2022 TOYOTA PRIUS PRIME warning

PRIUS PRIME_OM_OM47E74U_(U)
Pictorial indexSearch by illustration
1For safety
and securityMake sure to read through them
2Plug-in hybrid
systemPlug-in hybrid system features, charging method,
etc.
3Instrument
clusterHow to read the gauges and meters, the variety of
warning lights and indicators, etc.
4Operation of
each componentOpening and closing the doors and windows,
adjustment before driving, etc.
5DrivingOperations and advice which are necessary for
driving
6Interior featuresUsage of the interior features, etc.
7Maintenance
and careCaring for your vehicle and maintenance
procedures
8When trouble
arisesWhat to do in case of malfunction or emergency
9Vehicle
specificationsVehicle specifications, customizable features, etc.
10For ownersReporting safety defects for U.S. owners, and seat
belt, SRS airbag and headlight aim instructions for
Canadian owners
IndexSearch by symptom
Search alphabetically

TABLE OF CONTENTS2
PRIUS PRIME_OM_OM47E74U_(U)For your information....................... 8
Reading this manual .................... 14
How to search .............................. 15
Pictorial index .............................. 16
1-1. For safe use
Before driving ...................... 26
For safe driving ................... 28
Seat belts ............................ 30
SRS airbags ........................ 36
Front passenger occupant classification system ......... 50
Exhaust gas precautions ..... 56
1-2. Child safety Riding with children ............. 57
Child restraint systems ........ 58
1-3. Emergency assistance Safety Connect.................... 76
1-4. Theft deterrent system Immobilizer system ............. 83
2-1. Plug-in hybrid system Plug-in hybrid system features ............................. 86
Plug-in hybrid system precautions ....................... 99
Plug-in hybrid vehicle driving tips ....................... 106
EV driving range................ 109 2-2. Charging
Charging equipment .......... 111
Charging cable .................. 116
Smart lid & connector locking system ................. 122
Power sources that can be used................................. 132
Charging methods ............. 135
Charging tips ..................... 140
Things to know before charging........................... 142
How to charge ................... 147
Using the charging schedule function ............................ 158
When normal charging cannot be carried out....... 181
3. Instrument cluster Combination meter ............ 192
Warning lights and indicators ......................... 201
Main display....................... 209
Multi-information display ............................. 220
Head-up display................. 253
Energy monitor/ consumption screen
(vehicles with 7-inch
display) ............................ 261
Energy monitor/ consumption screen/
detail screen (vehicles
with 11.6-inch display) ..... 266
1For safety and security
2Plug-in hybrid system
3Instrument cluster

TABLE OF CONTENTS6
PRIUS PRIME_OM_OM47E74U_(U)8-1. Essential information
Emergency flashers .......... 660
If your vehicle has to be stopped in an
emergency ...................... 661
If the vehicle is submerged or water on the road
is rising ............................ 662
8-2. Steps to take in an emergency
If your vehicle needs to be towed ......................... 664
If you think something is wrong .............................. 670
If a warning light turns on or a warning buzzer
sounds ............................ 671
If a warning message is displayed ......................... 681
If you have a flat tire .......... 689
If the hybrid system will not start ........................... 706
If the electronic key does not operate properly ........ 708
If the 12-volt battery is discharged ...................... 712
If your vehicle overheats ... 718
If the vehicle becomes stuck................................ 723 9-1. Specifications
Maintenance data (fuel, oil level, etc.) .......... 726
Fuel information ................. 735
Tire information.................. 738
9-2. Customization Customizable features ....... 749
9-3. Initialization Items to initialize ................ 761
Reporting safety defects for U.S. owners ........................ 764
Reporting safety defects for Canadian owners ................ 765
Seat belt instructions for Canadian owners
(in French)................................ 766
SRS airbag instructions for Canadian owners
(in French)................................ 768
Headlight aim instructions for Canadian owners
(in French)................................ 777
8When trouble arises9Vehicle specifications
10For owners

12
PRIUS PRIME_OM_OM47E74U_(U)The SRS airbag and seat belt pretensioner devices in your Toyota contain
explosive chemicals. If the vehicle is scrapped with the airbags and seat belt
pretensioners left as they are, this may cause an accident such
as fire. Be
sure to have the systems of the SRS airbag and seat belt preten sioner
removed and disposed of by a qualified service shop or by your Toyota dealer
before you scrap your vehicle.
Special handling may apply,
See www.dtsc.ca.gov/hazardouswaste/perchlorate.
Your vehicle has components that may contain perchlorate. These compo-
nents may include the airbags, seat belt pretensioners, wireles s remote con-
trol batteries, and the batteries in the tire pressure warning valve and
transmitters.
Scrapping of your Toyota
Perchlorate Material
WARNING
■ General precautions while driving
Driving under the influence: Never drive your vehicle when under the influ-
ence of alcohol or drugs that have impaired your ability to operate your vehi-
cle. Alcohol and certain drugs delay reaction time, impair judg ment and
reduce coordination, which could lead to an accident that could result in
death or serious injury.
Defensive driving: Always drive defensively. Anticipate mistake s that other
drivers or pedestrians might make and be ready to avoid accidents.
Driver distraction: Always give your full attention to driving. Anything that
distracts the driver, such as adjusting controls, talking on a cellular phone or
reading can result in a collision with resulting death or serious injury to you,
your occupants or others.
■ General precaution regarding children’s safety
Never leave children unattended in the vehicle, and never allow children to
have or use the key.
Children may be able to start the vehicle or shift the vehicle into neutral.
There is also a danger that children may injure themselves by playing with
the windows, or other features of the vehicle. In addition, heat build-up or
extremely cold temperatures inside the vehicle can be fatal to children.

14
PRIUS PRIME_OM_OM47E74U_(U)
Reading this manual
WARNING:
Explains something that, if not obeyed, could cause death or
serious injury to people.
NOTICE:
Explains something that, if not obeyed, could cause damage to
or a malfunction in the vehicle or its equipment.
Indicates operating or working procedures. Follow the steps
in numerical order.
Indicates the action (push-
ing, turning, etc.) used to
operate switches and other
devices.
Indicates the outcome of an
operation (e.g. a lid opens).
Indicates the component or
position being explained.
Means “Do not”, “Do not do
this”, or “Do not let this hap-
pen”.
123

16Pictorial index
PRIUS PRIME_OM_OM47E74U_(U)
Pictorial index
■
Exterior
Side doors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 279
Locking/unlocking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 279
Opening/closing the side windows. . . . . . . . . . . . . . . . . . . . . . P. 309
Locking/unlocking by using the mechanical key . . . . . . . . . . . P. 708
Warning lights/warning messages . . . . . . . . . . . . . . . . . . P. 673, 681
Back door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 285
Opening from outside . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 285
Warning lights/warning messages . . . . . . . . . . . . . . . . . . P. 673, 681
Outside rear view mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 307
Adjusting the mirror angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 307
Folding the mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 307
Defogging the mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 512, 523
Windshield wipers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 359
Precautions against winter season . . . . . . . . . . . . . . . . . . . . . P. 502
Precautions against car wash (vehicles with rain-sensing
windshield wipers) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 576
Replacing the wiper insert . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 6411
2
3
4

17Pictorial index
PRIUS PRIME_OM_OM47E74U_(U)Fuel filler door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 365
Refueling method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 365
Fuel type/fuel tank capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 728
Charging port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 111
Charging method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 135
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . P. 612
Replacing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 626
Tire size/inflation pressure . . . . . . . . . . . . . . . . . . . . . . . . . P. 733
Winter tires/tire chain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 502
Checking/rotation/tire pressur e warning system . . . . . . . . .P. 612
Coping with flat tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 689
Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 595
Opening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 595
Engine oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 730
Coping with overheat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 718
Headlights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 347
Parking lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 347
Fog lights
* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 357
LED accent lights
*. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 347
Turn signal lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 345
Daytime running lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 347
Side marker lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 347
Tail lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 347
License plate lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 347
Back-up lights
Shifting the shift position to R . . . . . . . . . . . . . . . . . . . . . . . . . P. 339
5
6
7
8
Light bulbs of the exterior lights for driving
(Replacing method: P. 652, Watts: P. 734)
*: If equipped
9
10
11
12
13
14
15
16
17
18

18Pictorial index
PRIUS PRIME_OM_OM47E74U_(U)
■Instrument panel
Power switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 332
Starting the hybrid system/changing the modes . . . . . . . . . . . P. 332
Emergency stop of the hybrid system . . . . . . . . . . . . . . . . . . . P. 661
When the hybrid system will not start . . . . . . . . . . . . . . . . . . . P. 706
Warning messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 681
Shift lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 339
Changing the shift position . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 339
Precautions against towing . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 664
P position switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 340
Meters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 192
Reading the meters/adjusting the instrument
cluster light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 192, 194
Warning lights/indicator lights . . . . . . . . . . . . . . . . . . . . . . . . . P. 201
When the warning lights come on . . . . . . . . . . . . . . . . . . . . . . P. 6711
2
3
4
