176SAFETY
NOTE:When filling warm tires, the tire pressure may need to be
increased up to an additional 4 psi (28 kPa) above the
recommended cold placard pressure in order to turn the
TPMS Warning Light off.

Low Tire Pressure Monitoring System Display

Service Tire Pressure System Warning
If a system fault is detected, the Tire Pressure Monitoring
System (TPMS) Warning Light will flash on and off for 75
seconds and then remain on solid. The system fault will
also sound a chime. In addition, the instrument cluster will
display a "Service Tire Pressure System" message for a
minimum of five seconds and then display dashes (- -) in
place of the pressure value to indicate which sensor is not
being received.
If the ignition switch is cycled, this sequence will repeat,
providing the system fault still exists. If the system fault no
longer exists, the TPMS Warning Light will no longer flash,
and the "Service Tire Pressure System" message will no longer display, and a pressure value will display in place of
the dashes. A system fault can occur due to any of the
following:

Signal interference due to electronic devices or driving
next to facilities emitting the same radio frequencies
as the TPMS sensors.
 Accumulation of snow or ice around the wheels or
wheel housings.
 Using tire chains on the vehicle.
 Using wheels/tires not equipped with TPMS sensors.
Vehicles With Compact Spare

1. The compact spare tire or non-matching full size does not have a Tire Pressure Monitoring System
sensor. Therefore, the TPMS will not monitor the
pressure in the compact or non-matching full size
spare tire.

2. If you install the compact or non-matching full size spare tire in place of a road tire that has a pressure
below the low-pressure warning limit, upon the next
ignition key cycle, the TPMS Warning Light will remain
on and a chime will sound. In addition, the graphic in
the instrument cluster will still display a different
color pressure value and an "Inflate to XX" message.
3. After driving the vehicle for up to 20 minutes above 15 mph (24 km/h), the TPMS Warning Light will flash
on and off for 75 seconds and then remain on solid.
In addition, the instrument cluster will display a
“Service Tire Pressure System” message for five
seconds and then display dashes (- -) in place of the
pressure value. 4. For each subsequent ignition key cycle, a chime will
sound, the TPMS Warning Light will flash on and off
for 75 seconds and then remain on solid, and the
instrument cluster will display a “Service Tire
Pressure System” message for five seconds and then
display dashes (- -) in place of the pressure value.
5. Once you repair or replace the original road tire and reinstall it on the vehicle in place of the compact
spare or non-matching full size, the TPMS will update
automatically. In addition, the TPMS Warning Light
will turn off and the graphic in the instrument cluster
will display a new pressure value instead of dashes
(- -), as long as no tire pressure is below the
low-pressure warning limit in any of the four active
road tires. The vehicle may need to be driven for up to
20 minutes above 15 mph (24 km/h) in order for the TPMS to receive this information.
TPMS Deactivation — If Equipped
The Tire Pressure Monitoring System (TPMS) can be
deactivated if replacing all four wheel and tire assemblies
(road tires) with wheel and tire assemblies that do not
have TPMS sensors, such as when installing winter wheel
and tire assemblies on your vehicle.
To deactivate the TPMS, first replace all four wheel and
tire assemblies (road tires) with tires not equipped with
Tire Pressure Monitoring System (TPMS) sensors. Then,
drive the vehicle for 20 minutes above 15 mph (24 km/h).
The TPMS will chime, the TPMS Warning Light will flash on
and off for 75 seconds and then remain on. The
instrument cluster will display the “Service Tire Pressure
System” message and then display dashes (--) in place of
the pressure values.

23_LD_OM_EN_USC_t.book Page 176

284
Safety, Exhaust Gas ..................................................... 201
Satellite Radio .............................................................. 131
Saved Radio Stations .................................................. 135
Schedule, Maintenance...................................... 221
, 222
Seat Belt Reminder.........................................................70 Seat Belts ............................................................ 178
, 199
Adjustable Shoulder Belt........................................ 181
Adjustable Upper Shoulder Anchorage ................. 181
Adjustable Upper Shoulder Belt Anchorage.......... 181
Automatic Locking Retractor (ALR)........................ 182
Child Restraints ...................................................... 190
Energy Management Feature ................................ 182
Extender .................................................................. 181
Front Seat....................................................... 178
, 180
Inspection................................................................ 199 Lap/Shoulder Belt Operation................................. 180
Lap/Shoulder Belt Untwisting ................................ 180
Lap/Shoulder Belts ................................................ 178
Operating Instructions ............................................ 180
Pregnant Women .................................................... 182
Pretensioners.......................................................... 182
Rear Seat ................................................................ 178Reminder................................................................. 178
Seat Belt Extender .................................................. 181Seat Belt Pretensioner ........................................... 182Untwisting Procedure ............................................. 180
Seat Belts Maintenance .............................................. 266
Seats .................................................................. 28
, 30, 31
Adjustment ..........................................................28, 30
Easy Entry ...................................................................31
Head Restraints .........................................................33
Heated ........................................................................31 Height Adjustment..................................................... 30
Power ......................................................................... 30
Rear Folding........................................................ 28
, 29
Seatback Release .............................................. 28, 29
Tilting ................................................................... 28, 30
Vented ........................................................................ 32
Ventilated ................................................................... 32
Security Alarm ................................................... 18
, 19, 70
Arm The System......................................................... 19
Selection Of Coolant (Antifreeze)................................. 271
Sentry Key (Immobilizer) ................................................ 15
Service Assistance........................................................ 273
Service Contract ...........................................................275
Service Manuals ...........................................................276
Settings, Audio .............................................................. 136
Shifting ............................................................................ 80 Automatic Transmission .................................... 80
, 81
Shoulder Belts .............................................................. 178
Side View Mirror Adjustment ......................................... 35
Signals, Turn ................................................... 43
, 74, 201
Sirius Satellite Radio ....................................................131 Favorites .................................................................. 134
Replay ...................................................................... 133
SiriusXM Satellite Radio Browse in SXM......................................................... 134
Favorites .................................................................. 134
Replay ...................................................................... 133
Snow Chains (Tire Chains) ...........................................262
Snow Tires .....................................................................259
Spare Tires ................................................. 206
, 259, 260
Specifications Fuel (Gasoline)......................................................... 271
Oil .............................................................................271 Speed Control
Accel/Decel ............................................................... 86
Accel/Decel (ACC Only) ............................................. 90
Cancel ........................................................................ 86
Resume...................................................................... 86
Set .............................................................................. 86
Speed Control (Cruise Control) ........................ 85
, 86, 87
Sport Mode ..................................................................... 84 Starting............................................................................ 76 Automatic Transmission ........................................... 76
Button ........................................................................ 15
Cold Weather............................................................. 78
Engine Fails To Start ................................................. 78
Remote ...................................................................... 16
Starting And Operating................................................... 76
Starting Procedures ....................................................... 76 Steering ........................................................................... 24 Column Lock.............................................................. 24
Power ......................................................................... 85
Tilt Column.......................................................... 24
, 25
Wheel, Heated ........................................................... 25
Wheel, Tilt ........................................................... 24
, 25
Steering Wheel Audio Controls .................................... 129
Steering Wheel Mounted Sound System .................... 129
Storage ................................................................... 52
, 264
Storage, Vehicle..................................................... 52, 264
Store Radio Presets ..................................................... 135
Storing Your Vehicle ..................................................... 264
Stuck, Freeing............................................................... 218
Sun Roof .................................................................. 57
, 58
Sunglasses Storage ....................................................... 53 Supplemental Restraint System – Air Bag ................. 184
Symbol Glossary ................................................................8
Synthetic Engine Oil ..................................................... 229
System, Remote Starting ............................................... 16

23_LD_OM_EN_USC_t.book Page 284

285
T
Telescoping Steering Column .................................24, 25
Temperature Control, Automatic (ATC) ..........................51
Tilt Steering Column ................................................ 24
, 25
Time Delay Headlight ....................................................................42
Tire And Loading Information Placard ........................ 252
Tire Markings................................................................ 248
Tire Safety Information ................................................ 248
Tire Service Kit ...........................................209
, 210, 211
Tire Service Kit — If Equipped
b
............................... 209
Tires .................................................. 201, 255, 259, 263
Aging (Life Of Tires)................................................. 257 Air Pressure ............................................................. 255
Chains...................................................................... 262Changing ................................................................. 205
Compact Spare ....................................................... 259
General Information ...................................... 255
, 259
High Speed .............................................................. 256
Inflation Pressure ................................................... 255
Jacking..................................................................... 205
Life Of Tires ............................................................. 257
Load Capacity.......................................................... 252
Pressure Monitoring System (TPMS) .............. 72
, 174
Quality Grading ....................................................... 263
Radial ...................................................................... 256 Replacement ........................................................... 258
Rotation ................................................................... 263
Safety.............................................................. 248
, 255
Sizes ........................................................................ 249
Snow Tires ............................................................... 259 Spare Tires ............................................206
, 259, 260
Spinning .................................................................. 257 Trailer Towing .......................................................... 107
Tread Wear Indicators ............................................. 257
Wheel Nut Torque....................................................267
To Open Hood ................................................................. 59
Tongue Weight/Trailer Weight ..................................... 106
Towing ...........................................................................103 Behind A Motorhome .............................................. 109Disabled Vehicle ...................................................... 219
Guide ........................................................................ 105
Recreational ............................................................109Weight ...................................................................... 105
Towing Behind A Motorhome ....................................... 109
Traction ......................................................................... 109
Traction Control ............................................................168
Trailer Towing ................................................................ 103 Hitches .....................................................................105
Minimum Requirements ......................................... 106
Tips ...........................................................................108Trailer And Tongue Weight...................................... 106Wiring ....................................................................... 107
Trailer Towing Guide ..................................................... 105
Trailer Weight ................................................................ 105
Transfer Case Fluid.......................................................................... 272
Transmission................................................................... 81 Automatic ..........................................................81
, 237
Fluid.......................................................................... 272 Maintenance............................................................237Shifting ....................................................................... 80
Transporting Pets ......................................................... 199
Tread Wear Indicators ..................................................257
Trunk Lid (Deck Lid)........................................................ 59
Trunk Release Remote Control...................................... 59 Turn Signals ............................................................. 43
, 74
UUconnect Phone Call Features................................................ 145Things You Should Know About Your Uconnect Phone................................................. 147
Uconnect Settings ..................................................... 18
Uconnect Phone ........................................ 141
, 142, 143
Answer Or Ignore An Incoming Call — Call Currently In Progress .................................. 146
Answer Or Ignore An Incoming Call — No Call Currently In Progress ............................ 146
Bluetooth Communication Link.............................. 149
Call Continuation..................................................... 147
Call Controls ............................................................ 145
Call Termination ...................................................... 147
Cancel Command.................................................... 142
Connecting To A Particular Mobile Phone Or Audio Device After Pairing ............................ 143
Help Command ....................................................... 142 Join Calls.................................................................. 147
Making A Phone Or Audio Device A Favorite ......... 144
Making A Second Call While Current Call Is In Progress ......................................................... 147
Managing Your Favorites ........................................ 145 Natural Speech ....................................................... 141Operation ................................................................. 141
Overview .................................................................. 140
Pair (Link) Uconnect Phone To A Mobile Phone.... 142
Pair A Bluetooth Streaming Audio Device ............. 143Phonebook Download............................................. 144
Place/Retrieve A Call From Hold............................ 146
11

23_LD_OM_EN_USC_t.book Page 285
