2023 TOYOTA COROLLA HYBRID emergency towing

3707-2. Steps to take in an emergency
4Tighten down the towing eye-
let securely using a wheel nut
wrench (if equipped) or hard
metal bar.
5 Securely attach cables or
chains to the towing eyelet.
Take care not to damage the vehi-
cle body.
6Enter the vehicle being towed
and start the hybrid system.
If the hybrid system does not start,
turn the power switch to ON.
7Shift the shift lever to N and
release the parking brake.
Turn automatic mode off.
( P.184)
When the shift lever cannot
be shifted:  P. 1 8 1
■While towing
If the hybrid system is off, the power
assist for the brakes and steering
will not function, making steering
and braking more difficult.
■Wheel nut wrench
Vehicle without wheel nut wrench:
Wheel nut wrench can be pur-
chased at your Toyota dealer.
Vehicle with wheel nut wrench:
Wheel nut wrench is installed in
trunk. ( P.399)
 Fluid leaks under the vehicle.
(Water dripping from the air
conditioning after use is nor-
mal.)
 Flat-looking tires or uneven
tire wear
 Engine coolant temperature
gauge needle continually
points higher than normal.
 Changes in exhaust sound
 Excessive tire squeal when
cornering
 Strange noises related to the
suspension system
 Pinging or other noises
related to the hybrid system
 Engine missing, stumbling or
running roughly
 Appreciable loss of power
 Vehicle pulls heavily to one
If you think something
is wrong
If you notice any of the fol-
lowing symptoms, your
vehicle probably needs
adjustment or repair. Con-
tact your Toyota dealer as
soon as possible.
Visible symptoms
Audible symptoms
Operational symptoms

3887-2. Steps to take in an emergency
■A flat tire that cannot be
repaired with the emergency
tire puncture repair kit
In the following ca ses, the tire can-
not be repaired with the emergency
tire puncture repair kit. Contact your
Toyota dealer.
●When the tire is damaged due to
driving without sufficient air pres- sure
●When there are a
ny cracks or
damage at any location on the
tire, such as on the side wall,
except the tread
●When the tire is visibly separated
from the wheel
●When the cut or damage to the
tread is 0.16 in. (4 mm) long or
more
●When the wheel is damaged
●When 2 or more tires have been
punctured
●When 2 or more sharp objects
such as nails or screws have
passed through the tread on a sin-
gle tire
●When the sealant has expired
2WD models
Emergency tire puncture repair kit
Towing eyelet
Location of the emergency ti re puncture repair kit and
towing eyelet

3897-2. Steps to take in an emergency
7
When trouble arises
AWD models
Emergency tire puncture repair kit
Towing eyelet
BottleSticker
Compressor
Air pressure gauge
Compressor switch
Power plug
HoseEmergency tire puncture
repair kit components

3997-2. Steps to take in an emergency
7
When trouble arises
Jack handle
Jack
Towing eyelet
Spare tire
Wheel nut wrench
Location of the spare tire, jack and tools
WARNING
■Using the tire jack
Observe the following precau-
tions. Improper use of the tire jack
may cause the vehicle to sud-
denly fall off the jack, leading to
death or serious injury.
●Do not use the tire jack for any
purpose other than replacing
tires or installing and removing
tire chains.
●Only use the tire jack that
comes with this vehicle for
replacing a flat tire. Do not use it
on other vehicles, and do not
use other tire jacks for replacing
tires on this vehicle.
●Put the jack properly in its jack
point.

4187-2. Steps to take in an emergency
NOTICE
●If the vehicle remains stuck
even after these procedures are
performed, the vehicle may
require towing to be freed.

477Alphabetical Index
Replacing ............................. 398
Rotating tires ........................ 327
Size ...................................... 426
Snow tires ............................ 273
Spare tire.............................. 398
Tire pressure warning system........................................... 328
Warning light ........................ 376
Tools ................................ 388, 399
Top tether strap ........................ 68
Total load capacity ................. 420
To w i n g Dinghy towing....................... 169
Emergency towing................ 366
Towing eyelet ....................... 369
Trailer towing ........................ 169
Toyota Safety Sense AHB (Automatic High Beam) 191
Cruise control ....................... 244
Dynamic radar cruise control 236
Emergency Driving Stop System........................................... 247
LDA (Lane Departure Alert) .. 223
LTA (Lane Tracing Assist) ..... 218
PCS (Pre-Collision System) . 207
RSA (Road Sign Assist) ....... 234
Toyota Safety Sense 3.0[Toyota Safety Sense 3.0]PDA (Proactive driving assist) [PDA (Proactive driving assist)]........................................... 228
TRAC (Traction Control) ........ 266
Traction battery (hybrid battery) Hybrid battery (traction battery) air vents................................ 85
Location.................................. 82
Specification ......................... 422
Warning message .................. 86
Traction Control (TRAC) ........ 266
Traction motor (electric motor)77
Trailer towing .......................... 169 Transmission
Driving mode select switch ...264
Hybrid transmission ..............180
If th e s hif t le ver ca n no t b e s hif te d from P .................................181
Trip meters ........................97, 101
Trunk ........................................133 Internal trunk rele ase lever ...135
Smart key system .................134
Trunk light .............................135
Trunk opener ........................134
Wireless remote control........134
Trunk light ...............................135 Wattage ................................428
Turn signal lights Replacing light bulbs ............357
Turn signal lever ...................182
Wattage ................................428
U
USB charging port ..................291
V
Vanity lights ............................298Wattage ................................428
Vanity mirrors .........................298
Vehicle data recording ...............6
Vehicle identification number420
Vehicle information display .107, 11 3
Vehicle Stability Control (VSC) ...............................................266
VSC (Vehicle Stability Control) ...............................................266
W
Warning buzzers ABS ......................................374
Airbags .................................374
Approach warning ................243
