Cadillac Lyriq Owner Manual (GMNA-Localizing-U.S./Canada-15644413) -
2023 - CRC - 2/23/22
152 Infotainment System
.Press and hold when
the system is on to turn
the power off.
.Press to mute/unmute
the system when on.
.Scroll up or down to
increase or decrease
the volume.
Home Page
The Home Page is where
vehicle application icons are
accessed. Some applications
are disabled when the vehicle
is moving.
Swipe left or right across the
display or use the MFC to
move the home page. Move
the knob right/left to change
the page or touch on one of
the page count indicators at
the bottom of the screen to
jump to a specific page.
Managing Home Page Icons1. Touch and hold any of the Home Page icons to enter
edit mode. Edit mode is not
available when the vehicle is
moving. 2. Continue holding the icon
and drag it to the desired
position.
3. Release your finger to drop the icon in the desired
position.
4. To move an application to another page, drag the icon
to the edge of the display
toward the desired page
5. Continue dragging and dropping application icons
as desired.
6. Touch Done to save changes or Cancel to not
save and exit edit mode.
There will always be 10 icons
per page except on the last
page. If an icon is moved from
the first page to the second,
then that icon from the
second page will replace the
one removed from the first.
Steering Wheel
Controls
If equipped, some audio
controls can be adjusted at
the steering wheel.
x+ orx− :Toggle up or down to
increase or decrease the
volume.
e: Press show the audio
sources list.
6: Press to answer an
incoming phone call or show
the recent phone call list when
not in a call.

Cadillac Lyriq Owner Manual (GMNA-Localizing-U.S./Canada-15644413) -
2023 - CRC - 2/23/22
Infotainment System 153
CorB:Press to go to the
next or previous favorite when
listening to the radio. Press to
go to the next or previous
track when listening to a
media source.
c: Press to reject an
incoming phone call, end an
active phone call, end a voice
recognition session, or mute
the audio when there is no
phone call.
g: Press initiate voice
assistant.
Using the System
Audio
Touch the Audio icon on the
infotainment display or
eon
the Multifunction Controler
(MFC) to display the active
audio source page. Examples
of available sources may
include AM, FM, SXM (if
equipped), USB, and
Bluetooth.
Phone
Touch the Phone icon on the
infotainment display or
6on
the MFC to display the Phone
menu. See Bluetooth
(Overview) 0168 or
Bluetooth (Pairing and Using a
Phone) 0170.
Maps
Touch the Maps icon to
display the Google Maps
screen. See Using the
Navigation System 0162.
Google Assistant
Touch the Google Assistant
icon to open the Google
Assistant app. See Voice
Recognition 0166.
Google Play
Touch to download some of
your favorite apps in your
vehicle. Downloading apps on
Google Play require you to
sign into a Google Account
with an active service plan
with data. Some third-party apps require a separate
account and, in some cases, a
paid subscription for in-vehicle
access.
Apple CarPlay
Touch the Apple CarPlay icon
to activate Apple CarPlay (if
equipped) after a supported
device is connected. See
Apple CarPlay and Android
Auto
0174.
Android Auto
Touch the Android Auto icon
to activate Android Auto (if
equipped) after a supported
device is connected. See
Apple CarPlay and Android
Auto 0174.
Settings
Touch the Settings icon to
display the Settings menu. See
Settings 0176.
Virtual Controls
Touch the Virtual Controls
icon to display the Virtual
Controls menu.

Cadillac Lyriq Owner Manual (GMNA-Localizing-U.S./Canada-15644413) -
2023 - CRC - 2/23/22
154 Infotainment System
Application Tray
The Application Tray is along
the bottom of the display.
It shows up to six applications.
Infotainment Gestures
Use the following finger
gestures to control the
infotainment system.
Touch/Tap
Touch/tap is used to select an
icon or option, activate an
application, or change the
location inside a map.Touch and Hold
Touch and hold can be used to
move or delete an application.
Drag
Drag is used to move
applications on the Home
Page, or to pan the map. To
drag the item, it must be held
and moved along the display
to the new location. This canbe done up, down, right, or left.
This feature is only available
when vehicle is parked and not
in motion.
Nudge
Nudge is used to move items a
short distance on a list or a
map. To nudge, hold and move
the selected item up or down
to a new location.

Cadillac Lyriq Owner Manual (GMNA-Localizing-U.S./Canada-15644413) -
2023 - CRC - 2/23/22
Infotainment System 155
Fling or Swipe
Fling or swipe is used to scroll
through a list, pan the map,
or change page views. Do this
by placing a finger on the
display then moving it rapidly
up and down or right and left.
Spread
Spread is used to zoom in on a
map, certain images, or a web
page. Place finger and thumb
together on the display, then
move them apart.
Pinch
Pinch is used to zoom out on a
map, certain images, or a web
page. Place finger and thumb
apart on the display, then
move them together.
Cleaning High Gloss
Surfaces and Vehicle
Information and Radio
Displays
For vehicles with high gloss
surfaces or vehicle displays,
use a microfiber cloth to wipe
surfaces. Before wiping thesurface with the microfiber
cloth, remove dirt that could
scratch the surface. Then use
the microfiber cloth by gently
rubbing to clean. Never use
window cleaners or solvents.
Periodically hand wash the
microfiber cloth separately,
using mild soap. Do not use
bleach or fabric softener.
Rinse thoroughly and air dry
before next use.
Software Updates
Over-the-Air Software
Updates
If equipped, see
“Updates”
under Settings 0176 for
details on software updates.

Cadillac Lyriq Owner Manual (GMNA-Localizing-U.S./Canada-15644413) -
2023 - CRC - 2/23/22
156 Infotainment System
Radio
AM-FM Radio
Playing the Radio
From the Home Page, touch
the Audio icon to display the
active audio source page.
Touch
ªfrom the top of the
page to choose from AM, FM,
SiriusXM, or Bluetooth.
Finding a Station
Seeking a Station
From the AM or FM screen,
touch
@or9on the
infotainment display to search
for the previous or next
strong station. Tune
TouchZon the infotainment
display to display the Tune
screen. Enter a station using
the keypad.
The keypad will gray out
entries that do not contribute
to a valid frequency and will
automatically place a decimal
point within the frequency
number.
Touch
oto delete one
number at a time. Touch and
hold
oto delete all numbers.
A valid AM or FM station will
automatically tune to the new
frequency and display the now
playing screen. The list of all available stations
are on the right side of the
Tune display to browse. Touch
to go to that station or touch
Hto save the station as a
favorite.
Storing Radio Station
Favorites
Favorites show in the area on
the left of the display.
AM, FM, or SiriusXM :
Favorites can be stored by
touching Hold to Set on the
left side of the screen.
The number of favorites is
displayed automatically.
Audio Settings
From the AM or FM screen,
touch
Fto display the
following:
Equalizer : Touch to adjust
Bass, Midrange, or Treble
using the options on the
infotainment display.

Cadillac Lyriq Owner Manual (GMNA-Localizing-U.S./Canada-15644413) -
2023 - CRC - 2/23/22
Infotainment System 157
Fade/Balance :Touch to
adjust by using the controls on
the infotainment display.
Sound Mode : Touch to
selectFront or Rear to provide
the best sound for the front or
rear seating positions.
Adjust the Surround controls
to change from Stereo to
Surround mode.
Manage Radio Favorites :
Touch to display a list of Audio
favorites.
Favorites can be moved or
deleted.
To move, touch and hold the
move icon, and then drag up or
down to rearrange the
position.
Radio Text : This allows the
Radio Data System (RDS) to
be turned on or off.
Touch Off or On.Radio Data
System (RDS)
If equipped, RDS features are
available for use only on FM
stations that broadcast RDS
information. When supported,
the radio may:
.Display Category (Program
Type) such as Rock, Jazz,
Classical, etc. from radio
stations.
.Display text from radio
stations that include station
name and messages.
This system relies on receiving
specific information from
these stations and only works
when the information is
available. It is possible that a
radio station could broadcast
incorrect information that
causes the radio features to
work improperly. If this
happens, contact the radio
station.
When information is broadcast
from a RDS station, the
station name or call letters display on the audio screen.
Radio text supporting the
currently playing broadcast
may also appear.
Satellite Radio
SiriusXM Radio Service
If equipped, vehicles with a
valid SiriusXM radio
subscription can receive
SiriusXM programming.
SiriusXM radio has a wide
variety of programming and
commercial-free music, coast
to coast, in digital-quality
sound. In the U.S., see
www.siriusxm.com or call
1-888-601-6296. In Canada,
see www.siriusxm.ca or call
1-877-438-9677.
When SiriusXM is active, the
channel name, number, song
title, and artist appear on the
display.

Cadillac Lyriq Owner Manual (GMNA-Localizing-U.S./Canada-15644413) -
2023 - CRC - 2/23/22
158 Infotainment System
SiriusXM with 360L
SiriusXM with 360L interface
has enhanced in-vehicle
listening experience for
subscribers. The experience
now offers more categories
and system learned
recommendations toward
discovering more personalized
content.
To use the full SiriusXM 360L
program, including streaming
content and listening
recommendations, OnStar
Connected Access is required.
Connected vehicle services
vary by model and require a
complete working electrical
system, cell reception, and
GPS signal. An active
connected plan is required.
Reference the SiriusXM user
guide for use and subscription
information.
Finding a Channel
Seeking a Channel
From the SiriusXM active
source page, touch
SCH or
CH
Tto seek for the previous
or next channel. Touch Hold to
Set to save the channel as a
favorite.
Browsing Categories
Touch
(to show the
categories
Touching a category will show
the channels associated with
that category. Direct Tune
Access Direct Tune by
touching
Zon the Linear
Tuner screen. This will display
the Direct Tune keypad.
Navigate through all channels
using
SCH or CHTon the
Direct Tune display. Directly
enter a channel using the
keypad and touch GO. When a
new channel is entered, the
information about that channel
displays on the right side. This
information will update with
each new channel. Touch
Hto
save the channel as a favorite.

Cadillac Lyriq Owner Manual (GMNA-Localizing-U.S./Canada-15644413) -
2023 - CRC - 2/23/22
Infotainment System 159
Favorites
Audio favorites are displayed
on the left side of the active
audio source page.
Favorites are stored by
touching Hold to Set at the
left side of the active audio
source page.
User Settings
From the SiriusXM source
main page, touch
zto display
the following:
.Tune Start
.Location Services
.Help and Support
Tune Start
Select on or of to have songs
play from the start when
tuning.
Location Services
Select on or of to allow
SiriusXM to see your location.
Help and Support
Select to show the SiriusXM
help website.
Radio Reception
Unplug electronic devices
from the accessory power
outlets if there is interference
or static in the radio.
FM
FM signals only reach about 16
to 65 km (10 to 40 mi).
Although the radio has a
built-in electronic circuit that
automatically works to reduce
interference, some static can
occur, especially around tall
buildings or hills, causing the
sound to fade in and out.
AM
The range for most AM
stations is greater than for
FM, especially at night. The
longer range can cause station
frequencies to interfere with
each other. Static can also
occur when things like storms
and power lines interfere with
radio reception. When this
happens, try reducing the
treble on the radio.
SiriusXM Satellite Radio
Service
If equipped, SiriusXM Satellite
Radio Service provides digital
radio reception. Tall buildings
or hills can interfere with
satellite radio signals, causing
the sound to fade in and out.
In addition, traveling or
standing under heavy foliage,
bridges, garages, or tunnels
may cause loss of the
SiriusXM signal for a period of
time. Some cellular services
may interfere with SXM
reception causing loss of
signal.
Mobile Device Usage
Mobile device usage, such as
making or receiving calls,
charging, or just having the
mobile device on may cause
static interference in the radio.
Unplug the mobile device or
turn it off if this happens.
