ELECTRICAL WIRING ROUTING
Position of Parts in Instrument Panel
A 12 A/C Control Assembly C 9 CD Player
A 13 A/C Control Assembly C 10 Center Airbag Sensor Assembly
A 14 A/C Control Assembly C 11 Cigarette Lighter
A 15 A/C Control SW and Radio SW C 12 Combination Meter
A 16 A/C Evaporator Temp. Sensor C 13 Combination Meter
A 17 A/C Power Transistor C 14Combination Meter
A 18 A/C Power Transistor C 15 Combination SW
A 19 A/C Room Temp. Sensor C 16 Combination SW
A 20 A/C Solar Sensor C 17 Combination SW
A 21 A/T Indicator Light (for Shift Lever) C 19 Cruise Control ECU
A 22 ABS ECU (for M/T, w/o Traction Control) C 23 Clutch Start SW
A 23 ABS ECU (for M/T, w/o Traction Control) C 24 Cruise Control Clutch SW
A 24 ABS and Traction ECU
A 25 ABS and Traction ECU D 1 Diode (for Brake Fluid Level)
A 26 ABS and Traction ECU D 2 Diode (for Parking Brake)
A 27 Air Mix Control Servo Motor D 3 Diode (for Tension Reduser)
A 28 Air Vent Mode Control Servo Motor
A 29 Airbag Squib E 8 ECT Pattern Select SW
A 33 Air Inlet Control Servo Motor E 9 Engine and ECT ECU (for A/T) E 10 Engine and ECT ECU (for A/T)
B 2 Blower Motor E 11 Engine ECU (for M/T)
B 3 Blower Resistor (for Low Speed) E 12 Engine ECU (for M/T)
F 10 Fuel Lid Opener SW
G 1 Glove Box Light
G 2 Glove Box Light SW
WhereEverybodyKnowsYourName

29
Position of Parts in Instrument Panel
H 7 Hazard SW S 10 Shift Lock ECUS 11 Step Light
I 14 Ignition Key Cylinder Light S 12 Stop Light SW
I 15 Ignition SW, Unlock Warning SW and Key Inter Lock Solenoid S 22 Short Connector
I 16 Integration Relay S 23 Short Connector S 24 Seat Heater SW (for M/T)
K 3 Kick Down SW T 6 TDCL (Total Diagnostic Communication Link)
L 1 Luggage Compartment Door Open SW T 7 Telescopic Position Sensor T 8 Theft Deterrent and Door Lock Control ECU
N 4 Noise Filter (for A/C System) T 9 Theft Deterrent and Door Lock Control ECU T 10 Tilt and Power Telescopic ECU
O 5 O/D Main SW T 11 Tilt and Power Telescopic ECU T 12 Traction Cut SW and Seat Heater SW (for A/T)
P 2 PPS ECU T 13 Traction ECU (for A/T)
P 3 Parking Brake SW T 14 Traction ECU (for A/T) T 15 Trip SW and Theft Deterrent Indicator Light
R 2 Radio and Player
R 3 Radio and Player W 6 Water Temp. Sensor (for A/C System)
R 4 Radio and Player (w/ CD Player) W 7 Wireless Door Lock Main SW
R 5 Radio and Player (w/o CD Player)
R 6 Radio and Player (w/o CD Player)
R 7 Remote Control Mirror ECU
R 8 Remote Control Mirror ECU
R 9 Rheostat
WhereEverybodyKnowsYourName

149
1K
4 1I
10
B
9B 64 A 12
1
IJ2
2IJ2 1IJ1
6
PARKING
BRAKE SWM42
4 31
5
7
6
23
1 25A
STOP
7. 5A
ST
POTENTIO METER
CRUIS E CONTROL ACTUATOR GN DL
MC
MO
VR3
VR2
VR1
MAGNETIC
CLUTCH
S2 IDL1 OD1
ECT IDL OD VR1 VR2 VR3 MC MO L STP±
N& C STP+
CRUISE CONTROL ECU
STOP
LIGHT
SW
B±W B±W
W
B±W
W
W
G±W BR±Y
R
W±R
W±R
R
BR±Y
R±B
LG±R P
LG
G±R
W
R±L R±B
LG±R P
LG
G±R B±W
W±B
I9
S12
C19
P3C8
FROM POWER SOURCE SYSTEM
(
SEE PAGE 56 )
R±W
B
PKB
ENGINE AND ECT ECU E9 ,E10
I7
EA
IE 2
10
IE2
11
IE2
5
IE2
1
IE2
6
IE2
2
IG1
19
IJ2
9
B (
CANA DA )
(
USA )
R±L
22 23 9 3 24 25 26 12 11 10 16 1
A B IJ2
10
I9
C24 C23
CLUTCH
START SW CRUISE
CONTROL
CLUTCH SW(
A/T )
B±W
BB±W
B±W
B±W
(
A/T )
(
A/T )
1
2
2
21
WhereEverybodyKnowsYourName

150
CRUISE CONTROL
CURRENT IS APPLIED AT ALL TIMES THROUGH STOP FUSE TO TERMINAL 1 OF THE CONTROL ECU TERMINAL 2 OF STOP LIGHT
SWITCH, AND ALSO THROUGH THE DOME FUSE TO TERMINAL 15 OF CRUISE CONTROL ECU.
WITH THE IGNITION SWITCH TURNED TO ON, THE CURRENT FLOWS THROUGH GAUGE FUSE TO TERMINAL (A)1 OF COMBINATION
METER AND THE CURRENT THROUGH ECU±IG FUSE FLOWS TO TERMINAL 14 OF CRUISE CONTROL ECU.
WHEN THE IGNITION SWITCH IS ON AND THE CRUISE CONTROL MAIN SWITCH IS TUR\
NED ON, A SIGNAL IS INPUT FROM TERMINAL
15 OF CRUISE CONTROL MAIN SWITCH TO TERMINAL 4 OF CRUISE CONTROL ECU. AS A RESULT, THE CRUISE CONTROL ECU
FUNCTIONS AND THE CURRENT TO TERMINAL 14 OF CRUISE CONTROL ECU TO TERMINAL 13 OF CRUISE CONTROL ECU "
GROUND, AND THE CRUISE CONTROL SYSTEM IS IN A CONDITION READY FOR OPERATION.
AT THE SAME TIME, THE CURRENT THROUGH THE GAUGE FUSE FLOWS FROM TERMINAL (A)1 OF CRUISE CONTROL INDICATOR
LIGHT " TERMINAL (B)20 "TERMINAL 5 OF CRUISE CONTROL ECU "TERMINAL 13 " TO GROUND, CAUSING THE CRUISE
CONTROL INDICATOR LIGHT TO LIGHT UP, INDICATING THAT THE CRUISE CONTROL IS READY FOR OPERATION.
1. SET OPERATION
WHEN THE CRUISE CONTROL MAIN SWITCH IS TURNED ON AND THE SET SWITCH IS PUSHE\
D WITH THE VEHICLE SPEED WITHIN
THE SET LIMIT (APPROX. 40 KM/H, 2.5 MPH TO 200 KM/H, 124 MPH), A SIGNAL IS INPUT TO TERMINAL 18 OF THE CRUISE CONTROL
ECU AND THE VEHICLE SPEED AT THE TIME THE SET SWITCH IS RELEASED IS MEMORIZED IN THE ECU AS THE SET\
SPEED.
2. SET SPEED CONTROL
DURING CRUISE CONTROL DRIVING, THE ECU COMPARES THE SET SPEED MEMORIZED IN THE ECU WITH THE ACTUAL VEHICLE
SPEED INPUT INTO TERMINAL 20 OF THE CRUISE CONTROL ECU FROM THE SPEED SENSOR, AND CONTROLS THE CRUIS\
E
CONTROL ACTUATOR TO MAINTAIN THE SET SPEED.
WHEN THE ACTUAL SPEED IS LOWER THAN THE SET SPEED, THE ECU CAUSES THE CURREN\
T TO THE CRUISE CONTROL
ACTUATOR TO FLOW FROM TERMINAL 12 " TERMINAL 6 OF CRUISE CONTROL ACTUATOR "TERMINAL 7 " TERMINAL 11 OF
CRUISE CONTROL ECU. AS A RESULT, THE MOTOR IN THE CRUISE CONTROL ACTUATOR IS ROTATED TO OPEN THE THROTTLE
VALVE AND THE THROTTLE CABLE IS PULLED TO INCREASE THE VEHICLE SPEED. WHEN THE ACTUAL DRIVING SPEED IS HIGHER
THAN THE SET SPEED, THE CURRENT TO CRUISE CONTROL ACTUATOR FLOWS FROM TERMINAL 11 OF ECU "TERMINAL 7 OF
CRUISE CONTROL ACTUATOR "TERMINAL 6 "TERMINAL 12 OF CRUISE CONTROL ECU.
THIS CAUSES THE MOTOR IN THE CRUISE CONTROL ACTUATOR TO ROTATE TO CLOSE THE THROTTLE VALVE AND RETURN THE
THROTTLE CABLE TO DECREASE THE VEHICLE SPEED.
3. COAST CONTROL
DURING THE CRUISE CONTROL DRIVING, WHILE THE COAST SWITCH IS ON, THE CRUISE CONTROL ACTUATOR RETURNS THE
THROTTLE CABLE TO CLOSE THE THROTTLE VALVE AND DECREASE THE DRIVING SPEED. THE VEHICLE SPEED WHEN THE COAST
SWITCH IS TURNED OFF IS MEMORIZED AND THE VEHICLE CONTINUES AT THE NEW SET SPEED.
4. ACCEL CONTROL
DURING CRUISE CONTROL DRIVING, WHILE THE ACCEL SWITCH IS TURNED ON, THE CRUISE\
CONTROL ACTUATOR PULLS THE
THROTTLE CABLE TO OPEN THE THROTTLE VALVE AND INCREASE THE DRIVING SPEED.
THE VEHICLE SPEED WHEN THE ACCEL SWITCH IS TURNED OFF IS MEMORIZED AND THE \
VEHICLE CONTINUES AT THE NEW SET
SPEED.
5. RESUME CONTROL
UNLESS THE VEHICLE SPEED FALLS BELOW THE MINIMUM SPEED LIMIT (APPROX. 40 KM/H, 25 MPH) AFTER CANCELING THE SET
SPEED BY THE CANCEL SWITCH, PUSHING THE RESUME SWITCH WILL CAUSE THE VEHICLE \
TO RESUME THE SPEED SET BEFORE
CANCELLATION.
6. MANUAL CANCEL MECHANISM
IF ANY OF THE FOLLOWING OPERATIONS OCCURS DURING CRUISE CONTROL OPERATION, THE SAFETY MAGNETIC CLUTCH OF
THE ACTUATOR TURNS OFF AND THE MOTOR ROTATES TO CLOSE THE THROTTLE VALVE AND THE CRUISE CONTROL IS
RELEASED.
* PLACING THE SHIFT LEVER IN ªNº RANGE (NEUTRAL START SWITCH ON)). ªSIGNAL INPUT TO TERMINAL 2 OF ECUº
* DEPRESSING THE BRAKE LEVER (STOP LIGHT SWITCH ON). ªSIGNAL INPUT TO TERMINAL 16 OF ECUº
* PULLING THE PARKING BRAKE PEDAL (PARKING BRAKE SWITCH ON). ªSIGNAL INPUT TO TERMINAL 3 OF ECUº
* PUSHING THE CANCEL SWITCH (CANCEL SWITCH ON). ªSIGNAL INPUT TO TERMINAL 18ª
SYSTEM OUTLINE
WhereEverybodyKnowsYourName

130
ECT AND A/T INDICATOR
THIS SYSTEM, ELECTRICALLY CONTROLS THE LINE PRESSURE, THROTTLE PRESSURE, LOCK±UP PRESSURE AND\
ACCUMULATOR
PRESSURE ETC. THROUGH THE SOLENOID VALVE. THE ECT IS A SYSTEM WHICH PRECISELY CONTROLS GEAR SHIFT TIMING AND
LOCK±UP TIMING IN RESPONSE TO THE VEHICLE'S DRIVING CONDITIONS AND THE ENGINE OPERATING CONDITIONS DETECTED
BY VARIOUS SENSORS, MAKING SMOOTH DRIVING POSSIBLE BY SHIFT SELECTION FOR EA\
CH GEAR WHICH IS THE MOST
APPROPRIATE TO THE DRIVING CONDITIONS AT THAT TIME, AND CONTROLS THE ENGINE TORQUE DURING SHIFTING TO ACHIEVE
OPTIMUM SHIFT FEELING.
1. GEAR SHIFT OPERATION
WHEN DRIVING, THE ENGINE WARM UP CONDITION IS INPUT AS A SIGNAL TO TERMINAL (B)44 OF THE ECU FROM THE EFI WATER
TEMP. SENSOR AND THE VEHICLE SPEED SIGNAL FROM SPEED SENSOR NO.2 IS INPUT TO TERMINAL (B)23 OF THE ECU. AT THE
SAME TIME, THE THROTTLE VALVE OPENING SIGNAL FROM THE THROTTLE POSITION SENSOR (MAIN) IS INPUT TO TERMINAL
(B)43 OF THE ECU AS ENGINE RPM CONDITION (IDLING, HIGH LOAD AND ACCELERATION CONDITIONS) SIGNAL.
BASED ON THESE SIGNALS, THE ECU SELECTS THE BEST SHIFT POSITION FOR DRIVING C\
ONDITIONS AND SENDS CURRENT TO
THE ECT SOLENOIDS.
WHEN SHIFTING TO 1ST SPEED, THE CURRENT FLOWS FROM TERMINAL (B)10 OF THE ECU " TERMINAL 1 OF ECT SOLENOIDS "
GROUND AND CONTINUITY TO NO.1 SOLENOID CAUSES THE SHIFT (NO.2 SOLENOID DOES NOT HAVE CONTINUITY AT THIS TIME).
FOR 2ND SPEED, THE CURRENT FLOWS SIMULTANEOUSLY FROM TERMINAL (B)9 OF THE ECU " TERMINAL 2 OF ECT SOLENOIDS
" GROUND, AND FROM TERMINAL (B)10 OF THE ECU " TERMINAL 1 OF ECT SOLENOIDS " GROUND, AND CONTINUITY TO NO.1
AND NO.2 SOLENOIDS CAUSES THE SHIFT.
FOR 3RD SPEED, THERE IS NO CONTINUITY TO NO.1 SOLENOID, ONLY TO NO.2 SOLENOID, CAUSING THE SHIFT.
SHIFTING INTO THE 4TH SPEED (OVERDRIVE) OCCURS WHEN NO CURRENT FLOWS TO NO.1 AND NO.2 SOLENOIDS. THE NO.4
SOLENOID (FOR ACCUMULATOR BACK PRESSURE MODULATION) IS INSTALLED TO ADJUST THE BACK PRESSURE ON THE
ACCUMULATOR AND CONTROL THE HYDRAULIC PRESSURE DURING SHIFTING AND LOCK±UP IN \
ORDER TO PROVIDE SMOOTH
SHIFTING WITH LITTLE SHIFT SHOCK.
2. LOCK±UP OPERATION
WHEN THE ECT ECU DECIDES, BASED ON EACH SIGNAL, THAT THE LOCK±UP CONDITION HAS BEEN MET, THE CURRENT FLOWS
FROM " TERMINAL (B)8 OF THE ECU " TERMINAL 3 OF THE ECT SOLENOID " GROUND, CAUSING CONTINUITY TO THE LOCK±UP
SOLENOID AND CAUSING LOCK±UP OPERATION.
3. STOP LIGHT SW CIRCUIT
IF THE BRAKE PEDAL IS DEPRESSED (STOP LIGHT SW ON) WHEN DRIVING IN LOCK±UP CONDITION, A SIGNAL IS INPUT\
TO
TERMINAL (A)4 OF THE ECU. THE ECU OPERATES AND CUTS THE CURRENT TO THE SOLENOID TO RELEASE LOCK±UP.
4. OVERDRIVE CIRCUIT
*O/D MAIN SW ON
WHEN THE O/D MAIN SW IS TURNED ON (SW POINT IS OPEN), A SIGNAL IS INPU\
T TO TERMINAL (A)28 OF THE ECU AND THE ECT
CAUSES SHIFT TO OVERDRIVE WHEN THE CONDITIONS FOR OVERDRIVE ARE MET.
* O/D MAIN SW OFF
WHEN THE O/D MAIN SW IS TURNED OFF (SW POINT IS CLOSED), THE CURRENT FLOWI\
NG THROUGH THE O/D OFF INDICATOR
LIGHT FLOWS TO GROUND BY WAY OF THE O/D MAIN SW AND CAUSES THE O/D OFF INDICATOR LIGHT TO LIGHT UP. AT THE
SAME TIME, A SIGNAL IS INPUT TO TERMINAL (A)28 OF THE ECU AND THE ECT PREVENTS SHIFT INTO OVERDRIVE.
5. ECT PATTERN SELECT SW CIRCUIT
WHEN THE ECT PATTERN SELECT SW IS CHANGED FROM ªNORMALº TO ªPOWERº, THE CURRENT THROUGH THE GAUGE FUSE
FLOWS TO TERMINAL 4 OF ECT PATTERN SELECT SW " TERMINAL 3 " TERMINAL (B)4 OF A/T INDICATOR " TERMINAL (C)23 "
GROUND AND CAUSES THE INDICATOR LIGHT TO LIGHT UP. AT THE SAME TIME, THE CURRENT FLOWS TO TERMINAL (A)18 OF
THE ECU AND THE ECU PERFORMS SHIFT UP AND SHIFT DOWN AT A HIGHER VEHICLE SPEED RANGE COMPARED WITH
ªNORMALº POSITION.
6. KICK DOWN OPERATION
WHEN THE ACCELERATOR IS DEPRESSED FURTHER THAN THE FULL THROTTLE POSITION WHILE DRIVING, THE KICK DOWN SW
TURNS ON AND ITS SIGNAL IS INPUT TO TERMINAL (A)3 OF THE ECU. THEN, THE ECU CONTROLS THE CURRENT WHICH FLOWS
FROM TERMINALS (B)10 AND (B)9 OF THE ECU TO THE NO. 1 AND NO. 2 SOLENOIDS AND SHIFTS DOWN BY TURNING THE
SOLENOIDS ON AND OFF.
7. CRUISE CONTROL
WHEN CRUISE CONTROL OPERATION IS SELECTED A SIGNAL IS INPUT TO TERMINAL (A)12 OF THE ECU FROM CRUISE CONTROL
ECU. AS A RESULT, THE ECU OPERATES AND CONTROLS OVERDRIVE, LOCK±UP AND SO ON FOR SMOOTH DRIVING.
SYSTEM OUTLINE
WhereEverybodyKnowsYourName

131
E 1 ECT SOLENOID
1±4 : APPROX. 5.3

2±5 : APPROX. 3.7

3±GROUND : APPROX. 13.2

6±GROUND : APPROX. 13.2

E 2 EFI WATER TEMP. SENSOR
1±2 : APPROX. 16.2K
( ±20 °C ±4 °F)
APPROX. 2.5K
( 20 °C 68 °F)
APPROX. 0.32K
( 80 °C 176 °F)
E 8 ECT PATTERN SELECT SW
4±3 : CLOSED WITH ECT PATTERN SELECT SW AT POWER POSITION
E 9(A), E10(B) ENGINE AND ECT ECU
BATT ± E1: ALWAYS APPROX. 12 VOLTS
IGSW ± E1: APPROX. 12 VOLTS WITH IGNITION SW ON
BK ± E1: APPROX. 12 VOLTS WITH BRAKE PEDAL DEPRESSED
P ± E1: APPROX. 12 VOLTS WITH IGNITION SW ON POSITION AND ECT PATTERN SELECT SW AT POWER POSITION
KD±GROUND :CONTINUITY WITH KICK DOWN SW ON
OD2 ± E1: APPROX. 12 VOLTS WITH O/D MAIN SW ON
0 VOLTS WITH O/D MAIN SW ON
+B±GROUND : APPROX. 12 VOLTS WITH IGNITION SW AT ON POSITION
+B1±GROUND : APPROX. 12 VOLTS WITH IGNITION SW AT ON POSITION
MREL±GROUND:APPROX. 12 VOLTS WITH IGNITION SW AT ON POSITION
E01±GROUND : ALWAYS CONTINUITY
E02±GROUND : ALWAYS CONTINUITY
L±GROUND : APPROX. 12 VOLTS WITH SHIFT LEVER AT ªLº RANGE
2±GROUND : APPROX. 12 VOLTS WITH SHIFT LEVER AT ª2º RANGE
R±GROUND : APPROX. 12 VOLTS WITH SHIFT LEVER AT ªRº RANGE
E1±GROUND : ALWAYS CONTINUITY
VC±VTA1 : LESS THAN 1 VOLTS WITH THROTTLE VALVE FULLY CLOSED
MORE THAN 3 VOLTS WITH THROTTLE VALVE OPEN
VTA1 ± E2: CONTINUITY WITH THROTTLE VALVE FULLY CLOSED APPROX. 4K
WITH THROTTLE VALVE FULLY OPEN
VC ± E2: APPROX. 5 VOLTS
O 1 O/D DIRECT CLUTCH SPEED SENSOR
1±2 : APPROX. 620

S 4 SPEED SENSOR NO.2 (FOR ECT)
1±2 : APPROX. 620

S12 STOP LIGHT SW
2±1 : CLOSED WITH BRAKE PEDAL DEPRESSED
SERVICE HINTS
WhereEverybodyKnowsYourName

236
GROUND POINT
FRONT TURN SIGNAL
LIGHT LH
ENGINE HOOD
COURTESY SW
TRACTION PUMP AND
MOTOR
HEATER RELAY
ABS ACTUATOR RELAY
TELEPHONE
TRANSCEIVER
AND SPEAKER RELAY
ENGINE OIL LEVEL
WARNING SW
COMBINATION METER
(E1 )
EFI ECU
TRACTION ECU
CHECK CONNECTOR
(
E1 ) CORNERING LIGHT LH
FRONT SIDE MAKER
LIGHT LH
BRAKE FLUID LEVEL
SW
FRONT CLEARANCE
LIGHT LH
FRONT SIDE MAKER
LIGHT RH
FRONT CLEARANCE
LIGHT RH
ABS ACTUATOR
FRONT TURN SIGNAL
LIGHT RH
CRUISE CONTROL
ACTUATOR
OXYGEN SENSOR SUB
(
FOR USA SPEC. )
TDCL (
E1 )
WASHER LEVEL SW EFI MAIN RELAY
CORNERING LIGHT RH
A/C PRESSURE SW
(HI GH PRESSURE )
AIR FLOW METER POWER STERRI NG
PRESSURE SW
NOISE FI LTER
(
FOR IGNI TION SYSTEM ) E4
E10
E12 2
2
BS1 4 E4
E7
E1 E5
EB EA I23
I33
E1 6
I32
E20
E20
E20
IK2 24
ED EC IK1
1 BY1
5
W±B
W±B
W±B
W±B
W±B
W±B
W±B
W±B
W± B W±B
W±B
W±B
W±B
W±B
W±B
W±B
W±B
W±B
W±B
W±B
W±B BR
BR
W±B BR
BR
BR
W±B BR
BR±B BR BR
BR
BR
W± B
W± B
W± B
W± B
W± B
W± B
W± B
W±B
W±B
BR
BR
BR
BR BR
BR
BR
W±B
BR BR
BR
( EO1 )
( E11 )
( E1 )
( EO2 )
I27BR
(
S1 )
( E1 )
NOISE FILTER (
FOR
IGNITION SYSTEM )W±B
W/ TRACTION SYSTEM
NOI SE FILTER
(
FOR DEFOGGER SYSTEM )
W±B
W±B
WhereEverybodyKnowsYourName

OVERALL ELECTRICAL WIRING DIAGRAM
1234
8 LEXUS SC300 (
Cont . ne xt pa ge )
4 ACC
IG1
ST1
AM1 2
1J
7 66 66 66 66
21J
5
1B
4 6666
66 66 66 2 1I
8
4 3 5 4
2
4 3
2
1 4
3
2
1 6
4
3
1
71124 1F 2F 3F
AABA A A B
C
B
A
B
A
A
A
A
A
A
BAABAABBB A A A A A B GGGF F
F
M
15 2 12 1 25 21 24 10 1 9
1 1326128 7 222 13 5 18 16 17 4 4 7IE2
1IO1
2 3
1 2
1
6
EB EA IJ M
2Bc2
12 IE2
H
4H 5H6H1H 2H3
I
2I 1J1
SFR SFL SRR SRL AST MT BSR BSM BSA
BS BM GND E2 PR VC SRC SMC SAC
MTT
BT M
EM2
BBBBBBBC
C
C
C
C
C
C
C
C
C
C
B
B
C 9IO1
EB1
6
10 IO1
3BW1 8BW1
6Bc2 5Bc2 2BW1 6BW1
7BW1
3B
1
221 1 112 2 320 741361511 7 81214 510
15 5 14 3 8 6 17
SFR SFL SRR SRL AST MT GND1 GND2 GND3 FL+ FL± FSS FR+ FR± RL+ RL± RSS RR+ RR± ALT LVL1 PKB W
B± Y
B±R
B±R R
VL
P± B
V±W R±B P
Y± B
LG
LG±B P± L
P± G
V±R
L
GR B
R± W
W±B (
SHIELDED )(
SHI ELDED)
B± R B± R
W± B L± Y G
V±Y
R± W
W± B MTT SR MR TMR E2 PR VC SRC SMC SAC TSR R± BAT I G STPTS WA TC D/G ABSO
RLORRO
FL OFRO
BRFA THFA
BRCBRP
TRCO NL PW±LR
Y
W
W
L±W B±R
R±B
L
Y R
V±Y
V±Y
V±Y
W
B±Y
R
R±W R
B±R
B±R
R
G± W
G±W B±Y
L±Y
R± B
Y
G
( SHI ELDED )
W
B
R
V± Y
V
V± W R± W R±W R±W
B±R V±Y W
W± L
V L
P±B
W± B W± B W± B
L±W Y± G
P± B P
B± Y
Y
L±W
L
W± B
W± B W± B
W
B
O±L
W± L W
O
O
W
W
O
L±GL±Y
L±G
L±Y Y±G Y±G
B
R±W
LR±W
B±Y V±R P± GP± L
LG±B LG
Y±B
P
R± B R±B V± W B±R B±R
V± Y
W±B W±B
(SHIELDED )
(
SHI EL DED )
(
SHI ELDED )I15
IGNITION SW
40A
IGSW
4 2 1456
R
T5
TRACTION PUMP
A N D MOT ORTRACTI ON BRAKE
ACTUATOR
ABS AND T RACTI ON ECU
60A MAIN
30A ABS NO. 2 60A ABS
NO. 1100A AM1
ABS
ACTUATOR
RELAY
ABS MOTOR
RELAY
TRACTION MOTOR
RELAY
TRACTION BRAKE
MAI N RELAY
10A DOME
6 BATTERY AB S A CT UA TOR
(SHI ELDED ) W± B
A7
ABS SPEED SENSOR
FRONT LH
A8
ABS SPEED SENSOR
FRONT RHA30
ABS SPEED SENSOR
REAR LH
F9
FUSE BLOCK
B±Y
From Stop Light
SW<4±6><5±6>
5BW1
A31
ABS SPEED SENSOR
REAR RH
From Alternator
º Lº < 1±2>
Power
Source ABS and Traction Control
B±R15A ECU±IGY
23 22 16 9 20 10 19
T3 ,T4
FG
(
SHI ELDED )
A4 , A5 , A6
HJ I A2 4 A , A25 B , A2 6 C
W
120A ALT
R
Fro nt s id e of
left fenderRight kick panel
Fr ont side of
right f ender
1
3
WhereEverybodyKnowsYourName
