SERVICING AND MAINTENANCE243
F15 40 Amp Green –HVAC Blower
F16 20 Amp Blue –Left Spot Lamp – Police
F17 20 Amp Blue –Right Spot Lamp – Police
F18 30 Amp Pink –VISM Mod (Police)
F19 ––Spare
F20 ––Spare
F21 30 Amp Pink –Fuel Pump (Non 6.2L ADR)
F22 –5 Amp TanCyber Gateway Module
F23 –10 Amp RedFuel Door SW * / Diagnostic Port
F24 –10 Amp RedIntegrated Center Stack
F25 –10 Amp RedTire Pressure Monitor
F26 –15 Amp BlueTrans Mod (Charger / 300)
F27 –25 Amp ClearAmplifier *
F31 –25 Amp BreakerPower Seats *
F32 –15 Amp BlueHVAC Module / Cluster
F33 –15 Amp BlueIGN SW / Wireless Mod / Steer Clmn
Lock Mod / Remote Start *
F34 –10 Amp RedSteering Column Module / Clock (300)
F35 –5 Amp TanBattery Sensor
F36 –15 Amp BlueActive Exhaust Valve *
F37 –20 Amp YellowRadio
F38 –20 Amp YellowMedia Hub / Console APO
Cavity Cartridge Fuse Mini-FuseDescription
* If Equipped
8

23_LD_OM_EN_USC_t.book Page 243

244SERVICING AND MAINTENANCE
F40 30 Amp Pink –Fuel Pump #1 (6.2L ADR)
F41 30 Amp Pink –Fuel Pump #2 (6.2L ADR)
F42 30 Amp Pink –Rear Defrost
F43 –20 Amp YellowRear Heated Seats * / Heated Steering
Wheel *
F44 –10 Amp RedPark Assist */ Blind Spot */ Rear View
Camera *
F45 –15 Amp BlueCluster / Rearview Mirror /
Lane Departure *
F46 ––Spare
F47 –10 Amp RedAdaptive Front Lighting */ Day Time
Running Lamps *
F48 –20 Amp YellowActive Suspension – (6.4L*/ 6.2L)
F49 ––Spare
F50 ––Spare
F51 –20 Amp YellowFront Heated */ Vented Seats *
F52 –10 Amp RedHeated Cup Holders */ Rear Heated Seat
Switches *
F53 –10 Amp RedHVAC Module / In Vehicle Temperature
Sensor
Cavity
Cartridge Fuse Mini-FuseDescription
* If Equipped

23_LD_OM_EN_USC_t.book Page 244

SERVICING AND MAINTENANCE245
F54 ––Spare
F55 ––Spare
F56 ––Spare
F57 ––Spare
F58 –10 Amp RedAirbag Module
F59 –20 Amp YellowAdjustable Pedals – Police
F60 ––Spare
F61 ––Spare
F62 ––Spare
F63 ––Spare
F64 –25 Amp BreakerRear Windows (Charger/300)
F65 –10 Amp RedAirbag Module
F66 ––Spare
F67 –10 Amp RedRain & Light Sensor */ Sunroof */ Inside
RearView Mirror / Police Run Acc
F68 –10 Amp RedRear USB Timer / Rear Sunshade *
F69 ––Spare
F70 ––Spare
Cavity Cartridge Fuse Mini-FuseDescription
* If Equipped
8

23_LD_OM_EN_USC_t.book Page 245

256SERVICING AND MAINTENANCE
Check tire pressures more often if subject to a wide range
of outdoor temperatures, as tire pressures vary with
temperature changes.
Tire pressures change by approximately 1 psi (7 kPa) per
12°F (7°C) of air temperature change. Keep this in mind
when checking tire pressure inside a garage, especially in
the Winter.
Example: If garage temperature = 68°F (20°C) and the
outside temperature = 32°F (0°C) then the cold tire
inflation pressure should be increased by 3 psi (21 kPa),
which equals 1 psi (7 kPa) for every 12°F (7°C) for this
outside temperature condition.
Tire pressure may increase from 2 to 6 psi (13 to 40 kPa)
during operation. DO NOT reduce this normal pressure
build up or your tire pressure will be too low.
Tire Pressures For High Speed Operation
The manufacturer advocates driving at safe speeds and
within posted speed limits. Where speed limits or
conditions are such that the vehicle can be driven at high
speeds, maintaining correct tire inflation pressure is very
important. Increased tire pressure and reduced vehicle
loading may be required for high-speed vehicle operation.
Refer to an authorized tire dealer or original equipment
vehicle dealer for recommended safe operating speeds,
loading and cold tire inflation pressures.
Radial Ply Tires
Tire Repair
If your tire becomes damaged, it may be repaired if it
meets the following criteria:
The tire has not been driven on when flat.
 The damage is only on the tread section of your tire
(sidewall damage is not repairable).
 The puncture is no greater than ¼ of an inch (6 mm). Consult an authorized tire dealer for tire repairs and
additional information.
Damaged Run Flat tires, or Run Flat tires that have
experienced a loss of pressure should be replaced
immediately with another Run Flat tire of identical size and
service description (Load Index and Speed Symbol).
Replace the tire pressure sensor as well as it is not
designed to be reused.
Run Flat Tires — If Equipped
Run Flat tires allow you the capability to drive 50 miles
(80 km) at 50 mph (80 km/h) after a rapid loss of inflation
pressure. This rapid loss of inflation is referred to as the
Run Flat mode. A Run Flat mode occurs when the tire
inflation pressure is of/or below 14 psi (96 kPa).
Once a Run Flat tire reaches the Run Flat mode it has
limited driving capabilities and needs to be replaced
immediately. A Run Flat tire is not repairable. When a Run
Flat tire is changed after being driven in a Run Flat mode
14 psi (96 kPa) condition, please replace the TPMS sensor
as it is not designed to be reused.
NOTE:TPMS Sensor must be replaced after driving the vehicle on
a flat tire condition.
WARNING!
High speed driving with your vehicle under maximum
load is dangerous. The added strain on your tires could
cause them to fail. You could have a serious collision.
Do not drive a vehicle loaded to the maximum capacity
at continuous speeds above 75 mph (120 km/h).
WARNING!
Combining radial ply tires with other types of tires on
your vehicle will cause your vehicle to handle poorly.
The instability could cause a collision. Always use radial
ply tires in sets of four. Never combine them with other
types of tires.

23_LD_OM_EN_USC_t.book Page 256

282
ECO Mode Indicator...................................................73
Electric Power Steering Fault .................................... 69
Electronic Stability Control (ESC) Active Warning .... 71
Electronic Stability Program(ESP) Indicator ............. 70
Exterior ............................................................. 40
, 201
Fog .............................................................................. 42
Forward Collision Warning (FCW) OFF Indicator ......73
Front Fog Indicator ....................................................73
Hazard Warning Flasher ......................................... 202
Headlight Switch ........................................................40
Headlights ...........................................................40
, 42
Headlights On With Wipers .......................................42
High Beam..................................................................41
High Beam Indicator ..................................................74
High Beam/Low Beam Select ...................................41
Instrument Cluster ..................................................... 40
Intensity Control .........................................................45
Interior ........................................................................43
LaneSense Indicator...........................................73
, 74
License .................................................................... 247
Lights On Reminder ...................................................42
Low Fuel .....................................................................71
Low Washer Fluid Warning........................................71
Malfunction Indicator (Check Engine) ...................... 71
Oil Temperature Warning ..........................................70
Park ..................................................................... 42
, 73
Passing ....................................................................... 42
Reading ...................................................................... 44
Seat Belt Reminder ...................................................70
Security Alarm ............................................................70
Service ..................................................................... 246
Service Adaptive Cruise Control (ACC) Warning ......72
Service Forward Collision Warning (FCW) ................72
Service LaneSense Warning ..................................... 71
Traction Control ...................................................... 167 Transmission Temperature Warning ........................ 70
Trunk Open Warning ................................................. 70
Turn Signals ........................................41
, 43, 74, 201
Vanity Mirror .............................................................. 35
Warning Instrument Cluster Descriptions......... 70
, 74
Load Shed Battery Saver On .......................................... 67
Load Shed Electrical Load Reduction ........................... 67
Load Shed Intelligent Battery Sensor............................ 67
Loading Vehicle................................................... 102
, 103
Capacities ................................................................ 103
Tires.......................................................................... 252
Locks Auto Unlock................................................................ 23
Automatic Door.......................................................... 23
Child Protection ......................................................... 24
Power Door ................................................................ 21
Low Tire Pressure System ............................................174
Lubrication, Body .......................................................... 231
Lug Nuts/Bolts .............................................................. 267
MMaintenance ................................................................... 58 Maintenance Free Battery ...........................................228
Maintenance Schedule ...................................... 221
, 222
Malfunction Indicator Light (Check Engine) ........... 71, 75
Manual Service .....................................................................276
Media Hub....................................................................... 54
Media Mode .................................................................. 138
Memory Seat ................................................................... 27 Memory Settings............................................................. 27
Methanol ....................................................................... 269
Mirrors ............................................................................. 34 Electric Powered ........................................................ 36 Electric Remote ......................................................... 36
Heated ....................................................................... 36
Outside....................................................................... 35
Rearview .................................................... 34
, 35, 202
Vanity ......................................................................... 35
Modifications/Alterations Vehicle ..........................................................................8
Monitor, Tire Pressure System .................................... 174
Mopar Parts .................................................................. 276
MP3 Control .................................................................... 54
Multi-Function Control Lever ......................................... 41
NNew Vehicle Break-In Period ......................................... 79
OOccupant Restraints .................................................... 177
Octane Rating, Gasoline (Fuel) ........................... 268, 271
Oil Change Indicator ....................................................... 65 Reset.......................................................................... 65
Oil Filter, Change .......................................................... 229
Oil Filter, Selection ....................................................... 229
Oil Pressure Light ........................................................... 70
Oil, Engine ............................................................ 228
, 271
Capacity ................................................................... 270
Checking .................................................................. 227
Dipstick .................................................................... 227
Disposal ................................................................... 229
Filter ......................................................................... 229
Filter Disposal.......................................................... 229
Identification Logo .................................................. 229
Materials Added To ................................................. 229 Pressure Warning Light ............................................ 70
Recommendation...........................................228
, 270

23_LD_OM_EN_USC_t.book Page 282
