SERVICE DATA AND SPECIFICATIONS (S. D.S.)
Engine Cooling System
Radiator
Unit kPa lkg/cm'. psi1
Cap relief pressure
Leakase terr mesure
59 98106 10.9-141
157
I1 6.231 ~~ ~
Thermostat
Standard
76 5 I1701 Valve opentng temperature
Maximum
valve lift
"C I'FI
mmPC Id FI 10190 IO 39/194) ~ ~~~
~ ~
~
Fan coupling
Cut Off point rpm LOW 750
Hlgh Except turbo model 2.450
Turbo model 2.700
Low+ Hightemperature'C I'FI 60.70 1140.1581
Temperature switch (Turbocharged model)
Operatmg temperatwe
OFF - ON "C I'FI 100 (2121
Tightening torque
Unit Nm kgm ft-lb
Water pump securing bolt 16 -21 1621 12-15
Thermostat housing 16-21 16-21 12-15 securing bolt
Water inlet securing bolt
16. 21 16-21 12-15
Water outlet securing bolt 16.21 16-21 12-15
Coolant filler housing bolt 3 - 4 03-04 22-29
Radiator securing bolt 3 -4 03-04 22-29
Radiator hose clamp 3-5 03-05 22-36
Cooling fan securing bolt 6 - 10 06-10 43-72
Fan Coupling securing bolt 6 - 10 06-10 43-72
