2022 TOYOTA AVALON HYBRID load capacity

5428-1. Specifications
Glossary of tire terminology
Tire related termMeaning
Cold tire inflation pres-
sure
Tire pressure when the vehicle has been
parked for three hours or more, or has not
been driven more than 1 mile or 1.5 km under
that condition
Maximum inflation
pressureThe maximum cold inflated pressure to which
a tire may be inflated, shown on the sidewall
of the tire
Recommended infla-
tion pressureCold tire inflation pressure recommended by a
manufacturer
Accessory weight
The combined weight (in excess of those stan-
dard items which may be replaced) of hybrid
transmission, power steering, power brakes,
power windows, power seats, radio and
heater, to the extent that these items are avail-
able as factory-installed equipment (whether
installed or not)
Curb weight
The weight of a motor vehicle with standard
equipment, including the maximum capacity of
fuel, oil and coolant, and if so equipped, air
conditioning and additional weight optional
engine
Maximum loaded vehi-
cle weight
The sum of:
(a) Curb weight
(b) Accessory weight
(c) Vehicle capacity weight
(d) Production options weight
Normal occupant
weight150 lb. (68 kg) times the number of occupants
specified in the second column of Table 1
*
that follows
Occupant distributionDistribution of occupants in a vehicle as speci-
fied in the third column of Table 1
* below

5438-1. Specifications
8
Vehicle specifications
Production options
weight
The combined weight of installed regular pro-
duction options weighing over 5 lb. (2.3 kg) in
excess of the standard items which they
replace, not previously considered in curb
weight or accessory weight, including heavy
duty brakes, ride levelers, roof rack, heavy
duty 12-volt battery, and special trim
Rim
A metal support for a tire or a tire and tube
assembly upon which the tire beads are
seated
Rim diameter
(Wheel diameter)Nominal diameter of the bead seat
Rim size designationRim diameter and width
Rim type designationThe industry manufacturer’s designation for a
rim by style or code
Rim widthNominal distance between rim flanges
Vehicle capacity
weight (Total load
capacity)The rated cargo and l uggage load plus 150 lb.
(68 kg) times the vehicle’s designated seating
capacity
Vehicle maximum load
on the tire
The load on an individual tire that is deter-
mined by distributing to each axle its share of
the maximum loaded vehicle weight, and
dividing by two
Vehicle normal load on
the tire
The load on an individual tire that is deter-
mined by distributing to each axle its share of
curb weight, accessory weight, and normal
occupant weight (distributed in accordance
with Table 1
* below), and dividing by two
Weather sideThe surface area of the rim not covered by the
inflated tire
Bead
The part of the tire that is made of steel wires,
wrapped or reinforced by ply cords and that is
shaped to fit the rim
Bead separationA breakdown of the bond between compo-
nents in the bead
Tire related termMeaning

5478-1. Specifications
8
Vehicle specifications
Designated seating
capacity, Number of
occupantsVehicle normal load,
Number of occupantsOccupant distribution in a normally loaded
vehicle
2 through 422 in front
5 through 1032 in front, 1 in second seat
11 through 155
2 in front, 1 in second
seat, 1 in third seat, 1
in fourth seat
16 through 207
2 in front, 2 in second
seat, 2 in third seat, 1 in fourth seat

574Alphabetical index
Lane Tracing Assist (LTA) ...... 261
Language (multi- information display) .............. 118
LATCH anchors ......................... 59
Lever
Auxiliary catch lever .............. 423
Hood lock release lever ........ 423
Internal trunk release lever ... 150
Shift lever .............................. 209
Tilt and telescopic steering lock release lever ............... 170
Turn signal lever ................... 215
Wiper lever............................ 230
License plate lights Light switch ........................... 222
Replacing light bulbs............. 467
Light bulbs Replacing .............................. 467
Lights
Automatic High Beam ........... 226
Cornering lights..................... 223
Daytime running light system ......... ....................... 223
Door courtesy lights .............. 374
Headlight switch.................... 222
Illuminated entry system ....... 376
Interior lights ......................... 375
Interior lights list .................... 374
Personal lights ...................... 375
Replacing light bulbs............. 467
Trunk light ............................. 149
Turn signal lever ................... 215
Vanity lights .......................... 384
Wattage ................................ 531
Welcome lighting .................. 225
Load capacity........................... 197
Lock steering column ............. 203
LTA (Lane Tracing Assist) ...... 261 Maintenance
Do-it-yourself maintenance... 421
General maintenance ........... 416
Maintenance data ................. 524
Maintenance requirements ...................... 414
Resetting the message
indicating maintenance
is required .......................... 415
Malfunction indicator lamp..... 479
Master warning light ............... 481
Memory recall function ........... 166
Meter
Head-up display.................... 123
Indicators ................................ 95
Instrument panel light control .................................. 99
Meters..................................... 98
Multi-information display ....... 102
Settings................................. 111
Warning lights ......................... 93
Warning messages ............... 488
Mirrors Inside rear view mirror .......... 172
Outside rear view mirror defoggers ........................... 365
Outside rear view mirrors ..... 174
Vanity mirrors ....................... 384
Moon roof ................................. 181 Door lock linked moon roof operation ............................ 182
Jam protection function ........ 182
Operation .............................. 181
LM

580Alphabetical index
Tachometer ................................ 98
Tail lightsLight switch ........................... 222
Replacing light bulbs............. 467
Theft deterrent system Alarm ...................................... 88
Immobilizer system ................. 86
Tire inflation pressure ............. 449 Maintenance data ................. 530
Warning light ......................... 482
Tire information ....................... 535 Glossary................................ 542
Size ....................................... 538
Tire identification number ..... 537
Uniform Tire Quality Grading............................... 540
Tire pressure warning system Initializing .............................. 439
Installing tire pressure warning valve and
transmitters......................... 439
Registering ID codes ............ 441
Warning light ......................... 482 Tires .......................................... 437
Chains .................................. 355
Checking............................... 437
Glossary ............................... 542
If you have a flat tire ............. 494
Inflation pressure .................. 530
Replacing.............................. 494
Rotating tires ........................ 437
Size....................................... 530
Snow tires ............................. 356
Spare tire .............................. 494
Tire pressure warning system .......... ...................... 438
Uniform Tire Quality Grading .............................. 540
Warning light......................... 482
Tools ......................................... 494
Top tether strap ......................... 65
Total load capacity .................. 197
Towing Dinghy towing ....................... 199
Emergency towing ................ 474
Trailer towing ........................ 198
Toyota parking assist monitor
*
T

583Alphabetical index
Warning messages .................. 488
Washer...................................... 230Checking ............................... 432
Preparing and checking
before winter....................... 354
Switch ................................... 230
Washing and waxing ............... 408
Weight....................................... 524
Cargo capacity ...................... 197
Load limits............................. 197
Vehicle capacity weight ........ 524
Wheels ...................................... 452 Replacing .............................. 452
Size ....................................... 530
Window glasses....................... 177
Window lock switch ................ 177
Windows ................................... 177 Power windows ..................... 177
Rear window defogger .......... 365
Washer ................................. 230
Windshield wipers ................... 230
Winter driving tips ................... 354
Wireless charger...................... 388
Wireless remote control.......... 138 Battery-Saving Function ....... 154
Locking/Unlocking......... 142, 149
Panic mode ........................... 139
Replacing the battery ............ 461
