Keyless Entry System
▼Keyless Entry System
This system uses the key buttons to
remotely lock and unlock the doors,
liftgate, and fuel-filler lid, and opens/
closes the liftgate.
The system can start the engine
without having to take the key out of
your purse or pocket.
It can also help you signal for attention
or help.
Operating the theft-deterrent system is
also possible on theft-deterrent
system-equipped vehicles.

System malfunctions or warnings are
indicated by the following warning
lights or beeps.
Check the displayed message for more
information and, if necessary, have the
vehicle inspected at an Authorized
Mazda Dealer, according to the
indication.
KEY Warning Indication/Warning
Light (Red)
Refer to KEY Warning Indication/
Warning Light (Red) on page 7-26.
Ignition Not Switched Off (STOP)
Warning Beep
Refer to Ignition Not Switched
Off
(STOP) Warning Beep on page
7-37.
Key Removed from Vehicle Warning
Beep
Refer to Key Removed from Vehicle
Warning Beep on page 7-37.
If you have a problem with the key,
consult an Authorized Mazda Dealer.

If your key is lost or stolen, consult an
Authorized Mazda Dealer as soon as
possible for a replacement and to
make the lost or stolen key inoperative.
CAUTION
Radio equipment like this is governed
by laws in the United States.
Changes or modifications not expressly
approved by the party responsible for
compliance could void the user's
authority to operate the equipment.
NOTE
The keyless entry system operation
may vary due to local conditions.
The keyless entry system is fully
operational when the ignition is
switched off. The system does not
operate if the ignition is switched to
any position other than off.
If the key does not operate when
pressing a button or the operational
range becomes too small, the battery
may be weak. To install a new
battery, refer to Key Battery
Replacement (page 6-29).
Battery life is about 1 year. Replace
the battery with a new one if the
messages are displayed in the
instrument cluster. Replacing the
battery about once a year is
recommended because the KEY
warning indication may not display
depending on the rate of battery
depletion.
Additional keys can be obtained at
an Authorized Mazda Dealer. Up to
6 keys can be used with the keyless
functions per vehicle. Bring all keys
to an Authorized Mazda Dealer
when additional keys are required.
Before Driving
Keys
3-4
CX-50_8KB8-EA-22A_Edition2_new 2022-1-6 14:55:18

The liftgate can be closed when the
doors are locked with the key left in
the vehicle. However, to prevent
locking the key in the vehicle, the
liftgate can be opened by pressing
the electric liftgate opener. If the
liftgate cannot be opened despite
doing this procedure, first push the
liftgate completely closed, then press
the electric liftgate opener to fully
open the liftgate.
When the liftgate latch is released by
pressing the electric liftgate opener,
the liftgate raises slightly. If the
liftgate is not operated for a certain
period of time, the liftgate cannot be
raised.
To o p e n
Press the electric liftgate opener
again.
To c l o s e
To close the liftgate from its slightly
raised position, open it first by
pressing the electric liftgate opener,
then close it after waiting at least 1
second.
If the vehicle battery is dead or there
is a malfunction in the electrical
system and the liftgate cannot be
unlocked, the liftgate can be opened
by performing the emergency
procedure.
Refer to When Liftgate Cannot be
Opened on page 7-41.
Closing the liftgate
Lower the liftgate slowly using the
liftgate grip recess, then push the
liftgate closed using both hands.
Do not slam it. Pull up on the liftgate
to make sure it is secure.
For the power liftgate operation, refer
to Power Liftgate on page 3-22.
WARNING
Do not drive the vehicle with the
liftgate-ajar warning indication
displayed :
Otherwise, the liftgate may open
unexpectedly and result in an accident.
NOTE
Confirm that the liftgate is securely
closed.
Move the liftgate without pressing the
electric liftgate opener to verify that the
liftgate has not been left ajar.
Before Driving
Doors and Locks
3-21
CX-50_8KB8-EA-22A_Edition2_new 2022-1-6 14:55:18

4When Driving
Information concerning safer driving and stopping.
Start/Stop Engine..................... 4-4 Ignition Switch.......................4-4
Starting the Engine................. 4-5
Turning the Engine Off............ 4-9
Cylinder Deact ivat ion
*..........4-10
i-stop
*................................. 4-11
Instrument Cluster and
Display.................................. 4-18 Instrument Cluster and
Display................................4-18
Instrument Cluster............... 4-18
Active Driving Display
*......... 4-35
Automatic Transmission........... 4-37 Automatic Transmission
Controls.............................. 4-37
Shift-Lock System................. 4-38
Transmission Ranges............ 4-39
Manual Shift Mode.............. 4-41
Direct Mode
*.......................4-47
Driving Tips......................... 4-48
Switches and Controls............. 4-49 Lighting Control................... 4-49
Turn and Lane-Change
Signals................................ 4-54
Windshield Wipers and
Washer............................... 4-55
Rear Window Wiper and
Washer............................... 4-58
Rear Window Defogger........ 4-59
Horn................................... 4-61
Hazard Warning Flasher....... 4-61
HomeLink Wireless Control
System
*............................... 4-62
Brake.....................................4-67 Brake System....................... 4-67
AUTOHOLD........................ 4-73
Hill Launch Assist (HLA)........4-77
ABS/TCS/DSC....................... 4-78 Antilock Brake System
(ABS).................................. 4-78
Tra c t i o n C o n t r o l Sy s t e m
(TCS).................................. 4-79
Dynamic Stability Control
(DSC)................................. 4-81
Mazda intelligent Drive Select (Mi-
Drive).................................... 4-82 Mazda intelligent Drive Select
(Mi-Drive) (FWD)
*............... 4-82
Mazda intelligent Drive Select
(Mi-Drive) (AWD)
*...............4-83
i-ACTIV AWD......................... 4-86 i-ACTIV AWD Operation
*..... 4-86
Power Steering....................... 4-88 Power Steering.....................4-88
i-ACTIVSENSE......................... 4-89 i-ACTIVSENSE
*..................... 4-89
Adaptive Front Lighting System
(AFS)
*................................. 4-93
*Some models.4-1
CX-50_8KB8-EA-22A_Edition2_new 2022-1-6 14:55:18

This is for improved exhaust gaspurification and does not indicate
any parts defect.
Engine-starting is controlled by the
spark ignition system.
This system meets all Canadian
Interference-Causing Equipment
Standard requirements regulating the
impulse electrical field strength of
radio noise.
1. Make sure you are carrying the key.
2. Occupants should fasten their seat belts.
3. Make sure the parking brake is on.
4. Continue to depress the brake pedal firmly until the engine has
completely started.
5. Put the vehicle in park (P). If you must restart the engine while the
vehicle is moving, shift into neutral
(N).
NOTE
The starter will not operate if the
selector lever is not in P or N
position and the brake pedal is not
depressed sufficiently.
6. Make sure that the KEY indicator light (green) in the instrument
cluster and push button start
indicator light (green) turns on.
1. Indicator light
2. Push button start
NOTE
If the push button start indicator
light (green) flashes, make sure
that the key is being carried.
If the push button start indicator
light (green) flashes with the key
being carried, touch the key to
the push button start and start
the engine.
Refer to Engine Start Function
When Key Battery is Dead on
page 4-7.
CAUTION
If the KEY warning indication (red)
is displayed, or the push button
start indicator light (amber) flashes,
this could indicate a problem with
the engine starting system. This may
prevent the engine from starting or
from switching the ignition to ACC
or ON.
Refer to KEY Warning Indication/
Warning Light (Red) on page
7-26.
Have your vehicle inspected at an
Authorized Mazda Dealer as soon
as possible.
NOTE
Under the following conditions,
the KEY warning indication (red)
is displayed after the push button
start is pressed. This informs the
driver that the push button start
will not switch to ACC, even if it
is pressed from off (page 7-26).
The key battery is dead.The key is out of operational
range.
The key is placed in areas where
it is difficult for the system to
detect the signal (page 3-7).
When Driving
Start/Stop Engine
4-6
CX-50_8KB8-EA-22A_Edition2_new 2022-1-6 14:55:18

A key from another
manufacturer similar to the key
is in the operational range.
(Forced engine starting method)
If the KEY warning indication
(red) is displayed, or the push
button start indicator light
(amber) flashes, this could
indicate that the engine may not
start using the usual starting
method (page 7-26). Have your
vehicle inspected at an
Authorized Mazda Dealer as
soon as possible. If this occurs,
the engine can be force-started.
Press and hold the push button
start until the engine starts. Other
procedures necessary for starting
the engine, such as having the key
in the cabin, and depressing the
brake pedal are required.
When the engine is force-started,
the KEY warning indication (red)
remains displayed and the push
button start indicator light
(amber) remains flashing.
When the selector lever is in the
neutral (N) position, the push
button start indicator light (green)
does not turn on.
7. Press the push button start after the push button start indicator light
(green) turns on.
NOTE
After starting the engine, the push
button start indicator light
(amber) turns off and the ignition
switches to the ON position.
After pressing the push button
start and before the engine starts,
the operation sound of the fuel
pump motor from near the fuel
tank can be heard, however, this
does not indicate a malfunction.
8. After starting the engine, let it idlefor about 10 seconds.
NOTE
Do not use high engine speeds
until reaching the operating
temperature.
Whether the engine is cold or
warm, it should be started
without the use of the
accelerator.
If the engine does not start the
first time, refer to Starting a
Flooded Engine under Emergency
Starting. If the engine still does
not start, have your vehicle
inspected by an Authorized
Mazda Dealer (page 7-14).
▼Engine Start Function When Key
Battery is Dead
CAUTION
When starting the engine by holding
the transmitter over the push button
start due to a dead key battery or a
malfunctioning key, be careful not to
allow the following, otherwise the
signal from the key will not be received
correctly and the engine may not start.

Metal parts of other keys or metal
objects touch the key.
When Driving
Start/Stop Engine
4-7
CX-50_8KB8-EA-22A_Edition2_new 2022-1-6 14:55:18

▼Emergency Operation for Starting
the Engine
If the KEY warning indication (red) is
displayed, or the push button start
indicator light (amber) flashes, this
could indicate that the engine may not
start using the usual starting method.
Have your vehicle inspected at an
Authorized Mazda Dealer as soon as
possible. If this occurs, the engine can
be force-started. Press and hold the
push button start until the engine
starts. Other procedures necessary for
starting the engine such as having the
key in the cabin, and depressing the
brake pedal are required.
Turning the Engine Off
▼Turning the Engine
Off
WARNING
Do not stop the engine while the
vehicle is moving:
Stopping the engine while the vehicle
is moving for any reason other than in
an emergency is dangerous. Stopping
the engine while the vehicle is moving
will result in reduced braking ability
due to the loss of power braking,
which could cause an accident and
serious injury.
1. Stop the vehicle completely.
2. Shift the selector lever to the P
position and set the parking brake.
3. Press the push button start to turn off the engine. The ignition position
is off.
CAUTION
When leaving the vehicle, make sure
the push button start is off.
When Driving
Start/Stop Engine
4-9
CX-50_8KB8-EA-22A_Edition2_new 2022-1-6 14:55:18

NOTE
The cooling fan in the engine
compartment could turn on for a few
minutes after the ignition is switched
from ON to OFF, whether or not the
A/C is on or off, to cool the engine
compartment quickly.
If the system detects that the
remaining battery power of the key is
low when the ignition is switched
from ON to ACC or OFF, the
following is indicated.
Replace with a new battery before
the key becomes unusable.
Refer to Key Battery Replacement on
page 6-29.
A message is indicated in the display
of the instrument cluster.
Refer to KEY Warning Indication/
Warning Light (Red) on page 7-26.
If the engine is turned off while the
selector lever is in a position other
than P, the ignition switches to ACC.
▼ Emergency Engine Stop
Continuously pressing the push button
start or quickly pressing it any number
of times while the engine is running or
the vehicle is being driven will turn the
engine
off immediately. The ignition
switches to ACC.
Cylinder Deactivation*
▼ Cylinder Deactivation
The cylinder deactivation is a function
designed to reduce fuel consumption
and improve fuel economy by
deactivating 2 out of the 4 cylinders
while driving. The function constantly
determines which is better for driving;
4 cylinders or 2 cylinders, regardless of
the driver's operations, and it performs
the switching automatically.
When the cylinder deactivation
function does not operate
The cylinder deactivation function
does not operate under the following
conditions.
The selector lever is in the P, N, or R
position.
The engine oil temperature or engine
coolant temperature is low.
After disconnecting the battery
terminals for some reason, such as
for battery replacement.
When Driving
Start/Stop Engine
4-10*Some models.
CX-50_8KB8-EA-22A_Edition2_new
2022-1-6 14:55:18

WARNING
Do not rely completely on the vehicle
roll prevention function.
The vehicle roll prevention function
is a supplementary function which
operates for a maximum of 2
seconds after releasing the brake
pedal and accelerating the vehicle
from an engine idling stop condition.
Over reliance on the system may
result in an unexpected accident if
the vehicle were to suddenly
accelerate. Before starting to drive
the vehicle, always confirm the safety
of the surroundings and operate the
selector lever, brake pedal, and
accelerator pedal appropriately.
Note that the vehicle may move
suddenly depending on the vehicle's
load or if it is towing something.
 Note that the vehicle may move
suddenly after the vehicle roll
prevention function is released while
the vehicle is under the following
conditions:
 The selector lever is in the N
position.
 If the selector lever is shifted to the
N position and the brake pedal is
released while the i-stop function
is operating, the brake force is
gradually released. To accelerate
the vehicle, release the brake pedal
after the engine restarts and shift
the selector lever to a position
other than the N position.
NOTE
When the vehicle is stopped on a
steep grade, the vehicle roll
prevention function does not
operate because engine idling is not
stopped.
The brake pedal response may
change, sound may occur from the
brakes, or the brake pedal could
vibrate from the operation of the
vehicle roll prevention function.
However, this does not indicate a
malfunction.
▼ i-stop Warning Light (Amber)/
i-stop Indicator Light (Green)
The i-stop system constantly monitors
the driver's operations, the vehicle's
interior and exterior environment, and
the operational status of the vehicle,
and uses the i-stop warning light
(amber) and i-stop indicator light
(green) to inform the driver of various
cautions and warnings.
NOTE
On vehicles equipped with the center
display, the i-stop operation status is
displayed in the fuel efficiency monitor
display.
Refer to the Fuel Efficiency Monitor
section in the Mazda Connect
Owner's Manual.
i-stop warning light (amber)
When the light is turned on
The light turns on when the ignition
is switched ON and turns off when
the engine is started.
If the i-stop warning light (amber)
remains on while the engine is
running , the battery performance
may have decreased. Have your
vehicle inspected by an Authorized
Mazda Dealer.
When Driving
Start/Stop Engine
4-16
CX-50_8KB8-EA-22A_Edition2_new
2022-1-6 14:55:18
