[RE13500( F )01/89]
When the truck is ordered with a spare wheel
only (no tire), it is stowed with a wood spacer
in the usual spare tire location. Remove the
wood spacer before installing the spare tire and
wheel.
*
[RE13600( F )01/89]
After the spare tire and wheel are stowed, adjust
the driver side channel ball end bolt and the
eyebolt as necessary until the tire cannot be
moved by hand pressure.
*
[RE15100(BEF )05/95]
RWARNING
Make sure the spare tire and jacking
equipment are stowed and secured in the
proper storage location.
%*
[RE15200( ALL)03/95]
Preparing to Change the Tire
*
[RE15250( ALL)12/91]
NOTE: To lift your vehicle by other than the
front or rear jacking points, be sure to
use only hoist adapters with a wide
contact surface.
*
[RE15300(B F )03/91]
1. Make sure that your vehicle will not move
or roll. If you have an automatic
transmission, put the gearshift in Park. If
you have a manual transmission, put the
gearshift in Reverse. Set the parking brake
and block the wheel that is diagonally
opposite the tire that you are changing.
*
[RE15335(B F )12/91]
NOTE: Make sure the ignition is in the OFF
position.
File:ltref.ex
Update:Thu May 9 15:24:41 1996

274 [RE23615(BEF )02/95]8. Put the tire, jack, and wrench away. (Make
sure jack is securely fastened so it doesn't
rattle when you drive.) The carrier is
designed to hold the temporary spare which
comes with your vehicle. The stowage of a
full size tire in the spare tire carrier may
damage the tire or the vehicle. The flat full
size tire should be stowed securely in the
vehicle until it can be repaired.
*
[RE23700(BEF )01/95]
9. Unblock the wheels.
*
[RE24100( EFM)06/93]
On vehicles equipped with dual rear wheels
retighten the wheel lug nuts to the specified
torque at 100 miles (160 km), and again at 500
miles (800 km) of new vehicle operation and at
the intervals specified in theMaintenance Schedule
and Recordbooklet.
*
[RE24200( ALL)10/89]
Also retighten to the specified torque at 500
miles (800 km) of operation after any wheel
change or any time the lug nuts are loosened.
*
[RE24301( ALL)05/95]
RWARNING
Failure to retighten wheel lug nuts at
mileages specified could allow wheels to
come off while the vehicle is in motion.
File:ltref.ex
Update:Thu May 9 15:24:41 1996

280
*
[RE27400(B F )11/92]
q
When towing your vehicle with the rear
wheels on the ground or all four wheels on
the ground and the driveshafts connected, do
not exceed 35 mph (56 km/h) or
transmission damage could result. If a
distance of 50 miles (80 km) is exceeded,
disengage the automatic locking hubs and
disconnect the rear driveshaft from the axle
and secure. (Max speed 55 mph [88 km/h]
with driveshafts disconnected.)
*
[RE27500(BEF )03/91]
RWARNING
Never use a tow bar that attaches to the
bumper when you tow your vehicle. This
could damage the bumper and cause an
accident.
File:ltref.ex
Update:Thu May 9 15:24:41 1996

301
Servicing Your F-Series
%*
[SV00300( ALL)03/95]
Service Made Easy
*
[SV00400(BEF )01/95]
Ford has two goals for servicing your vehicle.
*
[SV00500(BEF )01/95]
1. When we can, we design parts that do not
need to be serviced.
*
[SV00600(BEF )01/95]
2. We want to make servicing your vehicle as
easy as possible. To help you:
*
[SV00700(BEF )01/95]
q
We highlight do-it-yourself items in yellow in
the engine compartment so that you can find
them easily.
*
[SV00800(BEF )01/95]
q
When possible, we design parts Ð such as
the headlamp bulbs Ð that can be replaced
without tools.
*
[SV00900(BEF )05/94]
q
We give you a Maintenance Schedule that
makes tracking routine service for your
vehicle easy. The maintenance schedule is
located in theMaintenance Schedule and Record
booklet.
*
[SV01000( ALL)01/95]
This chapter tells you about the basic parts that
you need to check and service regularly.
*
[SV01100( ALL)02/95]
If your vehicle needs professional servicing, your
dealership can provide the parts and service
required. Check yourWarranty Information Booklet
to find out which parts and services are covered.
Also see theCustomer Assistancechapter of this
Owner Guide.
*
[SV01300( ALL)03/95]
Ford Motor Company recommends that the
Owner Maintenance Checks listed in the
Maintenance Schedule and Recordbooklet be
performed for the proper operation of your
File:ltsvf.ex
Update:Thu May 9 15:30:19 1996

303
*
[SV02600( ALL)03/95]
Working with the engine off:
*
[SV02660(B F )05/95]
1. Always set the parking brake fully and make
sure that the gearshift is securely latched in
P (Park) (automatic transmission) or in 1
(First) (manual transmission).
*
[SV02675(B F )01/95]
2. When the transfer case is in the N (Neutral)
position, the engine and transmission are
disconnected from the rest of the driveline.
Therefore, the vehicle is free to roll even if
the automatic transmission is in P (Park) or
the manual transmission is in gear. Do not
leave the vehicle unattended with the
transfer case in the N (Neutral) position.
*
[SV02700( ALL)03/95]
3. Remove the key from the ignition after you
turn the engine off.
*
[SV02725( ALL)03/95]
4. Block the wheels. This will prevent your
vehicle from moving unexpectedly.
*
[SV02750( ALL)03/95]
Working with the engine on:1. Always set the parking brake fully and make
sure that the gearshift is securely latched in
P (Park) (automatic transmission) or in 1
(First) (manual transmission).
*
[SV02675(B F )01/95]
2. When the transfer case is in the N (Neutral)
position, the engine and transmission are
disconnected from the rest of the driveline.
Therefore, the vehicle is free to roll even if
the automatic transmission is in P (Park) or
the manual transmission is in gear. Do not
leave the vehicle unattended with the
transfer case in the N (Neutral) position.
*
[SV02900( ALL)02/95]
RWARNING
Do not start your engine with the air
cleaner removed and do not remove it
while the engine is running.
File:ltsvf.ex
Update:Thu May 9 15:30:19 1996

304
*
[SV02950(BEF )03/95]
Opening the Hood
*
[SV03000(B F )12/91]
1. Pull the hood release handle, located next to
the parking brake pedal.
*
[SV03050(BEF )12/91]
2. While applying downward pressure on the
hood, push the hood latch handle located
behind the grille near the center front of the
vehicle to the left.
*
[SV03150(B F )01/89]
3. As you open the hood to its fullest extent, a
clock spring will assist you and ªsnapº into
position. The clock spring lift secures the
hood at its fullest height.
*
[SV03300(BEF )03/91]
one third page art:0020333-A
Hood release handle
File:ltsvf.ex
Update:Thu May 9 15:30:19 1996

305
*
[SV03600(B F )06/93]
half page art:0020337-E
Hood and support
*
[SV03775(B F )12/89]
NOTE: Be sure to oil the hood latch every six
months to maintain smooth operation.
*
[SV03900(BEF )05/90]
Always attempt to lift the hood after closing to
be sure it is securely latched.
File:ltsvf.ex
Update:Thu May 9 15:30:19 1996

311
*
[SV06475( F )10/90]
one third page art:0020753-A
Fuel filler door
*
[SV06550(BEF )02/91]
Opening the Fuel Filler Door
*
[SV06600(BEF )10/94]
To open the fuel filler door of your vehicle, just
insert your finger in the divot and pull the door
open all the way.
*
[SV06700( ALL)01/95]
Removing the fuel cap
*
[SV06750( ALL)01/95]
The proper instructions for removing the fuel
cap are as follows:
*
[SV06800( ALL)03/90]
q
Unscrew the fuel cap by exerting pressure on
the plastic lock bar and rotating the fuel cap
counterclockwise.
*
[SV06850( ALL)12/91]
q
Turn the fuel cap 1/2 to 3/4 of a turn until a
hissing sound is heard. Wait until the hissing
sound stops and then continue rotating
counterclockwise to remove the fuel cap.
*
[SV06900( ALL)03/93]
q
Make sure that you follow the above fuel cap
removal instructions and use caution. Such
caution will minimize the possibility of fuel
spraying during removal of the fuel cap.
*
[SV06950( ALL)03/91]
To replace and secure the fuel cap; place it in
position and rotate it clockwise until it clicks
(ratchets). Doing so will not damage or break
the fuel cap. The ratcheting mechanism allows
the fuel cap to be sealed without overtightening.
