2023 DODGE CHARGER ignition

240SERVICING AND MAINTENANCE
F03 50 Amp Red –Electric Power Steering #1 *
F04 30 Amp Pink –Starter
F05 40 Amp Green –Anti-Lock Brake
F06 30 Amp Pink –Anti-Lock Brake
F07 20 Amp Blue –Police Ignition Run / ACC #1
F08 20 Amp Blue –Police Ignition Run / ACC # 2
F09 –20 Amp Yellow All-Wheel Drive Module *
F10 –10 Amp RedIntrusion MOD (300) * / Under Hood Lamp – Police
F11 –20 Amp Yellow Horns
F12 –10 Amp RedAir Conditioning Clutch
F13 ––Spare
F14 ––Spare
F15 ––Spare
F16 ––Spare
F18 50 Amp Red –Radiator Fan #2
F19 50 Amp Red –Electric Power Steering #2 *
F20 30 Amp Pink –Wiper Motor
F21 30 Amp Pink
–Headlamp Washers *
20 Amp Blue Police Bat Feed #2
F22 40 Amp Green
–LTR Cooling Pump (6.2L Eng)
20 Amp Blue Police Bat Feed # 3
F23 20 Amp Blue –Police Bat Feed # 1
Cavity Cartridge Fuse Mini-Fuse Description
* If Equipped

23_LD_OM_EN_USC_t.book Page 240

SERVICING AND MAINTENANCE241
F24 20 Amp Blue –Police Ignition Run/ACC Feed # 3
F28 ––Spare
F29 –15 Amp Blue Auto Trans (Challenger / Police)
F30 ––Spare
F31 –25 Amp Clear Engine Module
F32 ––Spare
F33 ––Spare
F34 –25 Amp Clear ASD Feed #1
F35 –20 Amp Yellow ASD Feed #2
F36 –10 Amp RedAnti-Lock Brake Module / Steering Column Lock Module *
F37 –10 Amp RedEngine Controller
F38 –10 Amp RedAirbag Module
F39 –10 Amp RedA/C Clutch / EPS */ Vacuum Pump *
F48 –10 Amp RedAWD Module / Front Axle Disconnect *
F49 ––Spare
F50 ––Spare
F51 –20 Amp Yellow Vacuum Pump *
F52 –5 Amp TanAdaptive Cruise Control *
F53 ––Spare
Cavity Cartridge Fuse Mini-Fuse Description
* If Equipped
8

23_LD_OM_EN_USC_t.book Page 241

TECHNICAL SPECIFICATIONS269
GASOLINE/OXYGENATE BLENDS
Some fuel suppliers blend unleaded gasoline with
oxygenates such as ethanol.
Problems that result from using gasoline containing more
than 15% ethanol (E-15) or gasoline containing methanol
are not the responsibility of the manufacturer and may
void or not be covered under New Vehicle Limited
Warranty.
DO NOT USE E-85 IN NON-FLEX FUEL
V
EHICLES
Non-Flex Fuel Vehicles (FFV) are compatible with gasoline
containing up to 15% ethanol (E-15). Use of gasoline with
higher ethanol content may void the New Vehicle Limited
Warranty. If a Non-FFV vehicle is inadvertently fueled with E-85 fuel,
the engine will have some or all of these symptoms:

Operate in a lean mode.
 OBD II Malfunction Indicator Light on.
 Poor engine performance.
 Poor cold start and cold drivability.
 Increased risk for fuel system component corrosion.
CNG AND LP FUEL SYSTEM
M
ODIFICATIONS
Modifications that allow the engine to run on Compressed
Natural Gas (CNG) or Liquid Propane (LP) may result in
damage to the engine, emissions, and fuel system
components. Problems that result from running CNG or LP
are not the responsibility of the manufacturer and may
void or not be covered under the New Vehicle Limited
Warranty.
METHYLCYCLOPENTADIENYL
M
ANGANESE TRICARBONYL (MMT) IN
G
ASOLINE
MMT is a manganese-containing metallic additive that is
blended into some gasolines to increase octane. Gasoline
blended with MMT provides no performance advantage
beyond gasoline of the same octane number without
MMT. Gasoline blended with MMT reduces spark plug life
and reduces emissions system performance in some
vehicles. The manufacturer recommends that gasoline
without MMT be used in your vehicle. The MMT content of gasoline may not be indicated on the
gasoline pump; therefore, you should ask your gasoline
retailer whether the gasoline contains MMT. MMT is
prohibited in Federal and California reformulated
gasoline.
FUEL SYSTEM CAUTIONS
NOTE:Intentional tampering with the emissions control system
can result in civil penalties being assessed against you.
CAUTION!
DO NOT use E-85, gasoline containing methanol, or
gasoline containing more than 15% ethanol (E-15). Use
of these blends may result in starting and drivability
problems, damage critical fuel system components,
cause emissions to exceed the applicable standard,
and/or cause the Malfunction Indicator Light to
illuminate. Please observe pump labels as they should
clearly communicate if a fuel contains greater than
15% ethanol (E-15).
CAUTION!
Follow these guidelines to maintain your vehicle’s
performance:

The use of leaded gasoline is prohibited by Federal
law. Using leaded gasoline can impair engine perfor -
mance and damage the emissions control system.
 An out-of-tune engine or certain fuel or ignition
malfunctions can cause the catalytic converter to
overheat. If you notice a pungent burning odor or
some light smoke, your engine may be out of tune or
malfunctioning and may require immediate service.
Contact an authorized dealer for service assistance.
 The use of fuel additives, which are now being sold
as octane enhancers, is not recommended. Most of
these products contain high concentrations of meth -
anol. Fuel system damage or vehicle performance
problems resulting from the use of such fuels or addi -
tives is not the responsibility of the manufacturer
and may void or not be covered under the New
Vehicle Limited Warranty.
9

23_LD_OM_EN_USC_t.book Page 269

281
Gross Axle Weight Rating ................................... 102, 103
Gross Vehicle Weight Rating .............................. 102, 103
GVWR ............................................................................ 102
HHazard Driving Through Flowing, Rising, OrShallow Standing Water .................................... 110
Hazard Warning Flashers ............................................ 202
Head Restraints .............................................................. 33
Head Rests ...................................................................... 33
Headlights Automatic ...................................................................42
Cleaning................................................................... 265
High Beam/Low Beam Select Switch .......................41
Lights On Reminder ...................................................42
On With Wipers ..........................................................42
Passing ....................................................................... 42
Switch .........................................................................40
Time Delay..................................................................42
Washers................................................................... 227
Heated Mirrors ................................................................36 High Beam/Low Beam Select (Dimmer) Switch ...........41
Hill Start Assist ............................................................. 167
Hitches Trailer Towing .......................................................... 105
Holder, Coin .....................................................................53
HomeLink (Garage Door Opener) ..................................36
Hood Prop ........................................................................59 Hood Release ..................................................................59
IIgnition............................................................................. 15 Switch......................................................................... 15
Illuminated Cupholder .................................................... 54 Indicator Lights Blue ............................................................................ 74
Green.......................................................................... 73
White .......................................................................... 74
Yellow ......................................................................... 73
Information Center, Vehicle ........................................... 64
Inside Rearview Mirror ................................... 34
, 35, 202
Instrument Cluster ................................................... 61, 63
Descriptions ............................................................... 74
Display................................................................. 63
, 65
Instrument Cluster
b
................................................... 63
Instrument Panel Lens Cleaning ................................. 266
Interior Appearance Care ............................................. 265
Interior Lights .................................................................. 43
JJack Location ................................................................ 206
Jacking And Tire Changing — If Equipped
b
............. 205
Jump Starting ...................................................... 213, 214
KKey Fob Arm The System......................................................... 19
Panic Alarm ................................................................ 13
Programming Additional Key Fobs ........................... 14
Unlatch The Trunk ..................................................... 13
Key Fob Battery Service (Remote Keyless Entry) ......... 13 Key Fob Programming (Remote Keyless Entry)............ 14
Keyless Enter 'n Go™ .............................................. 22
, 78
Enter The Trunk......................................................... 13
Passive Entry ............................................................. 22
Passive Entry Programming ..................................... 22
Keys ................................................................................. 12
LLane Change And Turn Signals ..................................... 43
Lane Change Assist ........................................................ 43 LaneSense ...................................................................... 98Lap/Shoulder Belts ...................................................... 178
Latches ......................................................................... 201 Hood........................................................................... 59
Lead Free Gasoline ...................................................... 268
Leaks, Fluid................................................................... 201
Life Of Tires ................................................................... 257
Light Bulbs ...........................................................201
, 246
Lights ............................................................................. 201 Adaptive Cruise Control (ACC) Set WithTarget Vehicle ...................................................... 73
Adaptive Cruise Control (ACC) Set Without Target Vehicle ...................................................... 73
Air Bag...................................................... 68
, 183, 200
Automatic Headlights ............................................... 42
Brake Assist Warning.............................................. 167
Brake Warning.................................................. 68
, 267
Bulb Replacement .................................................. 246
Cruise .................................................................. 73
, 74
Daytime Running....................................................... 41
Dimmer Switch, Headlight ........................................ 41
