Page 2450 of 3115
B04482
SST
B04483
B04484
SST
3/4 Turn
- LUBRICATIONOIL AND FILTER
LU-3
1784 Author: Date:
2004 LAND CRUISER (RM1071U)
(b) Using SST, remove the oil filter.
SST 09228-07501
(c) Clean the oil filter contact surface on the oil filter mount-
ing.
(d) Lubricate the filter rubber gasket with clean engine oil.
(e) Tighten the oil filter by hand until the rubber gasket con-
tacts the seat of the filter mounting.
(f) Using SST, give it an additional 3/4 turn to seat the filter.
SST 09228-07501
3. REFILL WITH ENGINE OIL
(a) Clean and install the oil drain plug with a new gasket.
Torque: 39 N´m (400 kgf´cm, 29 ft´lbf)
(b) Fill with new engine oil.
Capacity:
Drain and refill:
w/ Oil filter change: 6.8 liters (7.2 US qts, 6.0 Imp. qts)
w/o Oil filter change: 6.4 liters (6.8 US qts, 5.6 Imp. qts)
Dry fill: 8.0 liters (8.5 US qts, 7.0 Imp. qts)
(c) Reinstall the oil filler cap.
4. START ENGINE AND CHECK FOR ENGINE OIL
LEAKS
5. RECHECK ENGINE OIL LEVEL
6. REINSTALL ENGINE UNDER COVER NO.3 AND SER-
VICE HOLE COVER
Page 2482 of 3115
PP1AH-01
- PREPARATIONAIR CONDITIONING
PP-81
140 Author: Date:
2004 LAND CRUISER (RM1071U)
LUBRICANT
ItemCapacityClassification
Compressor oil-ND-OIL 8 or equivalent
When replacing condenser40 cc (1.4 fl. oz.)
When replacing evaporator40 cc (1.4 fl. oz.)
Page 2520 of 3115
PP1AW-07
PP-18
- PREPARATIONLUBRICATION
77 Author: Date:
2004 LAND CRUISER (RM1071U)
LUBRICANT
ItemCapacityClassification
Engine oil
Dry fill
Drain and refill
w/ Oil filter change
w/o Oil filter change
8.0 liters (8.5 US qts, 7.0 Imp. qts)
6.8 liters (7.2 US qts, 6.0 Imp. qts)
6.4 liters (6.8 US qts, 5.6 Imp qts)API grade SL Energy-Conserving or ILSAC mul-
tigrade engine oil.
Page 2531 of 3115
PP1BD-03
- PREPARATIONSUSPENSION AND AXLE
PP-51
11 0 Author: Date:
2004 LAND CRUISER (RM1071U)
LUBRICANT
FRONT DRIVE SHAFT
ItemCapacityClassification
Outboard joint grease
Inboard joint grease368 - 378 g (13.0 - 13.3 oz.)
293 - 303 g (10.3 - 10.7 oz.)
FRONT DIFFERENTIAL
ItemCapacityClassification
Hypoid gear oil1.70 liters (1.80 US qts, 1.50 lmp.qts)
Hypoid gear oil API GL-5
Above -18 °C (0°F) SAE 90
Below -18 °C (0°F) SAE 80W-90 or 80W
REAR DIFFERENTIAL
ItemCapacityClassification
Hypoid gear oil Normal
w/ Diff. lock3.30 liters (3.49 US qts, 2.90 lmp.qts)
3.20 liters (3.38 US qts, 2.82 lmp.qts)Hypoid gear oil API GL-5
Above -18 °C (0°F) SAE 90
Below -18 °C (0°F) SAE 80W-90 or 80W
Hypoid gear oil LSD w/ LSD3.30 liters (3.49 US qts, 2.90 lmp.qts)
Hypoid gear oil LSD API GL-5
Above -18 °C (0°F) SAE 90
Below -18 °C (0°F) SAE 80W-90 or 80W
Page 2556 of 3115
PP1BI-03
PP-38
- PREPARATIONTRANSFER
97 Author: Date:
2004 LAND CRUISER (RM1071U)
LUBRICANT
ItemCapacityClassification
Transfer oil1.3 liters (1.4 US qts, 1.1 lmp. qts)API GL-4 or GL-5
SAE 75W-90
Page 2936 of 3115
SA14K-04
F05234
SST
F05235
SST
F05233
Less than 5 mm (0.20 in.)
- SUSPENSION AND AXLEFRONT DIFFERENTIAL SIDE GEAR SHAFT OIL SEAL
SA-35
1985 Author: Date:
2004 LAND CRUISER (RM1071U)
REPLACEMENT
1. REMOVE FRONT WHEELS
Torque: 131 N´m (1,340 kgf´cm, 97 ft´lbf)
2. REMOVE FRONT DRIVE SHAFT
(See page SA-26)
3. REPLACE OIL SEAL
(a) Using SST, remove the oil seal.
SST 09308-00010
(b) Coat the hypoid gear oil to a new oil seal periphery.
(c) Using SST and a hammer, install the new oil seal.
SST 09550-00032, 09950-70010 (09951-07100)
(d) Coat the MP grease to the oil seal lip.
4. INSTALL FRONT DRIVE SHAFT
(See page SA-33)
5. FILL DIFFERENTIAL WITH HYPOID GEAR OIL
Torque: 49 N´m (500 kgf´cm, 36 ft´lbf)
Oil type: Hypoid gear oil API GL-5
Recommended oil viscosity:
Above -18°C (0°F) SAE 90
Below -18°C (0°F) SAE 80W-90 or 80W
Capacity: 1.70 liters (1.80 US qts, 1.50 lmp.qts)
Page 3044 of 3115
Z06905
Less than 5 mm
(0.20 in.)
- SUSPENSION AND AXLEREAR DIFFERENTIAL FRONT OIL SEAL
SA-97
2047 Author: Date:
2004 LAND CRUISER (RM1071U)
16. FILL DIFFERENTIAL WITH HYPOID GEAR OIL
Torque: 49 N´m (500 kgf´cm, 36 ft´lbf)
Oil type:
w/o LSD: Hypoid gear oil API GL-5
w/ LSD: Hypoid gear oil LSD API GL-5
Recommended oil viscosity:
Above -18°C (0°F) SAE 90
Below -18°C (0°F) SAE 80W-90 or 80W
Capacity:
w/ Diff. Lock: 3.20 liters (3.38 US qts, 2.82 lmp.qts)
Others: 3.30 liters (3.49 US qts, 2.90 lmp.qts)
Page 3112 of 3115
TR067-02
D02645
D02646
Oil Level
0 - 5 mm
Filler Plug
Drain Plug
D01618
Q09803
Wooden Block TR-4
- TRANSFERTRANSFER UNIT
1892 Author: Date:
2004 LAND CRUISER (RM1071U)
REMOVAL
1. RAISE VEHICLE
NOTICE:
Make sure that the vehicle is securely supported.
2. REMOVE TRANSFER CASE PROTECTOR
Remove the 3 bolts and transfer case protector.
Torque: 28 N´m (290 kgf´cm, 21 ft´lbf)
3. DRAIN TRANSFER OIL
Oil grade: API GL-4 or GL-5
Viscosity: SAE 75 W-90
Capacity: 1.3 liters (1.4 US qts, 1.1 lmp. qts)
Torque: 37 N´m (380 kgf´cm, 27 ft´lbf)
4. REMOVE FRONT AND REAR PROPELLER SHAFTS
(See page PR-4)
5. DISCONNECT TRANSFER SHIFT LEVER ROD AS-
SEMBLY
Remove the clip, plate washer, wave washer and bushing, and
disconnect the transfer shift lever rod assembly.
6. DISCONNECT GROUND CABLE
Remove the bolt and disconnect the ground cable from the
transfer.
7. REMOVE CROSSMEMBER
(a) Support the transmission, as shown.
NOTICE:
Use a wooden block so not to damage the transmission oil
pan.
(b) Remove the 8 bolts, 2 nuts and crossmember.
Torque:
Bolt: 50 N´m (510 kgf´cm, 37 ft´lbf)
Nut: 74 N´m (750 kgf´cm, 54 ft´lbf)
