2022 TOYOTA TUNDRA HYBRID spare tire

5237-2. Steps to take in an emergency
Owners Manual_USA_M0C031_en
7
When trouble arises
WARNING
■When the spare tire is
attached
The vehicle speed may not be
correctly detecte d, and the follow-
ing systems may not operate cor-
rectly:
• ABS & Brake assist
• VSC
• TRAC
• AUTO LSD (if equipped)
• PCS (Pre-Collision System)
• Automatic High Beam (if equipped)
• LTA (Lane Tracing Assist)
• Dynamic radar cruise control with full-speed range
• EPS
• Trailer Sway Control
• Tire pressure warning system
• BSM (Blind Spot Monitor)
• Panoramic view monitor (if equipped)
• Multi-terrain Monitor (if equipped)
• Toyota parking assist monitor (if equipped)
• Intuitive parking assist
• PKSB (Parking Support Brake)
• Navigation system (if equipped)
Also, not only can the following
system not be utilized fully, but it
may even negatively affect the
drive-train components:
• 4WD system (if equipped)
■Speed limit when using the
temporary spare tire
Do not drive at speeds in excess
of 50 mph (80 km/h) when a tem-
porary spare tire is installed on
the vehicle.
The temporary spare tire is not
designed for driving at high
speeds. Failure to observe this
precaution may lead to an acci-
dent causing death or serious
injury.
NOTICE
■Do not drive the vehicle with
a flat tire
Do not continue driving with a flat
tire.
Driving even a short distance with
a flat tire can damage the tire and
the wheel beyond repair.
■Driving with tire chains and
the temporary spare tire
Do not fit tire chains to the tempo-
rary spare tire.
Tire chains may damage the vehi-
cle body and adversely affect driv-
ing performance.
■When stowing the flat tire
Ensure that ther e is no object
caught between t he tire and the
vehicle underbody.
■When replacing the tires
When removing or fitting the
wheels, tires or th e tire pressure
warning valve and transmitter,
contact your Toyota dealer as the
tire pressure warning valve and
transmitter may be damaged if not
handled correctly.

5478-1. Specifications
Owners Manual_USA_M0C031_en
8
Vehicle specifications
18-inch tires (type A)
18-inch tires (type B)
20-inch tires (type A)
Tires and wheels
Tire size265/70R18 116T, 265/70R18 116T (spare)
Tire inflation pressure
(Recommended cold tire
inflation pressure)
35 psi (240 kPa, 2.4 kgf/cm2 or bar)
Wheel size18  7 1/2 J, 18  7J (spare)
Wheel nut torque
Steel wheels:
154 ft·lbf (209 N·m, 21.3 kgf·m)
Aluminum wheels:
97 ft·lbf (131 N·m, 13.4 kgf·m)
Tire size285/65R18 116T, 265/70R18 116T (spare)
Tire inflation pressure
(Recommended cold tire
inflation pressure)
35 psi (240 kPa, 2.4 kgf/cm2 or bar)
Wheel size18  8 1/2 J, 18  7J (spare)
Wheel nut torque
Steel wheels:
154 ft·lbf (209 N·m, 21.3 kgf·m)
Aluminum wheels:
97 ft·lbf (131 N·m, 13.4 kgf·m)
Tire size265/60R20 112H, 245/75R18 112T (spare)
Tire inflation pressure
(Recommended cold tire
inflation pressure)35 psi (240 kPa, 2.4 kgf/cm2 or bar)
36 psi (250 kPa, 2.5 kgf/cm
2 or bar) (spare)
Wheel size20  8J, 18  7J (spare)
Wheel nut torque
Steel wheels:
154 ft·lbf (209 N·m, 21.3 kgf·m)
Aluminum wheels:
97 ft·lbf (131 N·m, 13.4 kgf·m)

5488-1. Specifications
Owners Manual_USA_M0C031_en
20-inch tires (type B)
22-inch tires
A: Wedge base bulbs (amber)
Tire size265/60R20 112H, 265/70R18 116T (spare)
Tire inflation pressure
(Recommended cold tire
inflation pressure)
35 psi (240 kPa, 2.4 kgf/cm2 or bar)
Wheel size20  8 1/2 J, 18  7J (spare)
Wheel nut torque
Steel wheels:
154 ft·lbf (209 N·m, 21.3 kgf·m)
Aluminum wheels:
97 ft·lbf (131 N·m, 13.4 kgf·m)
Tire size265/50R22 112H, 245/75R18 112T (spare)
Tire inflation pressure
(Recommended cold tire
inflation pressure)38 psi (260 kPa, 2.6 kgf/cm2 or bar)
36 psi (250 kPa, 2.5 kgf/cm
2 or bar) (spare)
Wheel size22  8J, 18  7J (spare)
Wheel nut torque
Steel wheels:
154 ft·lbf (209 N·m, 21.3 kgf·m)
Aluminum wheels:
97 ft·lbf (131 N·m, 13.4 kgf·m)
Light bulbs
Light bulbsBulb No.WTy pe
ExteriorFront turn signal/parking
lights7444NA28/8A

594What to do if... (Troubleshooting)
Owners Manual_USA_M0C031_en
played, refer to P.501, 511.
 Stop the vehicle in a safe
place and replace the flat tire
with the spare tire. ( P.515)
 Try the procedure for when
the vehicle becomes stuck in
mud, dirt, or snow. ( P.538)
When a problem has
occurred
If you have a flat tire
The vehicle becomes
stuck

606Alphabetical Index
Owners Manual_USA_M0C031_en
Spare tire Inflation pressure.................. 547
Storage location ................... 515
Spark plug ............................... 544
Specifications ......................... 540
Speedometer ............................ 91
Steering wheel Adjustment ........................... 143
Heated steering wheel ......... 407
Meter control switches ........... 96
Power easy access system .. 137
Steering wheel position memory........................................... 137
Stop lights Replacing light bulbs ............ 490
Storage features ..................... 413
Stuck If the vehicle becomes stuck 538
Sun visors ............................... 431
Switches Activating the Automatic High Beam .................................. 214
Automatic High Beam system ........................................... 214
Brake Hold switch ................ 208
DAC/CRAWL switch .... 365, 372, 372
Display change button............ 93
Door lock switches ............... 116
DRIVE MODE switch ........... 358
Driving position memory switches ............................. 137
Dynamic radar cruise control with full-speed range switch256
Emergency flashers switch .. 494
Fog light switch .................... 214
Front-wheel drive control switch ........................................... 361
Garage door opener switches ........................................... 433
Heated steering wheel switch ........................................... 407 Height control mode select
switch .................................355
Height control switch ............355
HUD (Head-up display) switch ...........................................103
Light bar ...............................218
Light switches ....................... 211
LTA (Lane Tracing Assist) switch ...........................................247
Meter control switches............96
Mode select switch ......358, 365, 369, 372, 372
MTS switch ...........................369
Outer mirror extend switch ...158
Outside rear v iew mirror
switches..............................156
Panoramic moon roof switches ...........................................164
Parking brake switch ............205
PKSB (Parking Support Brake) ...........................................289
Power door lock switch......... 116
Power steps switch ....... 119, 127
Power switch ........................195
Power window switches .......160
Rear differential lock system 364
Rear window and outside rear view mirror defoggers switch...........................................401
Seat heater switches ............407
Seat ventilator switches........407
“SOS” button ..........................68
Tilt and telescopic steering con- trol switch ...........................143
Tire pressure warning reset switch .................................471
TOW HAUL switch................203
Trailer brake control switch...380
Trailering light switch ............159
Vehicle-to-vehicle distance switch .................................256
VSC OFF switch ...................376
