions: (1) This device

may not cause harmful interference, and
(2) this device must accept any

interference received, including
interference that may cause undesired
operation.

Changes or modifications not expressly
approved by the party responsible for
compliance should void the user's

authority to operate the equipment.
Childproof Door Locks
The childproof door locks are
designed to prevent children seated
in the rear from accidentally opening
the rear doors. Each rear door has a
lock lever near the edge. With the
lever in the LOCK position, the door cannot be opened from the inside
regardless of the position of the lock
tab. To open the door, pull the lock
tab up and use the outside door
handle.
Tailgate
Use your key to lock and unlock the
tailgate. (On the U.S. EX model, you remote transmitter will also lock andunlock the tailgate.)
To open the tailgate, pull the handle, then lift up the tailgate.

Instruments and Controls
LEVERProCarManuals.comMain Menu s t Table of Contents

Power Windows, Sunroof
The MAIN switch controls power to the passengers' windows. With this
switch off, the passengers' windowscannot be raised or lowered. The
MAIN switch does not affect thedriver's window. Keep the MAIN
switch off when you have children in
the car so they do not injure them- selves by operating the windows
unintentionally.

On some models

Use the switch on the dashboard to open and close the sunroof. The
ignition must be ON (II). Push and hold the switch to open the
sunroof. Release the switch when
the sunroof reaches the desired
position. To close the sunroof, press and hold the switch.

CONTINUED

Instruments and Controls

Sunroof

SUNROOF SWITCH

Closing a power window on a
child's hands or fingers can
cause serious injury.
Make sure your children are

away from the windows before
closing them.
ProCarManuals.coms t Main Menu Table of Contents

Sunroof, Mirrors

If you try to open the sunroof in below-
freezing temperatures, or when it is covered with snow or ice, you can
damage the sunroof panel or motor. Mirrors
Keep the inside and outside mirrors
clean and adjusted for best visibility.
Be sure to adjust the mirrors before
you start driving.
The inside mirror has day and nightpositions. The night position reduces
glare from headlights behind you.Flip the tab on the bottom edge of
the mirror to select the day or night
position.
Adjusting the Power Mirrors
Adjust the outside mirrors with theadjustment switch on the driver's
door armrest:
1. Turn the ignition switch ON (II).
2. Move the selector switch to L (driver's side) or R (passenger's

side).

Instruments and Controls

Closing the sunroof on
someone's hands or fingers can

cause serious injury.

Make sure passengers are
clear of the sunroof before

closing it.

TAB
NOTICE
SELECTOR SWITCHProCarManuals.coms t Main Menu Table of Contents

Maintenance Schedule

Your authorized Honda dealer knows your car best and can providecompetent, efficient service.
However, service at a dealer is not
mandatory to keep your warranties
in effect. Maintenance may be doneby any qualified service facility or
person who is skilled in this type ofautomotive service. Keep all thereceipts as proof of completion, and
have the person who does the workfill out the Maintenance Record.Check your warranty booklet formore information. We recommend the use of Genuine
Honda parts and fluids whenever you
have maintenance done. These are manufactured to the same high-quality standards as the originalcomponents, so you can be confidentof their perfomance and durability.
U.S. Cars: Maintenance, replacement or
repair of emission control devices
and systems may be done by anyautomotive repair establishment or individual using parts that are
"certified" to EPA standards. According to state and federal
regulations, failure to perform
maintenance on the items marked
with an asterisk (*) will not void youremissions warranties. However,
Honda recommends that all mainte-nance services be performed at the
recommended time or mileage
period to ensure long-term reliability.

MaintenanceProCarManuals.comMain Menu s t Table of Contents

Taking Care of the Unexpected

This section covers the more- common problems that motorists
experience with their cars. It gives
you information about how to safely evaluate the problem and what to do
to correct it. If the problem has stranded you on the side of the road,
you may be able to get going again. If not, you will also find instructionson getting your car towed. Compact Spare Tire....................... 192
Changing a Flat Tire..................... 193
If Your Engine Won't Start........... 199
Nothing Happens....................... 199
The Starter Operates Normally................................. 200
Jump Starting................................. 200
If Your Engine Overheats............. 202
Low Oil Pressure........................... 204
Charging System Indication......... 205
Malfunction Indicator Lamp........ 206
Closing the Sunroof....................... 207
Fuses............................................... 208
Checking and Replacing........... 209

Towing............................................ 213

Taking Care of the UnexpectedProCarManuals.comMain Menu s t
