342
*
[SV31993( F )04/95]
2. You can brighten the wheels, even after
years of use, with readily-available buffing
compounds, such as Ford Custom Bright
Metal Cleaner or equivalent. Follow the
buffing instructions that come with the
compound.
*
[SV31995( F )04/95]
3. When tires are removed, the entire wheel
must be cleaned and inspected. Remove any
soil or oxidation products from the tire side
of the rim with a wire brush.
*
[SV31997( F )04/95]
4. Aluminum alloys resist corrosion. This is
why your Forged F-350 Aluminum Wheels
never need sanding or painting. However,
certain environments can lead to corrosion:
salt, chloride compounds used for snow
removal and highly alkaline materials. Wash
corrosives elements off the wheel before they
have time to react.
*
[SV32100( ALL)03/95]
Battery
*
[SV32200( ALL)02/95]
Your vehicle may have a Motorcraft
maintenance-free battery. When the original
equipment battery is replaced under warranty, it
may be replaced by a Motorcraft
Low-Maintenance Battery.
*
[SV32500( ALL)02/95]
The Low-Maintenance Battery has removable
vent caps for checking the electrolyte level and
for adding water, if necessary. The electrolyte
level should be checked at least every 24 months
or 24,000 miles (40,000 km) in temperatures up
to 90ÊF (32ÊC) andmore often in temperatures
above90ÊF (32ÊC).Keep the electrolyte level in
each cell up to the level indicator. Do not
overfill.
*
[SV32700( ALL)02/95]
If the level gets low, you can add tap water to
the battery, provided the water isn't hard or
doesn't have a high mineral or alkali content.
However, if possible you should refill the battery
File:ltsvf.ex
Update:Thu May 9 15:30:19 1996

343
with distilled water. If the battery needs water
quite often, have the charging system checked
for a possible malfunction.
%*
[SV32725( ALL)03/95]
Help Us Protect Our Environment
*
[SV32750( ALL)04/95]
Ford Motor Company strongly recommends that
used lead-acid batteries be returned to an
authorized recycling facility for disposal.
*
[SV32775( ALL)03/95]
one inch art:0000983-A
Battery recycling symbol
*
[SV33200( ALL)01/95]
RWARNING
Batteries normally produce explosive gases
which can cause personal injury.
Therefore, do not allow flames, sparks or
lit tobacco to come near the battery. When
charging or working near a battery, always
cover your face and protect your eyes, and
also provide ventilation.
%*
[SV33300( ALL)05/95]
RWARNING
Batteries contain sulfuric acid which burns
skin, eyes, and clothing.
*
[SV33305( ALL)05/95]
If the acid touches someone's skin, eyes, or
clothing, immediately flush the area with water
for at least 15 minutes. If someone swallows the
acid, have him or her drink lots of milk or water
first, then Milk of Magnesia, a beaten egg, or
vegetable oil. Call a doctor immediately.
File:ltsvf.ex
Update:Thu May 9 15:30:19 1996

344 %
*
[SV33400( ALL)05/95]
RWARNING
Applying too much pressure on the ends
when lifting a battery could cause acid to
spill. Lift the battery with a carrier or
with your hands on the opposite corners.
*
[SV33500( ALL)01/95]
Automatic Transmission Fluid
*
[SV33601( ALL)04/95]
Under normal driving conditions automatic
transmission fluid should be changed every
30,000 miles (48,000 km) or 21,000 miles
(34,000 km) if under severe duty conditions.
However, if the transmission is not working
properly, for instance, the transmission may slip
or shift slowly, or you may notice some sign of
fluid leakage, the fluid level should be checked.
[SV33605( ALL)04/95]
NOTE: Except E4OD transmission, there is no
30,000 mile (48,000 km) sheduled
transmission fluid change requirement.
[SV33615( ALL)05/95]
Transmission fluid, filter and seal assembly
should be changed every 21,000 miles
(34,000 km) only under any of the following
conditions.
[SV33620( ALL)04/95]
q
Extended periods of high speed driving
during hot weather at/or above+90ÊF
(+30ÊC).
[SV33625( ALL)04/95]
q
Towing a trailer for distances over 1,000 miles
(1,600 km) per trip.
[SV33630( ALL)04/95]
q
Accumulating 5,000 miles (8,000 km) or more
per month.
[SV33635( ALL)04/95]
q
Continuous operation and/or extensive idling
(a delivery service as an example).
[SV33640( ALL)04/95]
q
Operating in severe dust conditions.
File:ltsvf.ex
Update:Thu May 9 15:30:19 1996

359
*
[SV41300( ALL)10/92]
Power distribution box
*
[SV41400( ALL)10/92]
The high current fuses contained in the Power
Distribution Box protect your vehicle's main
electrical systems from overloads; these fuses
provide the connection between the battery and
your vehicle's electrical systems.
*
[SV41500( ALL)10/92]
The high current fuses are coded as follows: 30
amp -light green, 40 amp - orange, 50 amp - red,
60 amp -blue.
*
[SV41600( ALL)05/95]
RWARNING
Always disconnect the battery before
servicing high current fuses.
*
[SV41620( ALL)05/95]
Ford recommends that high current fuses be
replaced by a qualified technician.
*
[SV41700( ALL)03/93]
RWARNING
Always replace the cover to the Power
Distribution Box before reconnecting the
battery or refilling fluid reservoirs.
*
[SV41800( ALL)04/95]
A blown high current fuse may be replaced but
will continue to blow until the cause of the
overload condition is corrected.
*
[SV41900( ALL)05/95]
RWARNING
Always replace a fuse with one that has
the specified amperage rating. Using a
fuse with a higher amperage rating can
cause severe wire damage and could start
a fire.
File:ltsvf.ex
Update:Thu May 9 15:30:19 1996

375 %
*
[SV51456( ALL)05/95]
Readiness for Inspection/Maintenance
Testing
*
[SV51457( ALL)05/95]
In some localities it may become a legal
requirement to pass an
Inspection/Maintenance (I/M) test of the
On-Board Diagnostic (OBD) II system. If the
vehicle's powertrain system or its battery has
just been serviced, the OBD II system is reset to
a not ready for I/M testing condition. To
prepare for I/M testing, the law specifies a
ªneed for additional mixed city and highway
driving to complete the checkº of the OBD II
system. As soon as all of the OBD II system
checks are successfully completed, the OBD II
system is set to the ready condition. The amount
of driving required to reach the ready condition
varies with individual driving patterns. To
complete this requirement in the minimum
amount of time, refer to the OBD II Drive Cycle
defined below. If the vehicle owner cannot or
does not want to do the additional driving
required by law, a service center can perform
this drive cycle as it would any other type of
repair work.
[SV51458( ALL)05/95]
OBD II Drive Cycle
[SV51459( ALL)04/95]
The engine must be warmed up and at
operating temperature before proceeding with
the drive modes of the following OBD II Drive
Cycle.
[SV51461( ALL)04/95]
1. Start the engine. Drive or idle (in neutral)
the vehicle for 4 minutes.
[SV51463( ALL)04/95]
2. Idle the vehicle in drive (neutral for manual
transmission) for 40 seconds.
*
[SV51465( ALL)05/95]
3. Accelerate the vehicle to 45 mph (72 km/h)
at 1/4 to 1/2 throttle for 10 seconds.
File:ltsvf.ex
Update:Thu May 9 15:30:19 1996

394 %
*
[SV58400( ALL)01/95]
Battery
*
[SV58500( ALL)01/95]
q
Check and recharge as necessary.
*
[SV58600( ALL)01/95]
q
Keep connections clean and covered with a
light coat of grease.
%*
[SV58700( ALL)01/95]
Brakes
*
[SV58800( ALL)01/95]
q
Make sure brakes and parking brake are fully
released.
%*
[SV58900( ALL)01/95]
Tires
*
[SV59000(B FM)05/95]
q
Maintain recommended air pressures.
*
[SV59100( ALL)01/95]
Miscellaneous
*
[SV59200( ALL)01/95]
q
Make sure all linkages, cables, levers and
clevis pins under vehicle are covered with
grease to prevent rust.
*
[SV59300( ALL)03/95]
q
Move vehicles at least 25 feet (8 m) every 15
days to lubricate working parts to prevent
corrosion.
