8. Double check that the retractor is in the
automatic locking mode. Try to pull more
belt out of the retractor. If you cannot, the
belt is in the automatic locking mode,
Figure 8.
*
[SR16420(BEF )04/95]
half page art:0011245-B
Checking the retractor
*
[SR16425(BEF )04/95]
9. Check to make sure that the child seat is
properly secured prior to each use. If the
retractor is not locked, repeat steps 4
through 7.
*
[SR16430(BEF )04/95]
To remove the retractor from automatic lock
mode, allow webbing to retract fully to its
stowed position and the retractor will
automatically switch back to the vehicle sensitive
locking mode for normal adult usage.
File:ltsrf.ex
Update:Thu May 9 15:26:26 1996

45 [SR16440(BEF )04/95]
Installing a Child Safety Seat at the Rear
Center Seating Position with Locking
Adjustable Lap Belt
[SR16450(BEF )04/95]
1. Lengthen the lap belt. To lengthen the belt,
hold the tongue so that its bottom is
perpendicular to the direction of webbing
while sliding the tongue up the webbing.
[SR16455(BEF )04/95]
2. Place the child safety seat in the center
seating position.
[SR16460(BEF )04/95]
3. Route the tongue and webbing through the
child seat according to the child seat
manufacturer's instructions.
[SR16465(BEF )04/95]
4. Insert the belt tongue into the proper buckle
for the center seating position until you hear
a snap and feel it latch. Make sure the
tongue is securely fastened to the buckle by
pulling on tongue.
[SR16470(BEF )04/95]
5. Push down on the child seat while pulling
on the loose end of the lap belt webbing to
tighten the belt.
[SR16475(BEF )04/95]
6. Before placing the child into child seat,
forcibly tilt the child seat from side-to-side
and in forward directions to ensure that the
seat is held securely in place. If the child
seat moves excessively, repeat steps 5
through 6, or properly install the child seat
in a different seating position.
File:ltsrf.ex
Update:Thu May 9 15:26:26 1996

47
*
[SR19100( F )12/91]
If a tethered seat is installed in the front seat,
Ford recommends placement of the tethered
safety seat in the center front seating position,
with the tether strap secured to the center rear
lap belt tongue or to the webbing of the buckled
center rear lap belt behind the child safety seat.
*
[SR19400(B F )04/95]
The rear lap/shoulder safety belts should not be
used to secure the tether strap of a safety seat
located in the front seat.
*
[SR19500(BEF )05/95]
RWARNING
Failure to follow these precautions could
increase the chance of injury in an
accident.
[SR19575( F )05/95]
In SuperCabs equipped with center facing jump
seats, the tether strap anchor bracket should be
installed only at the center of the cab's back
panel with the child seat in the front center
seating position. Installing an anchor bracket at
the right rear of the cab may increase risk of
injury to an occupant of the right rear center
facing jump seat in the event of a collision or
sudden stop. If a tethered child seat is installed
in the right front seating position, secure the
tether strap to the webbing of the buckled right
rear lap belt.
*
[SR19600( F )05/95]
RWARNING
Do not install a child seat in a center
facing jump seat.
File:ltsrf.ex
Update:Thu May 9 15:26:26 1996

70
*
[LG04662( F )05/95]
NOTE: If your light truck is equipped with
dual fuel tanks, the ªCHECK ENGINEº
light may come on if fuel is restricted
to the engine or if the fuel flow is
momentarily disrupted because of an
empty fuel tank before you switched to
the auxiliary fuel tank. This condition
is normal and the light should go off
after full fuel flow is restored.
*
[LG04675( ALL)05/95]
An example of a condition which corrects itself
occurs when an engine running out of fuel
begins to misfire. In this case, the Check Engine
Warning Light may turn on and will then set a
Diagnostic Trouble Code indicating that the
engine was misfiring while the last of the fuel
was being consumed. After refueling, the Check
Engine Warning Light will turn off after the
vehicle has completed three consecutive warm
up cycles without a misfire condition occurring.
A warm up cycle consists of engine start from a
cold condition (engine at ambient temperature)
and running until the engine reaches normal
operating temperature.
*
[LG04700( ALL)05/95]
On the fourth engine start up, the Check Engine
Warning Light will turn off as soon as the
engine begins to crank. It is not necessary to
have the engine serviced.
*
[LG04725( ALL)05/95]
Under certain conditions, the Check Engine
Warning Light may come on if the fuel cap is
not properly installed. If the Check Engine
Warning Light comes on and you suspect that
the fuel cap is not properly installed, pull off the
road as soon as it is safely possible and turn off
the engine. Remove and replace the fuel cap,
making sure it is properly seated.
File:ltlgf.ex
Update:Thu May 9 15:22:28 1996

71
*
[LG04750( ALL)05/95]
After completing the three consecutive warm up
cycles and on the fourth engine start up, the
Check Engine Warning Light should turn off. If
the light does not go off after the fourth engine
restart, have your vehicle serviced by your
dealer or a qualified technician.
*
[LG05900( ALL)01/95]
Charging System Light
*
[LG06000( ALL)03/95]
This light, shown as a battery symbol on your
cluster, indicates that your battery is not being
charged and that you need to have the electrical
system checked.
*
[LG06050( ALL)03/91]
one inch art:0020777-A
The charging system light
*
[LG06100( ALL)05/95]
This light comes on every time you turn the
ignition to the ON or START position (engine
off). The light should go off when the engine
starts and the alternator begins to charge.
*
[LG06300(B FM)01/95]
If the light stays on or comes on when the
engine is running, have the electrical system
checked as soon as possible.
*
[LG06305(BEF )06/93]
Supplemental Air Bag Readiness Light and
Tone Generator
*
[LG06310(BEF )06/93]
This light illuminates for six seconds when the
ignition is turned to the ON position. If the light
fails to illuminate, continues to flash, remains on,
or if a series of five beeps is heard, have the
system serviced as soon as possible.
File:ltlgf.ex
Update:Thu May 9 15:22:28 1996

118
*
[FV24101(BEF )01/95]
Seats
*
[FV24801(BEF )05/90]
Adjusting the Front Seat Manually
*
[FV24901(BEF )08/94]
To move the front seat forward or rearward:
*
[FV25001(BEF )08/94]
1. Find the adjustment lever at the lower left
corner of the front seat.
*
[FV25101(BEF )10/89]
2. Push the lever to the left to unlatch the seat.
*
[FV25201(BEF )04/95]
3. Move the seat to the desired position.
*
[FV25301(BEF )04/89]
4. Release the lever to latch the seat in its new
position. Make sure the seat locks securely in
place.
*
[FV25600(B F )03/91]
one third page art:0020218-B
Adjusting bucket seat
*
[FV25700(B F )05/95]
one third page art:0020220-E
Adjusting the bench seat
File:ltfvf.ex
Update:Thu May 9 15:20:08 1996

125
*
[FV40901( F )01/89]
Rear Bench Seat (SuperCab Only)
*
[FV41001( F )01/89]
The forward facing rear seat in the SuperCab
forms a cargo floor when folded.
*
[FV41101( F )01/89]
To fold the seat:
*
[FV41201( F )01/89]
1. Move the front seat forward if necessary.
*
[FV41301( F )12/91]
2. Pull the strap at the passenger's side of the
seat bottom and pivot the seat assembly
forward (180 degrees).
*
[FV41401( F )03/90]
3. Raise the release lever at the top of the seat
back on the passenger's side of the vehicle,
and lower the seat back.
*
[FV41501( F )02/92]
one third page art:0020234-C
Using the rear bench seat (SuperCab only)
*
[FV41601( F )05/90]
To return seat to normal seating position:
*
[FV41701( F )05/90]
1. Lift the seat back until it locks in the vertical
position.
*
[FV41801( F )05/90]
2. Check to see if the seat back is securely
latched by pulling forward on the top of the
seat back.
*
[FV41901( F )05/90]
3. Grasp the seat bottom and pivot rearward
(180 degrees).
*
[FV42001( F )12/91]
4. Check to see if the seat bottom is securely
latched by pulling up on the rear portion of
the seat bottom.
File:ltfvf.ex
Update:Thu May 9 15:20:08 1996

147
*
[AS06300(BEF )04/95]
Once a disc is inserted, operation of the CD
player will override that of the radio.
*
[AS06350(BEF )04/95]
NOTE: The volume, bass, treble, balance and
fader controls on the radio are also
used with the CD player. Refer to
earlier operating instructions on these
controls.
*
[AS06400(BEF )04/95]
How to insert a disc and begin play
*
[AS06450(BEF )04/95]
Insert one disc,label side upinto the disc
opening. When inserted, the disc automatically
loads into the unit and play starts at the
beginning of the first track (selection).
*
[AS06500(BEF )04/95]
When the disc reaches the end, the disc player
automatically returns to the beginning of the
disc and resumes playing.
*
[AS06550(BEF )04/95]
NOTE: Once a disc is inserted, the disc
opening is secured to prevent the
accidental insertion of a second disc.
*
[AS06600(BEF )04/95]
NOTE: The CD player has heat protection
circuitry to protect the laser diode. If
the temperature of the player reaches
167ÊF (75ÊC), theheat detection circuit
will shut off the player and ªTOO
HOTº will scroll in the display for
approximately five seconds (radio will
resume playing). When the temperature
returns to normal operating range, the
CD player will again be operational.
*
[AS06650(BEF )04/95]
How to stop and restart the CD player
*
[AS06700(BEF )04/95]
When a disc is loaded, the unit automatically
enters the play mode and the play indicator
a
illuminates. To stop temporarily, press the
ªPLAY/STOPº button or the ªAM/FMº button.
The stop indicator
Xin the display illuminates
and operation returns to the radio mode. To
