1996 FORD PROBE engine

62
*
[LG07250(ALL)03/95]
For instructions on checking and adding coolant
to your engine, seeEngine coolantin the Index. If
you do not follow these instructions, you or
others could be injured.
*
[LG07300(ALL)05/92]
5. Add as much coolant as your engine needs.
If the engine continues to overheat, have the
coolant system serviced.
*
[LG07500(ALL)01/95]
Speedometer
*
[LG07600(ALL)01/95]
The speedometer tells you how many miles
(kilometers) per hour your vehicle is moving.
*
[LG07700(ALL)01/95]
Odometer
*
[LG07800(ALL)01/95]
The odometer tells you the total number of miles
(kilometers) your vehicle has been driven.
*
[LG08000(ALL)11/94]
Trip Odometer
[LG08050(ALL)01/95]
Use the trip odometer to track your mileage.
Simply set the trip odometer to zero by pressing
the reset button.
*
[LG09000(ALL)02/95]
Tachometer
[LG09001(ALL)01/95]
The tachometer indicates approximate engine
revolutions per minute, and is located on the
right-hand side of the instrument cluster. The
tachometer pointer may move slightly when the
key is placed in the ACC or ON position, with
the engine off. This pointer movement is normal,
and will not affect the accuracy of the
tachometer once the engine is running.
File:prlgp.ex
Update:Fri Jun 23 19:38:06 1995

69
*
[IP06950(ALL)01/95]
Sometimes you may notice slight engine surging
if you have the air conditioner on. This is
normal, as the system is designed to cycle the
compressor on and off to maintain desired
cooling. The reduced compressor operation
should benefit fuel economy.
*
[IP07000(ALL)01/95]
On some vehicles with air conditioning,
wide-open throttle acceleration will temporarily
cut off the air conditioning.
*
[IP07050(ALL)01/95]
Since the air conditioner removes a lot of
moisture from the air during operation, it is
normal for water to drip on the pavement under
the air conditioner drain after you have stopped
the vehicle.
[IP07150(ALL)08/91]
Action for heating and windshield defrosting are
identical for cars equipped with either the
Heating Only Systemor theHeating and Air
Conditioning System. For instructions about these
functions, see the previous section,Heating Only
System. For instructions about using the air
conditioning, see the following sections.
[IP07350(ALL)01/95]
MAX A/C
[IP07360(ALL)01/95]
When MAX A/C is selected, cooled interior air
is recirculated through the system. This position
is more efficient than NORM A/C.
*
[IP07375(ALL)09/93]
To cool your vehicle quickly in warm weather:
[IP07400(ALL)08/91]
1. Turn the function selector control to MAX
A/C.
[IP07450(ALL)08/91]
2. Turn the temperature control to the blue
(cool) area.
[IP07475(ALL)08/91]
3. Set the fan at the desired speed.
*
[IP07500(ALL)09/93]
If the inside of your vehicle is very warm,
drive for a few minutes with the windows
down. This forces most of the hot, stale air
out of the vehicle and helps the air
conditioning cool the vehicle faster.
File:pripp.ex
Update:Fri Jun 23 19:37:35 1995

71
*
[IP13850(ALL)02/91]
Engine Idle Speed Control System
*
[IP13875(ALL)02/91]
Genuine Ford air conditioning (either
factory-installed or dealer-installed) has an
engine idle speed control system that
compensates for engine speed loss that may
occur when the air conditioning compressor is
running. This idle speed control holds the engine
idle essentially constant, regardless of whether
the air conditioning system is on or off.
[IP13890(ALL)01/95]
NOTE: Whenever service to the air
conditioning system is required, make
sure the service facility uses a
refrigerant recycling system. These
systems will capture the refrigerant for
reuse. Releasing certain refrigerants
into the atmosphere is hazardous to the
environment.
*
[IP13900(ALL)12/93]
Rear Window Defroster (If equipped)
(Standard in Canada)
[IP14000(ALL)06/94]
quarter page art:0032068-D
Rear window defroster button
[IP14200(ALL)01/95]
The defroster for the rear window clears frost,
fog, or thin ice from both the inside and outside
of the rear window. The rear window defroster
button is located on the lower right of the
instrument panel below the climate control
panel. This button is also used to activate your
heated power mirrors (if equipped).
File:pripp.ex
Update:Fri Jun 23 19:37:35 1995

72
*
[IP14300(ALL)02/95]
To defrost the rear window:
*
[IP14400(ALL)02/95]
1. Clear any snow from the rear window.
*
[IP14500(ALL)09/93]
2. Get in your vehicle and start the engine.
[IP14600(ALL)03/91]
3. Press the rear defrost button. The indicator
light turns on.
[IP14800(ALL)01/92]
The defroster turns off automatically after 15 to
25 minutes. If the window is not clear, turn on
the defroster again. It will also automatically
shut off any time the engine is shut off.
%*
[IP14900(ALL)03/94]
NOTE: Never use sharp instruments or
window cleaners with abrasives to
clean the inside of your rear window.
If you do, you may damage the heating
elements that are bonded to the inside
of the rear window and cause damage
to the rear window defroster.
*
[IP17700(ALL)01/92]
Interior Lights
*
[IP20500(ALL)01/95]
Lighting Up the Interior and Instrument
Panel
*
[IP20600(ALL)01/92]
With the parking lamps or headlamps on, the
brightness of the instrument panel lighting can
be adjusted.
*
[IP20700(ALL)09/93]
To brighten or dim the instrument panel
lighting, rotate the dimmer control thumbwheel
as desired.
[IP20800(ALL)01/94]
quarter page art:0030050-B
Dimmer control thumbwheel
File:pripp.ex
Update:Fri Jun 23 19:37:35 1995

82 [SC02475(ALL)04/95]If the flashers run for longer than 2 hours while
your engine is not running, or if your battery is
not fully charged, your battery could be drained.
[SC02500(ALL)08/91]
half page art:0032030-A
Hazard warning flasher switch
File:prscp.ex
Update:Fri Jun 23 19:37:07 1995

110 [FV14600(ALL)01/89]Your seat cushion power adjust lever is operated
by a motor. To avoid damage to the motor, you
should avoid operating this feature for an
extended period of time. You should also avoid
using the six-way power adjust lever
continuously with the engine stopped. This
could run down the battery.
[FV14700(ALL)02/92]
Use the lever to make only one adjustment at a
time.
*
[FV14800(ALL)11/94]
Using the Split-Folding Rear Seat
*
[FV14900(ALL)11/94]
Your vehicle is equipped with split-folding rear
seats. One or both rear seatbacks can be folded
down to provide additional cargo space.
[FV14950(ALL)02/92]
NOTE: When folding down the rear seatback,
the seat belt tongue should be hanging
on the hook of the lower, side trim
panel, near the edge of the side of the
seat cushion.
File:prfvp.ex
Update:Fri Jun 23 19:36:28 1995

148 [DR02205(ALL)06/93]
two third page art:0032064-DAutomatic shift lever
*
[DR02400(ALL)03/94]
Your automatic transaxle vehicle has a
console-mounted shift selector lever. You must
step on the brake pedal, start the engine, and
then push in the thumb button to move the shift
selector lever to the position you choose.
*
[DR02500(ALL)05/95]
RWARNING
Hold the brake pedal down while you
move the gearshift lever from position to
position. If you do not hold the brake
pedal down, your vehicle may move
unexpectedly and injure someone.
File:prdrp.ex
Update:Fri Jun 23 19:35:02 1995

151 [DR03700(ALL)05/93]
When to use Drive (D with Overdrive OFF)
[DR03800(ALL)05/95]
In Drive (Overdrive OFF), your vehicle
automatically upshifts or downshifts from 1st
through 4th gears as the vehicle speeds up or
slows down. It also downshifts when you need
extra acceleration to pass or when driving up a
hill.
[DR03900(ALL)01/94]
Selecting Drive (Overdrive OFF) will eliminate
the transaxle's tendency to ªhuntº between third
and fourth gears while driving over hilly terrain.
It also gives your vehicle more engine braking to
slow your vehicle than Overdrive does.
*
[DR03925(ALL)01/93]
When to use Second (2)
[DR03935(ALL)01/94]
Use Second (2) to help drive up moderately
steep hills or when starting on slick surfaces. It
prevents the transaxle from frequently shifting
up and down. It also gives more engine braking
than Overdrive or Drive when going down hills.
[DR03940(ALL)06/93]
Do not go faster than 64 mph (102 km/h) with
the gearshift in the Second (2) position. If you
shift from Overdrive or Drive to Second because
of hilly terrain, your transaxle will automatically
downshift in the proper sequence.
*
[DR04005(ALL)12/93]
When to use First (1)
[DR04100(ALL)01/94]
When your vehicle is in First (1), it gives more
engine braking to slow your car than Drive (D
with Overdrive OFF) on downgrades.
[DR04200(ALL)05/95]
Do not go faster than 32 mph (50 km/h) in this
gear. You can upshift from First (1) into D
Position at any speed. If you shift from
Overdrive or Drive to First (1) because of hilly
terrain, your transaxle will automatically
downshift in the proper sequence.
