982-1. Instrument cluster
■Display items
 Odometer
Displays the total distance the vehi-
cle has been driven.
Trip meter A/Trip meter B
Displays the distan ce the vehicle
has been driven si nce the meter
was last reset. Trip meters A and B
can be used to record and display
different distances independently.
To reset, display the desired trip
meter and press and hold the dis-
play change button.
The brightness of the instrument
panel lights can be adjusted.
1 Brighter
2 Darker
■Instrument panel light bright-
ness adjustment
The brightness of the instrument
panel lights can be adjusted sepa-
rately for when the tail lights are on
and off.
■The clocks can be adjusted
on the audio system
screen.
Refer to “MULTIMEDIA
OWNER’S MANUAL”.
Changing the instrument
panel light brightness
Adjusting the clock

992-1. Instrument cluster
2
Vehicle status information and indicators
■Locations of gauges and metersEngine coolant temperature gauge
Displays the engine c oolant temperature
Outside temperature
Displays the outside temperature within the range of -40°F (-40 °C) to 140°F
(60°C)
Hybrid System Indicator/Analog speedometer/Tachometer
Displays hybrid system output or regeneration level ( P.100)
This setting can be changed on the setting screen. ( P.442)
Clock ( P.102)
Fuel gauge
Displays the quantity of fu el remaining in the tank
Odometer and trip meter display ( P.101)
Shift position indicator ( P.180)
Multi-information display
Presents the driver with a variety of vehicle data (P.109)
Displays warning messages if a malfunction occurs (P.382)
Gauges and meters (7-inch display)
Meter display

1022-1. Instrument cluster
■Instrument panel light bright-
ness adjustment
The brightness of the instrument
panel lights can be adjusted sepa-
rately for when the tail lights are on
and off.
■The clocks can be adjusted
on the audio system
screen.
Refer to “MULTIMEDIA
OWNER’S MANUAL”.
■Display
Driving support system status
display area
Displays an image when the follow-
ing systems are operating and a
menu icon other than is
selected:
• LTA (Lane Tracing Assist)
• LDA (Lane Departure Alert)
• Dynamic radar cruise control
• RSA (Road Sign Assist) (if equipped) ( P.234)
Content display area
By selecting menu icons on the
multi-information di splay, a variety
of driving-related information can
be displayed. The multi-information
display can also be used to change
display settings and other vehicle
settings.
Warning or advice pop-up displays
are also displayed in certain situa-
tions.
■Menu icons
The menu icons will be dis-
played by pressing the or
Adjusting the clock
Multi-infor mation dis-
play (4.2-inch display)
Display and menu icons

2785-1. Using the air conditioning system and defogger
5-1.Using the air conditioning system and defogger
Temperature control switch
Fan speed control switch
“A/C” switch
Outside air mode switch
Recirculated air mode switch
Eco air conditioning mode switch
Airflow mode control switch
Rear window defogger and outside rear view mirror defoggers
switch
*
Windshield defogger switch
Off switch
Automatic mode switch
Rear window defogger switch
*
*: If equipped
■Adjusting the temperature
setting
To adjust the temperature set- ting, turn the temperature con-
trol switch clockwise (warm) or
counterclockwise (cool).
If “A/C” switch is not pressed, the
Automatic air conditioning system
Air outlets are automatically selected and fan speed is auto-
matically adjusted according to the set temperature setting.
Also, the display and button positions will differ depending on

the type of the system.
Air conditioning controls

2795-1. Using the air conditioning system and defogger
5
Interior features
system will blow ambient tempera-
ture air or heated air.
■Setting the fan speed
To adjust the fan speed, turn the
fan speed control switch clock-
wise (increase) or counterclock-
wise (decrease).
Pressing the off switch to turns off
the fan.
■Change the airflow mode
Press the airflow mode control
switch.
The airflow mode changes as fol-
lows each time the switch is
pressed.
1 Upper body
2 Upper body and feet
3 Feet
4 Feet and the windshield
defogger operates
■Switching between outside
air and recirculated air
modes
 To change to recirculated air
mode, press the recirculated air mode switch.
The indicator illuminates on the
recirculated air mode switch.

To change to outside air
mode, press the outside air
mode switch.
The indicator illuminates on the out-
side air mode switch.
■Set cooling and dehumidifi-
cation function
Press the “A/C” switch.
When the function is on, the indica-
tor illuminates on the “A/C” switch.
■Defogging the windshield
Defoggers are used to defog the
windshield and front side win-
dows.
Press the windshield defogger
switch.
Set the outside/recirculated air
mode switch to outside air mode if
the recirculated air mode is used. (It
may switch automatically.)
To defog the windshield and the
side windows quickly, turn the air
flow and temperature up.
To return to the previous mode,
press the windshield defogger
switch again when the windshield is
defogged.
When the windshield defogger
switch is on, the indicator illumi-
nates on the windshield defogger
switch.

473Alphabetical Index
Maintenance requirements... 308
Malfunction indicator lamp.... 373
Menu icons ..................... 102, 109
Meter Clock ................................ 96, 99
Indicators................................ 94
Instrument panel light control98, 101
Meter control switches . 103, 110
Meter light control ................. 101
Meters .............................. 96, 99
Multi-information display .... 102, 109
Settings ........................ 108, 114
Warning lights....................... 372
Warning message ................ 382
Mirrors Inside rear view mirror.......... 147
Outside rear view mirror defog-gers .................................... 280
Outside rear view mirrors ..... 148
Vanity mirrors ....................... 298
Moon roof Door lock linked moon roof oper-ation ................................... 153
Jam protection function ........ 153
Operation ............................. 153
Multi-information display Audio system-linked display107, 11 3
Clock .............................. 98, 102
Cruise control ....................... 245
Driving informatio n display . 103,
11 0
Driving support system informa- tion display ................. 107, 113
Dynamic radar cruise control 239
ECO Accelerator Guidance 104, 111
Eco score ..................... 104, 111
Energy monitor ..................... 116
EV Driving Ratio ........... 106, 112 EV Ratio ....................... 106, 112
Fuel economy ............... 104, 110
Hybrid System Indicator .......104
Menu icons ...................102, 109
Meter control switches.. 103, 110
Navigation system-linked display
................................... 107, 113
Settings ........................ 108, 114
Tire pressure ...... ..................328
Vehicle information display .107, 11 3
Warning message.................382
N
Navigation system-linked display ....................................... 107, 113
Noise from under ve hicle...........5
O
Odometer...........................97, 101
Odometer and trip meter display
Display change button ....97, 101
Display items ..................98, 101
Oil Engine oil..............................422
Rear differential oil................424
Open tray .................................290
Opener Fuel filler door.......................196
Hood .....................................316
Trunk ....................................134
Outside rear view mirrors Adjustment ...........................148
BSM (Blind Spot M onitor) .....249
Folding..................................149
Outside rear view mirror defog- gers ....................................280
RCTA function.......................254
Safe Exit Assist.....................260
Outside temperatur e ..........96, 99
Overheating.............................414
