Care and storage
96
TIP
Make sure that the air filter case cover is se-
curely installed.
(6) Fasten the fuel hose to the holder usingthe plastic tie.
(7) Make sure that the area around the wa- tercraft is clear, and then start the engine
in a well-ventilated area and let it run at
idle for 15 seconds. (See page 26 for in-
formation on starting the engine.)
(8) Stop the engine.
(9) Securely install the seats in their original positions.
UF4N71E0.book Page 96 Thursday, August 5, 2021 11:58 AM

Maintenance
97
EJU3376A
Maintenance
Periodic checks and lubrication will keep
your watercraft in the safest and most effi-
cient condition possible. Therefore, make
sure to carry out the periodic maintenance.
Safety is an obligation of the watercraft own-
er. Proper maintenance must be carried out
to keep the exhaust emission and sound lev-
els within the regulated limits. The most im-
portant points of watercraft inspection and
lubrication are explained on the following pa-
ges.
See a Yamaha dealer for genuine Yamaha re-
placement parts and optional accessories
designed for your watercraft.
Remember, failures that are the result of the
installation of parts or accessories which are
not qualitatively equivalent to genuine
Yamaha parts are not covered by the limited warranty.
Maintenance, replacement, or repair of
the emission control devices and system
may be performed by any marine SI engine
repair establishment or individual. War-
ranty repair, however, must be performed
at an authorized Yamaha marine dealer-
ship.
EWJ00312
Be sure to turn off the engine when you
perform maintenance unless otherwise
specified. If you are not familiar with ma-
chine servicing, this work should be done
by a Yamaha dealer or other qualified me-
chanic.
UF4N71E0.book Page 97 Thursday, August 5, 2021 11:58 AM

Maintenance
98
EJU43103Periodic maintenance chart
The periodic maintenance chart gives general guidelines for periodic maintenance. Have a
Yamaha dealer perform the checks in the following chart. However, maintenance may need to be performed more frequently depending on your operating conditions. If you have any
questions, consult a Yamaha dealer.
This “ √” mark indicates items to be checked and serviced by a Yamaha dealer.
Item OperationInitial Thereafter every
Page
10 hours 50 hours
or 12
months *1 100
hours or 12
months *1 200
hours or 24
months *1
Fuel line Check fuel hoses and
clamps
√
—
Fuel filler cap/Wa-
ter separator Check O-rings for cracks
and deformation
√
—
Fuel tank Check installation and
straps
√
—
Water inlet strainer Check for clogs and dam-
age
√
—
Cooling water hos-
es Check for damage and
leakage, and check
clamps
√
—
Engine oil Replace √√ 100
Oil filter Replace √100
Intermediate hous-
ing Lubricate
√—
Spark plugs Check √√ —
Battery Check state of charge,
terminals and bands
√
—
Battery leads Check terminals √—
Steering master Check operation and for
looseness
√√
—
Steering cable Check exterior and con-
nections, and lubricate
√
—
Shift rod and re-
verse gate (VX /
VX DELUXE /
VX CRUISER / VX
LIMITED) Check exterior and con-
nections, and lubricate
√
—
Air filter element Check for damage and
dirt
√
—
Air intake hoses Check for damage, and
check clamps
√
—
Throttle body Lubricate throttle valve √—
UF4N71E0.book Page 98 Thursday, August 5, 2021 11:58 AM

Maintenance
99
*1: Whichever comes first.
*2: Check every 200 hours.
Perform the pre-operation checks and post-operation checks before performing periodic
maintenance.
Exhaust systemCheck for exhaust leak-
age, and check hoses and
clamps √
—
Breather hose Check breather hose and
clamps
√
—
Impeller Check for bends, dam-
age, and foreign material
√
—
Drive shaft spline Check for damage and lu-
bricate splines
√
—
Jet pump bearings Check bearings and
grease condition
√
—
Jet thrust nozzle Check movement, and lu-
bricate
√
—
Jet vacuum bilge Check hoses for clogs
and damage, check
clamps, and clean bilge
strainer
√
—
Stern drain plugs Check O-rings √—
Anode Check for corrosion, and
clean
√
*2 —
Valve clearance Check and adjust √ *2 —
Rubber coupling Check for cracks, inden-
tations, looseness, and
noise √
—
Engine mount Check for damage and
peeling
√
—
Item Operation
Initial Thereafter every
Page
10 hours 50 hours
or 12
months *1 100
hours or 12
months *1 200
hours or 24
months *1
UF4N71E0.book Page 99 Thursday, August 5, 2021 11:58 AM

Maintenance
100
EJU36943Engine oil and oil filterEWJ00341
Engine oil is extremely hot immediately af-
ter the engine is turned off. Coming in con-
tact with or getting any engine oil on your
clothes could result in burns.
ECJ00992
Do not run the engine with too much or not
enough oil in the engine, otherwise the en-
gine could be damaged.
It is recommended to have a Yamaha dealer
change the engine oil and the engine oil filter.
However, if you choose to change the oil and
filter on your own, consult a Yamaha dealer.
UF4N71E0.book Page 100 Thursday, August 5, 2021 11:58 AM

Specifications
101
EJU46451
Specifications
Watercraft capaci-
ty:Maximum people on board: 3 person
Maximum load capacity: 240 kg (530 lb)
Dimensions and
weight: Length: 3.33 m (131.1 in) (VX-C)
3.37 m (132.7 in) (VX LIMITED /
VX CRUISER / VX DELUXE / VX)
Width: 1.24 m (48.8 in)
Height: 1.20 m (47.2 in)
Dry weight: 306 kg (675 lb) (VX DELUXE)
308 kg (679 lb) (VX CRUISER)
314 kg (692 lb) (VX DELUXE with au-
dio)
316 kg (697 lb) (VX LIMITED /
VX CRUISER with audio)
318 kg (701 lb) (VX-C)
326 kg (719 lb) (VX)
Performance: Maximum output (according to ISO
8665/SAE J1228): 74.6 kW at 7300 r/min (VX-C)
85.0 kW at 8000 r/min (VX LIMITED /
VX CRUISER / VX DELUXE / VX)
Maximum fuel consumption: 29.1 L/h (7.7 US gal/h, 6.4 Imp.gal/h)
(VX-C)
33.0 L/h (8.7 US gal/h, 7.3 Imp.gal/h)
(VX LIMITED / VX CRUISER /
VX DELUXE / VX)
Cruising range at full throttle: 2.12 hour (VX LIMITED /
VX CRUISER / VX DELUXE / VX)
2.41 hour (VX-C)
Trolling speed: 1500 ±100 r/min
Engine: Engine type: Liquid cooled 4-stroke, DOHC
Number of cylinders: 3
Engine displacement: 1049 cm³
Bore × stroke: 82.0 × 66.2 mm (3.23 × 2.61 in)
Compression ratio: 11.0 : 1
Valve clearance-intake (cold): 0.15–0.22 mm (0.0059–0.0087 in)
Valve clearance-exhaust (cold): 0.26–0.32 mm (0.0102–0.0126 in)
Lubrication system: Dry sump
Cooling system: Water
Starting system: Electric
Ignition system: T.C.I.
Spark plug (NGK): CR9EB
Spark plug gap: 0.7–0.8 mm (0.028–0.031 in)
Battery capacity: 12 V, 18 Ah
Battery type: YTX20L-BS
Charging system: Flywheel magneto
UF4N71E0.book Page 101 Thursday, August 5, 2021 11:58 AM

Specifications
102
Drive unit:Propulsion system: Jet pump
Jet pump type: Axial flow, single stage
Impeller rotation: Counterclockwise
Jet thrust nozzle angle: 24+24 °
Fuel and oil: Recommended fuel: Regular unleaded gasoline
Minimum octane rating (PON): 86
Minimum octane rating (RON): 90
Recommended engine oil: YAMALUBE 4W or 4-stroke motor oil
Recommended engine oil type SAE: SAE 10W-30, 10W-40, 20W-40,
20W-50
Recommended engine oil grade API: API SG, SH, SJ, SL
Fuel tank total capacity: 70 L (18.5 US gal, 15.4 Imp.gal)
Engine oil quantity with oil filter re-
placement: 3.4 L (3.59 US qt, 2.99 Imp.qt)
Engine oil quantity without oil filter re-
placement: 3.2 L (3.38 US qt, 2.82 Imp.qt)
Engine oil total quantity: 3.7 L (3.91 US qt, 3.26 Imp.qt)
UF4N71E0.book Page 102 Thursday, August 5, 2021 11:58 AM

Trouble recovery
103
EJU34562
Troubleshooting
If you have any trouble with your watercraft, use the troubleshooting chart to check for the
possible cause.
If you cannot find the cause, consult a Yamaha dealer.
EJU46272Troubleshooting chart
Confirm the possible cause and remedy, and then refer to the applicable page.
TROUBLEPOSSIBLE CAUSE REMEDYPAGE
Engine does not
start (Starter motor
does not turn over)
Ya m a h a S e - curity System
(VX DELUXE /
VX CRUISER /
VX LIMITED)Lock mode selected Select unlock mode
25
Engine shut-
off switch Clip not in place Install clip
26
Fuse Burned out Have serviced by Yamaha dealer—
Battery Run down Recharge 92 Poor terminal con-
nections Tighten as required
92
Terminal corroded Clean or replace 92
Starter motor Faulty Have serviced by Yamaha dealer—
Engine does not
start (Starter motor
turns over) Throttle lever Squeezed Release 27
RiDE lever
(VX /
VX DELUXE /
VX CRUISER /
VX LIMITED)Squeezed
Release
27
Fuel Fuel tank empty Refill as soon as pos-
sible 61
Stale or contaminat-
ed Have serviced by
Yamaha dealer
—
Fuel tank Water or dirt present Have serviced by Yamaha dealer—
Spark plug Fouled or defective Have serviced by Yamaha dealer—
Fuel injec-
tion system Fuel pump faulty Have serviced by
Yamaha dealer —
