1996 FORD PROBE wheel

18
*
[SR14952(ALL)05/95]
THE FORCE OF THE RAPIDLY INFLATING
PASSENGER AIR BAG COULD PUSH THE TOP
OF THE REAR-FACING SEAT AGAINST THE
VEHICLE SEATBACK, ARMRESTS OR
CONSOLE. REAR-FACING INFANT SEATS
MUST ALWAYS BE SECURED IN THE REAR
SEAT.
*
[SR14960(ALL)05/95]
RWARNING
Do not place objects or mount equipment
on or near the air bag cover on the
steering wheel or in front seat areas that
may come in contact with a deploying air
bag. Failure to follow this instruction may
increase the risk of personal injury in the
event of a collision.
*
[SR14980(ALL)05/95]
For additional important safety information on
the proper use of seat belts, child seats, and
infant seats, please read the other sections of this
part of the Owner Guide, especially sections
entitledSafety Belts for ChildrenandSafety Seats
for Children.
*
[SR15000(ALL)01/95]
How the Air Bag Supplemental Restraint
System Operates
*
[SR15005(ALL)06/95]
The Air Bag Supplemental Restraint System
consists of the driver and passenger air bags,
impact sensors, a system diagnostic module, a
readiness light and tone, and the electrical
wiring which connects the components.
*
[SR15008(ALL)05/95]
The driver air bag is in the center of the steering
wheel. The front passenger seat air bag is
located in the center of the instrument panel
ledge above the glove compartment. Both air
bags are designed to stay out of sight until they
are activated.
File:prsrp.ex
Update:Fri Jun 23 19:39:12 1995

37
Starting Your Probe
*
[ST01700(ALL)03/95]
Ignition
*
[ST01800(ALL)01/95]
Understanding the Positions of the Ignition
[ST02050(ALL)01/92]
one third page art:0032054-A
Ignition lock cylinder
*
[ST02100(ALL)09/93]
LOCK locks the steering wheel. It also locks the
gearshift lever in P (Park) (automatic transaxle).
*
[ST02200(ALL)01/95]
LOCK is the only position that allows you to
remove the key. The LOCK feature helps to
protect your vehicle from theft.
[ST02250(ALL)08/91]
To remove the key if you have a manual
transaxle, push the key in while turning it to the
LOCK position.
*
[ST02300(ALL)05/95]
If your key is stuck in the LOCK position and
will not turn, move your steering wheel left or
right until the key turns freely.
[ST02350(ALL)01/94]
ACC (Accessory) allows some of your vehicle's
electrical accessories to operate while the engine
is not running.
File:prstp.ex
Update:Fri Jun 23 19:38:23 1995

43
*
[ST05700(ALL)03/95]
Testing the Warning Lights
*
[ST05800(ALL)03/95]
Before you start your vehicle, you should test
the warning lights on the instrument panel to
make sure that they work. Refer to theWarning
Lights and Gaugeschapter.
*
[ST06000(ALL)02/95]
Starting Your Engine
*
[ST06100(ALL)02/95]
To start your engine:
*
[ST06300(ALL)05/95]
1. Follow the steps underPreparing to Start
Your Vehicleat the beginning of this section.
*
[ST06320(ALL)03/95]
2. Keep your foot on the brake pedal and turn
the ignition key to the ON position.
*
[ST06330(ALL)03/95]
3. DO NOT depress the accelerator pedal when
starting your engine. DO NOT use the
accelerator while the vehicle is parked.
*
[ST06340(ALL)02/95]
4. Turn the key to the START position
(cranking) until the engine starts. Allow the
key to return to the ON position after the
engine has started.
*
[ST06400(ALL)02/95]
If you have difficulty in turning the key,
rotate the steering wheel slightly because it
may be binding.
%*
[ST06430(ALL)04/95]
For a cold engine:
*
[ST06440(ALL)05/95]
q
At temperatures10ÊF (-12ÊC) andbelow:If
the engine does not start infifteen (15)
secondson the first try, turn the key to OFF,
wait approximately ten (10) seconds so you
do not flood the engine, then try again.
*
[ST06450(ALL)04/95]
q
At temperaturesabove10ÊF(-12ÊC):If the
engine does not start infive (5) secondson
the first try, turn the key to OFF, wait
approximately ten (10) seconds so you do not
flood the engine, then try again.
File:prstp.ex
Update:Fri Jun 23 19:38:23 1995

72
*
[IP14300(ALL)02/95]
To defrost the rear window:
*
[IP14400(ALL)02/95]
1. Clear any snow from the rear window.
*
[IP14500(ALL)09/93]
2. Get in your vehicle and start the engine.
[IP14600(ALL)03/91]
3. Press the rear defrost button. The indicator
light turns on.
[IP14800(ALL)01/92]
The defroster turns off automatically after 15 to
25 minutes. If the window is not clear, turn on
the defroster again. It will also automatically
shut off any time the engine is shut off.
%*
[IP14900(ALL)03/94]
NOTE: Never use sharp instruments or
window cleaners with abrasives to
clean the inside of your rear window.
If you do, you may damage the heating
elements that are bonded to the inside
of the rear window and cause damage
to the rear window defroster.
*
[IP17700(ALL)01/92]
Interior Lights
*
[IP20500(ALL)01/95]
Lighting Up the Interior and Instrument
Panel
*
[IP20600(ALL)01/92]
With the parking lamps or headlamps on, the
brightness of the instrument panel lighting can
be adjusted.
*
[IP20700(ALL)09/93]
To brighten or dim the instrument panel
lighting, rotate the dimmer control thumbwheel
as desired.
[IP20800(ALL)01/94]
quarter page art:0030050-B
Dimmer control thumbwheel
File:pripp.ex
Update:Fri Jun 23 19:37:35 1995

73 [IP20900(ALL)01/94]
The dimmer control thumbwheel is located to
the left of the steering wheel on the instrument
panel.
[IP21800(ALL)02/91]
Dome Lamp
[IP22950(ALL)05/95]
The dome lamp illuminates whenever one of the
front doors is opened and turns off
automatically when the doors are closed. You
may turn the dome lamp on and off while the
doors are closed by using the ON/OFF switch
located on the interior/map lamp control panel.
[IP23100(ALL)05/95]
half page art:0030286-L
Interior/map lamp control panel
[IP23125(ALL)04/95]
Map lamps (if equipped)
[IP23150(ALL)01/95]
The map lamps can be turned on by using the
interior/map lamp control panel located between
the sun visors.
[IP23200(ALL)01/95]
There are two map lamps, one for the driver
and one for the passenger. To turn on the map
lamp, push the button that is next to the lamp.
File:pripp.ex
Update:Fri Jun 23 19:37:35 1995

77
Steering Column Controls
*
[SC00300(ALL)01/95]
The controls on the steering column and wheel
are designed to give you easy access to the
controls while you are driving.
*
[SC00400(ALL)01/95]
The Turn Signal Lever
*
[SC00500(ALL)01/95]
You can use the turn signal lever on the left side
of the steering column to:
*
[SC00600(ALL)08/91]
q
operate the headlamps and parking lamps
*
[SC00700(ALL)03/95]
q
operate the turn signals and cornering lamps
*
[SC00800(ALL)01/95]
q
turn the high beams on/off
*
[SC00900(ALL)05/95]
q
flash the lamps
*
[SC00950(ALL)08/91]
Headlamps and Parking Lamps
*
[SC00975(ALL)01/92]
To turn the parking lamps or headlamps on,
twist the knob at the end of the turn signal
lever.
[SC01000(ALL)05/95]
FIRST STOP Ð Turning the knob to the first
stop (g) will turn on the the license plate
lamps, parking lamps, side marker lamps, tail
lamps and instrument panel lamps.
[SC01050(ALL)05/95]
SECOND STOP Ð Turning the knob to the
second stop (B) will turn on the headlamps,
license plate lamps, parking lamps, side marker
lamps, tail lamps and instrument panel lamps.
File:prscp.ex
Update:Fri Jun 23 19:37:07 1995

87
*
[SC05000(ALL)01/95]
Horn
*
[SC05200(ALL)08/91]
To sound the horn, push the horn button on
either side of the steering wheel. Check the horn
regularly to be sure it operates properly.
[SC05450(ALL)08/91]
half page art:0032036-A
Using the horn
File:prscp.ex
Update:Fri Jun 23 19:37:07 1995

88
*
[SC05500(ALL)10/91]
Tilt Steering Column
(If equipped)
*
[SC05510(ALL)04/95]
RWARNING
Never adjust the steering column/wheel
when the vehicle is moving. You could
lose control of the vehicle and injure
someone.
*
[SC05520(ALL)04/95]
To change the position of the steering
column/wheel, pull the release lever on the
column toward you. Tip the steering wheel to
the desired position. Release the lever to lock the
steering wheel in place.
[SC05900(ALL)08/91]
half page art:0032044-A
Tilt steering column
File:prscp.ex
Update:Fri Jun 23 19:37:07 1995
