1996 FORD F150 warning

264 [RE15445( FM)05/95]On F-Super Duty vehicles, the parking brake is
on the transmission. Therefore, the vehicle will
not be prevented from moving when a rear
wheel is lifted, even if the vehicle is in Park and
the parking brake is applied. Be sure to block
both directions of the wheel that is diagonally
opposite to the wheel that is being lifted.
*
[RE15450( FM)05/95]
RWARNING
If the vehicle slips off the jack, you or
someone else could be seriously injured.
*
[RE15550(BEF )05/95]
2. Get out the spare tire and jack.
*
[RE15800(B F )10/92]
The jack and lug wrench are stowed under the
hood on the right front fender inner panel, and
the jack handle is on the radiator support.
*
[RE15900(B F )06/93]
half page art:0020286-E
Jack and assembly location
File:ltref.ex
Update:Thu May 9 15:24:41 1996

265
*
[RE16800(BEF )12/91]
3. Use the tapered end of the lug nut wrench
to unscrew wheel ornaments attached by
retaining screws. Remove any wheel trim.
Insert the tapered end of the lug nut wrench
behind wheel covers or hubcaps and twist
off.
*
[RE16900(BEF )10/89]
4. Loosen the wheel nuts by pulling up on the
handle of the lug nut wrench about one-half
turn (counterclockwise). Do not remove the
wheel lug nuts until you raise the tire off the
ground.
%*
[RE16950(BEF )05/95]
Removing and Replacing the Tire
[RE17100(B F )02/95]
1. Insert the jack handle into the jack and use
the handle to slide the jack under the
vehicle.
*
[RE17175(BEF )05/95]
RWARNING
To avoid injury, never run the engine
with one wheel off the ground, such as
when changing a tire.
*
[RE17200(BEF )05/95]
RWARNING
To lessen the risk of personal injury, do
not put any part of your body under the
vehicle while changing a tire. Do not start
the engine when your vehicle is on the
jack. The jack is only meant for changing
the tire.
File:ltref.ex
Update:Thu May 9 15:24:41 1996

273
*
[RE22425( EF )05/90]
quarter page art:0020317-A
Lug nut tightening sequence
*
[RE22450( FM)03/94]
quarter page art:0020319-C
Lug nut tightening sequence
*
[RE23400(BEF )05/95]
RWARNING
Use of wheels or lug nuts other than
original equipment could cause damage to
the wheel or mounting system and allow
the wheels to come off while the vehicle
is in motion.
*
[RE23500(BEF )01/95]
7. Replace any wheel covers, ornaments, or hub
caps that your vehicle has. Make sure that
they are screwed or snapped into place.
File:ltref.ex
Update:Thu May 9 15:24:41 1996

274 [RE23615(BEF )02/95]8. Put the tire, jack, and wrench away. (Make
sure jack is securely fastened so it doesn't
rattle when you drive.) The carrier is
designed to hold the temporary spare which
comes with your vehicle. The stowage of a
full size tire in the spare tire carrier may
damage the tire or the vehicle. The flat full
size tire should be stowed securely in the
vehicle until it can be repaired.
*
[RE23700(BEF )01/95]
9. Unblock the wheels.
*
[RE24100( EFM)06/93]
On vehicles equipped with dual rear wheels
retighten the wheel lug nuts to the specified
torque at 100 miles (160 km), and again at 500
miles (800 km) of new vehicle operation and at
the intervals specified in theMaintenance Schedule
and Recordbooklet.
*
[RE24200( ALL)10/89]
Also retighten to the specified torque at 500
miles (800 km) of operation after any wheel
change or any time the lug nuts are loosened.
*
[RE24301( ALL)05/95]
RWARNING
Failure to retighten wheel lug nuts at
mileages specified could allow wheels to
come off while the vehicle is in motion.
File:ltref.ex
Update:Thu May 9 15:24:41 1996

280
*
[RE27400(B F )11/92]
q
When towing your vehicle with the rear
wheels on the ground or all four wheels on
the ground and the driveshafts connected, do
not exceed 35 mph (56 km/h) or
transmission damage could result. If a
distance of 50 miles (80 km) is exceeded,
disengage the automatic locking hubs and
disconnect the rear driveshaft from the axle
and secure. (Max speed 55 mph [88 km/h]
with driveshafts disconnected.)
*
[RE27500(BEF )03/91]
RWARNING
Never use a tow bar that attaches to the
bumper when you tow your vehicle. This
could damage the bumper and cause an
accident.
File:ltref.ex
Update:Thu May 9 15:24:41 1996

303
*
[SV02600( ALL)03/95]
Working with the engine off:
*
[SV02660(B F )05/95]
1. Always set the parking brake fully and make
sure that the gearshift is securely latched in
P (Park) (automatic transmission) or in 1
(First) (manual transmission).
*
[SV02675(B F )01/95]
2. When the transfer case is in the N (Neutral)
position, the engine and transmission are
disconnected from the rest of the driveline.
Therefore, the vehicle is free to roll even if
the automatic transmission is in P (Park) or
the manual transmission is in gear. Do not
leave the vehicle unattended with the
transfer case in the N (Neutral) position.
*
[SV02700( ALL)03/95]
3. Remove the key from the ignition after you
turn the engine off.
*
[SV02725( ALL)03/95]
4. Block the wheels. This will prevent your
vehicle from moving unexpectedly.
*
[SV02750( ALL)03/95]
Working with the engine on:1. Always set the parking brake fully and make
sure that the gearshift is securely latched in
P (Park) (automatic transmission) or in 1
(First) (manual transmission).
*
[SV02675(B F )01/95]
2. When the transfer case is in the N (Neutral)
position, the engine and transmission are
disconnected from the rest of the driveline.
Therefore, the vehicle is free to roll even if
the automatic transmission is in P (Park) or
the manual transmission is in gear. Do not
leave the vehicle unattended with the
transfer case in the N (Neutral) position.
*
[SV02900( ALL)02/95]
RWARNING
Do not start your engine with the air
cleaner removed and do not remove it
while the engine is running.
File:ltsvf.ex
Update:Thu May 9 15:30:19 1996

312 [SV06975( ALL)05/95]If you lose the fuel cap, replace it with an
authorized Motorcraft or equivalent part.
%*
[SV07000( ALL)05/95]
RWARNING
If you do not use the proper fuel cap, the
pressure in the fuel tank can damage the
fuel system or cause it to work improperly
in a collision.
*
[SV07025( ALL)05/95]
NOTE: If you replace your fuel cap with an
aftermarket fuel filler cap, the customer
warranty may be void for any damage
to the fuel tank and/or fuel system.
*
[SV07050( ALL)05/95]
RWARNING
If the fuel cap is venting vapor or if you
hear a hissing sound, wait until it stops
before completely removing the cap.
*
[SV07060(BEF )11/89]
A venting fuel tank is not an abnormal
condition. It may be caused by:
*
[SV07061(BEF )03/90]
q
Too volatile a fuel for the weather conditions.
The service stations sometimes sell winter
grade fuel in the summer.
*
[SV07062(BEF )11/89]
q
Pulling a heavy load on hot days, or at high
altitudes.
*
[SV07063(BEF )11/89]
q
Extended periods of idling with the engine
RPM increased above the normal idle range.
*
[SV07064(BEF )11/89]
q
Parking vehicle in full sunlight for extended
periods on extremely hot days.
File:ltsvf.ex
Update:Thu May 9 15:30:19 1996

315
*
[SV09875( ALL)04/95]
Gasolines for clean air
*
[SV09900( ALL)05/95]
Fuels in certain areas of the country are required
to contain oxygenates to improve air quality.
Common oxygenates are ethanol or grain alcohol
(blended at no more than 10%), methanol or
wood alcohol (blended at no more than 5% with
cosolvents and additives), and MTBE or methyl
tertiary butyl ether (blended at no more than
15%).
[SV09950( ALL)04/95]
Reformulated gasoline is also required in certain
areas of the U.S. These fuels are designed to
further reduce the emissions from your vehicle.
[SV10000( ALL)04/95]
Generally, you should not experience difficulties
operating your vehicle on reformulated gasoline
or on fuels containing oxygenates. We encourage
you to use these fuels.
%*
[SV10185( ALL)05/95]
Safety Information Relating to Automotive
Fuels
*
[SV10195( ALL)05/95]
RWARNING
Automotive fuels can cause serious injury
or death if misused or mishandled.
*
[SV10200( ALL)05/95]
Gasoline and other automotive fuels are
extremely flammable. Turn your vehicle off and
do not smoke while refueling your vehicle. Keep
sparks and other sources of ignition away from
fuels.
*
[SV10205( ALL)03/95]
Automotive fuels can be harmful or fatal if
swallowed. Further, gasoline may be blended
with methanol. Even small amounts of methanol
can cause blindness and possibly death when
swallowed. Therefore, never attempt to siphon
any fuel by mouth.
*
[SV10210( ALL)03/95]
If any fuel is swallowed, call a physician or
poison control center immediately.Do not delay
calling a physician merely because no adverse
File:ltsvf.ex
Update:Thu May 9 15:30:19 1996
