1991 MITSUBISHI MONTERO relay

Fig. 3: Identifying Rear Wiper Motor Terminals (Montero)
Courtesy of Mitsubishi Motor Sales of America.
Automatic Stop Check (Montero)
1) Start motor operation by connecting battery voltage to one
terminal and grounding another terminal. See
REAR WIPER MOTOR OPERATION CHECK table. See Fig. 3. Disconnect wires
during operation to stop motor in mid-sweep.
2) Jumper terminals No. 2 and 3 together. Connect battery
voltage to remaining terminal and ground wiper motor bracket. Ensure
motor parks wiper arm.
REAR WIPER RELAY
Operation Check (Montero)
Relay is located to right of heater blower assembly. Leave
intermittent relay connected to wiring harness. Operate rear wiper and
check voltage at terminal No. 1. See Fig. 4. There should be 12 volts
when rear wiper stops. Zero volts should be present when rear wiper is
operating.
Fig. 4: Identifying Rear Wiper Relay Terminals
Courtesy of Mitsubishi Motor Sales of America.
REAR WIPER SWITCH

article in the ACCESSORIES/SAFETY EQUIP Section.
REAR WIPER MOTOR
Removal & Installation
Remove wiper blade and arm assembly. Remove tailgate trim, 2
bolts and wiper motor. To install, reverse removal procedure. Ensure
grommet is in good condition.
REAR WIPER RELAY
Removal & Installation
Rear wiper relay (Except Montero), is located behind right
rear quarter trim. On Montero, relay is located to right of heater
blower housing.
REAR WIPER SWITCH
Removal & Installation
Using flat-bladed tool, pry rear wiper switch from instrument
panel and remove wiring connector. To install, connect wiring
connector, and push switch into instrument panel.
WIRING DIAGRAMS
See appropriate chassis wiring diagram in the WIRING DIAGRAMS
section.

WIR IN G D IA G RAM S YM BO LS
1991 M it s u bis h i M onte ro
WIRING DIAGRAMS
How To Use The Wiring Diagrams
WIRING DIAGRAMS
INTRODUCTION
The wiring diagrams and technical service bulletins,
containing wiring diagram changes, are obtained from the domestic and
import manufacturers. These are checked for accuracy and are all
redrawn into a consistent format for easy use.
All diagrams are arranged with the front of the vehicle at
the left side of the first page and the rear of the vehicle at the
right side of the last page. Accessories are shown near the end of the
diagram.
Components are shown in their approximate location on the
vehicle. Due to the constantly increasing number of components on
vehicles today, it is impossible to show exact locations.
In the past, when cars were simpler, diagrams were simpler.
All components were connected by wires, and diagrams seldom exceeded 4
pages in length. Today some wiring diagrams require more than 16
pages. It would be impractical to expect a service technician to trace
a wire from page 1 across every page to page 16.
Removing some of the wiring maze reduces eyestrain and time
wasted searching across several pages. Today, the majority of diagrams
now follow a much improved format, which permits space for internal
switch details and connector shapes.
Any wires that don't connect directly to their components are
identified on the diagram to indicate where they go. There is a legend
on the first page of each diagram, detailing component location. It
refers you to sub-systems, using grid NUMBERS at the top and bottom of
the page and grid LETTERS on each side. This grid system works in a
manner similar to that of a road map.
HOW TO USE THE WIRING DIAGRAMS
1) On the first page of the diagram, you will find a listing
of major electrical components or systems. Locate the specific
component or system you wish to trace. A grid number and letter will
follow the component's name.
2) Use the grid NUMBERS (arranged horizontally across the top\
and bottom of each page) to find the page of the wiring diagram that
contains the component you're seeking. When you reach this page, use
the grid LETTERS on the side of the page to determine the component's
vertical location.
3) Locate the circuit you need to service. The internals are
shown for switches and relays to assist you in understanding how the
circuit operates.
NOTE: In some of the newer wiring diagram articles in this
product, there is a Legend for the wiring diagrams that has
been created to make locating components easier. For these
articles, there will be a COMPONENT LOCATION MENU title in
the article main menu. These articles will also have the
original legend available on the first graphic.

White .................. WHT ................... WT
Yellow ................. YEL ................... YL









\









\









\









\









\









\

WIRING DIAGRAM SYMBOL IDENTIFICATION
NOTE: Standard wiring symbols are used on diagrams. The list below
will help clarify any symbols that are not easily understood
at a glance. Most components are labeled "Motor", "Switch" or
"Relay" in addition to being drawn with the standard symbol.
WIRING DIAGRAM SYMBOLS
Views of the symbols used in the WIRING DIAGRAM articles are
in the following graphics. See Figs. 3 through 25.
Fig. 3: Circuit Breaker
Fig. 4: Coil (Internal)
Fig. 5: Connector
Fig. 6: Diode (In-Line)
Fig. 7: Diode (Internal)

WIR IN G D IA G RAM S

1991 M it s u bis h i M onte ro
1991 Wiring Diagrams
Mitsubishi
Montero
IDENTIFICATION
COMPONENT LOCATION MENU
COMPONENT LOCATIONS TABLE








\









\









\









\









\









\






Component Figure No. (Location)
A/C RELAYS .......................... 4 (C 12), 4 (A-B 15)
A/C SYSTEM ................................. 4 (A-C 12-15)
ALTERNATOR ................................... 1 (B-C 1-2)
ALTERNATOR RELAY ............................... 1 (C 1-2)
AUTO FREE-WHEELING HUB CONTROL UNIT ............. 3 (D 11)
BACK DOOR LOCK SW ............................... 7 (B 27)
BACK-UP LT SW (M/T) ............................. 7 (A 26)
BATTERY .......................................... 1 (A 1)
BLOWER SWITCH ................................. 4 (A-B 12)
BUZZER .......................................... 5 (E 17)
CARGO LIGHT ..................................... 6 (A 23)
CIG LIGHTER ..................................... 3 (E 11)
CLOCK ........................................... 3 (E 11)
COLUMN SW ..................................... 5 (A-E 19)
CRUISE CONTROL SYSTEM ...................... 4 (D-E 13-15)
DEFOGGER ...................................... 7 (C-D 27)
DIAG CONNECTION .................................. 2 (E 7)
DIMMER CONTROL SWITCH ............................ 3 (E 8)
DIR FLASHER ..................................... 5 (C 16)
DIR SWITCH ...................................... 5 (C 19)
DOME LT ............................... 6 (A 23), 7 (A 24)
DOOR LOCK SYSTEM ........................... 6 (D-E 21-23)
DOOR SWITCHES ......................... 5 (D 17), 6 (C 23)
FRONT WIPER SYSTEM ........................... 5 (A 16-17)
FUEL GAUGE UNIT ................................. 6 (C 22)
FUEL PUMP ........................................ 2 (C 4)
FUSE BLOCK .................................... 3 (C 9-10)
HAZARD FLASHER .................................. 5 (C 16)
HAZARD SW ....................................... 5 (B 16)
HEAD LIGHT WASHER RELAY ....................... 5 (C-D 17)
HEATER RELAY .................................... 4 (A 12)
HORN SWITCH ..................................... 5 (E 19)
IGNITION COIL .................................... 2 (E 4)
IGNITION SW ..................................... 3 (A 11)
ILLUMINATION LIGHTS ............................ 3 (D-E 8)
INHIBITOR SW ..................................... 3 (A 9)
INSTRUMENT CLUSTER ............................ 6 (A-D 20)
KEY REMINDER SW ................................. 5 (E-17)
LIGHT CONTROL RELAY ............................. 5 (E 19)
LIGHT SWITCH .................................... 5 (D 19)
MAIN FUSE LINKS ................................ 1 (A 1-2)
METER UNIT ...................................... 6 (E 20)
MPI CONTROL RELAY ................................ 2 (B 4)
MPI CONTROL UNIT ............................... 2 (A 4-7)
NOISE FILTER ..................................... 2 (E 6)
OVERDRIVE CONTROL RELAY .......................... 3 (A 8)
