1996 FORD MUSTANG light

189
*
[DR13700(M )03/95]
RWARNING
When parking, do not use the gearshift in
place of the parking brake. Turn the key
to LOCK whenever you leave your
vehicle. Always set the parking brake
fully and make sure that the gearshift is
securely latched in P (Park) (automatic
transmission) or in 1 (First) (manual
transmission). Never leave your vehicle
unattended while it is running. If you do
not take these precautions, your vehicle
may move unexpectedly and injure
someone.
[DR13900(M )10/95]
To release the parking brake, pull the handle
upward, push in the button, then lower the
handle. The Brake System warning light will
glow if the parking brake is not fully released
when the engine is running.
*
[DR14200( ALL)03/95]
Always check the Brake Warning Light each
time you start your engine. Driving with the
parking brake on will cause the brakes to wear
out quickly and will reduce the fuel economy.
*
[DR14300( ALL)01/93]
RWARNING
If the parking brake is fully released, but
the Brake System light remains on, have
the brakes checked immediately. They
may not be working properly.
[DR14400( ALL)07/93]
The parking brake system is designed for static
parking only and is not designed to stop a
moving vehicle, but you can use the parking
brake to stop your vehicle in an emergency if
the normal brakes fail. However, since the
parking brake applies only the rear brakes, the
stopping distance will increase greatly and the
handling of your vehicle will be adversely
affected.
File:10rcdrm.ex
Update:Wed Mar 27 09:33:56 1996

191
*
[DR16225( ALL)03/95]
RWARNING
If your vehicle has speed control, do not
use it on slippery roads. You could lose
control of your vehicle and could injure
someone.
[DR16300(MBC )03/92]
If your vehicle gets stuck (for example, in mud
or snow), you may try to ªrockº it out of the
spot. Shift, in a steady rhythm, between forward
and reverse gears. At the same time, press
lightly on the accelerator.
*
[DR16400( ALL)05/95]
RWARNING
Do not spin the wheels at over 35 mph
(55 km/h). The tires may fail and injure a
passenger or bystander.
[DR16500( ALL)12/94]
By moving the vehicle backward and forward,
you may gain enough momentum to move out
of the spot. Do not rock the vehicle for more
than a few minutes. This may overheat the
engine, damage the transmission, or damage the
tires. If you are still stuck after a minute or two
of rocking, call for a tow truck.
%*
[DR16700( ALL)01/95]
High water
*
[DR16800( ALL)01/95]
Do not drive through flooded areas unless you
are sure that the water is below the bottom of
the wheel rims.
*
[DR16900( ALL)04/94]
If you must drive through high water, drive
slowly. You may have limited traction or wet
brakes, so allow extra stopping distance because
your vehicle will not stop as quickly as usual.
*
[DR17000( ALL)01/95]
After you drive through the standing water,
apply your brakes gently several times as your
vehicle moves slowly. This helps to dry the
brakes.
File:10rcdrm.ex
Update:Wed Mar 27 09:33:56 1996

194
%*
[DR17550(MBC )04/95]
Trailer Towing
*
[DR17650( ALL)01/95]
Your vehicle does not come from the factory
fully equipped to tow. No towing packages are
available through Ford or Lincoln/Mercury
dealers.
*
[DR17700( ALL)01/95]
Because towing a trailer puts extra strain on
your vehicle, you must follow certain
precautions for your safety and the good of your
vehicle:
*
[DR17800( ALL)01/95]
q
Stay within the load limits for towing your
vehicle. (SeeTrailer towing specificationsin this
chapter.)
*
[DR17900( ALL)01/95]
q
Carefully and thoroughly prepare your
vehicle for towing, making sure to use the
right equipment and to attach it properly.
(SeePreparing to Towin this chapter.)
*
[DR18000( ALL)01/95]
q
Use extra caution when driving your vehicle
while you tow. (SeeDriving while you towin
this chapter.)
*
[DR18100( ALL)01/95]
q
Service your vehicle more frequently if you
tow a trailer. (SeeServicing your vehicle if you
towin this chapter.)
*
[DR18175( ALL)01/95]
Ten to 15% of the loaded trailer's weight should
be on the tongue. However, the tongue load
should never exceed 10% of the maximum
weight that your vehicle can safely tow.
*
[DR18250( ALL)05/95]
RWARNING
Do not tow a trailer when the temporary
spare tire is being used.
[DR18300( ALL)12/94]
Your vehicle is classified as a light duty towing
vehicle. The amount of weight that you can
safely tow depends on the optional equipment
on your vehicle. See the following chart.
File:10rcdrm.ex
Update:Wed Mar 27 09:33:56 1996

197 %
*
[DR22350( ALL)01/95]
Connecting the trailer's lights
*
[DR22400( ALL)01/95]
Do not connect a trailer's lighting system
wiring directly to your vehicle's lighting system
wiring.To get the proper equipment for
hooking up your trailer's lights, see your local
trailer dealer and your Ford dealer. Be sure to
follow their instructions carefully.
[DR22450( ALL)03/95]
If your vehicle is equipped with the optional
trailer tow package, the proper lamp wiring and
equipment has been installed at the factory. The
trailer feed wire (supplied in a box in the
luggage compartment) needs a connector
compatible with your trailer prior to installation.
*
[DR22500( ALL)01/95]
If you do not install trailer lights correctly, you
may cause damage to the vehicle's lighting
system.
%*
[DR22600( ALL)01/95]
Driving While You Tow
*
[DR22650( ALL)05/95]
Be especially careful when driving while you
tow a trailer. Never drive faster than 45 mph
(70 km/h) when you tow in hilly country on
hot days. Also, anticipate stops so that you can
brake gradually.
[DR22950(MBC )09/93]
If you tow in Overdrive while riding through
hilly country, your vehicle may frequently shift
between Overdrive and Third gears. To prevent
your vehicle from shifting too much, depress the
Transmission Control Switch (TCS). This will
also give the engine more power going up hills
and better engine braking going down hills.
File:10rcdrm.ex
Update:Wed Mar 27 09:33:56 1996

199
Roadside Emergencies
%*
[RE00400( ALL)03/95]
Jump-Starting Your Vehicle
*
[RE00450( ALL)08/95]
Your vehicle's battery may die if you leave the
lights on or any electrical equipment on after
you turn the engine off. If this happens, you
may be able to jump-start your vehicle with a
booster battery.
*
[RE00500( ALL)02/95]
RWARNING
The gases around the battery can explode
if exposed to flames, sparks, or lit
cigarettes. An explosion could result in
injury or vehicle damage.
*
[RE00600( ALL)02/95]
RWARNING
To protect yourself when charging a
battery, always shield your face and eyes.
Make sure that you can breathe fresh air.
%*
[RE00700( ALL)06/95]
RWARNING
Applying too much pressure on the ends
when lifting a battery could cause acid to
spill. Lift the battery with a carrier or
with your hands on the opposite corners.
%*
[RE00800( ALL)07/95]
RWARNING
Batteries contain sulfuric acid which burns
skin, eyes, and clothing.
*
[RE00900( ALL)07/95]
If the acid touches someone's skin, eyes, or
clothing, immediately flush the area with water
for at least 15 minutes. If someone swallows the
File:12rcrem.ex
Update:Wed Mar 27 09:34:49 1996

200acid, have him or her drink lots of milk or water
first, then Milk of Magnesia, a beaten egg, or
vegetable oil. Call a doctor immediately.
*
[RE01000( ALL)03/95]
To avoid damaging your vehicle or your battery,
and to avoid injury to yourself, follow these
directions for preparing your vehicle to
jump-start and connecting the jumper cables in
the order they are given. If in doubt, call for
road service.
*
[RE01100( ALL)03/95]
Preparing Your Vehicle
[RE01150( ALL)11/90]
NOTE: also see label on battery.
*
[RE01200( ALL)03/95]
1. Your vehicle has a 12-volt starting system, so
you need to use a 12-volt jumper system.
You will damage your starting motor,
ignition system, and other electrical parts if
you connect them to a 24-volt power supply
(either two 12-volt batteries in series or a
24-volt generator set).
*
[RE01300( ALL)03/95]
2. Do not disconnect the battery of the disabled
vehicle. You could damage the vehicle's
electrical system.
*
[RE01400( ALL)04/95]
3. Park the booster vehicle close to the hood of
the disabled vehicle.Make sure the vehicles
do not touch each other.Set the parking
brake on both vehicles and stay clear of the
engine cooling fan and other moving parts.
*
[RE01500( ALL)03/95]
4. Check all battery terminals and remove any
excessive corrosion before you attach the
jumper cables.
*
[RE01600( ALL)02/95]
5. Turn on the heater fan in both vehicles.
Turning on the fan helps protect the
electrical system from voltage surges. Turn
off all other switches and lights in both
vehicles to prevent possible damage to either
vehicle's electrical systems.
File:12rcrem.ex
Update:Wed Mar 27 09:34:49 1996

218 [HS01800( ALL)05/95]
one inch art:0010630-AVehicle Identification Number (VIN/Serial Number)
*
[HS02200( ALL)03/95]
If you still have a service or product complaint,
you may wish to contact the Dispute Settlement
Board (U.S. only) or the Canadian Motor Vehicle
Arbitration Plan (CAMVAP) in Canada.
%
*
[HS02300( ALL)02/95]
The Dispute Settlement Board
(U.S. Only)
*
[HS02400( ALL)03/95]
The Dispute Settlement Board is a voluntary,
independent dispute-settlement program
available free to owners or lessees of qualifying
Ford Motor Company vehicles.
*
[HS02500( ALL)01/95]
The Dispute Settlement Board may not be
available in all states. Ford Motor Company
reserves the right to change eligibility
limitations, modify procedures and/or to
discontinue this process at any time without
notice and without incurring obligations.
*
[HS02600( ALL)01/95]
What Kind of Cases Does the Board
Review?
*
[HS02700( ALL)08/95]
The Board reviews unresolved warranty
performance complaints on Ford, Mercury and
Lincoln cars and Ford and Mercury Light Trucks
under warranty that have not been resolved by a
dealer or Ford Motor Company.
*
[HS02750( ALL)03/95]
The Board does not review issues involving:
*
[HS02800( ALL)01/95]
q
A non-Ford product
*
[HS02900( ALL)01/95]
q
A non-Ford dealership
File:13rchsm.ex
Update:Wed Mar 27 09:35:14 1996

235
Servicing Your Mustang
%*
[SV00300( ALL)03/95]
Service Made Easy
*
[SV00400( ALL)01/95]
Ford has two goals for servicing your vehicle.
*
[SV00550( ALL)01/95]
1. When we can, we design parts that do not
need to be serviced.
*
[SV00600( ALL)01/95]
2. We want to make servicing your vehicle as
easy as possible. To help you:
*
[SV00700( ALL)01/95]
q
We highlight do-it-yourself items in yellow in
the engine compartment so that you can find
them easily.
*
[SV00800( ALL)01/95]
q
When possible, we design parts Ð such as
the headlamp bulbs Ð that can be replaced
without tools.
*
[SV00900( ALL)05/94]
q
We give you a Maintenance Schedule that
makes tracking routine service for your
vehicle easy. The maintenance schedule is
located in theMaintenance Schedule and Record
booklet.
*
[SV01000( ALL)01/95]
This chapter tells you about the basic parts that
you need to check and service regularly.
*
[SV01100( ALL)02/95]
If your vehicle needs professional servicing, your
dealership can provide the parts and service
required. Check yourWarranty Information Booklet
to find out which parts and services are covered.
Also see theCustomer Assistancechapter of this
Owner Guide.
*
[SV01250( ALL)03/95]
Ford Motor Company recommends that the
Owner Maintenance Checks listed in the
Maintenance Schedule and Recordbooklet be
performed for the proper operation of your
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996
