1996 FORD PROBE park brake

38
*
[ST02400(ALL)05/95]
ON allows you to test your vehicle's warning
lights (except the brake system warning light) to
make sure they work before you start the
engine. The key returns to the ON position once
the engine is started and remains in this position
while the engine runs.
*
[ST02500(ALL)03/95]
START cranks the engine. Release the key once
the engine starts so that you do not damage the
starter. The key should return to ON when you
release it. The START position also allows you
to test the brake warning light.
*
[ST02505(ALL)09/93]
Shift-lock System
*
[ST02510(ALL)09/93]
For your safety, the optional automatic transaxle
has the shift-lock system, which prevents shifting
the transaxle out of the P (Park) position without
depressing the brake pedal when the ignition
switch is in the ON position.
*
[ST02515(ALL)07/89]
To shift the transaxle out of the P (Park)
position:
*
[ST02521(ALL)05/90]
1. Depress and hold the brake pedal.
*
[ST02526(ALL)11/93]
2. Start the engine.
[ST02528(ALL)01/94]
3. Push in the thumb button and move the
shift selector lever.
[ST02530(ALL)06/93]
4. SeeShift Lock Emergency Overridein this
section for more information.
File:prstp.ex
Update:Fri Jun 23 19:38:23 1995

39 [ST02532(ALL)06/93]
two third page art:0032064-D
Automatic console-mounted gearshift lever
*
[ST02535(ALL)09/93]
NOTE: When the ignition key is in the ACC
or LOCK position, the transaxle cannot
be shifted from the P (Park) position.
If the brake pedal is repeatedly
depressed and released when the
ignition is in the ON position and the
selector lever is in the P (Park)
position, a chattering near the gearshift
lever may be heard. This is not a
malfunction.
File:prstp.ex
Update:Fri Jun 23 19:38:23 1995

40
*
[ST02538(ALL)03/94]
NOTE: Your vehicle's gearshift lever is
securely latched in P (Park) if you
cannot move it without pushing in the
thumb button. Keep the brake pedal
depressed while moving your gearshift
lever.
*
[ST02540(ALL)09/93]
To make the system more effective, the ignition
key cannot be removed unless the gearshift
selector lever is in the P (Park) position.
[ST02545(ALL)06/93]
Shift lock emergency override
[ST02550(ALL)01/94]
If the gearshift selector lever should fail to move
from the P (Park) position with the brake pedal
depressed, continue depressing the brake pedal.
[ST02557(ALL)06/93]
1. Remove the shift lock override cover with a
screwdriver.
[ST02563(ALL)06/93]
2. Insert the screwdriver into the shift lock
override opening and push the screwdriver
handle down.
*
[ST02570(ALL)06/93]
3. Push and hold the thumb button.
[ST02600(ALL)01/94]
4. Move the shift selector lever.
*
[ST02690(ALL)06/95]
If you need to shift out of P (Park) by using the
alternate procedure described above, it is
possible that a fuse has blown and that your
brakelamps may also not be functional. Please
refer to the chapter titledServicing Your Probein
this Owner Guide for instructions on checking
and replacing fuses.
*
[ST02700(ALL)05/95]
RWARNING
DO NOT DRIVE YOUR VEHICLE UNTIL
YOU VERIFY THAT THE BRAKELAMPS
ARE WORKING.
File:prstp.ex
Update:Fri Jun 23 19:38:23 1995

41 %
*
[ST02900(ALL)02/95]
Removing the Key From the Ignition
*
[ST03000(ALL)09/93]
1. Put the gearshift selector lever in P (Park)
(automatic transaxle) or 1 (First) (manual
transaxle).
*
[ST03100(ALL)01/95]
2. Set the parking brake fully.
[ST03400(ALL)01/94]
3.For a manual transaxle:Push in on the lock
cylinder and turn the key from ACC to
LOCK.
[ST03425(ALL)01/94]
For an automatic transaxle:Turn the key to
LOCK.
*
[ST03500(ALL)03/95]
4. Remove the key.
*
[ST03600(ALL)10/90]
If the driver or passenger door is open while the
key is still in the ignition, a warning chime
sounds.
*
[ST03700(ALL)05/95]
RWARNING
Always set the parking brake fully and
make sure that the gearshift is securely
latched in P (Park) (automatic transaxle) or
in 1 (First) (manual transaxle).
*
[ST03900(ALL)01/93]
RWARNING
Do not leave children, unreliable adults,
or pets alone in your vehicle. They could
accidentally injure themselves or others
through inadvertent operation of the
vehicle. Further, on hot, sunny days,
temperatures in a closed vehicle could
quickly become high enough to cause
severe and possibly fatal injuries to
people as well as animals.
File:prstp.ex
Update:Fri Jun 23 19:38:23 1995

42
%*
[ST04100(ALL)03/95]
Fuel-Injected Engines
*
[ST04200(ALL)03/95]
When starting a fuel-injected engine,the most
important thing to remember is to avoid
pressing down on the accelerator before or
during starting. Only use the accelerator when
you have problems getting your vehicle started.
SeeStarting Your Enginein this chapter for
details about when to use the accelerator while
you start your vehicle.
*
[ST04500(ALL)03/95]
Starting Your Vehicle
%*
[ST05000(ALL)05/94]
Preparing to Start Your Vehicle
*
[ST05100(ALL)05/95]
RWARNING
Do not start your vehicle in a closed
garage or other enclosed area. Never sit in
a stopped vehicle for more than a short
period of time with the engine running.
Exhaust fumes are toxic. SeeGuarding
Against Exhaust Fumesin this chapter for
more instructions.
*
[ST05200(ALL)01/95]
Before you start your vehicle, do the following:
*
[ST05300(ALL)01/95]
1. Make sure you and all your passengers
buckle your safety belts. SeeSafety Restraints
in the Index for more details.
*
[ST05400(ALL)03/95]
2. Make sure the headlamps and other
accessories are turned off when starting.
*
[ST05500(ALL)02/92]
3.If you have an automatic transaxle, make
sure that the gearshift is in P (Park) and the
parking brake is set before you turn the key.
*
[ST05600(ALL)07/93]
If you have a manual transaxle, make sure
that the parking brake is fully set, push the
clutch pedal to the floor, and put the
gearshift into Neutral before you turn the
key.(Remember, the starter will operate
only if the clutch pedal is pushed all the
way to the floor.)
File:prstp.ex
Update:Fri Jun 23 19:38:23 1995

43
*
[ST05700(ALL)03/95]
Testing the Warning Lights
*
[ST05800(ALL)03/95]
Before you start your vehicle, you should test
the warning lights on the instrument panel to
make sure that they work. Refer to theWarning
Lights and Gaugeschapter.
*
[ST06000(ALL)02/95]
Starting Your Engine
*
[ST06100(ALL)02/95]
To start your engine:
*
[ST06300(ALL)05/95]
1. Follow the steps underPreparing to Start
Your Vehicleat the beginning of this section.
*
[ST06320(ALL)03/95]
2. Keep your foot on the brake pedal and turn
the ignition key to the ON position.
*
[ST06330(ALL)03/95]
3. DO NOT depress the accelerator pedal when
starting your engine. DO NOT use the
accelerator while the vehicle is parked.
*
[ST06340(ALL)02/95]
4. Turn the key to the START position
(cranking) until the engine starts. Allow the
key to return to the ON position after the
engine has started.
*
[ST06400(ALL)02/95]
If you have difficulty in turning the key,
rotate the steering wheel slightly because it
may be binding.
%*
[ST06430(ALL)04/95]
For a cold engine:
*
[ST06440(ALL)05/95]
q
At temperatures10ÊF (-12ÊC) andbelow:If
the engine does not start infifteen (15)
secondson the first try, turn the key to OFF,
wait approximately ten (10) seconds so you
do not flood the engine, then try again.
*
[ST06450(ALL)04/95]
q
At temperaturesabove10ÊF(-12ÊC):If the
engine does not start infive (5) secondson
the first try, turn the key to OFF, wait
approximately ten (10) seconds so you do not
flood the engine, then try again.
File:prstp.ex
Update:Fri Jun 23 19:38:23 1995

44 %
*
[ST06460(ALL)05/95]
For a warm engine:
*
[ST06470(ALL)04/95]
q
Do not hold the key in the START position
for more thanfive (5) secondsat a time. If
the engine does not start within five (5)
seconds on the first try, turn the key to the
OFF position. Wait a few seconds after the
starter stops, then try again.
*
[ST06480(ALL)05/95]
Whenever you start your vehicle, release the key
as soon as the engine starts. Excessive cranking
could damage the starter or flood the engine.
*
[ST06490(ALL)05/95]
After you start the engine, let it idle for a few
seconds. Keep your foot on the brake pedal and
put the gearshift lever in gear. Release the
parking brake. Slowly release the brake pedal
and drive away in the normal manner.
*
[ST06500(ALL)05/95]
NOTE: Your vehicle is equipped with an
automatic transaxle that has an
interlock that prevents you from
shifting out of P (Park) unless your
foot is on the brake pedal.
%*
[ST06510(ALL)04/95]
If the engine does not start after two attempts:
*
[ST06520(ALL)04/95]
1. Turn the ignition key to the OFF position.
*
[ST06530(ALL)04/95]
2. Press the accelerator all the way to the floor
and hold it.
*
[ST06540(ALL)04/95]
3. Turn the ignition key to the START position.
*
[ST06550(ALL)04/95]
4. Release the ignition key when the engine
starts.
*
[ST06560(ALL)04/95]
5. Release the accelerator gradually as the
engine speeds up. Then drive away in the
normal manner.
*
[ST06570(ALL)04/95]
If the engine still does not start, the fuel pump
shut-off switch may have been triggered. For
directions on how to reset the switch seeFuel
Pump Shut-Off Switchlater in this chapter.
File:prstp.ex
Update:Fri Jun 23 19:38:23 1995

56 [LG02350(ALL)01/94]This light should come on as you start the
vehicle. If it doesn't come on then, have it fixed
so it will be ready to warn you if there's a
problem.
[LG02550(ALL)06/93]
one inch art:0030319-E
Brake system and parking brake light
[LG02600(ALL)01/93]
This light comes on briefly when you turn the
ignition key to START. It normally goes off
shortly after the engine starts and you release
the parking brake, but it may stay on for up to
60 seconds. If the light stays on for longer than
60 seconds or comes on after you have fully
released the parking brake, have the hydraulic
brake system serviced.
*
[LG02650(ALL)02/94]
This light will also come on if the parking brake
does not release fully. If it does stay onafterthe
parking brake is fully released, it means there
may be a brake problem. Pull off the road and
stop carefully. You may notice that the pedal is
harder to push, the pedal may go closer to the
floor, or it may take longer to stop the vehicle.
Try the brakes again after you have stopped.
*
[LG02700(ALL)05/95]
RWARNING
The BRAKE light indicates that the brakes
may not be working properly. Have the
brakes checked immediately.
File:prlgp.ex
Update:Fri Jun 23 19:38:06 1995
