BE-8
- BODY ELECTRICALTROUBLESHOOTING
2381 Author
: Date
:
2004 LAND CRUISER (RM1071U) ECT PWR indicator light does not light up.
1. LED
2. ECT Pattern Select Switch
3. Combination Meter
4. Wire Harness
5. ECT System-
-
BE-58
-
DI-358
2nd start ETCS indicator light does not light up.
1. LED
2. Combination Meter
3. Wire Harness
4. ECM-
BE-58
-
DI-1
Center Diff. lock indicator light does not light up.
1. LED
2. Combination Meter
3. Transfer 4WD Position Detection Switch
4. Wire Harness-
BE-58
TR-49
-
Indicator lights do not light up. (Except Turn, Hi-beam and
security)1. GAUGE2 Fuse
2. Wire Harness-
-
DEFOGGER SYSTEM:
SymptomSuspect AreaSee page
All defogger systems do not operate.
1. DEFOG Fuse
2. DEFOG Relay
3. Defogger Switch (Integration Control Panel Assembly)
4. Wire Harness-
-
BE-75
-
Rear window defogger does not operate.
1. Defogger Wire
2. Choke Coil
3. Wire HarnessBE-75
-
-
Mirror defogger does not operate.
1. MIR HTR Fuse
2. Engine Room J/B Relay Circuit
3. Mirror Defogger
4. Wire Harness-
BE-15
BE-75
-
POWER WINDOW CONTROL SYSTEM:
This system uses the multiplex communication system, so check diagnosis system of the multiplex commu-
nication system before you proceed with troubleshooting.
SymptomSuspect AreaSee page
All the power windows do not operate.
(Power Door Lock System is normal.)1. P/W (FL, FR, RL, RR) Fuse
2. Power Window Master Switch
3. Wire Harness-
BE-79
-
Only the driver's window does not operate.
1. Power Window Master Switch
2. Body ECU
3. Power Window Motor
4. Wire HarnessBE-79
DI-1038
BE-79
-
ºWindow lock functionº does not operate.1. Power Window Master SwitchBE-79
POWER DOOR LOCK CONTROL SYSTEM:
This system uses the body control system, so check diagnosis system of the body control system before
you proceed with troubleshooting.
SymptomSuspect AreaSee page
All the doors cannot be locked or unlocked.
(Power Window Control System is normal.)
1. DOOR Fuse
2. Door Lock Control Switch
3. Wire Harness
4. Body ECU-
BE-88
-
DI-1038
Only one side door lock control does not operate.1. Door Lock Motor
2. Wire HarnessBE-88
-

BE2F2-01
I20790
Key Plate Inserted
ON
OFFWithin. 5secs.
1 Key Plate Not Inserted
23 910Within. 30secs.
Once 9 times BE-100
- BODY ELECTRICALWIRELESS DOOR LOCK CONTROL SYSTEM
2473 Author
: Date
:
2004 LAND CRUISER (RM1071U)
INSPECTION
1. CHARACTERS OF WIRELESS DOOR LOCK
(a) The operation distance changes according to how cus-
tomers hold the transmitter or where it is used.
(b) Because of using the very weak radio wave, if there is a
strong wave or noise on the frequency being used, the op-
eration distance may become shorter.
2. WIRELESS DOOR LOCK BASIC FUNCTION
(a) Stand on the driver's side. Stay 1 m away from the ve-
hicle.
(b) Turn the transmitter toward the vehicle and press any one
of the transmission switched for 1 sec.
3. INSPECT WIRELESS DOOR LOCK DIAGNOSIS MODE
(a) Start up diagnosis mode.
HINT:
Follow the method below.
(1) Insert the ignition key into the ignition key cylinder.
(2) Remove the ignition key from the ignition key cylin-
der.
(3) Insert the key into the ignition switch.
(4) Turn the ignition switch ON once within 5 sec.
(5) Repeat turnning the ignition switch OFF " ON 9
times within 30 sec.
(6) Enter the diagnosis mode, and make sure that the
taillight lights up.
(b) Finishing the Diagnosis Mode.
During the Diagnosis mode, turn the ignition switch OFF
" ON to go back to the normal mode.
At this time make sure that the taillight lights up.

START
The vehicle should be in the following conditions:

Ignition switch ON
Hand-held tester operation:
1. Select ºL/C 100º from the menu.
2. Select ºTDSº (Theft Deterrent System).
3. Select ºWIRELESS REGISTRATIONº.
After the above operations, proceed to the succeeding operations
according to the prompts on the tester screen.
Transmitter SW Operation:
HINT: Perform this operation during the countdown screen.
Press both lock and unlock SW. (Between 1 and 1.5 sec.)
Press any one of SW. (For more than 1 sec.)
This wireless buzzer sounds when the registration is completed
normally.
Continue the registration.Register other transmitters?
Or
Finish the registration?
Finish the registration.
ENDHINT: Select the next step
on the tester screen.
Within 3 sec. BE-94
- BODY ELECTRICALWIRELESS DOOR LOCK CONTROL SYSTEM
2467 Author
: Date
:
2004 LAND CRUISER (RM1071U)
(c) By TOYOTA Hand-Held Tester
HINT:
This page is to show briefly the registration procedure using the hand-held tester.
For detailed procedures, please refer to the prompts on the tester screen.
The number of currently registered codes can be checked out on the first screen of the WIRELESS REG-
ISTRATION.

Close"open"close"open
START
The vehicle should be in the following conditions:

Driver door open (Other doors are closed).
Insert and remove the key into/from the ignition cylinder twice.
Insert"remove "insert"remove
HINT: If the IG switch operation is
not performed with the specified
number of times (If it is 4 times, 6
times or more), this operation is
finished with no response.
HINT: The registration operation is
cancelled if each operation is not
completed within the specified
time.

No key inserted in the IG key cylinder.
Close and open the driver door twice.
Close"open"close"open
Insert and remove the key into/from the ignition cylinder once.
Insert"remove
Insert the key into the ignition key cylinder.
Close all the doors.
Mode Selection
Turn the IG SW ON
u"LOCK once.Add modeTurn the IG SW ON
u"LOCK twice.Rewrite modeTurn the IG SW ON
u"LOCK 3 times. Confirmation modeTurn the IG SW ON
u"LOCK 5 times. Prohibition mode
Remove the key from the IG key cylinder.
Within 5 sec.
Within 40 sec.
Within 40 sec.
Within 40 sec.
Close and open the driver door twice.
- BODY ELECTRICALWIRELESS DOOR LOCK CONTROL SYSTEM
BE-95
2468 Author
: Date
:
2004 LAND CRUISER (RM1071U)
(d) By Switch Operation:

BR12C-05
F04456
F08307
BR-60
- BRAKEHYDRAULIC BRAKE BOOSTER
2196 Author
: Date
:
2004 LAND CRUISER (RM1071U)
REMOVAL
NOTICE:
Before starting the work, make sure that the ignition switch
is OFF and depress the brake pedal more than 40 times.
HINT:
When a pressure in power supply system is released, reaction
force becomes light and stroke becomes longer.
NOTICE:

As high pressure is applied to the brake actuator tube
No. 1, never deform it.

Until the work is over, do not turn the ignition switch
ON.
1. DRAW OUT FLUID WITH SYRINGE
NOTICE:
Do not let brake fluid remain on a painted surface. Wash it
off immediately.
2. REMOVE SCUFF PLATE, COWL SIDE TRIM, LOWER
NO. 1 PANEL, LH LOWER PANEL AND NO. 2 HEATER
TO REGISTER DUCT (See page BO-81)
3. REMOVE ABS OR ABS & TRAC & VSC ECU
Remove the 2 nuts and ABS or ABS & TRAC & VSC ECU.
Torque: 5.0 N´m (51 kgf´cm, 44 in.´lbf)
4. w/ ABS only:
DISCONNECT 4 CONNECTORS
5. w/ ABS & TRAC & VSC only:
DISCONNECT 5 CONNECTORS

- BRAKETROUBLESHOOTING
BR-3
2139 Author
: Date
:
2004 LAND CRUISER (RM1071U) Noise from brakes
1. Pad (Cracked or distorted)
2. Installation bolt (Loose)
3. Disc (Scored)
4. Pad support plate (Loose)
5. Sliding pin (Worn)
6. Pad (Dirty)
7. Pad (Glazed)
8. Tension or return spring (Faulty)
9. Anti-squeal shim (Damaged)
10.Shoe hold-down spring (Damaged)BR-15
BR-24
BR-18
BR-27
BR-21
BR-30
BR-24
BR-27
BR-15
BR-24
BR-15
BR-24
BR-33
BR-15
BR-24
BR-33
Noise from hydraulic brake booster
(Abnormal pump motor operation noise)Accumulator bracket clearance (Out of adjustment)BR-66
Brake warning light lights up*1
(Parking brake pedal released)
1. Brake fluid level
2. Hydraulic brake booster power supply system (Faulty)-
BR-40
Brake warning light lights up and brake warning buzzer sounds*2Hydraulic brake booster power supply system (Faulty)BR-40
ABS warning light lights up*31. Anti - lock brake system (Faulty)
2. Hydraulic brake booster power supply system (Faulty)-
BR-40
*1, *3: The light may stay on for about 60 seconds after the engine is started. It is normal if it goes out after
a while.
*
2, *3: Depressing the brake pedal repeatedly may turn on the warning light and buzzer. It is normal if the
light goes off and the buzzer stops sounding after a few seconds.
*
3: While ABS warning light is ON.

Z03473
Ammeter
Disconnect Wire
from Terminal B
Battery
VoltmeterB
Generator CH-4
- CHARGINGCHARGING SYSTEM
1839 Author
: Date
:
2004 LAND CRUISER (RM1071U)
8. CHECK CHARGE WARNING LIGHT CIRCUIT
(a) Warm up the engine and then turn it off.
(b) Switch off all accessories.
(c) Turn the ignition switch ON, and check that the charge
warning light is lit.
(d) Start the engine, and check that the light goes off.
If the light does not go off as specified, troubleshoot the charge
light circuit.
9. INSPECT CHARGING CIRCUIT WITHOUT LOAD
HINT:
If a battery/generator tester is available, connect the tester to
the charging circuit as per manufacturer's instructions.
(a) If a tester is not available, connect a voltmeter and amme-
ter to the charging circuit as follows:

Disconnect the wire from terminal B of the genera-
tor, and connect it to the negative (-) tester probe
of the ammeter.

Connect the positive (+) tester probe of the amme-
ter to terminal B of the generator.

Connect the positive (+) tester probe of the voltme-
ter to terminal B of the generator.

Ground the negative (-) tester probe of the voltme-
ter.
(b) Check the charging circuit as follows:
With the engine running from idling to 2,000 rpm, check
the reading on the ammeter and voltmeter.
Standard amperage:
10 A or less
Standard voltage:
13.2 - 14.8 V
If the value is not specified, check the generator.
10. INSPECT CHARGING CIRCUIT WITH LOAD
(a) With the engine running at 2,000 rpm, turn on the high
beam headlights and place the heater blower switch at HI.
(b) Check the reading on the ammeter.
Standard amperage:
30 A or more
If the ammeter reading is less than the standard amperage, re-
pair the generator.
HINT:
If the battery is fully charged, the indication will sometimes be
less than standard amperage.
11. REINSTALL ENGINE UNDER COVER NO.1

ABS Antilock Brake System
A/C Air Conditioner
assy assembly
ECT Electronic Controlled Transmission
ECU Electronic Control Unit
e.g. Exempli Gratia (for Example)
Ex. Except
4WD Four Wheel Drive Vehicles
in. inch
LH Left-hand
LHD Left-hand Drive
MIG Metal Inert Gas
M/Y Model Year
PPS Progressive Power Steering
RH Right-hand
RHD Right-hand Drive
SRS Supplemental Restraint System
SSM Special Service Materials
w/ with
w/o without
5. ECU (ELECTRONIC CONTROL UNIT)
Many ECUs are mounted in this vehicle.
Take the following precautions during body repair to prevent damage to the ECUs.

Before starting electric welding operations, disconnect the negative (-) terminal cable from the battery.
When the negative (-) terminal cable is disconnected from the battery, memory of the clock and audio
systems will be cancelled. So before starting work, make a record of the contents memorized by each
memory system. Then when work is finished, reset the clock and audio systems as before.
When the vehicle has tilt and telescopic steering, power seat and outside rear view mirror, which are all
equipped with memory function, it is not possible to make a record of the memory contents. So when the
operation is finished, it will be necessary to explain this fact to the customer, and request the customer to
adjust the features and reset the memory.

Do not expose the ECUs to ambient temperatures above 80°C (176°F).
NOTICE: If it is possible the ambient temperature may reach 80° (176°F) or more, remove the ECUs
from the vehicle before starting work.

Be careful not to drop the ECUs and not to apply physical shocks to them.
ABBREVIATIONS USED IN THIS MANUAL
For convenience, the following abbreviations are used in this
manual.
INTRODUCTIONIN-9
