1996 FORD F150 battery

53
*
[ST04750( ALL)01/93]
RWARNING
Do not leave children, unreliable adults,
or pets alone in your vehicle. They could
accidentally injure themselves or others
through inadvertent operation of the
vehicle. Further, on hot, sunny days,
temperatures in a closed vehicle could
quickly become high enough to cause
severe and possibly fatal injuries to
people as well as animals.
%
*
[ST04800( ALL)03/95]
Fuel-Injected Engines
*
[ST04850( EF )04/94]
NOTE: For owners of diesel-powered vehicles,
refer to theDiesel Engine Owners Guide
Supplementfor information on starting
your vehicle.
*
[ST04900(BEF )03/95]
When starting a fuel-injected engine,the most
important thing to remember is to avoid
pressing down on the accelerator before or
during starting. Only use the accelerator when
you have problems getting your vehicle started.
SeeStarting Your Enginein this chapter for
details about when to use the accelerator while
you start your vehicle.
*
[ST05000(B F )01/95]
Because your vehicle's engine is electronically
controlled by a computer, some control
conditions are maintained by power from the
battery. If you ever disconnect the battery, install
a new battery, or experience a dead battery, you
must allow the computer to ªrelearnº its idle
conditions before your vehicle will idle at its
best. To let the engine do this, apply the parking
brake, put the gearshift in Park (automatic
transmission) or Neutral (manual transmission),
turn off all the accessories, and start the vehicle.
Let the engine idle for at least one minute.
File:ltstf.ex
Update:Thu May 9 15:26:52 1996

71
*
[LG04750( ALL)05/95]
After completing the three consecutive warm up
cycles and on the fourth engine start up, the
Check Engine Warning Light should turn off. If
the light does not go off after the fourth engine
restart, have your vehicle serviced by your
dealer or a qualified technician.
*
[LG05900( ALL)01/95]
Charging System Light
*
[LG06000( ALL)03/95]
This light, shown as a battery symbol on your
cluster, indicates that your battery is not being
charged and that you need to have the electrical
system checked.
*
[LG06050( ALL)03/91]
one inch art:0020777-A
The charging system light
*
[LG06100( ALL)05/95]
This light comes on every time you turn the
ignition to the ON or START position (engine
off). The light should go off when the engine
starts and the alternator begins to charge.
*
[LG06300(B FM)01/95]
If the light stays on or comes on when the
engine is running, have the electrical system
checked as soon as possible.
*
[LG06305(BEF )06/93]
Supplemental Air Bag Readiness Light and
Tone Generator
*
[LG06310(BEF )06/93]
This light illuminates for six seconds when the
ignition is turned to the ON position. If the light
fails to illuminate, continues to flash, remains on,
or if a series of five beeps is heard, have the
system serviced as soon as possible.
File:ltlgf.ex
Update:Thu May 9 15:22:28 1996

72 [LG06320(B F )05/95]
one inch art:0000653-CSupplemental air bag readiness light
*
[LG06400( ALL)05/94]
Battery Voltage Gauge (Voltmeter)
*
[LG06601( ALL)05/94]
This gauge shows you the battery voltage when
the ignition key is in the ON position.
*
[LG06700( ALL)11/89]
If you are running electrical accessories (when
the engine is off, or idling at a low speed), the
pointer may move toward the lower end of the
normal band. If it stays outside the normal band
area, have your vehicle's electrical system
checked as soon as it is safely possible.
*
[LG06701( ALL)05/95]
If the battery is operating under cold weather
conditions, the pointer may indicate in the upper
range of the NORMAL band while the battery is
charging. If you are running electrical accessories
with the engine off or idling at a low speed, or
the battery is not fully charged, the pointer may
move toward the lower end of the NORMAL
band.
*
[LG06750( ALL)05/94]
If it stays outside the NORMAL band, have your
vehicle's electrical system checked as soon as it
is safely possible.
*
[LG06900(B F )03/93]
quarter page art:0020052-D
Battery voltage gauge
File:ltlgf.ex
Update:Thu May 9 15:22:28 1996

99
*
[SC05400( ALL)01/93]
RWARNING
In freezing weather, the washer solution
may freeze on the windshield and obscure
your vision. Always warm up the
windshield with the defroster before you
use the washer fluid. If you cannot see
through the windshield clearly, it can
increase the risk of being involved in a
collision.
*
[SC05500(BEF )04/95]
For information about refilling the washer fluid
or replacing your windshield wiper blades, see
Windshield washer fluid and Wipersin the Index.
%
*
[SC05510( ALL)03/95]
Hazard Flasher
*
[SC05520( ALL)04/95]
The hazard flasher is used to alert other drivers
to hazardous situations.
*
[SC05525( FM)10/92]
The flashers will continue to flash with the brake
pedal depressed.
*
[SC05530( ALL)03/95]
The flashers work whether your vehicle is
running or not. The flashers work for up to two
hours when the battery is fully charged and in
good condition without draining the battery
excessively. If the flashers run for longer than
two hours or if the battery is not fully charged,
the battery can be drained.
*
[SC05540( ALL)09/93]
To use the hazard flasher:
*
[SC05550( ALL)10/92]
1. Push in the flasher button; it will pop out
and the lamps will begin to flash.
*
[SC05560( ALL)10/92]
2. To stop the flashers, push in the flasher
button again.
*
[SC05562( ALL)10/92]
NOTE: The flasher button will be sticking up
slightly higher when ON than when
OFF.
File:ltscf.ex
Update:Thu May 9 15:25:14 1996

116
*
[FV18900(B F )04/94]
Battery Saver (with Remote Entry Ð
If equipped)
*
[FV19000(B F )03/95]
When the ignition is turned off, the vehicle will
turn off battery voltage to all of these lights after
40 minutes: glove box, engine compartment,
overhead console, mirror, courtesy and
interior (including cargo) lamps.
*
[FV19102(B F )03/95]
This will prevent draining of the battery if these
lights have been left on inadvertently or if a
door is not completely closed. Battery voltage to
these lamps will be restored when the remote
entry transmitter is used, any door is opened, or
the ignition key is turned on again.
*
[FV19250(BEF )02/95]
Windows
*
[FV19300(BEF )03/95]
Operating the Windows Manually
*
[FV21100( F )02/91]
Cab rear sliding window (If equipped)
*
[FV21300( F )06/94]
To open the sliding cab window, release the
latch by pulling the left portion of the snap lock
away from the window, then move the window
to the desired position. To close, slide the
windows to the center and snap the latch closed.
*
[FV21400( F )06/92]
quarter page art:0020208-A
Sliding cab window
File:ltfvf.ex
Update:Thu May 9 15:20:08 1996

143
*
[AS03400(BEF )04/95]
2. Press one of the memory buttons and hold
the button until the sound returns. That
station is now held in memory on that
button.
*
[AS03500(BEF )04/95]
3. Follow the two steps above for each station
memory preset button you want to set.
*
[AS03510(BEF )04/95]
NOTE: If the vehicle's battery is disconnected,
the clock and station memory preset
buttons (if programmed in auto mode)
will need to be reset.
*
[AS03520(BEF )04/95]
q
Using the Automatic Memory Load feature
*
[AS03530(BEF )04/95]
You can activate theAuto Memory Load
feature by pressing and holding the ªAUTO
PRESETº buttonfor approximately three
seconds. Auto Memory Load sets all memory
buttons in AM, FM1 and FM2 sequentially by
seeking out the first five strong stations for
the respective band and storing them in
memory buttons 1-5. (FM2 will store the
second set of strong stations from the FM
band.)
*
[AS03800(BEF )05/95]
With Auto Memory Store, you can
continually set strong stations into your
memory buttons without losing your existing
memory presets, which is especially handy
while traveling. Your radio will automatically
set your memory buttons to the strong local
stations so you don't have to continually
manually tune to existing stations.
*
[AS03900(BEF )05/95]
Activate Auto Memory Store by pushing the
ªAUTO PRESETº button once. Your radio
will set the first five strong stations of the
band you are in (AM, FM1 or FM2) into the
memory buttons. The display will show
ªAUTOº, then run through the frequencies,
stopping momentarily on the stations being
set into the memory buttons. The radio is
File:ltasf.ex
Update:Thu May 9 15:15:21 1996

157
*
[AS23200(BEF )04/95]
q
Setting the Station Memory Preset buttons
*
[AS23250(BEF )05/95]
Your radio is equipped with 5 station
memory buttons. These buttons can be used
to select up to 5 preset AM stations and 10
preset FM stations (5 in FM1 and 5 in FM2).
*
[AS23400(BEF )02/95]
Follow the easy steps below to set these buttons
to the desired frequencies:
*
[AS23500(BEF )04/95]
1. Select a band, then select a frequency.
*
[AS23700(BEF )04/95]
2. Press one of the memory buttons and hold
the button until the sound returns. That
station is now held in memory on that
button.
*
[AS23800(BEF )04/95]
3. Follow the two steps above for each station
memory preset button you want to set.
*
[AS23900(BEF )04/95]
NOTE: If the vehicle's battery is disconnected,
the clock and station memory preset
buttons (if programmed in auto mode)
will need to be reset.
*
[AS24000(BEF )02/95]
Adjusting the tone balance and speaker
output of your radio
*
[AS24150(BEF )05/95]
Push the ªAUDIOº button repeatedly until
the display reads ªBASS.º Push the right (+)
side of the ªVOLUMEº button to increase
bass (more ªlowsº), and push the left (-) side
to decrease bass (less ªlowsº).
*
[AS24300(BEF )04/95]
q
Increasing or decreasing treble response
*
[AS24350(BEF )05/95]
Push the ªAUDIOº button repeatedly until
the display reads ªTREB.º Push the right (+)
side of the ªVOLUMEº button to increase the
treble (more ªhighsº), and push the left (-)
side to decrease treble (less ªhighsº).
File:ltasf.ex
Update:Thu May 9 15:15:21 1996

164
*
[AS33500( EF )04/95]
q
Setting the Station Memory Preset buttons
*
[AS33600( EF )08/89]
Your radio is equipped with 6 station
memory buttons. These buttons can be used
to select up to 6 preset AM stations. Follow
the easy steps below to set these buttons to
the desired frequencies:
*
[AS33800( EF )05/94]
1. Tune to the desired frequency.
*
[AS33900( EF )07/94]
2. Press one of the memory buttons and hold
the button in until the sound returns. That
station is now held in memory on that
button.
*
[AS34000( EF )08/89]
3. Follow the two steps above for each station
memory preset you want to set.
*
[AS34100( EF )04/95]
NOTE: If the vehicle's battery is disconnected,
the clock and station memory preset
buttons (if programmed in auto mode)
will need to be reset.
*
[AS34200( EF )02/95]
Adjusting the tone balance and speaker
output of your radio
*
[AS34300( EF )08/89]
The ªTONEº button on the right side of your
radio controls the bass and treble balance. Rotate
the control clockwise to increase the treble
response (more highs) and counterclockwise to
increase the bass response (more lows).
*
[AS34400( EF )03/95]
Clock Operation
*
[AS34500( EF )07/90]
How to view the clock mode
*
[AS34600( EF )07/93]
Press the ªCLOCKº button to alternate the
frequency and time in the display. In the clock
mode, pressing any radio function will
automatically display the radio frequency for
approximately ten seconds before changing back
to the clock mode.
File:ltasf.ex
Update:Thu May 9 15:15:21 1996
