1996 FORD PROBE door lock

10
*
[SR02200(ALL)05/95]
RWARNING
Never wear the shoulder belt under the
arm. Never swing it around the neck over
the inside shoulder. Never use a single
belt for more than one person or across
more than one seating position. Each
seating position in your vehicle has a
specific safety belt assembly which is
made up of one buckle and one tongue
that are designed to be used as a pair.
Failure to follow these precautions could
increase the risk and/or severity of injury
in a collision.
*
[SR02550(ALL)05/95]
RWARNING
Ford recommends that all safety belt
assemblies and attaching hardware should
be inspected by a qualified technician
after any collision. Safety belt assemblies
not in use during a collision should also
be inspected and replaced if either
damage or improper operation is noted.
*
[SR02800(ALL)05/95]
RWARNING
To reduce the risk of serious injury in a
collision, children should always ride with
the seatback upright.
*
[SR02850(ALL)05/95]
RWARNING
Never let a passenger hold a child on his
or her lap while the vehicle is moving.
The passenger cannot protect the child
from injury in a collision.
*
[SR02875(ALL)05/95]
Lock the doors of your vehicle before driving to
lessen the risk of the door coming open in a
collision.
File:prsrp.ex
Update:Fri Jun 23 19:39:12 1995

11
*
[SR03475(ALL)05/95]
Combination Lap and Shoulder
Belts
*
[SR03500(ALL)05/95]
While your vehicle is in motion, the combination
lap and shoulder belt adjusts to your movement.
However, if you brake hard, turn hard, or if
your vehicle receives an impact of 5 mph
(8 km/h) or more, the lap and shoulder belt
locks and helps reduce your forward movement.
*
[SR03600(ALL)05/94]
After you get into your vehicle, close the door
and lock it. Then adjust the driver or passenger
seat to the position that suits you best.
*
[SR03700(ALL)05/95]
Pull the combination lap/shoulder belt from the
retractor so that the shoulder portion of the belt
crosses your shoulder and chest. Be sure the belt
is not twisted. If it is, remove the twist. Insert
the belt tongue into the proper buckle until you
hear a snap and feel it latch. Make sure the
tongue is securely fastened to the buckle by
pulling on tongue.
[SR03800(ALL)05/95]
one third page art:0030008-B
Fastening the front seat combination lap and shoulder belt
*
[SR03810(ALL)05/95]
NOTE: Be sure to read and understand
Important Safety Belt Informationat
the beginning of this chapter.
File:prsrp.ex
Update:Fri Jun 23 19:39:12 1995

41 %
*
[ST02900(ALL)02/95]
Removing the Key From the Ignition
*
[ST03000(ALL)09/93]
1. Put the gearshift selector lever in P (Park)
(automatic transaxle) or 1 (First) (manual
transaxle).
*
[ST03100(ALL)01/95]
2. Set the parking brake fully.
[ST03400(ALL)01/94]
3.For a manual transaxle:Push in on the lock
cylinder and turn the key from ACC to
LOCK.
[ST03425(ALL)01/94]
For an automatic transaxle:Turn the key to
LOCK.
*
[ST03500(ALL)03/95]
4. Remove the key.
*
[ST03600(ALL)10/90]
If the driver or passenger door is open while the
key is still in the ignition, a warning chime
sounds.
*
[ST03700(ALL)05/95]
RWARNING
Always set the parking brake fully and
make sure that the gearshift is securely
latched in P (Park) (automatic transaxle) or
in 1 (First) (manual transaxle).
*
[ST03900(ALL)01/93]
RWARNING
Do not leave children, unreliable adults,
or pets alone in your vehicle. They could
accidentally injure themselves or others
through inadvertent operation of the
vehicle. Further, on hot, sunny days,
temperatures in a closed vehicle could
quickly become high enough to cause
severe and possibly fatal injuries to
people as well as animals.
File:prstp.ex
Update:Fri Jun 23 19:38:23 1995

95
Features
*
[FV00250(ALL)02/95]
Your vehicle has a variety of features designed
for your comfort, convenience and safety. Read
this chapter to find out about standard and
optional features.
*
[FV00400(ALL)01/95]
Doors
[FV00700(ALL)04/95]
quarter page art:0030072-C
The outside of the door
[FV00800(ALL)06/94]
one third page art:0030073-C
The inside of the door
[FV00900(ALL)01/89]
If you close the door with the lock button
depressed, the door will remain locked.
File:prfvp.ex
Update:Fri Jun 23 19:36:28 1995

96
*
[FV02400(ALL)04/95]
Power Door Locks (If equipped)
[FV02500(ALL)01/94]
If your vehicle has power door locks, the
controls to lock the doors are below the inside
door handles on each door. When you close the
doors after you set the door locks, the doors
remain locked. If the power mechanism ever
fails, the manual door locks will override the
power controls.
[FV02550(ALL)02/92]
NOTE: Vehicles equipped with power locks
have a safety feature which allows you
to unlock one or both front doors from
either door key lock cylinder. To
unlock the driver's or passenger door
only, insert the key in the door lock
cylinder and turn to the left
(counterclockwise) to the first position.
To unlock the other door at the same
time, simply continue turning the key
to the left to the second position. Both
doors are locked by turning the key to
the right (clockwise).
File:prfvp.ex
Update:Fri Jun 23 19:36:28 1995

97 [FV02600(ALL)06/94]
half page art:0030079-C
Power locks on the driver's door
[FV02920(ALL)08/91]
Remote Keyless Entry System
(If equipped)
[FV02940(ALL)01/94]
Your vehicle may be equipped with a remote
keyless entry system. This option will allow you
to open your vehicle using a remote transmitter
from distances of up to 33 feet (10 meters) away.
The remote feature will operate only when the
ignition is in the OFF position.
[FV02950(ALL)06/94]
The transmitter can unlock the driver's door,
unlock all doors, lock all doors, or activate the
vehicle's horn and hazard warning lamps for the
panic alarm feature.
[FV02960(ALL)05/95]
By pressing the UNLOCK button on the
transmitter once, you can unlock the driver side
door. Pressing the UNLOCK button a second
time within five seconds of unlocking the
driver's door will unlock the other doors.
File:prfvp.ex
Update:Fri Jun 23 19:36:28 1995

98 [FV02970(ALL)05/95]You can lock all your vehicle doors by pressing
the LOCK button. If you press the LOCK button
a second time within five (5) seconds, the horn
will sound briefly to verify that the doors have
been locked.
[FV02990(ALL)06/94]
When the PANIC button is pressed, the horn
will sound and the hazard warning lamps will
flash. This will continue for up to approximately
two minutes and 45 seconds unless it is turned
off by pressing the PANIC button a second time.
The panic mode can also be cancelled by turning
the ignition key to ON or ACC.
[FV03000(ALL)05/95]
Up to four transmitters can be programmed for
your vehicle. Your vehicle comes with two
transmitters. Additional transmitters can be
ordered from your dealer.
[FV03050(ALL)01/95]
one third page art:0032046-C
Remote keyless entry transmitter
[FV03052(ALL)06/95]
The remote keyless entry system is equipped
with an illuminated entry system. This system is
activated by opening the door.
[FV03054(ALL)06/95]
When the system is activated, the dome lamp
will illuminate, and will stay lit for
approximately 25 seconds. The dome lamp will
shut off when the doors are closed.
File:prfvp.ex
Update:Fri Jun 23 19:36:28 1995

115
*
[FV24500(ALL)01/95]
Storage Compartments
*
[FV24600(ALL)01/95]
Your vehicle may have several small storage
compartments:
[FV24700(ALL)08/91]
q
a glove compartment that locks and unlocks
using the ignition key
*
[FV24800(ALL)09/93]
q
two map pockets on the door panels (if
equipped)
[FV24825(ALL)03/94]
q
storage compartment below the climate
controls
*
[FV25550(ALL)11/91]
q
a storage bin in the center console
*
[FV25600(ALL)05/95]
RWARNING
Do not put objects on the ledge between
the back seat and the rear window, as
they can become dangerous projectiles and
injure someone.
[FV25900(ALL)01/92]
Center Console Storage (If equipped)
[FV25950(ALL)04/93]
To open the center console storage bin, push the
button and slide the lid back. When it is back as
far as it will go, push the button and lift the lid.
[FV25955(ALL)06/94]
Cupholders
[FV25960(ALL)06/94]
The cupholders are located inside the center
console storage bin. The driver cupholder is
integrated in the storage bin. To use the
passenger cupholder, rotate it upward then twist
the cupholder until it is in a horizontal position.
When the passenger cupholder is not in use,
twist it back to the vertical position and rotate it
into the storage bin.
*
[FV25970(ALL)06/94]
NOTE: Do not place heavy objects in the
cupholders.
File:prfvp.ex
Update:Fri Jun 23 19:36:28 1995
