Active driving display

Furthermore, if the possibility of a road
departure increases, a screen display
and a warning sound notify the driver
of the danger. Operate the steering
wheel according to the screen display.
Instrument cluster
Active driving display
NOTE
The Head-on traffic avoidance assist
may not operate normally when any
of the following conditions is met.
The Forward Sensing Camera (FSC)
cannot detect target objects.
Refer to Forward Sensing Camera
(FSC) on page 5-127.
The front radar sensors cannot
detect target objects.
The width of the vehicle lane is
narrow or wide.
The vehicle is driven on a section
with a closed lane or temporary
lane due to construction.
The vehicle is driven on a forked
road or junction.
If the driver operates the steering
wheel while the steering wheel
operation assist is operating, the
steering wheel operation assist is
canceled.
When the Head-on traffic avoidance
assist is temporarily canceled
The Head-on traffic avoidance assist
goes on stand-by when any of the
following conditions is met. The
Head-on traffic avoidance assist is
automatically restored when its
operation conditions are met.
The accelerator pedal is depressed
abruptly.
The brake pedal is depressed.The steering wheel is operated
abruptly.
The TCS/DSC is operating.The TCS/DSC is turned off.Multiple vehicles are traveling in the
detecting area near your vehicle.
Turning off the ELK
There are 2 ways to turn off the ELK.
Turn off the ELK using Mazda
Connect.
Refer to the Settings section in the
Mazda Connect Owner's Manual.
Turn off the ELK using the
i-ACTIVSENSE OFF switch.
Refer to How to Use the
i-ACTIVSENSE OFF switch on page
5-126.

When the ELK is turned off, the ELK
OFF indicator
turns on.
Driving
Emergency Lane Keeping (ELK)
5-196
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Smart Brake Support(SBS)
*
SBS is a system designed to avoid
collisions and reduce damage in the
event of a collision by controlling the
brakes. Sensors and camera equipped
on the vehicle detect objects, and
operate brake control if there is a
possibility of your vehicle colliding with
the object.
One part of the SBS functions when
you are driving forward and the other
part functions when you are driving in
reverse.
Forward drive detection
Forward drive detection has the
following 4 functions.
Forward detection function
*
The forward detection function is
designed to assist the driver in avoiding
collisions with objects (vehicles ahead,
pedestrians, bicycles, and motorcycles)
at the front and to reduce damage in
the event of a collision.
If there is a possibility of your vehicle
colliding with a target object at the
front, you are notified of possible
danger by a screen display and a
warning sound. Furthermore, if the
possibility of a collision increases,
brake control is performed to avoid
collision and reduce damage in the
event of a collision.
In addition, when the driver depresses
the brake pedal, the brakes are applied
firmly and quickly to assist.
Tu r n -A c ro s s Tra ffi c*
The Turn-Across Traffic is designed to
assist the driver in avoiding a collision
with a vehicle approaching in the
opposite direction when making a left
turn at an intersection and to reduce
damage in the event of a collision.
If there is a possibility of your vehicle
colliding with a vehicle approaching in
the opposite direction when you make
a left turn at an intersection, you are
notified of possible danger by a screen
display and a warning sound.
Furthermore, if the possibility of a
collision increases, brake control is
performed to avoid collision and
reduce damage in the event of a
collision.
Driving
Smart Brake Support (SBS)
*Some models.5-197
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Rear Crossing*
The Rear Crossing is designed to avoid
collision and reduce damage in the
event of a collision with a vehicle
approaching from the rear sides.
If there is a possibility of your vehicle
colliding with a vehicle approaching
from the rear sides, you are notified of
possible danger by a screen display
and a warning sound. Furthermore, if
the possibility of a collision increases,
brake control is performed to avoid
collision and reduce damage in the
event of a collision.
Warnings and Cautions
for Using the Smart Brake Support (SBS)
WARNING
Do not rely completely on the SBS.
The SBS is only designed to reduce
damage in the event of a collision.
Over reliance on the system leading to
the accelerator pedal or brake pedal
being mistakenly operated could result
in an accident.
Heed the following cautions so that
the SBS can operate normally.
Do not modify the suspensions.
 Handle the Forward Sensing Camera
(FSC) appropriately. Otherwise, the
Forward Sensing Camera (FSC) may
not be able to detect target objects,
which could result in an accident.
Refer to Forward Sensing Camera
(FSC) on page 5-127.
 Handle the radar sensors
appropriately. Otherwise, the radar
sensors may not be able to detect
target objects, which could result in
an accident.
Refer to Radar Sensors on page
5-131.
 Handle the ultrasonic sensors
appropriately. Otherwise, the
ultrasonic sensors may not be able to
detect target objects, which could
result in an accident.
Refer to Ultrasonic Sensors on page
5-135.
 Handle the rear camera
appropriately. Otherwise, the rear
camera may not be able to detect
target objects, which could result in
an accident.
Driving
Smart Brake Support (SBS)
*Some models.5-199
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

1. “BRAKE!”

Active driving display
1. “BRAKE!”
NOTE
If any of the following conditions is
met, the forward detection function
may not operate normally.
The Forward Sensing Camera (FSC)
cannot detect target objects.
Refer to Forward Sensing Camera
(FSC) on page 5-127.
The front radar sensor cannot
detect target objects.
Refer to Radar Sensors on page
5-131.
When there is the possibility of a
partial contact with a target object.
The driver deliberately performs
driving operations (accelerator pedal
operation, steering wheel operation,
selector lever operation, and turn
signal lever operation).
If any of the follo wing conditions is
met, the forward detection function
may operate.
An animal or object on the road is
detected.
Passing an approaching vehicle
while rounding a curve.
Vehicle is passing through a narrow
gate or a gate with a low ceiling.
There is a metal object, bump, or a
protruding object on the road.
(Vehicles with Driver Monitoring
(DM))
If the system determines that the
driver is not paying attention to the
road, it activates the collision
warning earlier than normal.
If the forward detection function
performs brake control and the
vehicle is stopped, the system will
continue to hold the brakes for a
brief time unless there is an
operation performed by the driver.
The operation distance and volume
of the collision warning can be
changed.
Refer to the Settings section in the
Mazda Connect Owner's Manual.
The Turn-Across Tra ffi c operation
conditions*
The Turn-Across
Tra ffi c operates when
all of the following conditions are met.
The vehicle speed is about 4 km/h
to 20 km/h (3 mph to 12 mph).
The left turn signal light is turned on
and the vehicle is turning left.
A lane line between your vehicle and
the vehicle approaching in the
opposite direction is detected.
The system determines that there is a
possibility of collision with an object
ahead.
When the Turn-Across Tra ffi c operates,
the driver is notified of the danger by
the screen display and warning sound.
Furthermore, if the possibility of a
collision increases, brake control is
performed.
Instrument cluster
Driving
Smart Brake Support (SBS)
*Some models.5-201
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

1. “BRAKE!”

Active driving display
1. “BRAKE!”
NOTE
If any of the following conditions is
met, the Turn-Across Traffic may not
operate normally.
The Forward Sensing Camera (FSC)
cannot detect target objects.
Refer to Forward Sensing Camera
(FSC) on page 5-127.
The front radar sensor cannot
detect target objects.
Refer to Radar Sensors on page
5-131.
The vehicle approaching in the
opposite direction is a
two-wheeled vehicle or a bicycle.
All of or only a part of a vehicle
approaching in the opposite
direction is hidden and it cannot
be recognized.
The speed of the on-coming
vehicle is too slow or too fast.
Turning at a large intersection with
two lanes or more on one side.
The accelerator pedal or brake
pedal is being operated.
The steering wheel is being
operated in the straight-ahead
position.
T h e Tu r n -A c ro s s Tra ffi c m ay n o t
operate depending on the country
where the vehicle is driven.
If any of the following conditions is
met, the Turn-Across Tra ffi c may
operate.
The steering wheel is turned
towards the on-coming traffic lane
with a vehicle approaching in the
opposite direction.
Turning right after or right before
an oncoming vehicle passes.
The direction of movement of a
vehicle approaching in the
opposite direction cannot be
predicted due to sudden right/left
turning or sudden deceleration.
The brakes are released by the brake
co n t ro l o f t h e Tu r n -A c ro s s Tra ffi c a s
soon as the danger of a collision
passes.
When Front Crossing is Operating
*
The Front Crossing operates when all
of the following conditions are met.
The vehicle is traveling straight at a
speed of about 5 km/h to 20 km/h
(3 mph to 12 mph).
The DSC/TCS is not operating.When an approaching vehicle is
traveling straight in a direction
perpendicular to your vehicle.
The approaching vehicle is traveling
at a constant speed within the range
of about 20 km/h to 60 km/h (12
mph to 37 mph).
The system determines that there is a
possibility of a collision with a
vehicle approaching from the front.
NOTE
Front Crossing may not operate
normally if any of the following
conditions is met.
If the front side radar sensors
cannot detect any target objects,
Front Crossing may not operate
correctly.
Refer to Radar Sensors on page
5-131.
Driving
Smart Brake Support (SBS)
5-202*Some models.
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

1. “BRAKE!”

Active driving display
1. “BRAKE!”
NOTE
If any of the following conditions is
met, the rearward detection function
may not operate normally.
The rear ultrasonic sensors cannot
detect an object.
Refer to Ultrasonic Sensors on
page 5-135.
The rear camera cannot detect an
object.
Refer to Cameras on page 5-137.
If any of the following conditions is
met, the rearward detection function
may operate.
There is a hanging curtain.Vehicle is passing through a narrow
gate or a gate with a low ceiling.
There is a metal object, bump, or a
protruding object on the road.
If the rearward detection function
performs brake control and the
vehicle is stopped, the system will
continue to hold the brakes for a
brief time unless there is an
operation performed by the driver.
When the Rear Crossing is operating
*
The Rear Crossing operates when all of
the following cond itions are met.
The vehicle speed is about 15 km/h
(9.3 mph) or slower.
The system determines that there is a
possibility of a collision with a
vehicle approaching from a rear side.
When the Rear Crossing operates, the
screen display and warning sound
notify the driver is notified of the
danger. Furthermore, if the possibility
of a collision increases, brake control is
performed.
Instrument cluster
1. “BRAKE!”

Active driving display
1. “BRAKE!”
NOTE
If any of the following conditions is
met, the Rear Crossing may not
operate normally.
The rear side radar sensors cannot
detect an object.
Refer to Radar Sensors on page
5-131.
A vehicle is approaching directly
from the rear of your vehicle.
A vehicle is approaching at an
angle from the rear of your vehicle.
A vehicle is approaching from a
direction at an acute angle.
If any of the following conditions is
met, the Rear Crossing may operate.
There is a hanging curtain.Vehicle is passing through a narrow
gate or a gate with a low ceiling.
Driving
Smart Brake Support (SBS)
5-204*Some models.
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

To w i n g
Your Mazda was designed and built
primarily to carry passengers and
cargo.
If you tow a trailer, follow these
instructions because driver and
passenger safety depends on proper
equipment and safe driving habits.
Towing a trailer will affect handling,
braking , durability, performance, and
economy.
Never overload vehicle or trailer.
Consult an Authorized Mazda Dealer if
you need further details.
NOTE
Your vehicle is equipped with a
Trailer Stability Control (TSC)
mechanism, which enhances vehicle
stability when towing a trailer.
Refer to Trailer Stability Control
(TSC) on page 5-90.
When towing a trailer, do not use the
following safety systems (If a Mazda
genuine trailer hitch is used, these
systems are automatically turned off
when the trailer's electrical
connector is connected):
Blind Spot Monitoring (BSM)Rear Cross Traffic Alert (RCTA)Smart Brake Support (SBS) reverse
drive detection
Parking Sensor System (Rear)Emergency Lane Keeping (ELK)
Blind Spot Assist
Emergency Lane Keeping (ELK)
Head-on traffic avoidance assist
Turn off the aforementioned safety
systems when towing a trailer
without a genuine Mazda trailer
hitch.
Your vehicle is equipped with a
Mazda intelligent Drive Select
(Mi-Drive) towing mode which
enhances vehicle stability when
towing a trailer.
Refer to Mazda intelligent Drive
Select (Mi-Drive) on page 5-96.
Other Equipment
Towing (U.S.A. and Canada)
7-59
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Exterior Maintenance
WARNING
Dry off brakes that have become wet
by driving slowly, releasing the
accelerator pedal and lightly applying
the brakes several times until the
brake performance returns to normal.
Driving with wet brakes is dangerous.
Increased stopping distance or the
vehicle pulling to one side when
braking could result in a serious
accident. Light braking will indicate
whether the brakes have been
affected.
CAUTION
Before lifting the windshield wiper
blades off the windshield, always
follow the procedure for moving the
windshield wiper blades. Otherwise,
a wiper blade, wiper arm, or the
hood could be damaged.
Refer to the Replacing Windshield
Wiper Blade Rubbers section (page
9-23) for the procedure on how to
move the windshield wiper blades to
the service position.
 When the vehicle power is switched
ON and the wiper lever is in the
AUTO position, the windshield
wipers may operate automatically in
the following cases:
The area of the windshield above the
rain sensor is touched or wiped with
a cloth.
The windshield or the rain sensor
area in the cabin is hit.
When the vehicle power is switched
ON and the wiper lever is in the
AUTO position, do not touch the
windshield or the windshield wipers
Otherwise, the windshield wipers
will operate automatically which
could catch your fingers or damage
the windshield wipers.
When removing ice or snow, or
cleaning the windshield, always
make sure the wiper lever is in the
OFF position.
 Do not spray water in the engine
compartment. Otherwise, it could
result in engine-starting problems or
damage to electrical parts.
 When washing and waxing the
vehicle, be careful not to apply
excessive force to any single area of
the vehicle roof. Otherwise, you
could dent the vehicle.
 Make sure that the fuel-filler lid is
closed and lock the doors.
Otherwise, the fuel-filler lid may be
forcefully opened by water pressure
causing damage to the vehicle or
fuel-filler lid.
 (Vehicles with hands-free liftgate)
When washing or waxing the vehicle,
turn off the hands-free liftgate using
the Mazda Connect or do not bring
the transmitter into the area around
the liftgate. Otherwise, the liftgate
could open unexpectedly resulting in
an accident. Refer to Power Liftgate
section (page 4-21).
 Do not use steel wool, abrasive
cleaners, or strong detergents
containing highly alkaline or caustic
agents on chrome-plated or
anodized aluminum parts. This may
damage the protective coating; also,
cleaners and detergents may discolor
or deteriorate the paint.
Inspection and Servicing/Cleaning
Exterior Maintenance
9-35
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04
