1986 TOYOTA LAND CRUISER battery replacement

BE0N7-06
BE4671
Antenna Nut
BE5781
BE5780
BE4674
Twist
- BODY ELECTRICALANTENNA
BE-177
2550 Author
: Date
:
2004 LAND CRUISER (RM1071U)
REPLACEMENT
1. Auto antenna models:
REMOVE ANTENNA ROD
HINT:
Do this operation with the battery negative (-) cable connected
to the battery terminal.
(a) Remove the antenna nut.
(b) Turn the radio switch ºONº position.
(c) Turn the antenna switch to ºUPº.
(d) Catch the antenna rod by hand and turn the radio switch
ºOFFº.
(e) Try again to turn the radio switch ºONº and antenna switch
ºUPº.
(f) Remove antenna rod.
HINT:
The rod will extend fully and be released form the motor anten-
na.
NOTICE:
To prevent body damage when the antenna rod is released,
hold the rod while it comes out.
2. Auto antenna models:
INSTALL ANTENNA ROD
(a) Insert the cable of the rod until it reaches the bottom.
HINT:

When inserting the cable, the teeth on the cable must face
toward the rear of the vehicle.

Insert the antenna approx. 350 mm.
(b) Turn the radio switch to ºOFFº.
HINT:

In case the cable is not wound, twist it, as shown in the
illustration.

Even if the rod has not retracted fully, install the antenna
nut and inspect the antenna rod operation. It will finally re-
tract fully.
(c) Inspect the antenna rod operation by pushing the radio
wave band select buttons.

BE01I-05
- BODY ELECTRICALBODY ELECTRICAL SYSTEM
BE-1
2374 Author
: Date
:
2004 LAND CRUISER (RM1071U)
BODY ELECTRICAL SYSTEM
PRECAUTION
HINT:
Take care to observe the following precautions when performing inspections or removal and replacement
of body electrical related parts.
1. HEADLIGHT SYSTEM
Halogen bulbs have pressurized gas inside and require special handling. They can burst if scratched or
dropped. Hold a bulb only by its plastic or metal case. Don't touch the glass part of a bulb with bare hands.
2. SRS (SUPPLEMENTAL RESTRAINT SYSTEM)
The LAND CRUISER is equipped with an SRS (Supplemental Restraint System) such as the driver airbag
and front passenger airbag. Failure to carry out service operation in the correct sequence could cause the
SRS to unexpectedly deploy during servicing, possibly leading to a serious accident. Before servicing (in-
cluding removal or installation of parts, inspection or replacement), be sure to read the precautionary notices
in the RS section.
3. AUDIO SYSTEM

If the negative (-) terminal cable is disconnected from the battery, the preset AM, FM 1 and FM 2 sta-
tions stored in memory are erased, so be sure to note the stations and reset them after the negative
(-) terminal cable is reconnected to the battery.

If the negative (-) terminal cable is disconnected from the battery, the ºANTI-THEFT SYSTEMº will
operate when the cable is reconnected, but the radio, tape player and CD player will not operate. Be
sure to input the correct ID number so that the radio, tape player and CD player can be operated again.
4. MOBILE COMMUNICATION SYSTEM
If the vehicle is equipped with a mobile communication system, refer to precautions in the IN section.

I26371
BE23K-02
I04155
O-Ring
I04156
Terminal
BE-104
- BODY ELECTRICALWIRELESS DOOR LOCK CONTROL SYSTEM
2477 Author
: Date
:
2004 LAND CRUISER (RM1071U)
REPLACEMENT
REPLACE TRANSMITTER (LITHIUM) BATTERY
NOTICE:
Special caution should be taken for handling each compo-
nent as they are precision electronic components.
(a) Using a screwdriver, remove the screw and cover.
NOTICE:
Do not pry out the cover forcibly.
HINT:
Push the cover with a finger as shown in the illustration, so that
there becomes clearance, then pry out the cover from that
clearance.
(b) Remove the transmitter.
(c) Using a screwdriver, remove the 2 screws and cover.
(d) Remove the battery (lithium battery).
NOTICE:

Do not push the terminals with a finger.

If prying up the battery (lithium battery) forcibly to re-
move, the terminals are deformed.
(e) Install a battery (lithium battery) as shown in the illustra-
tion.
NOTICE:
Face the battery upward. Take care not to deform the termi-
nals.
(f) Check that O-ring is not distorted or slipped off, and
install the cover.
(g) Using a screwdriver, tighten the 2 screws.
NOTICE:
When the shrews are tightened loosely, it might cause
faulty contact of battery (lithium battery) and terminals.
(h) Assemble the transmitter to the key plate and the cover.
(i) Using a screwdriver, tighten the screw.

HANDLING PRECAUTIONS ON RELATED COMPONENTS
1. FOR VEHICLES EQUIPPED WITH SRS AIRBAG AND SEAT BELT PRETENSIONER
The TOYOTA LAND CRUISER is equipped with an SRS (Supplemental Restraint System), such as the driver
airbag and front passenger airbag and seat belt pretensioners. Failure to carry out service operations in the
correct sequence could cause the supplemental restraint system to unexpectedly deploy during servicing, pos-
sibly leading to a serious accident. Further, if a mistake is made in servicing the supplemental restraint system,
it is possible the SRS may fail to operate when required. Before servicing (including removal or installation of
parts, inspection or replacement), be sure to read the following items carefully, then follow the correct proce-
dure described in this manual.

Malfunction symptoms of the supplemental restraint system are difficult to confirm, so the diagnostic
trouble codes become the most important source of information when troubleshooting.
When troubleshooting the supplemental restraint system, always inspect the diagnostic trouble codes
before disconnecting the battery.

Work must be started after 90 seconds from the time the ignition switch is turned to the ºLOCKº position
and the negative (-) terminal cable is disconnected from the battery.
(The supplemental restraint system is equipped with a back-up power source so that if work is started
within 90 seconds of disconnecting the negative (-) terminal cable from the battery, the SRS may
deploy.)
When the negative (-) terminal cable is disconnected from the battery, memory of the clock and audio
systems will be cancelled. So before starting work, make a record of the contents memorized by the
audio memory system.
Then when work is finished, reset the clock and audio systems as before.
To avoid erasing the memory of each memory system, never use a back-up power supply from outside
the vehicle.

Even in cases of a minor collision where the SRS does not deploy, the passenger's airbag assembly,
the steering wheel pad and seat belt pretensioners should be inspected.
Never use SRS parts from another vehicle. When replacing parts, replace them with new parts.

Before repairs, remove the airbag sensor if shocks are likely to be applied to the sensor during repairs.

Never disassemble and repair the airbag sensor assembly, steering wheel pad in order to reuse it.

If the airbag sensor assembly, steering wheel pad have been dropped, or if there are cracks, dents or
other defects in the case, bracket or connector, replace them with new ones.

Do not expose the airbag sensor assembly, steering wheel pad directly to hot air or flames.

Use a volt/ohmmeter with high impedance (10 k
/V minimum) for troubleshooting of the electrical cir-
cuit.

Information labels are attached to the periphery of the SRS components. Follow the instructions on the
notices.

After work on the supplemental restraint system is completed, check the SRS warning light.

Before repairing the body, remove the SRS parts if, during repair, shocks are likely to be applied to the
sensors due to vibrations of the body or direct tapping with tools or other parts.

Do not expose the SRS parts directly to hot air or flames.
NOTICE:
1) The maximum ambient temperature tolerance is 120
°C (248°F) for the front airbag sensor, 105°C
(221
°F) for the center airbag sensor assembly and 93°C (200°F) for the steering wheel pad, and
front passenger airbag assembly. If it is possible that the ambient temperature may reach or ex-
ceed the temperature limit, remove the sensors and the steering wheel pad from the vehicle or
protect them with a hot insulation material before staring work.
2) Prior to welding, remove adjacent SRS parts form the vehicle or protect them with fire-proof cov-
ers.

If the vehicle is damaged, visually inspect for damage to the steering wheel pad using the inspection
procedures described in section RS of the repair manual for the relevant model year.
INTRODUCTIONIN-6

RADIATOR SIDE SUPPORT (ASSY)
(Without Battery Carrier Support): RH (With Battery Carrier Support):
REMOVAL (With the radiator upper support removed.)
LH:
RH (With Battery Carrier Support):
LH:
BODY PANEL REPLACEMENTRE-4

(Without Battery Carrier Support): RH (With Battery Carrier Support):
INSTALLATION
LH:
RH (With Battery Carrier Support):
[RH only]
LH:
Intercooler Mounting Retainer
1. Temporarily install the new parts and measure
each part in accordance with the body dimen-
sion diagram.
HINT: First install the radiator upper support.
BODY PANEL REPLACEMENTRE-5

RADIATOR SUPPORT (ASSY)
REMOVAL
LH:
RH (With Battery Carrier Support):
LH:
RH (With Battery Carrier Support):
BODY PANEL REPLACEMENTRE-8

Assembly Mark
INSTALLATION
[RH]
Intercooler Mounting
Retainer
LH:
RH (With Battery Carrier Support):
LH:
RH (With Battery Carrier Support):
1. When temporarily installing the new parts,
determine the installation position by the
assembly mark. Then, measure each part in
accordance with the body dimension dia-
gram.
BODY PANEL REPLACEMENTRE-9
