1996 FORD F150 display

74
*
[LG08900( ALL)01/95]
High Beam Light
*
[LG09001( ALL)03/95]
This light comes on when the headlamps are
turned on high beam or when you flash the
lights.
*
[LG09025( ALL)11/89]
one inch art:0020537-B
High beam indicator light
*
[LG09300(BEF )03/95]
ªHeadlamps Onº Alert Chime
*
[LG09400(BEF )03/95]
This chime will sound if you open the door
while the headlamps or parklamps are on.
*
[LG09500( ALL)01/95]
Fuel Gauge
*
[LG09700( ALL)06/93]
The fuel gauge displays approximately how
much fuel is in the fuel tank only when the
ignition switch is ON.
*
[LG09860( ALL)06/93]
The fuel gauge indicator may vary slightly when
the vehicle is in motion.
*
[LG09875( ALL)08/93]
With ignition switch OFF, the fuel gauge
indicator may drift from the ignition switch ON
position.
*
[LG10125(B F )06/93]
quarter page art:0020691-C
Fuel gauge
File:ltlgf.ex
Update:Thu May 9 15:22:28 1996

77
*
[LG12756(B F )05/95]
If you are experiencing an ªengine cut-outº
condition at high speeds, it may be the result of
this limiting device. It is a normal condition and
can be avoided by reducing vehicle/engine
speed.
*
[LG12770(B F )03/93]
one third page art:0020871-C
Speedometer
*
[LG13130( ALL)10/92]
Odometer/Trip Odometer
*
[LG13160( ALL)10/92]
The Liquid Crystal Display (LCD) odometer is a
combination trip odometer and total odometer.
The total odometer is normally displayed. To see
the trip odometer, press and release the ªSelectº
button on the upper right side of the
speedometer. To zero out the trip odometer,
press and release the ªResetº button on the
upper left side of the speedometer while the trip
odometer is displayed. If the trip odometer is
displayed, press and release the ªSelectº button
to return the display to the total odometer value.
File:ltlgf.ex
Update:Thu May 9 15:22:28 1996

88
*
[IP16300( F )03/91]
Dual Fuel Tank Selector Switch
*
[IP16400( F )03/91]
Not Available on F-Series Standard
Wheelbase (117") (4 x 4)
*
[IP16501( F )03/91]
To choose which fuel tank that you want your
engine to draw fuel from (front or rear) you
must use this switch. Your fuel gauge will
display the amount of fuel available in the
currently selected tank.
*
[IP16601( F )03/91]
The fuse that protects the fuel tank selector
circuit is labeled AUX FUEL TANK SELECTOR
on your fuse panel cover.
*
[IP16701( F )03/91]
quarter page art:0020066-B
Fuel tank selector switch
File:ltipf.ex
Update:Thu May 9 15:21:29 1996

140
*
[AS01200(BEF )04/95]
Compact Disc Radio
*
[AS01250(BEF )05/95]
The Compact Disc Radio combines the Electronic
Stereo Radio with the Ford Compact Disc Player.
*
[AS01300(BEF )04/95]
Using the Controls on Your New Radio/CD
Player
*
[AS01400(BEF )04/95]
Most of the features of this unit work for both
radio and CD operation. Also, some of the knobs
and buttons control several different functions,
so be sure to read all of the operating
instructions carefully.
*
[AS01500(BEF )04/95]
How to turn the radio on and off
*
[AS01600(BEF )04/95]
Press the ªPOWERº button to turn the radio on.
Press it again to turn it off.
*
[AS01625(BEF )04/95]
How to adjust the volume
*
[AS01650(BEF )05/95]
Press the (+/-) side of the ªVOLº button to
increase/decrease the volume. Bars illuminate in
the display to show the relative volume level.
*
[AS01675(BEF )04/95]
NOTE: If the volume level is set above a
certain listening level when the
ignition switch is turned off, when the
ignition switch is turned back on, the
volume will come back to a ªnominalº
listening level. However, if the radio
power is turned off (with the
ªPOWERº button), the volume will
remain in the position it was set at
when radio power is switched back on.
*
[AS01700(BEF )04/95]
Selecting the AM or FM frequency band
*
[AS01800(BEF )04/95]
Push the ªAM/FMº button to select the desired
frequency band. When in the radio mode,
pushing the button more than once will alternate
between AM, FM1 and FM2. These functions are
used with the station memory buttons described
underHow to tune radio stations.
File:ltasf.ex
Update:Thu May 9 15:15:21 1996

141 %
*
[AS01900(BEF )05/95]
How to tune radio stations
*
[AS02000(BEF )07/94]
There are four ways for you to tune in a
particular station. You can manually locate the
station using the ªSCAN/TUNEº button,
ªSEEKº the station, ªSCANº to the station or
select the station by using the memory buttons,
which you can set to any desired frequency.
These four methods are described below.
*
[AS02100(BEF )04/95]
q
Using the ªSCAN/TUNEº button to manually
tune
*
[AS02200(BEF )04/95]
You can change the frequency up or down
one increment at a time (FM changes in
increments of 200kHz; AM changes in
increments of 10kHz) by first pressing the
ªSCAN/TUNEº button twice (display shows
ªTUNEº), then Ðwithin approximately five
secondsÐpressing and releasing either the
top
aor bottom
bhalf of the ªSEEKº
button. To change frequencies quickly, press
andhold downeither the top or bottom half
of the ªSEEKº button. While you are
manually tuning, the display will show a
blinking ªMº.
*
[AS02300(BEF )04/95]
Manual tuning adjusts your radio to any
allowable broadcast frequency, whether or
not a station is present on that frequency.
(SeeAll About Radio Frequenciesin this
section.)
File:ltasf.ex
Update:Thu May 9 15:15:21 1996

142
*
[AS02400(BEF )04/95]
q
Using the ªSEEKº function
*
[AS02500(BEF )04/95]
This feature on your radio allows you to
automatically select listenable stations up or
down the frequency band. Press the top
a
half of the ªSEEKº button to select the next
listenable station up the frequency band.
Press the bottom
bhalf of the button to
select the next listenable station down the
frequency band. By pressing and holding the
button, listenable stations can be passed over
to reach the desired station.
*
[AS02600(BEF )04/95]
q
Using the ªSCAN/TUNEº button to scan
radio stations
*
[AS02700(BEF )04/95]
Pressing the ªSCAN/TUNEº button once
enters the scan mode (display will indicate
ªSCNº). Pushing the top
ahalf of the
ªSEEKº button will begin the scan mode up
the frequency band, stopping on each
listenable station for approximately five
seconds. Pushing the bottom
bhalf of the
ªSEEKº button will begin the scan mode
down the frequency band, again stopping on
each listenable station for approximately five
seconds.
*
[AS02800(BEF )04/95]
To stop the scan mode on the presently
sampled station press the ªSCAN/TUNEº
button again.
*
[AS03000(BEF )04/95]
q
Setting the Station Memory Preset buttons
*
[AS03100(BEF )04/95]
Your radio is equipped with 5 station memory
buttons. These buttons can be used to select up
to 5 preset AM stations and 10 FM stations (5 in
FM1 and 5 in FM2). Follow the easy steps below
to set these buttons to the desired frequencies.
*
[AS03200(BEF )04/95]
1. Select a band, then select a frequency.
File:ltasf.ex
Update:Thu May 9 15:15:21 1996

143
*
[AS03400(BEF )04/95]
2. Press one of the memory buttons and hold
the button until the sound returns. That
station is now held in memory on that
button.
*
[AS03500(BEF )04/95]
3. Follow the two steps above for each station
memory preset button you want to set.
*
[AS03510(BEF )04/95]
NOTE: If the vehicle's battery is disconnected,
the clock and station memory preset
buttons (if programmed in auto mode)
will need to be reset.
*
[AS03520(BEF )04/95]
q
Using the Automatic Memory Load feature
*
[AS03530(BEF )04/95]
You can activate theAuto Memory Load
feature by pressing and holding the ªAUTO
PRESETº buttonfor approximately three
seconds. Auto Memory Load sets all memory
buttons in AM, FM1 and FM2 sequentially by
seeking out the first five strong stations for
the respective band and storing them in
memory buttons 1-5. (FM2 will store the
second set of strong stations from the FM
band.)
*
[AS03800(BEF )05/95]
With Auto Memory Store, you can
continually set strong stations into your
memory buttons without losing your existing
memory presets, which is especially handy
while traveling. Your radio will automatically
set your memory buttons to the strong local
stations so you don't have to continually
manually tune to existing stations.
*
[AS03900(BEF )05/95]
Activate Auto Memory Store by pushing the
ªAUTO PRESETº button once. Your radio
will set the first five strong stations of the
band you are in (AM, FM1 or FM2) into the
memory buttons. The display will show
ªAUTOº, then run through the frequencies,
stopping momentarily on the stations being
set into the memory buttons. The radio is
File:ltasf.ex
Update:Thu May 9 15:15:21 1996

144
now in the ªAUTOº mode and this display
will show ªAUTOº each time a preset is
activated.
*
[AS04000(BEF )05/95]
NOTE: If there are fewer than five strong
stations in the frequency band, the
remaining unfilled buttons will store
the last strong station detected on the
band.
*
[AS04100(BEF )05/95]
After all stations have been filled, the radio
will begin playing the station stored on
memory button 1.
*
[AS04200(BEF )04/95]
To deactivate the Auto Memory Store mode
and return to the manually-set memory
button stations (or those stations set using
Auto Memory Load), simply push the
ªAUTO PRESETº button. Display will show
ªAUTOº then ªOFFº. The next time Auto
Memory Store is activated on that band, the
radio will store the next set of five strong
stations.
*
[AS04400(BEF )04/95]
Using the ªAUDIOº button to adjust the
tone balance and speaker output
*
[AS04500(BEF )04/95]
q
Increasing or decreasing bass response
*
[AS04600(BEF )04/95]
Push the ªAUDIOº button repeatedly until
the display reads ªBASS.º Push the ª+º side
of the ªVOLº button to increase bass (more
ªlowsº), and push the ª-º side to decrease
bass (less ªlowsº).
*
[AS04700(BEF )04/95]
q
Increasing or decreasing treble response
*
[AS04800(BEF )04/95]
Push the ªAUDIOº button repeatedly until
the display reads ªTREB.º Push the ª+º side
of the ªVOLº button to increase treble (more
ªhighsº), and push the ª-º side to decrease
treble (less ªhighsº).
File:ltasf.ex
Update:Thu May 9 15:15:21 1996
