1996 FORD MUSTANG light

159
*
[AS39300(M )10/95]
How to eject the disc
*
[AS39310(M )06/95]
Push the ªEJECTº button in the upper left
corner of your CD player to stop play, eject the
disc and resume radio or tape operation of your
audio system.
%*
[AS41201(M )08/95]
How To Take Care of and Clean Your CD
Player and Discs
*
[AS41301(M )08/95]
To ensure the continued performance of your
Ford Compact Disc Player, carefully read the
following precautions:
*
[AS41401(M )08/95]
q
Always handle the disc by its edge. Never
touch the playing surface.
*
[AS41501(M )08/95]
q
Before playing, inspect the disc for any
contamination. If needed, clean the disc with
an approved disc cleaner, such as the
DiscwasherHCompact Disc Cleaner or the
Allsop 3HCompact Disc Cleaner, by wiping
from the center out to the edges.Do not use
a circular motion to clean.
*
[AS41601(M )08/95]
q
Do not clean discs with solvents such as
benzine, thinner, commercially available
cleaners or antistatic spray intended for
analog records.
*
[AS41701(M )08/95]
q
Do not expose the disc to direct sunlight or
heat sources such as defroster and floor
heating ducts. Do not leave any discs in a
parked car in direct sunlight where there may
be a considerable rise in temperature or
damage may result.
*
[AS41801(M )08/95]
q
After playing, store the disc in its case.
*
[AS41901(M )08/95]
q
If a disc has already been inserted, do not try
to insert another disc. Doing so may damage
the disc player.
*
[AS42001(M )08/95]
q
Do not insert anything other than a disc into
the disc player.
File:09rcasm.ex
Update:Wed Mar 27 09:33:20 1996

168
*
[AS44010(MBC )10/95]
q
Adjusting speaker fader
*
[AS44020(MBC )06/95]
Fade control allows you to adjust the sound
distribution between the front and rear
speakers. Push the ªAUDIOº button
repeatedly until the display reads ªFADE.º
Push the right (+) side of the ªVOLUMEº
button to shift the sound to the front
speakers, and push the left (s) side to shift
the sound to the rear speakers.
*
[AS44030(MBC )10/95]
NOTE: Illuminated bars in the display show
relative levels of bass and treble, and
positions of speaker balance and fader
functions (left to right, front to rear).
%*
[AS44040(MBC )08/95]
Using the Controls of Your Cassette Tape
Player
*
[AS44050(MBC )09/95]
NOTE: Radio power must be on to use the
cassette tape player or eject a tape.
[AS44060(MBC )04/95]
NOTE: Adjust the volume, treble, bass, balance
and fader controls in the same manner
as for radio stations.
*
[AS44070(MBC )08/95]
How to insert a tape
*
[AS44080(MBC )08/95]
Your cassette tape player is equipped with
power loading. Once you insert a tape and push
slightly (with theopen edge to the right), the
loading mechanism draws the tape the rest of
the way in and play will begin after a
momentary tape tightening process. Display
indicates ªMº (for metal/CrO
2) while tape is
playing.
*
[AS44090(MBC )09/95]
NOTE: A cassette tape can be loaded and
stored with the ignition and radio
power off.
File:09rcasm.ex
Update:Wed Mar 27 09:33:20 1996

172
*
[AS44530(MBC )08/95]
Error 2Ð Tape eject or load failure. Your
cassette tape player will go into the pause mode.
Push ªEJCTº to eject the tape. If the tape doesn't
eject, refer the problem to qualified personnel for
service.
*
[AS44540(MBC )08/95]
Tips on Caring for the Cassette Player and
Tapes
*
[AS44550(MBC )08/95]
In order to keep your cassette tape player
performing the way it was meant to, read and
follow these simple precautions:
*
[AS44560(MBC )08/95]
q
Using a Ford Cassette Cleaning Cartridge to
clean the tape player head after 10-12 hours
of play will help maintain the best playback
sound and proper tape operation.
*
[AS44570(MBC )08/95]
q
Only cassettes that are 90 minutes long or
less should be used. Tapes longer than 90
minutes are thinner and subject to breakage
or may jam the tape player mechanism.
*
[AS44580(MBC )08/95]
q
Protect cassettes from exposure to direct
sunlight, high humidity and extreme heat or
cold. If they are exposed to extreme
conditions, allow them to reach a moderate
temperature before playing.
*
[AS44590(MBC )08/95]
q
Loose labels on cassette tapes can become
lodged in the mechanism. Remove any loose
label material before inserting cassette.
*
[AS44600(MBC )08/95]
q
Do not leave a tape in the cassette tape
player. High heat in the vehicle can cause the
cassette to warp.
File:09rcasm.ex
Update:Wed Mar 27 09:33:20 1996

174
*
[AS61900( ALL)08/95]
To minimize these conditions, a stereo/mono
blend circuit has been incorporated into this
system. This feature automatically switches a
weak stereo signal to a clearer monaural signal,
which improves the quality of reception.
*
[AS62000( ALL)08/95]
Several sources of static are normal conditions
on AM frequencies. These can be caused by
power lines, electric fences, traffic lights and
thunderstorms.
*
[AS62100( ALL)08/95]
Another reception phenomenon isStrong Signal
Capture and Overload. This can occur when
listening to a weak station and when passing
another broadcast tower. The close station may
capture the more distant station, although the
displayed frequency does not change. While
passing the tower, the station may switch back
and forth a few times before returning to the
original station.
*
[AS62200( ALL)08/95]
When several broadcast towers are present
(common in metropolitan areas) several stations
may overload the receiver, resulting in
considerable station changing, mixing and
distortion.
*
[AS62300( ALL)08/95]
Automatic gain control circuitry for both AM
and FM bands has been incorporated into this
system to reduce strong signal capture and
overload.
%
*
[AS62400( ALL)08/95]
All About Radio Frequencies
*
[AS62500( ALL)08/95]
The Federal Communications Commission (FCC)
and the Canadian Radio Telecommunications
Commission (CRTC) establish the frequencies
that AM and FM radio stations may use for
their broadcasts. The allowable frequencies are,
AM: 530, 540...1600, 1610 kHz in 10 kHz steps;
FM: 87.9, 88.1...107.7, 107.9 MHz in 0.2 MHz
steps.
File:09rcasm.ex
Update:Wed Mar 27 09:33:20 1996

180 %
*
[DR01900( ALL)01/95]
Driving
[DR01945(M )05/95]
Your vehicle's gearshift is console-mounted on
the floor. The Transmission Control Switch (TCS)
is located on the console to the right of the
gearshift handle and is marked ªO/Dº. The
Transmission Control Indicator Light is located
on the instrument panel. You can put the
gearshift lever in any of the several positions.
[DR01951(MBC )03/95]
The OVERDRIVE OFF light is off (not
illuminated) during normal vehicle operation.
This allows the transmission to upshift and
downshift from 1st through 4th gears. When the
TCS is pressed, the Transmission Control
Indicator Light will illuminate (O/D OFF) on the
instrument panel. When this O/D OFF is
illuminated the transmission will upshift and
downshift from 1st through 3rd gears.
[DR01957( ALL)11/94]
If the O/D OFF light does not come ªonº when
the TCS is depressed or if the light ªFLASHESº
when you are driving, have your vehicle
serviced at the first opportunity. If this condition
persists, damage could occur to the transmission.
[DR01965(M )06/93]
To return the transmission to normal operation
(1st through 4th gear) depress the TCS marked
ªO/Dº again. This switch may be used to cancel
overdrive any time the vehicle is being driven.
Each time your vehicle is started, the overdrive
system will automatically be in the normal
overdrive mode and the light will not be
illuminated.
%*
[DR02010(MBC )05/95]
When to use D (Overdrive)
*
[DR02100( ALL)01/95]
Overdrive is the usual driving position for an
automatic overdrive transmission. It works the
same way Drive works, automatically upshifting
or downshifting as the vehicle speeds or slows.
File:10rcdrm.ex
Update:Wed Mar 27 09:33:56 1996

181
*
[DR02200( ALL)01/95]
However, Overdrive also shifts into a fourth
gear Ðan overdrive gear Ð when your vehicle
cruises at an appropriate consistent speed for
any length of time. This fourth gear will increase
your fuel economy when you travel at cruising
speeds.
[DR02500(MBC )05/95]
When to use D (Overdrive) Ð with
transmission control switch activated (O/D
OFF light illuminated)
*
[DR02600(MBC )01/95]
Overdrive may not be appropriate for certain
terrain. If the transmission shifts back and forth
between Third and Fourth gears while you are
driving on hilly roads or if your vehicle does
not have adequate power for climbing hills,
depress the TCS.
[DR02606(M )06/93]
You can depress the TCS marked ªODº at any
speed.
*
[DR02610( ALL)01/95]
When to use 2 (Second)
*
[DR02620( ALL)01/95]
Use 2 (Second) for start-up on slippery roads or
to give you more engine braking to slow your
vehicle on downgrades.
*
[DR02700( ALL)01/95]
When to use 1 (Low)
*
[DR02800( ALL)03/95]
Use 1 (Low) when driving down steep grades. It
gives more engine braking to slow your vehicle
than 2 (Second) on the downgrades. You can
upshift from 1 (Low) to 2 (Second) or from 1
(Low) to Overdrive at any speed.
*
[DR03000( ALL)01/95]
P (Park)
*
[DR03100( ALL)01/95]
Always come to a complete stop before you shift
into P (Park). Make sure that the gearshift is
securely latched in P (Park). This locks the
transmission and prevents the rear wheels from
rotating.
File:10rcdrm.ex
Update:Wed Mar 27 09:33:56 1996

187
wheels to continue to roll while you are slowing
down, which lets you steer properly.
[DR11300( ALL)03/95]
On vehicles without anti-lock brakes, extreme
braking can make the wheels lock and slide,
possibly decreasing your control of the steering.
If you lock the wheels, release the brake pedal
and repeat the ªsqueezeº technique.
[DR11310( ALL)05/95]
Braking with ABS brakes
[DR11400( ALL)03/95]
On vehicles with anti-lock brakes, the wheels
will not lock and slide when you press down
hard on the brake pedal. The anti-lock brakes
automatically start releasing and reapplying the
front brakes independently and the rear brakes
together whenever your wheels start to lock. Do
not ªpumpº the brake pedal on vehicles
equipped with anti-lock brakes. When this
happens, you will feel the brake pedal pulse.
This ªpulseº may be an unfamiliar feeling but it
is normal and indicates the ABS is working as
designed.
*
[DR11650( ALL)05/95]
Do not drive with your foot resting on the brake
pedal; you will wear out the linings and increase
your vehicle's stopping distance. Brake rotor
damage may also eventually occur.
*
[DR11700( ALL)09/95]
NOTE: If you are driving down a long or
steep hill, shift to a lower gear and do
not apply your brakes continuously. If
you apply your brakes continuously,
they may overheat and become less
effective.
%*
[DR11800( ALL)10/95]
Occasional brake squeal during light to moderate
stops does not affect the function of the brake
system and is normal. However, if the squeal
becomes louder or more frequent, have your
brakes inspected by your dealer or a qualified
service technician.
File:10rcdrm.ex
Update:Wed Mar 27 09:33:56 1996

188 [DR11900( ALL)05/94]Ford Motor Company has not found any
detrimental effects of popular mobile radio
transmitting equipment installed on vehicles
with the anti-lock brake system, if the equipment
is installed according to the manufacturer's
instructions. However, if mobile radio
transmitting equipment is installed in your
vehicle and, if either the anti-lock brake system
cycles or the check anti-lock light comes on at
any time other than right after you turn the key
to ON or during a sudden stop, have your
mobile radio dealer inspect the installation.
%*
[DR12000( ALL)03/95]
Parking Brake
*
[DR12050( ALL)01/95]
The parking brake should be used whenever
you park your vehicle.
[DR12100(M )01/89]
The brake handle is located between the front
seats.
[DR12600(M )03/95]
To set the parking brake after parking your
vehicle, apply the brake pedal with your right
foot and pull up on the parking brake handle.
The brake system warning light will glow.
[DR13100(M )08/93]
one third page art:0010314-B
The parking brake
File:10rcdrm.ex
Update:Wed Mar 27 09:33:56 1996
