2023 MAZDA CX5 display

▼Average Fuel Economy
This mode displays the average fuel
economy by calculating the total
traveled distance and the total fuel
consumption since the vehicle was
purchased or the past data was reset.
The average fuel economy is calculated
and displayed every 30 seconds.

The average fuel economy can be reset
by pressing the INFO switch for 1.5
seconds or more. After the data is
cleared, the fuel consumption is
recalculated and the - - - L/100 km
(- - - mpg) for the 30 seconds prior to
it being displayed is indicated.
▼Current Fuel Economy
This displays the current fuel economy
by calculating the amount of fuel
consumption and the distance
traveled.

NOTE
Indicates the 0 position when the
vehicle speed is about 5 km/h (3
mph) or slower.
▼ Mazda intelligent Drive Select
(Mi-Drive) Display*
The display changes depending on the
driving mode.

Sport mode
Off-road mode
To w i n g m o d e
When Driving
Instrument Cluster and Display
4-26*Some models.
CX-50_8KB8-EA-22A_Edition2_new
2022-1-6 14:55:18

▼i-ACTIVSENSE Display*
Displays the system status.

Refer to Lane Departure Warning
System (LDWS) on page 4-98.
Refer to Blind Spot Monitoring
(BSM) on page 4-102.
Refer to Traffic Sign Recognition
System (TSR) on page 4-106.
Refer to Distance & Speed Alert
(DSA) on page 4-111.
Refer to Driver Attention Alert (DAA)
on page 4-113.
Refer to Mazda Rada
r Cruise Control
with Stop & Go function (MRCC
with Stop & Go function) on page
4-118.
Refer to Traffic Jam Assist (TJA) on
page 4-128.
Refer to Lane-keep Assist System
(LAS) on page 4-140.
Refer to Emergency Lane Keeping
(ELK) on page 4-141.
Refer to Smart Brake Support (SBS)
on page 4-148.
Refer to Cruise Control on page
4-199.
▼ Compass Display
The direction the vehicle is moving is
displayed in one of eight directions
while the vehicle is being driven.

Display
Direction
NN orth
SS outh
EE ast
WW est
NE Northeast
NW Northwest
SE Southeast
SW Southwest
When Driving
Instrument Cluster and Display
*Some models.4-27
CX-50_8KB8-EA-22A_Edition2_new 2022-1-6 14:55:18

▼Message Display
A message such as the system
operation status, a malfunction, or an
abnormality is indicated.
Warning/indicator light in instrument
cluster turns on/flashes or symbol is
indicated on display at same time as
message
Check the information regarding the
warning/indicator light or indicated
symbol.
Refer to If a Wa
rning Indication/
Warning Lights on page 4-29.
Refer to If a Indication/Indicator Lights
on page 4-31.
Message only is indicated on display
Follow the instructions indicated on
the display. For the display content,
refer to the next page.
Refer to If a Message Indicated on
Multi-information Display on page
7-32.
▼ Warning/Indicator Lights
Instrument Cluster varies depending
on model and specifications.
1. Instrument Cluster
2. Front Center of Headliner

Warning lights will appear in any of the
highlighted areas
When Driving
Instrument Cluster and Display
4-28
CX-50_8KB8-EA-22A_Edition2_new
2022-1-6 14:55:18

▼Warning Indication/Warning Lights
These lights turn on or flash to notify th
e user of the system operation status or a
system malfunction.
Signal Warning Refer to
Brake System Warning Indication/Warning Light*17-20
ABS Warning Indication/Warning Light*1
Electronic
Brake Force
Distribution
System Warn- ing
7-21
ABS warning 7-23
Charging System Warning Indication/Warning Light*17-21
Engine Oil Warning Indication/Warning Light*17-21
High Engine Coolant Temperature Warning Indication 7-22
Power Steering Malfunction Indication/Indicator Light*17-22
Master Warning Indication7-23
Brake Control System Warning Indication/Warning Light*17-23
Brake Override Warning Indication7-24
Check Engine Indication/Light*17-24
(Amber)
*i-stop Warning Indication/Warning Light*17-24
Automatic Transmission Warning Indication/Warning Light*17-24
When Driving
Instrument Cluster and Display
*Some models.4-29
CX-50_8KB8-EA-22A_Edition2_new 2022-1-6 14:55:18

SignalWarning Refer to
*AWD Warning Indication/Warning Light*17-24
Air Bag/Front Seat Belt Pretensioner System Warning Indication/
Warning Light*17-25
Tire Pressure Monitoring System (TPMS) Warning Indication/Warning
Light*1
Flashing
7-26
Tu r n s o n 7-30
(Red) KEY Warning Indication/Warning Light
*17-26
(Amber)
*High Beam Control System (HBC) Warning Indication/Warning
Light*17-27
i-ACTIVSENSE Warning Indication/Warning Light*17-27
Exterior Light Warning Indication/Warning Light*17-27
Low Fuel Warning Indication/Warning Light 7-28
Check Fuel Cap Warning Indication/Warning Light*17-28
Engine Oil Level Warning Indication/Warning Light*17-28
Seat Belt Warning Indication/Warning Light (Front seat) 7-28
(Red)Seat Belt Warning Light (Rear seat)
7-29
*Low Washer Fluid Level Warning Indication/Warning Light7-29
Door-Ajar Warning Indication
7-29
When Driving
Instrument Cluster and Display
4-30*Some models.
CX-50_8KB8-EA-22A_Edition2_new 2022-1-6 14:55:18

SignalWarning Refer to
Liftgate-Ajar Warning Indication 7-29
Hood-Ajar Warning Indication7-29
Door-Ajar Warning Light7-29
*1 The light turns on when the ignition is switched on for an operation check, and turns off a few
seconds later or when the engine is started. If the light does not turn on or remains turned on, have
the vehicle inspected at an Authorized Mazda Dealer.
▼ Indication/Indicator Lights
These lights turn on or flash to notify th
e user of the system operation status or a
system malfunction.
Signal Indicator Refer to
(Green)Seat Belt Indicator Light (Rear seat)
2-26
*Front Passenger Air Bag Deactivation Indicator Light2-67
Security Indicator LightImmobilizer
System3-43
Theft-Deterrent System
3-44
Malfunction 7-27
(Green) KEY Indicator Light
4-5
(Green)
*i-stop Indicator Light4-16
Wrench Indication/Indicator Light*14-34
When Driving
Instrument Cluster and Display
*Some models.4-31
CX-50_8KB8-EA-22A_Edition2_new
2022-1-6 14:55:18

SignalIndicator Refer to
Shift Position Indication 4-40
Lights-On Indicator Light4-49
Headlight High-Beam Indicator LightHeadlight
High-Low Beam4-52
Flashing the Headlights 4-52
Turn Signal/Hazard Warning Indicator Lights Tu r n a n d
Lane-Change
Signals4-54
Hazard Warn- ing Flasher 4-61
Electric Parking Brake (EPB) Indication/Indicator Light*1*27-23
AUTOHOLD Active Indicator Light*14-75
*Mazda Radar Cruise Control with Stop & Go function (MRCC with
Stop & Go function) indicator Light 4-123
*Tra ffi c
Jam Assist (TJA) indicator Light 4-136
TCS/DSC Indication/Indicator Light*1
Tra c t i o n C o n -
trol System (TCS)4-79
Dynamic Sta- bility Control
(DSC)4-81
Tu r n s o n 7-25
TCS OFF Indicator Light*14-80
When Driving
Instrument Cluster and Display
4-32*Some models.
CX-50_8KB8-EA-22A_Edition2_new 2022-1-6 14:55:18

SignalIndicator Refer to
*Select Mode Indicator Light 4-82
(White)
i-ACTIVSENSE Status Symbol (Warning/Risk Avoidance Support Sys-
tem) 4-90
(Green)
(Amber)
i-ACTIVSENSE OFF Symbol (Warning/Risk Avoidance Support Sys-
tem)
4-90
(Green)
*High Beam Control System (HBC) Indicator Light
4-94
(White)
*Mazda Radar Cruise Control with Stop & Go function (MRCC with
Stop & Go function) Standby Indication 4-120
*Traffic Jam Assist (TJA) Standby Indication
4-130
(Green)
*Mazda Radar Cruise Control with Stop & Go function (MRCC with
Stop & Go function) Set Indication 4-120
*Traffic Jam Assist (TJA) Set Indication
4-130
*Smart Brake Support (SBS) OFF Indicator Light*14-155
*Emergency Lane Keeping (ELK) OFF Indicator Light*14-147
(White)
*Cruise Standby Indication4-198
(Green)
*Cruise Set Indication4-198
*1 The light turns on when the ignition is switched on for an operation check, and
turns off a few seconds later or when the en gine is started. If the light does not
When Driving
Instrument Cluster and Display
*Some models.4-33
