1992 HONDA PRELUDE check engine light

If Your Engine Won't Start, Jump Starting

The Starter Operates
Normally

In this case, the starter motor
sounds normal when you turn the
ignition switch to START (III), but
the engine does not run. Are you using the proper starting
procedure? Refer to Starting
the Engine on page 109 . Do you have gas? Turn the
ignition switch to ON (II) for a
minute and watch the fuel gauge.
There may be an electrical
problem, such as no power to the
fuel pump. Check all the fuses
(see page 199 ).

If you find nothing wrong, you will
need a qualified technician to find
the problem. See Towing on page
202.
Jump Starting

If your car's battery has run down,
you may be able to start the engine
by using a booster battery. Although this seems like a simple
procedure, there are several precau-
tions you should take. Follow the
directions closely.
You cannot start a Honda with an
automatic transmision by pushingor pulling it. To jump start your car:
1. Open the hood and check the physical condition of the battery
(see page 152 ). In very cold
weather, check the condition of the electrolyte. If it seems slushy
or like ice, do not try jump
starting until it thaws.
If a battery sits in extreme cold, the
electrolyte inside can freeze.
Attempting to jump start with a frozen battery can cause it to
rupture or explode.
2. Turn off all the electrical acces- sories: heater, A/C, stereo system,
lights, etc. Put the transmission in Neutral
or Park and set the parking
brake.

Taking Care of the Unexpected
CONTINUED
A battery can explode if you
do not follow the correct

procedure, seriously injuring

anyone nearby.

Keep all sparks, open flames,

and smoking materials away

from the battery.
NOTICE
ProCarManuals.comMain Menu Table of Contents s t

Low Oil Pressure

The low oil pressure light should never come on when the engine is
running. If this light comes on with
the engine running, take immediate

action.

Running the engine with low oil
pressure can cause serious mechani-
cal damage almost immediately.
Turn off the engine as soon as you
can safely get the car stopped. 1. Safely pull off the road and shut
off the engine.

2. Le
t
the car sit for a minute. Open

the hood and check the oil level
(see page 135). Although oil level
and oil pressure are not directly
connected, an engine that is very
low on oil can lose pressure
during cornering and other
driving maneuvers.

3. I f
necessary, add oil to bring the

level back to the full mark on the
dipstick (see page 135
).

4. Star t
the engine and watch the

oil pressure light. If the light
does not go out within ten
seconds, turn off the engine.
There is a mechanical problem
that needs to be repaired before
you can continue driving. (See
Towin g on

page 202 .
)

Taking Car e
of the Unexpected

LOW OIL PRESSURE LIGHT
NOTICEProCarManuals.comMain Menu Table of Contents s t

Check Engine Light
If the
check engine light comes on
while driving, there is a problem with your engine or its emissioncontrol systems. Even though you
may feel no difference in your car's
performance, it can reduce your
fuel economy and cause your car to put out excessive emissions.
Continued operation may cause
serious engine damage. If this light comes on, safely pull
off the road and turn off the engine.
Restart the engine and watch the
check engine light. If it stays on,
have your car checked by the dealer as soon as possible. You
should also have the dealer inspect
your car if the light comes on
frequently, even though it goes off
when you do the above procedure. If you keep driving with the check
engine light on, you can damage
your car's emission controls and
engine. Those repairs are not
covered by your car's warranties.

Taking Care of the Unexpected

CHECK ENGINE LIGHT

NOTICEProCarManuals.comMain Menu Table of Contents s t

Index

Accessories
Installation................................. 105

ACCESSORY
(Ignition Key Position).............. 48

Adding
Automatic Transmission
Fluid........................................ 144

Brake Fluid............................... 146 Clutch Fluid.............................. 147

Engine Oil...:.............................. 135

Manual Transmission Fluid... 145

Power Steering Fluid.............. 148

Radiator Coolant...................... 139

Windshield Washer fluid ........ 143

Additional Safety Information .... 16
Door Locks.................................. 16

Driving with Pets....................... 17

Seat-back Position..................... 16

Storing Cargo Safely................. 17

Additives, Engine Oil................... 136

Adjustments
Mirrors....................................... .
59

Seats............................................. 51
Steering Wheel..........................

43

Airbag (SRS).................................. 1
0

Air Conditioning............................. 68

Maintenance..............................
157

Usage............................................ 6 8

Ai
r Filter........................................
149
Air Outlet
s
(Vents)......................... 68

Air Pressure, Tires ......................
159

Alcohol an d
Drugs.......................... 24

Alcohol in Gasoline........................ 98

Antifreeze......................................
139

Anti-lock Brake s
(ABS)

Description................................
208

Indicator Light.................. .
34,
118

Operation................................... 117

Anti-theft Steerin
g
Column

Lock.............................................. 48

Appearance Care..........................
175

Ashtray............................................. 65

Audio System................................. .
75

Automatic Speed Control............. 44
Automatic Transmission............ 112

Capacity, Fluid........................
.

206

Checking Fluid Level.............. 144

Shifting
...................................... 113

Shift Leve r
Positions...............
112
Shift Lock Release................... 115
Battery
Charging System Light............. 33

Jump Starting............................ 191

Maintenance.............................. 152

Specifications............................ 207

Before Driving
................................ 97

Belts, Seat ......................................... 4
Body Repair
...................................
181

Brakes

Anti-lock Syste
m (ABS)..........
117
Break-in, Ne
w
Linings.............. 98
Fluid............................................
146
Light, Burned-out................... .

169
Parking......................................... 61

System Light.............................. .
33

Wear Indicators.....................
116
Brakes, AB S

Description...............................
.
208

Operation................................... 117

System Indicator...............
.
34,
118

Braking System...........................
.

116

Break-in, Ne
w
Car ......................... 98

CONTINUEDProCarManuals.comMain Menu s t

Index

Brightness Control, Instruments................................. 41
Brights, Headlights........................ 40
Bulb Replacement Back-up Lights......................... 169
Brake Lights.............................

169
Front Parking

Lights ..............
165
Front Side

Marker Lights......
166
Headlights................................. 164
High-mount Brake

Light........
168
License Plate

Lights................
171
Rear Sid
e
Marker Lights........
170

Specifications............................ 207

Turn Signa
l
Lights ..................
167
Bulbs, Halogen.............................
.

164

Cables, Jum
p
Starting With........
191

Capacities Chart...........................
206

Carbo
n Monoxide Hazard ............ 25

Cargo, Loading.............................
106

Cassette Playe r

Care..............................................
. 94

Operation.............................. 81,
91

Catalytic Converter.................... .

213

CAUTION, Explanatio
n
of............ ii
Center Console Compartment..... 64
Certification Label....................... 204

Chains............................................. 163

Change Oil
How to........................................ 137

When to...................................... 129

Changing a Flat Tire................... 185

Changing Engine Coolant........... 140

Charging System Light........ 33, 196
Check Engine Light............. 34, 197

Checking
Automatic Transmission
Fluid........................................
144

Battery Condition.................... .

152

Brake Flui
d
...............................
146

Clutch Fluid.............................
.

147

Engine Belts.............................
.

158

Engine Oil.................................
.

135

Fuses........................................... 199

Manual Transmissio
n
Fluid...
145
Power Steerin
g
Fluid..............
148
Radiator Coolant.....................
.

139
Checklist, Befor
e
Driving...........
108
Child Safety....................................
.
18
Cigarette Lighter........................... 65
Cleaner, Air...................................
149

Cleaning

Exterior......................................
176

Interior....................................... 179

Seat Belts...................................

179

Vinyl........................................... 179
CLEAN Light................................
.
94

Clock, Setting the.......................... 63

Clutch Fluid..................................
147

CO i n
the Exhaust........................
211
Cold Weather
,
Starting in...........
110

Compact Spare.............................
.

184

Consumer Information................
217

Controls, Instruments
and............ 29

Coolant
Adding........................................ 139

Checking.................................... 139

Proper Solution......................... 139

Temperature Gauge.................. 38

Corrosion Protection................... 180

Crankcase Emission Control
System........................................ 211

Cruise Control Operation ............. 44

Customer Relations Office......... 217ProCarManuals.comMain Menu s t

Index

DANGER, Explanation of.............. ii

Dashboard........................................ 30

Daytime Running Lights.............. 40
Dead Battery, What to Do........... 191
Defects, Reporting Safety ............ 26
Defogger, Rear Window ............... 56
Defrosting the Windows............... 74
DEXRON ®
II Automatic
Transmission Fluid.................. 144

Dimensions.................................... 206

Dimming the Headlight
s .............. 40
Dipstick Automatic Transmission........
144

Engine Oil................................. .

135

Directional Signals........................
.
41
Disabled, Towing Your Car If ... 202
Disc Brake Wear Indicators.......
116
Disposal o f
Used Oil.....................
138

Doors

Locking an
d Unlocking ............ 48
Power Door Locks ..................... 48
DOT Tire Quality Grading......... 161
Downshifting,

5-speed Transmission.............. 111

Driving .......................................... .
107

Economy.................................... 104
In Bad Weather......................... 119
In Foreign Countries................. 99
Economy, Fuel.............................. 104
Emergencies on the Road........... 183 Battery, Jump Starting............ 191
Changing a Flat Tire............... 185
Charging System Light........... 196
Check Engine Light................. 197
Checking the Fuses.................
200
Low Oi l
Pressure Light........... 195
Manually Closing Sunroof...... 198
Overheated Engine.................. 193

Emergency Brake ......................... 61

Emergency Flashers...................... 56
Emission Controls......................... 211
Engine Check Light....................... 34, 197
Coolant Temperature Gauge... 38
Oil Pressure Light............. 33, 195
Oil, What Kind to Use .............
135
Overheating............................... 193

Specifications........................... 206

Ethano l
in Gasoline........................ 98
Evaporative Emission Controls......................................
211
Exhaust Fumes.............................. .
25
Expectant Mothers, Use of Seat Belts by.................................. 8
Exterior, Cleaning the.................
176

Fabric, Cleaning........................... 179

Fan, Interior.................................... 68

Fan, Radiator.................................. 27

Features, Comfort
and Convenience........................ 67

Filling the Gas Tank.................... 100

Filters

Air
............................................... 149

Fuel............................................. 150

Oil ............................................... 137

First Gear, Shifting...................... 111

5-Speed Transmissio n
Checkin
g Fluid Level..............
145

CONTINUED
ProCarManuals.comMain Menu s t

Index

5-Speed Transmission,
Shifting the ............................... 111

Flashers, Hazard
Warning ........... 56
Flat Tire, Changing a..................
185
Fluids Automatic Transmission.......
. 144
Brake.......................................... 146
Clutch......................................... 147
Manual Transmission.............. 145
Power Steering......................... 148
Windshield Washer..................
155
FM Stereo
Radio

Reception.............................. 75, 84

Folding Rear Seat.......................... 55
Foreign Countries, Driving in...... 99
Four-way Flashers......................... 56
Four Wheel Steering (4WS)
Description................................ 210

Indicator Light........................... 35

Operation...................................
118

Front End ,
Towing by Emergency

Wrecker..................................... 202

Fuel................................................... 9
8

Fille
r Door and Cap..................
100

Filter........................................... 150

Gauge............................................ 3
8
Octan
e Requirement................. 98

Oxygenated................................. 98

Tank, Filling the ...................... 100

Fuses, Checking the .................... 200

Gas Mileage, Improving.............. 104

Gasohol............................................ 98

Gasoline............................................ 98
Filter...........................................
150

Gauge............................................ 3 8

Octan
e Requirement................. 98
Tank, Filling the ......................
100
Gas Statio n
Procedures...............
100

Gauges

Engine Coolan
t Temperature.. 38

Fuel............................................... 38

Gearshift Lever Positions Automatic Transmission........
112

5-speed Transmission............. .

111

Glass Cleaning.............................
.

180

Glove Box........................................
.
62
Halogen Headlight Bulbs............ 164

Hazard Warning Flashers ............ 56

Headlights
Daytime Running Lights.......... 40

High Beam Indicator................. 35

High Beams, Turning on.......... 40
Low Beams, Turning on........... 40

Reminder Chime........................ 40

Replacing Halogen Bulbs ....... 164

Turning on.................................. 40

Heating and Cooling...................... 68

High Altitude, Starting at...........
110

High-Low Bea m
Switch ............... 40
Hood, Opening the........................
101

Horn.................................................. 4 7

Ho
t Coolant, Warning about......
139

Hydraulic Clutch.........................
.

147

Hydroplaning................................. 119

Identification Number
,

Vehicle......................................
.
204

If You
r
Car Has to be Towed ....
202
ProCarManuals.comMain Menu s t

Index

Octane Requirement, Gasoline.... 98

Odometer......................................... 37

Odometer, Trip............................... 37

Oil Change, How to........................ 137
Change, When
to ......................
129
Checking Engine......................


135
Pressure Light............................

33
Selecting Proper Viscosity
Chart.......................................
136

ON (Ignitio n
Key Position)........... 47
Opening the Hood.........................
101
Opening th e
Trunk ........................ 50
Operation in Foreign Countries... 99
Outside Mirrors.............................. 60
Overheating, Engine....................
193

Panel Brightnes s
Control.............. 41

Park Gear Position.......................
113

Parking Brake................................ .
61

Parking Lights................................ 40

Parking Over Things that
Burn............................................ 213

PGM-FI System............................ 212
Polishing and Waxing..................
177
Power

Door Locks.................................
. 48

Mirrors......................................... 60

Steering...................................... 148
Windows.......................................
57
Pregnancy, Usin g
Seat Belts......... 8
Proper Seat Belt Usage................... 6

Radiator Overheating..................
193

Radio/Cassette Sound System
..... 75

Rear En d
Towing.........................
202

Rear Lights, Bulb

Replacement.............................. 169

Rear Seat, Folding ......................... 55

Rear Vie w
Mirror .......................... 59
Rear Window Defogger ................ 56

Reclining the Seat Backs.............. 52

Recommended Shift Speeds....... 111

Reminder Lights............................
.
31

Replacement Information

Air Filter...................................
.
149

Coolant....................................... 140

Engine Oil and Filter............... 137 Fuel Filter..................................
150

Fuses...........................................
200

Ligh
t Bulbs................................ 164

Schedule..................................... 129

Spark Plugs............................... 150
Tires............................................ 161
Wiper Blades............................. 155
Replacing Seat Belts After a Crash................................. 9

Reserve Tank, Coolant...............
139

Restraint, Child.............................. .
18

Reverse Gear Position..................
114
Rotation, Tire............................... ..

160

Safety Belts......................................
.
5

Safety Defects, Reporting............ 26
Safety Labels, Location of............ 27
Safety Messages............................... ii

Seat Belts........................................... 5
Advice for Pregnant Women..... 8Child Seat Anchor Plate ........... 21
Cleaning.....................................
179
Frayed o r
Torn............................. 9

Maintenance.................................. 9ProCarManuals.comMain Menu s t
