1992 HONDA PRELUDE clock

Instruments and Controls

This section gives information
about the controls and displays that
contribute to the daily operation of

your Honda. All the essential

controls are within easy reach.
Control Locations......................... 30

Indicator Lights.............................. 31

Gauges............................................. 37
Speedometer
.............................
37

Tachometer................................. 37
Odometer
.................................... 37

Trip Meter................................... 37

Fuel Gauge..................................
38
Temperature Gauge
..................

38

Controls Near the
Steering

Wheel
....................................... 39

Headlights................................... 40

Daytime Running Lights.......... 40

Instrument Panel Brightness... 41

Turn Signals................................ 41

Windshield Wipers.....................
42

Windshield Washers.................
42

Steering Wheel Adjustment ....
. 43

Steering Wheel Controls............... 44
Cruise Control............................ 44
Horn ............................................ 47
Keys and Locks.............................. 47

Keys.............................................. 47

Ignition Switch........................... 47

Door Locks.................................. 48
Power Door Locks ..................... 48

Trunk.......................................... 50

Seat Adjustments........................... 51

Rear Seat Access........................ 52
Additional Driver' s
Seat

Adjustments...........................
53

Seat Heaters.................................... 54

Folding Rea r
Seat.......................... 55

Hazard Warning............................ 56

Rear Window Defogger ................ 56

Power Windows.............................. 57

Sunroof ...........................................
58

Mirrors ........................................... 59

Parking Brake................................ .

61

Glove Box........................................
.

62

Digital Clock..................................
.
63

Center Console Compartment .... 64
Vanity
Mirror
..............................
64
Cigarette Lighter
..........................
.
65

Ashtray........................................... 65

Interior Lights...............................
.

66
Instruments an
d
ControlsProCarManuals.comMain Menu s t

Control Locations

MIRROR
CONTROLS(P.60)

FUEL FILLER
DOOR RELEASE
(P.100) DOOR LOCK
SWITCH (P.49) POWER WINDOW
SWITCH
(P.57) DIGITAL CLOCK
(P.63)

TRUNK RELEASE HANDLE
(P.50)
HOOD RELEASE

HANDLE

(P.101)
HEATING/
COOLING
CONTROL

(P.68)

AUDIO SYSTEM (P.75, 84)

Instruments and ControlsProCarManuals.comMain Menu Table of Contents s t

Folding Rear Seat
The back of the right rear seat
folds down, giving you direct
access to the trunk. The seat-back
can be released from inside the car
or inside the trunk.
To fold down the seat-back from
inside the car, insert the master
key in the lock on the rear shelf.
Turn the key clockwise and pull
down the top of the seat-back. To release the seat-back from
inside the trunk, pull the release
loop under the rear shelf.
To lock the seat-back upright, push if firmly against the rear shelf.
Make sure it is latched in place by
pulling on the top of the seat. Make sure all items in the trunk, or
items extending through the opening into the back seat, are tied
down. Loose items can fly forward
and cause injury if you have to
brake hard. See Loading Cargo

on page 106.

Never driv e
with the seat-back
folded down and the trunk lid open.
See Carbon Monoxide Hazard

on page 25.

Instruments and Controls

MASTER KEY

RELEASE LOOPProCarManuals.comMain Menu Table of Contents s t

Glove Box

Open the glove box by turning the
knob clockwise. To close, push the
lid up and turn the knob counter-
clockwise to lock.
Instruments and Controls
KNOB

GLOVE BOX An open glove box can cause
serious injury to your passen-
ger in a crash, even if the pas-
senger is wearing the seat belt.
Always keep the glove box
closed while driving.ProCarManuals.comMain Menu Table of Contents s t

Digital Clock

The digital clock displays the time
with the ignition switch ON (II).
To set the clock:1. Turn the ignition switch ON (II)
to display the time.

2. To
set the hour, turn the knob

toward H (counterclockwise) and
hold it until the hour advances to
the desired time.

3. To
set the minutes, turn the

knob toward M (clockwise) and
hold it until the numbers advance
to the desired time.

You ca
n
use the same knob to
quickly set the time to the nearest
hour. If the displayed time is before
the half hour, pressing the knob
sets the clock back to the previous
hour. If the displayed time is after
the half hour, pressing the knob
sets the clock forward to the
beginning of the next hour.
For example: 1:06 would RESET backward to
1:00. 1:52 would RESET forward to

2:00.

Instruments and

Controls

KNOBProCarManuals.comMain Menu Table of Contents s t

Center Console Compartment, Vanity Mirror

Center Console Compartment

To open the console compartment, pull up on the lever on the left front
corner of the lid.
To close, lower the lid and push it
down until it latches. Use the master key to lock the
console compartment. Turn the
key clockwise to lock, and counter-
clockwise to unlock.
Vanity Mirror

To use the vanity mirror, pull down either sunvisor and swing down the
cover.

Instruments and Controls
LEVER
MASTER KEY

CENTER CONSOLE

COMPARTMENTProCarManuals.comMain Menu Table of Contents s t

Audio System (S)

Operating the Radio

The ignition switch must be in AC- CESSORY (I) or ON (II) to operate
the audio system. Turn the system on by turning the ON/VOL knob
clockwise. The radio comes on and
displays the frequency of the
station it was last tuned to.
The antenna extends automatically.
The system turns off and the anten-
na retracts when you turn the igni-
tion switch to LOCK (0).
Adjust the volume by turning the
ON/VOL knob.
STEREO INDICATOR
ON/VOL KNOB

Select the band you want to listen
to by pressing the AM/FM button.
You will see the selected band and
the frequency in the display.
AM/FM BUTTON

ST will be displayed next to the fre- quency if the station is broadcast-
ing in FM stereo. The AM stereo
feature is not available.

CONTINUED
Comfort and Convenience FeaturesProCarManuals.comMain Menu Table of Contents s t

Audio System (Si, SR)

Operating the Radio

The ignition switch must be in AC-
CESSORY (I) or ON (II) to operate
the audio system. Turn the system on by turning the ON/OFF/VOL
knob clockwise. The radio comes on and displays the frequency of
the station it was last tuned to.
The antenna extends automatically.
The system turns off and the anten-
na retracts when you turn the igni-
tion switch to LOCK (0).
Adjust the volume by turning the ON/OFF/VOL knob.
Select the band you want to listen
to by pressing the AM or FM1/FM2
button. You will see the selected
band and the frequency in the
display.
ST will be displayed next to the fre-
quency if the station is broadcast-
ing in FM stereo. The AM stereo
feature is not available.

Comfort and Convenience Features
STEREO INDICATOR

ON/OFF/VOL KNOB

AM/FM BUTTONProCarManuals.comMain Menu Table of Contents s t
