Page 1000 of 1938
Component/
GroundColor Location Fig.
Right Rear
Sliding Door
ContactBK RT B-Pillar 14
Right Rear
Sliding Door
Lock MotorBK At Motor N/S
Right Rear
SpeakerBK At Speaker 22
Right Rear Vent
MotorNAT At Motor 22
Right Rear
Wheel Speed
SensorGY Center Rear of
Floor Pan16
Right Repeater
LampGY At Lamp N/S
Right Speed
Control SwitchRight Side of
Steering Wheel
Pad11
Right Stop/Turn
Signal RelayBK LT Quarter
PanelN/S
Right Visor/
Vanity LampBK At Lamp 17
S02 BK Under Seat N/S
Seat Belt Switch BK RT B-Pillar N/S
Sentry Key
Immobilizer
ModuleBK Near Steering
Column at
Module11
Stop Lamp
SwitchGY Top of Brake
Pedal12
T05 BK LT Quarter
PanelN/S
T08 BK RT Quarter
PanelN/SComponent/
GroundColor Location Fig.
Throttle Position
SensorNAT On Throttle
Body5, 6, 7,
8, 9
Trailer Tow
ConnectorBK LT Quarter
PanelN/S
Transmission
Control ModuleBK RT Fender Side
Shield3
Transmission
Range SensorBK Top of
Transmission7. 9
Transmission
Control
SolenoidsBK Front of
Transmission7, 9
Turbine Speed
SensorGY Front of
Transmission7, 9
Turn Signal/
Hazard SwitchBK Part of
Multifunction
Switch11
Upstream
Heated Oxygen
SensorGY Rear of Engine 5, 6, 7,
8, 9
Vehicle Speed
Control ServoBK LT Rear of
Engine
Compartment5, 6, 7,
8, 9
Vehicle Speed
SensorBK Rear of
Transmission5, 6, 8
Windshield
Wiper SwitchBK Part of
Multifunction
Switch11
Wiper Module BK LT Side of
Engine2
8W - 90 - 36 8W - 90 CONNECTOR/GROUND LOCATIONSNS/GS
DESCRIPTION AND OPERATION (Continued)
Page 1002 of 1938
Fig. 2 Engine Compartment ConnetionsÐRHD
8W - 90 - 38 8W - 90 CONNECTOR/GROUND LOCATIONSNS/GS
DESCRIPTION AND OPERATION (Continued)
Page 1003 of 1938
Fig. 3 Engine Compartment ConnectionsÐRHD
NS/GS8W - 90 CONNECTOR/GROUND LOCATIONS 8W - 90 - 39
DESCRIPTION AND OPERATION (Continued)
Page 1004 of 1938
Fig. 4 Engine Compartment ConnectionsÐRHD
8W - 90 - 40 8W - 90 CONNECTOR/GROUND LOCATIONSNS/GS
DESCRIPTION AND OPERATION (Continued)
Page 1005 of 1938
Fig. 5 Engine ConnectionsÐ2.0L, RHD
NS/GS8W - 90 CONNECTOR/GROUND LOCATIONS 8W - 90 - 41
DESCRIPTION AND OPERATION (Continued)
Page 1006 of 1938
Fig. 6 Engine ConnectionsÐ2.4L (M/T), RHD
8W - 90 - 42 8W - 90 CONNECTOR/GROUND LOCATIONSNS/GS
DESCRIPTION AND OPERATION (Continued)
Page 1007 of 1938
Fig. 7 Engine ConnectionsÐ2.4L (A/T), RHD
NS/GS8W - 90 CONNECTOR/GROUND LOCATIONS 8W - 90 - 43
DESCRIPTION AND OPERATION (Continued)
Page 1008 of 1938
Fig. 8 Engine ConnectionsÐ2.5L, RHD
8W - 90 - 44 8W - 90 CONNECTOR/GROUND LOCATIONSNS/GS
DESCRIPTION AND OPERATION (Continued)
